FUJITSU DL7600 DOT MATRIX PRINTER USER'S MANUAL
IMPORTANT NOTE TO USERS READ THE ENTIRE MANUAL CAREFULLY BEFORE USING THIS PRODUCT. INCORRECT USE OF THE PRODUCT MAY RESULT IN INJURY OR DAMAGE TO USERS, BYSTANDERS OR PROPERTY. While FUJITSU ISOTEC has sought to ensure the accuracy of all information in this manual, FUJITSU ISOTEC assumes no liability to any party for any damage caused by any error or omission contained in this manual, its updates or supplements, whether such errors or omissions result from negligence, accident, or any other cause.
Federal Communications Commission Radio Frequency Interference Statement for United States Users NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15B of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Notice for Canadian Users This class B digital apparatus (M33325A) meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil (M33325A) numérique de la Classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Notice for German Users Bescheinigung des Herstellers/Importeurs Hiermit wird bescheinigt, daß der/die/das • M33325B in Übereinstimmung mit den Bestimmungen der 2004/108/EC und 2006/95/EC ist.
Energy Saving As an ENERGY STAR® Partner, FUJITSU ISOTEC LIMITED has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. The International ENERGY STAR® Office Equipment Program is an international program that promotes energy saving through the use of computers and other office equipments. The program backs the development and dissemination of products with functions that effectively reduce energy consumption.
The contents of this manual may be revised without prior notice and without obligation to incorporate changes and improvements into units already shipped. Every effort has been made to ensure that the information included here is complete and accurate at the time of publication; however, Fujitsu Isotec Limited cannot be held responsible for errors and omissions. Printer model specifications differ with the power supply input voltage (M33325A; 100-120 or M33325B; 220-240 VAC).
ABOUT THIS MANUAL Thank you for buying the Fujitsu DL7600 dot matrix printer. You can expect years of reliable service with very little maintenance. This manual explains how to use your printer to full advantage. It is written for both new and experienced printer users. This manual describes how to install, set up, and use your printer and printer options. It also explains how to keep the printer in good working condition and what to do should something go wrong.
ORGANIZATION This manual is organized as follows: Quick Reference summarizes everyday printer operations. After you become familiar with the printer, use this section as a memory aid. Chapter 1, Introduction, introduces the printer and identifies key features and options that enhance the printer’s capabilities. Chapter 2, Setting Up, gives step-by-step procedures for setting up the printer for immediate use and identifies the main parts of the printer.
CONVENTIONS Special information, such as warnings, cautions, and notes, are indicated as follows: WARNING A WARNING indicates that personal injury may result if you do not follow a procedure correctly. CAUTION A CAUTION indicates that damage to the printer may result if you do not follow a procedure correctly. NOTE A NOTE provides “how-to” tips or suggestions to help you perform a procedure correctly. NOTEs are particularly useful for first-time users.
z Warning symbols Various graphic symbols are used in this manual. They serve as signs to help users of this product use the product safely and correctly as well as prevent damage and personal injury to the users or bystanders. The following tables show and explain each symbol. Be sure that you understand the meaning of each symbol before reading the manual. WARNING A WARNING indicates that death or serious personal injury may result if you do not follow a procedure correctly.
Notes on Safety WARNING WARNING Do not place a container containing water, such as a vase, potted plant, and drinking glass, or a metal object on or near the printer. Otherwise, electric shock or fire may result. Do not place the printer in a humid or dusty area, in an area with explosive fumes, an area with poor ventilation or close to a fire. Otherwise, electric shock or fire may result. Use only one of the power cords included with this product, for this product.
WARNING When mounting or removing an optional device or component, turn off the power to the printer and personal computer and disconnect their power plugs from the outlets before performing the work. Otherwise, electric shock may result. Connect only Fujitsu-recommended optional devices and components. Otherwise, electric shock, fire, or failure may result. CAUTION Do not block openings in the printer (e.g., ventilation openings).
Notes about the printer in operation WARNING If the printer is making a strange noise, which indicates a problem, discontinue printer operation. Request your printer dealer to fix the problem. Continued operation of the printer without repairs may result in electric shock or fire. Do not use a power source whose voltage is other than that indicated. Also, an excessive number of plugged-in power cords must not be connected to a single outlet. Otherwise, electric shock or fire may result.
WARNING If excessive heat, smoke, a strange odor, or a strange noise is coming the printer or any other abnormality is observed, immediately turn off the power to the printer by using the power switch, and be sure to disconnect the power plug from the outlet. Then, after verifying the end of the abnormality (e.g., no more smoke is coming from the printer), request your printer dealer to make repairs. Do not repair the printer by yourself as doing so is dangerous.
CAUTION Insert the power plug completely into an outlet so that it is securely connected. Otherwise, electric shock or fire may result. Exercise caution to keep loose clothing, hair, neckties, etc. away from paper feed- or ejection openings, and tractors while the printer is operating. Otherwise, personal injury may result. When disconnecting the power plug from the outlet, pull it out while grasping the plug, not the cord.
CAUTION Do not touch the paper feed- or ejection openings while the printer is operating. Otherwise, personal injury may be result. Do not touch the printer cable connectors or the metal part of the print head. Otherwise, personal injury or a printer failure may result. Do not touch the print head while it is moving. Otherwise, burns or personal injury may result. Note that continuous forms that are fed in the reverse direction continuously may come off the paper feed tractors.
TABLE OF CONTENTS QUICK REFERENCE ....................................................QR-1 CHAPTER 1 INTRODUCTION ...................................................................... 1-1 FEATURES....................................................................... 1-1 MODELS........................................................................... 1-3 OPTIONS.......................................................................... 1-3 CHAPTER 2 SETTING UP ..........................................
FEEDING AND POSITIONING PAPER..........................3-24 Line Feed/Form Feed ................................................3-24 Micro Feed .................................................................3-24 Load Position Adjust ..................................................3-24 TIPS ON PAPER HANDLING.........................................3-26 General Tips ..............................................................3-26 Multipart Forms ..........................................................
Procedure .................................................................. 5-56 Checking Vertical Print Alignment (V-ALMNT).......... 5-58 Procedure .................................................................. 5-58 SETUP MODE REFERENCE......................................... 5-60 DPL24C PLUS ORGANIZATION .............................. 5-61 Differences in IBM Proprinter XL24E Emulation ....... 5-64 Differences in Epson ESC/P2 Emulation .................. 5-64 ONLINE SETUP MODE.......................
APPENDIX C COMMAND SETS .................................................................... C-1 FUJITSU DPL24C PLUS ................................................. C-2 Bar Code Printing Control ......................................... C-14 IBM PROPRINTER XL24E EMULATION ...................... C-22 EPSON ESC/P2 EMULATION....................................... C-27 APPENDIX D INTERFACE INFORMATION................................................... D-1 PARALLEL INTERFACE ..................................
QUICK REFERENCE QUICK REFERENCE Q Quick Reference is written for experienced users — users who are familiar with how the printer works, but who may need to refresh their memory occasionally. Only the printer’s normal (non-setup) mode is covered. For details on setup mode, see Chapter 5. Normal mode operation includes everyday operations, such as paper handling and font selection. The printer comes up in normal mode when turned on.
QUICK REFERENCE Printer Operations (Normal Mode) 9: Operation can be performed when the printer is in this state. —: Operation cannot be performed when the printer is in this state. N/A: Does not apply. Operation Online Offline Required Response Enter normal mode N/A N/A Turn printer on. (Press I on the power switch.) Place printer offline (Stop printing) Place printer online (Start printing) 9 — — 9 Load paper 9 9 Press LOAD.
QUICK REFERENCE Printer Operations (Normal Mode) (Cont.) 9: Operation can be performed when the printer is in this state. —: Operation cannot be performed when the printer is in this state. N/A: Does not apply. Operation Online Offline Select auto adjusting for paper thickness. 9 9 Adjust for paper thickness 9 9 (LED type) Press AUTO GAP 2 second or more. So that AUTO GAP lamp lights (LCD type) Press GAP ADJUST. So that LCD display “AUTO” (LED type) Press AUTO GAP 2 second or more.
QUICK REFERENCE QR-4 User's Manual
CHAPTER 1 INTRODUCTION INTRODUCTION Congratulations on purchasing this printer. This printer is a compact, versatile, flat paper path printer that offers maximum compatibility with today’s software packages and personal computers. 1 The 24-wire print head provides crisp, clear printing for business, office, and home environments. This printer is also easy to install and use.
INTRODUCTION • Large print buffer. 128K bytes are available in total for storing input data and downloading fonts. A large input data buffer allows you to send files to the printer and return to work in your application. A large download buffer allows you to use custom fonts. • 136-column print line. 136-column printers print in landscape mode using legal- or standard-size computer forms. • Simple switching of paper types.
INTRODUCTION MODELS OPTIONS • Power Supply type; 100-120VAC input (M33325A) 220-240VAC input (M33325B) • Interface type; Centronics parallel + USB interfaces Centronics parallel + RS232C serial interface • Control panel type; LED type. LCD type. Printer add-on options are listed below. For details, see Chapter 8. • Cut sheet feeder. The SF940 single-bin feeder is available as an option. Two cut sheet feeders can be installed in front of and behind the printer at the same time.
INTRODUCTION • Small paper table. Paper table should be installed instead of sound proof cover when use single sheets and install cut sheet feeder to front of printer. • Large stacker. The large stacker accommodates sheets output from the rear. It is used in continuous printing with a cut sheet feeder. • Large paper table. The large paper table helps to increase operability when large cut sheets are used. Also, sheets that are output from the front are easier to keep properly organized.
CHAPTER 2 SETTING UP SETTING UP 2 Your new printer is easy to install and set up. This chapter tells you how to set up the printer and start printing right away. If this is your first printer, you should read the entire chapter before attempting to use the printer.
SETTING UP 9 Use only the power cord supplied with the printer or recommended by your dealer. Do not use an extension cord. 9 Do not plug the printer into a power outlet that is shared with heavy industrial equipment, such as motors, or appliances, or such as copiers or coffee makers. Such equipment often emits electrical noise or causes power degradation. UNPACKING THE PRINTER Unpack the printer as follows: 1. Open the carton and remove the printer and its components.
SETTING UP 2. Carefully examine each item for damage. Report any problems to your dealer or shipping agent. 3. Place the printer where you plan to use it. 4. Remove the tapes and cushions securing the printer. Open the front cover and remove the shipping restraint cardboard that holds the print head carriage in place (shown below). Removing the shipping restraint cardboard 5. Store the original shipping carton and packaging materials for future use.
SETTING UP Checking Options and Supplies The following options and supplies, if ordered, are shipped separately: • LAN card (option) • Cut sheet feeder (option) • Tractor unit (option) • Small Paper Table (option) • Large Stacker (option) • Large Paper Table (option) • Extra monochrome ribbon cartridges Make sure that you received all the options you ordered. Installation of options is described in Chapter 8. Once you are sure you have everything, you are ready to assemble the printer.
SETTING UP ASSEMBLING THE PRINTER This section explains how to handling the soundproof cover, changing the tractor unit position and installing the ribbon cartridge. Handling the soundproof cover You must open and close the soundproof cover when you operate the front tractor. 1 Open the soundproof cover. Slightly raise the front end of the front tractor cover (1), then pull (2) and lift the table (3).
SETTING UP 2 Close the sound proof cover. Lower the soundproof cover as shown in the figure below (1), then push (2) and close (3) the cover. (2) (1) (3) The complete setup conditions are shown below. Make sure that the top end of the soundproof cover is engaged with the printer guide pin and the guide pin on the soundproof cover is inserted into the cover groove. Cover groove.
SETTING UP Installing the Ribbon cartridge CAUTION (HOT) 1. The print head and metal frame is hot during printing or immediately after printing. Do not touch them until it cools down. Prepare the printer to install the ribbon cartridge. Make sure that the print head protecting cardboard used for transportation has been removed, then turn on the printer power with the top cover closed. Ensure that the print head moves and stops at the ribbon replacement position.
SETTING UP 5. Remove the ribbon cassette from its package. Push in the two ribbon release tabs. The tabs snap into the cassette and the ribbon feed mechanism engages. Preparing the ribbon cassette 6. Remove the ribbon guide (green part) from the ribbon cassette. Don’t turn the ribbon feed knob before installation.
SETTING UP 7. Put the green ribbon guide into the space in front of print head. And then place the mounting pins (both side of ribbon cassette) on the slot of the printer cover. And then push the ribbon cassette so that the ribbon cassette is installed vertically. Mounting pin Slot Mounting pin Print head Space Slot Ribbon guide Push the ribbon cassette until it clicks.
SETTING UP 8. Attach the green ribbon guide on the print head. Please make sure that the ribbon slack lightly. (If the ribbon is strained, it will quirk when installation.)Push the green ribbon guide until the triangle mark ” ”meets the round projection of print head. Print Head Triangle mark Projections Ribbon Guide 9. Turn the ribbon feed knob clockwise to take up any slack in the ribbon. Knob 10. Return the control panel. 11. Close the front cover. NOTE A Fujitsu ribbon cassette is recommended.
SETTING UP Selecting the Tractor Unit Position NOTE This printer uses a detachable tractor that can be used on either the front or back of the printer. You can attach the tractor to either the front or back of the printer according to your installation or operating conditions. The printer is delivered to you with the tractor attached to the front. You can detach it from the front and then attach it to the back if needed. See “SELECTING PAPER PATH” in Chapter 3.
SETTING UP Mounting and removing the tractor unit Tractor unit at the front [Removing the tractor unit] Lock lever Raise the soundproof cover. While pressing the lock levers of the tractor frames located on both sides of the tractor unit, lift out the tractor unit to remove it. Soundproof cover Lock lever [Mounting the tractor unit] 1) Position the U-shaped slots on both sides of the tractor unit over the guide pins of the printer unit.
SETTING UP 3) Verify that the hooks on both sides of the tractor unit are securely hooked onto guide pin 2 as shown in the following figure. Tractor unit at the rear [Removing the tractor unit] While pressing the lock levers of the tractor frames located on both sides of the tractor unit, lift out the tractor unit to remove it.
SETTING UP [Mounting the tractor unit] 1) Position the U-shaped slots on both sides of the tractor unit over the guide pins of the printer unit. (To set the tractor unit in position, line it up with the groove of the left guide pin. The right guide pin has no groove). 2) Push down the shaft at the front of the tractor unit until it locks with an audible click. (Do not press the lock levers when pushing down the shaft.
SETTING UP GETTING ACQUAINTED WITH YOUR PRINTER Now that your printer is assembled, take a moment to become familiar with its major parts. Looking at the printer from the front left side and rear right side, you can see the parts of the printer shown in the figure below.
SETTING UP Rear stacker Rear CSF connector Power Connector INF connector Tractor unit (option).
SETTING UP CONNECTING THE POWER CORD Before you plug in the printer: 9 Make sure that the printer power is switched off. The side marked “{” on the power switch should be depressed. 9 Make sure that the power outlet is properly grounded. 9 Make sure that you use the power cord shipped with the printer. This cord is designed to minimize radio frequency interference. To plug in the power cord: 1. Plug one end of the power cord into the power connector on the rear of the printer. 2.
SETTING UP TESTING THE PRINTER (OFFLINE) At this point, load paper and run the printer self-test. The self-test checks printer performance and print quality before you connect the printer to the computer. Loading Paper for the Self-Test To print the self-test, load continuous form wider than 254 mm (10 inches) and set the left tractor so that the left end of continuous form may suit “0-10mm” of a scale (see Chapter 3). Printing the Self-Test The printer has a built-in self-test program.
SETTING UP 4. Examine the self-test page. It should look like the sample on the below. Check that printing is uniform and that there are no light, dark, or smudged areas. If the print quality is good, go to step 5. Otherwise, try to correct the problem as follows: • Make sure that the ribbon is installed correctly. • Load a new sheet of paper. • Repeat the self-test procedure. Sample self-test page 5. To exit the self-test mode, press the ONLINE button. The printer will return online.
SETTING UP 5. To exit demo mode, turn the printer off.
SETTING UP CONNECTING THE PRINTER TO YOUR COMPUTER Your printer supports one of the following interface options: • Centronics parallel interface+RS-232C serial interface • Centronics parallel interface+USB (+LAN) interface The parallel interface connector has wire clips. The serial interface connector has tapped holes. Cables for these interfaces are available from dealers, cable manufacturers, and other suppliers. The LAN card is a user installable option.
SETTING UP Selecting a USB Cable 9 When the USB interface is used to connect to the host computer, the parallel interface and the serial interface (factory add-on option) cannot be connected simultaneously. 9 The USB interface does not guarantee all connections of USBsupported devices. Selecting a LAN cable 9 When the LAN cable is connected, the parallel and USB cables cannot be used. 9 The LAN cable, when used in 100BASE-TX environments, must conform to category 5 or higher.
SETTING UP NOTE The LAN interface is a user add-on option. When installing a LAN card, remove the two screws securing the cover and remove the cover. Then insert the LAN card and reattach the cover with the two screws removed earlier. For details, refer to the Online Manual that comes with the LAN card. SELECTING AN EMULATION 3. To secure a parallel interface cable, flip the fastener clips located on the printer into the notches on the cable connector.
SETTING UP 9 If you are using more than one software package, determine which emulation is supported by the software you use most frequently. Select that emulation. 9 If your software supports more than one emulation, select the DPL24C PLUS emulation if possible. This emulation has the greatest capabilities. 9 If you want to use an emulation that is not supported by your software, contact your software manufacturer or printer dealer and ask whether support is available.
SETTING UP <> menu Function Initial printout in setup mode Check that the <> menu is printed at the bottom of the page. 3. Select the MENU1 function.(LED) Locate the cursor on left edge of the Card guide (aluminum print guide). Initially, this cursor should be positioned at SAVE & END at the beginning of the <> menu.
SETTING UP Press the MICRO FEED button to select MENU1 and print the following options: DPL24C+ XL24E ESC/P2 The currently selected emulation is indicated by a short underline. In the figure shown above, the Fujitsu DPL24C PLUS emulation is selected. 4. Select an emulation.(LED) Press the LOAD button repeatedly to position the cursor at the required emulation. Press the MICRO FEED button to select the emulation and print the next MENU1 item. 5. Exit MENU1.
SETTING UP 4. Use your software printer selection menus or the printer setup mode (described in Chapter 5) to make required changes in the page layout or other print features. If the printer does not print or prints the wrong characters, proceed as follows: • Make sure that the interface cable is properly connected. • Make sure that the printer emulation selected in your software is the same as that selected on the printer.
SETTING UP Using MS-DOS to Specify Serial Interface Settings For an IBM PC or compatible device, use the following MS-DOS MODE commands to set the computer serial settings to match the printer factory settings: MODE COM1:9600,N,8,1,P MODE LPT1:=COM1 To activate these settings whenever you turn the computer on, write the MODE commands in your AUTOEXEC.BAT file. Make sure that the MODE.COM file is included in your root directory.
CHAPTER 3 PAPER HANDLING PAPER HANDLING This chapter explains how your printer uses paper. 3 Topics covered are: • Selecting paper • Overview of paper operations • Selecting the paper path • Adjusting for paper thickness • Using continuous forms (front-tractor feed and rear-tractor feed) • Using single sheets • Feeding and positioning paper • Switching paper types Tips for paper handling are given at the end of this chapter.
PAPER HANDLING OVERVIEW OF PAPER OPERATIONS The following buttons are used in paper handling: • LF/FF, TEAR OFF, PAPER PATH, MICRO FEED, MICRO FEED and LOAD buttons on the control panel (A different function is enabled when each button is pressed in conjunction with the ONLINE button.) The following figure shows the location of each button: Location of the buttons Table 3.1 summarizes the use of buttons in paper handling. More detailed information is provided later in this chapter.
PAPER HANDLING Table 3.1 Buttons Used for Paper Handling Button/Dial ONLINE Purpose Change the printer mode Action Press ONLINE to place the printer online or offline. Press ONLINE to stop or resume printing. Stop/resume printing LOAD LF/FF User's Manual Load/unload paper Press LOAD to load paper or to retract continuous forms to the “park position.
PAPER HANDLING Table 3.1 Buttons Used for Paper Handling (Cont.) Button/Dial Purpose PRINT MODE/ FRONT DIR Select cut sheet ejection Action Press PRINT MODE/FRONT DIR at Offline to select a direction of ejecting cut sheet. • Front ejection – FRONT indicator lights. It blinks when paper is ejected to the paper table prompting the user to remove the paper. • Rear ejection – FRONT indicator does not light. When you save your setting in the setup mode, it becomes the new default.
PAPER HANDLING SELECTING PAPER PATH This printer has a variety of paper paths and feed directions. Paper Paths and Feed Directions See the following five cases.
PAPER HANDLING With front and rear tractors (either optional) (1) Front tractor → Print → Rear eject (2) Rear tractor → Print → Front eject [3] [2] (2) (1) With front and rear tractors (either optional) and Large paper table (optional) (1) Front tractor → Print → Rear eject (2) Rear tractor → Print → Front eject (3) Paper table → Print → Paper table (4) Paper table → Print → Rear stacker [4] [1] [2] (2) [3] (3)(4) (1) Note Large and small paper table are available as option.
PAPER HANDLING In the next two cases, the number of cut sheets stacked in the printer may be reduced depending on printing conditions and environments. Follow the notes. With rear tractor and front optional cut sheet feeder and large stacker(optional) and large paper table(optional).
PAPER HANDLING With rear tractor and front and rear optional cut sheet feeder and large stacker and large paper table. In addition, the front and rear tractor (either is optional) can be mounted.
PAPER HANDLING ADJUSTING FOR PAPER THICKNESS (LED) The printer can handle paper of different thicknesses, including multipart forms with up to nine parts (original plus eight copies). For details on paper thickness specifications, see Appendix B. The printer automatically adjusts for different paper thicknesses. You can use the MANUAL GAP DIAL to adjust the paper thickness manually at manual mode. To place printer manual mode, press AUTO GAP buttons 2 seconds or more so that AUTO GAP lamp is off.
PAPER HANDLING ADJUSTING FOR PAPER THICKNESS (LCD) The printer can handle paper of different thicknesses, including multipart forms with up to nine parts (original plus eight copies). For details on paper thickness specifications, see Appendix B. The printer automatically adjusts for different paper thicknesses. You can use the GAP ADJUST button to adjust the paper thickness manually. Area for Gap adjust value Adjusting the manual gap Table 3.
PAPER HANDLING USING CONTINUOUS FORMS Continuous forms paper, fanfolded at the horizontal perforations, is ideal for printing rough drafts and long files. The paper is fed into the printer using the forms tractors. Positioning the Paper Stack Place the stack of continuous forms paper directly below the rear of the printer or below the front of the printer.
PAPER HANDLING Loading Continuous Forms (Front Feed) This section explains how to use continuous forms as the tractor unit is installed at the front of the printer. The tractor unit pushes continuous forms. This condition applies when you first purchase the printer. Up to 8-ply media can be fed by the front tractor unit. You can use continuous forms paper even if you have a cut sheet feeder installed at the rear of the printer. To load continuous forms paper: 1. Make sure that the printer is turned on.
PAPER HANDLING 6. Adjust the left margin. Below the left tractor, there is a tractor guide, short inch-based ruler graduated in 10 columns per inch. Use the ruler to help position the tractor. When the paper edge is positioned to the zero line, the left margin is 12 mm (0.5 inch) including perforation area and the arrow indicates the location of the first character. 7. Pull the right tractor to stretch the paper taut. Push the right locking lever down to secure the tractor in place.
PAPER HANDLING CAUTION • Before lowering the paper table, make sure that the paper holders are closed. If the holders are opened, they may cause damage to the tractors and the paper table. • Make sure that the paper table is positioned to its normal mode. If it is not done, jamming may occur when continuous forms paper is fed. 9. Press the PAPER PATH button to select “FRONT TRACTOR”. (The indicator lights.) 10. Press the LOAD button to advance the paper to the top-of-form position.
PAPER HANDLING Loading Continuous Forms (Rear Feed) A tractor is supplied as standard and is attached to the front of the printer. It can be attached to the rear of the printer. You can also buy a tractor unit as an additional rear tractor unit. A maximum of 8-ply media can be fed from the rear tractor unit. For reinstalling the tractor unit for rear feed, see page 2-10 to 2-13. 1. Release the tractor locking levers by pulling them up(①). Open the tractor paper holders. See the following figure(②). 2.
PAPER HANDLING 4. Adjust the left margin. Below the left tractor, there is a tractor guide, short inch-based ruler graduated in 10 columns per inch. Use the ruler to help position the tractor. When the paper edge is positioned to the zero line, the left margin is 12 mm (0.5 inch) including perforation area and the arrow indicates the location of the first character. 5. Lock Lever 6. Pull the right tractor to stretch the paper taut. Push the right locking lever down to secure the tractor in place.
PAPER HANDLING Unloading Continuous Forms To unload continuous forms: 1. Make sure that the FRONT TRACTOR or REAR TRACTOR indicator lights. 2. Press the LOAD button. The continuous forms paper is retracted to the park position. If the paper cannot be retracted in one operation, continue to press the LOAD button until the paper is parked. NOTE The printer can retract continuous forms paper up to a maximum of 55.8 cm (22 inches) per operation. 3.
PAPER HANDLING Check that the paper length is specified correctly. For information on specifying page length using setup mode, see Chapter 5. 2. Tear the paper off at the perforation. Tearing off continuous forms (front feed) Tearing off continuous forms (rear feed) 3. 3-18 Press any button to retract the forms back to the top-of-form position.
PAPER HANDLING USING SINGLE SHEETS This section describes how to load paper from the paper table or cut sheet feeder. The paper table allows paper to be loaded manually, one sheet at a time. A cut sheet feeder allows paper to be loaded automatically from the paper bin. Loading a Paper From The Paper Table. (option) To load a sheet of paper from the paper table: 1. Make sure that the printer is turned on. 2. Press the PAPER PATH button to select CUT SHEET (the indicator lights). 3.
PAPER HANDLING Preparing to load a sheet of paper Loading a sheet of paper 6. Insert a sheet of paper into the paper table. Make sure that the front edge of the paper engages snugly with the feed roller. NOTE If paper skews when it is loaded, the printer does not print and ejects the paper. (This function can be disabled by a setting in setup mode.) 7. Press the LOAD button. The paper will advance to the top-ofform position. The top-of-form position is the first line on which printing can start.
PAPER HANDLING Loading Paper from the Cut Sheet Feeder (Option) A cut sheet feeder (SF940) allows automatic printing on single sheets without the need to manually insert the sheets one-by-one. This can save you a lot of time when printing long files using single sheets. See Chapter 8 for more information on the cut sheet feeder. For installation of the feeder, refer to its user’s manual.
PAPER HANDLING • 3. Slide the right paper guide until the distance between the two guides is the approximate width of your paper. Manually fan the stack of paper and place it in the paper bin. NOTE A short horizontal mark inside the left paper guide indicates the maximum capacity of the bin. Make sure that your paper stack does not exceed this horizontal mark. Loading the cut sheet feeder (Front feed) Loading the cut sheet feeder (Rear feed) 3-22 4.
PAPER HANDLING 7. • Load the paper manually. Press the LOAD button. The paper will advance to the top-of-form position. Adjust the position of the paper as needed by the MICRO button or the MICRO button (micro feed). • Load the paper using your software. Press the ONLINE button to place the printer online. Load paper according to the instructions in your software documentation. Most software packages load paper automatically. After loading paper, the printer goes into online mode.
PAPER HANDLING FEEDING AND POSITIONING PAPER The following functions are available whether the printer is online or offline. Line Feed/Form Feed Use the line feed/form feed function to move paper forward. • Pressing and holding down the LF/FF button feeds one sheet of paper. • Pressing the LF/FF button once advances the paper one line (do not hold the button more than three seconds). Micro Feed Use the micro feed function to fine tune the position of the paper. • Press the inch.
PAPER HANDLING Print Head Adjusting Load Position by Using Window of Card Guide The lines of window on the right side of card guide indicate printing line. So use this as a guide to adjust load position.
PAPER HANDLING TIPS ON PAPER HANDLING General Tips • Use high-quality paper. Do not use paper that is wrinkled or curled at the edges. • Do not use paper with staples or metal parts. • Do not use paper with unpredictable variations in thickness, such as paper with partial multilayers, paper with embossed printing, and labels with the backing sheet exposed. • Store paper in a clean, dry environment. Multipart Forms • Avoid using carbon-interleaved single sheets if possible.
CHAPTER 4 PRINTING PRINTING This chapter describes the following everyday printing operations: MULTIPART FORMS (HI IMPACT MODE) • Using multipart form (hi impact mode) • Selecting the print mode(quiet mode) • Starting, stopping, or resuming printing • Removing printed pages • Clearing the print buffer • Selecting the print features 4 Instructions for loading paper are given in Chapter 3. This printer has enough capability to print multipart forms.
PRINTING PRINT MODE (QUIET MODE) Quiet mode reduces acoustic noise as follows. The consecutive dots are omitted (LQ). The print speed is slowed to LQ speed (except for LQ). Skipping the space (no characters) at higher speed doesn’t work. To select Quiet mode: 1. Press the ONLINE button to place the printer online. 2. Press the PRINT MODE button. When QUIET indicator lights, QUIET MODE is valid.
PRINTING STARTING OR STOPPING PRINTING Starting Printing Before you start to print, make sure that paper is loaded. To start printing, press the ONLINE button to place the printer online. Then start your software. Stopping Printing To stop printing immediately, press the ONLINE button to place the printer offline. You can also use your software to stop printing, but there will be a slight delay before printing stops.
PRINTING CAUTION When printing remaining lines, be careful not to print on the platen. Printing on the platen may damage both the platen and the print head. Continuing printing after supplying paper 1. Install paper on the forms tractors or on the cut sheet stand, or in the cut sheet feeder bin, as described in Chapter 3. 2. To load the first sheet of paper, press the LOAD button. The PAPER OUT indicator will turn off. 3. Press the ONLINE button to place the printer online.
PRINTING REMOVING PRINTED PAGES This section describes the best methods for removing single sheets or continuous forms paper after printing. Removing Single Sheets When you print using software, the printer automatically ejects each sheet of paper when the end of the printed page is reached. To eject sheets manually, use one of the following methods: • Press and hold down the LF/FF button to execute a form feed.
PRINTING SELECTING PRINT FEATURES The print features you select determine how your printed pages will look. Print features include the following: • • • • • Print quality Fonts Pitch (characters per horizontal inch) Page length and width Line spacing (lines per vertical inch) To select print features, you can use either commercial software or the printer control panel. The method you use depends on the capabilities of your software.
PRINTING Using the Control Panel Use the ONLINE and LF/FF button to directly select one of the two menus. Printer control panel The ONLINE and LF/FF buttons specify MENU1 or MENU2, either of which allows you to specify different sets of options in advance. Some of the print features include emulation, print quality, character pitch, and line spacing. To setup the print features to MENU1 and MENU2, refer to the chapter 5.
PRINTING Selecting MENU1 or MENU2 When you first turn the printer on, MENU1 is selected. To change to MENU2 or back to MENU1, proceed as follows: 4-8 1. Press the ONLINE button to place the printer offline. 2. Repeatedly press the ONLINE and LF/FF buttons. The lighted indicator (1 or 2) shows the menu selected. When the menu selection is changed, the font (font, pitch, and quality) assigned in the selected menu becomes valid. 3. Press the ONLINE button to return online.
PRINTING Using the Control Panel (LCD type only) LCD type Control panel also can select print features including FONT/PITCH/QUALITY that assigned current MENU1 or 2 directly. To select print features enter select mode as follows. 1. Press the ONLINE button to place the printer online. 2. Press the FONT/PITCH button to enter select menu. 3. To move layer and in transverse direction, use , , and buttons. 4. To save or exit press SAVE/EXIT buttons.
PRINTING Table 4.1 MENU1 and MENU2 Settings Setting Print Feature Default Settings For easy reference, check (9) or record your default settings in the space below.
CHAPTER 5 USING SETUP MODE USING SETUP MODE Your printer has two modes: normal and setup. Normal mode is used for everyday printer operations and is explained in Chapters 3 and 4. 5 Setup mode serves two purposes. It enables you to: • Select the printer’s optional settings • Help diagnose printer problems These setup mode functions can be done either offline, using the printer control panel (offline setup), or remotely, using a setup program in your computer system or software (online setup).
USING SETUP MODE • Head Gap Adjustment Items and Options • Exiting and Saving To restore the printer default settings (factory defaults or power-on defaults), see the section Resetting Defaults later in this chapter. For information on using the SELF-TST, HEX-DUMP, and V-ALMNT functions, see the section Using the Diagnostic Functions later in this chapter. For Experienced Users: Once you are familiar with setup mode, you may want to use the flowchart at the end of this chapter for quick reference.
USING SETUP MODE 4. When the printer enters offline setup mode, it prints the following information. Function buttons in Setup mode <> menu Cursor Function Card guide (aluminum print guide (head guide)) Initial printout in setup mode The initial printout contains a header, help menu, and <> menu. The header tells you that the printer is offline and in setup mode. The help menu provides a quick summary of how to use setup mode.
USING SETUP MODE OVERVIEW OF SETUP MODE (LED) << FUNCTION >> SAVE&END MENU1 HEX-DUMP V-ALMNT MENU2 INITIAL When you enter setup mode, the following <> menu is printed: HARDWRE ADJUST CONFIG GAP-ADJ DEFAULT LIST SELF-TST Table 5.1 summarizes the purpose of each function. Table 5.1 Setup Mode Functions Function Purpose SAVE & END Exits setup mode and saves any changes made while in setup mode. MENU1 and MENU2 Assigns print features to MENU1 and MENU2 on the printer control panel.
USING SETUP MODE The first three MENU1 items and their options are shown below. Items are enclosed in single brackets < >. A short underlined portion is current option and long underlined portion is selected option. < EMULATE>DPL24C+ PRSTG12 N.SAN-N LETTER XL24E ESC/P2 COMPRSD N.SAN-B BOLDFCE N.SAN-I PICA 10 TIMLS-N REPORT DRAFT HI-DRFT CORRESP TIMLS-B OCR-B TIMLS-I OCR-A DOWNLD0 COUR-N DOWNLD1 COUR-B To select an option from the - menu: 1.
USING SETUP MODE 4. Select the current emulation. Since you do not want to change the emulation, press the “ ” button to select the current emulation and print the next item, and its options. 5. Change the font to Prestige Elite 12. Press the “TEAR OFF” or “LOAD” button once to position the cursor on the left edge of the aluminum print guide on PRSTG12. Press the “ ” button to select PRSTG12 and print the next item, , and its options. 6. Select the current print quality.
USING SETUP MODE Points to Remember • Whenever you enter setup mode, short help menus are printed at the top of the page. Help menus are also printed when you select the SELF-TST, HEX-DUMP, or V-ALMNT functions. Use help menus for quick reference while in setup mode. • When printing the items and options for each function, you can only print one item at a time. However, you can move either forward or backward in the item list. To move forward (print the next item), press the button.
USING SETUP MODE 2. Select the LIST function. Repeatedly press the “TEAR OFF” or “LOAD” button to position the cursor on the left edge of the aluminum print guide on LIST. Next press the button or the button to select the LIST function. The printer starts to print a list of the currently selected options. The preselected factory settings, also called factory defaults, are shown on the opposite page. When the printer finishes printing the list of options, it reprints the <> menu. 3.
USING SETUP MODE *1 FORMAT to CD are not printed when PARALEL option is selected for INTRFCE. It is printed equipped with RS-232C. *2 TEAR-EN is printed when AUTO option is selected for TEAROFF.
USING SETUP MODE To enter setup mode, follow these steps: ENTERING SETUP MODE(LCD) 1. Press the ONLINE button to place the printer offline. 2. Press the SETUP button until the printer beeps. Entering setup mode 3. When the printer enters offline setup mode, LCD display shall change as follows.
USING SETUP MODE Available functions of LCD types SETUP MODE are as follows. OVERVIEW OF SETUP MODE (LCD) Table 5.2 summarizes the purpose of each function. Table 5.2 Setup Mode Functions(LCD) Function Purpose MENU1 and MENU2 Assigns print features to MENU1 and MENU2 on the printer control panel. HARDWRE Changes the printer hardware options. ADJUST Changes the print position adjustment options. CONFIG Changes the configuration options.
USING SETUP MODE The previous page shows a printout of the printer’s factory default DECIDING WHICH OPTIONS TO CHANGE settings.
USING SETUP MODE Table 5.3 Required Options (Cont.) Function Item Option HARDWRE FORMAT BAUD-RT PROTOCL DSR DUPLEX CTS CD If you have a serial interface, the serial interface options selected on the printer must be the same as the settings you selected using your software or your computer operating system. If the settings are not the same, the printer will not print or will print garbage.
USING SETUP MODE MENU1 AND MENU2 ITEMS AND OPTIONS The MENU1 and MENU2 functions allow you to change the print options assigned to MENU1 and MENU2 on the printer control panel. In normal (nonsetup) mode, you can easily switch between the menus for printing, as described in Chapter 4. MENU1 is invoked when you first turn the printer on. Select the same emulation on the printer as is selected in your software. If the emulations are not the same, the printer will not work correctly with your software.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table. MENU1 and MENU2 Items Options Description Select the same emulation as is selected in your software. See the section Selecting an Emulation in Chapter 2 for information on selecting an emulation.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table. MENU1 and MENU2 Items (continued) Options Description TIMLS-N TIMLS-B TIMLS-I DOWNLD# Font 0 or font 1 in the printer’s download RAM See Appendix F for font examples.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table. MENU1 and MENU2 Items Options Description Selects an attribute to add emphasis to your documents. Only one attribute may be selected at a time.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table. MENU1 and MENU2 Items Options Description Specifies the number of space lines for the top margin. The resultant blank space is the setting minus 1 line.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table. MENU1 and MENU2 Items Options Description Selects a language. Appendix E shows the character sets for each language.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table. MENU1 and MENU2 Items Options Description For continuous forms, this option specifies whether an inch is skipped around the perforation.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table. MENU1 and MENU2 Items (*4) (*2) Options ENABLE Description Enables the DC1 and DC3 codes. Any data received between DC3 and the next DC1 is ignored. DISABLE Disables the DC1 and DC3 codes.
USING SETUP MODE Table 5.4 MENU1 and MENU2 Items and Options (Cont.) NOTES: • Underlined options are the factory defaults. • Asterisks identify items and options that differ for the IBM XL24E and Epson ESC/P2 emulations. The notes are defined at the end of the table. MENU1 and MENU2 Items <==END==> Options Description WRAP End-of-line wrap. Causes a carriage return plus a line feed. OVR-PRT Characters are overprinted at the end of a line. (LED only) Indicates the end of MENU1 items.
USING SETUP MODE Resetting MENU1 and MENU2 To reset the factory defaults for both MENU1 and MENU2, select the DEFAULT/INITIAL function. For more information, see the section Resetting Defaults later in this chapter. The DEFAULT function cannot reset those options which are handled by the HARDWRE, ADJUST, CONFIG, and GAP-ADJ functions. The INITIAL function can reset those options which are handled by the HARDWRE, ADJUST, CONFIG, and GAP-ADJ functions.
USING SETUP MODE Table 5.5 HARDWRE Items and Options (Cont.) NOTE: Underlined options are the factory defaults. HARDWRE Items Options Description BI-DIR Bidirectional printing. The printer prints in either direction while seeking the next print direction for a shorter print time. UNI-DIR Unidirectional printing. Unidirectional printing is used for printing vertical lines in tables even if vertical alignment is not adjusted. Unidirectional printing is slower than bidirectional printing.
USING SETUP MODE Table 5.5 HARDWRE Items and Options (Cont.) NOTE: Underlined options are the factory defaults. HARDWRE Items Options (continued) Description NOTE: • 0BYTE option is recommended only for graphics application. • With 128KB selected, the printer cannot accept any download font data. Selects the type of the interface to the computer.
USING SETUP MODE Table 5.5 HARDWRE Items and Options (Cont.) NOTE: Underlined options are the factory defaults. HARDWRE Items Options Description Serial Interface or USB interface Items. The following to items are not printed when you select the PARALEL option for the item. Be sure that the options selected on the printer are the same as the options selected using your computer operating system or your software.
USING SETUP MODE Table 5.5 HARDWRE Items and Options (Cont.) NOTE: Underlined options are the factory defaults. HARDWRE Items Options <==END==> Description Indicates data transmission protocol. XON/XOF The DC1 and DC3 codes are used. DTR The Data Terminal Ready signal is used. REV-CHL The Reverse Channel signal is used. IGNORE DSR is ignored by the printer. DETECT DSR is detected by the printer.
USING SETUP MODE CHANGING PRINT POSITION ADJUSTMENT OPTIONS When you print using ruled paper, you often want to adjust the print position so that the print sits properly on the ruled lines. The ADJUST function allows you to: • Set top-of-form position • Fine-tune top-of-form position • Fine-tune left print start column (left margin) • Adjust for accumulative line spacing error in a page The top edge of your paper is the physical top of the page.
USING SETUP MODE Table 5.6 ADJUST Items and Options NOTE: Underlined options are the factory defaults. Options HARDWRE Items 1/6 IN 1.8/6 IN : 6/6 IN : 66/6 IN Sets the top-of-form for front continuous forms in increments of 1/6 inch (4.2 mm) from the physical top of the page. The default is recommended if your top margin is not software-specified. A setting of 1/6 inch is preferable when your top margin is software-specified.
USING SETUP MODE Table 5.6 ADJUST Items and Options (Cont.) NOTE: Underlined options are the factory defaults. Options HARDWRE Items 1/6 IN 1.8/6 IN : 6/6 IN : 66/6 IN Sets the top-of-form for front single sheets in increments of 1/6 inch (4.2 mm) from the physical top of the page. The default is recommended if your top margin is not software-specified. A setting of 1/6 inch is preferable when your top margin is software-specified.
USING SETUP MODE Table 5.6 ADJUST Items and Options (Cont.) NOTE: Underlined options are the factory defaults. HARDWRE Items Options Fine-tunes the left print start position for continuous forms. -10/90, ..., 0/90, ..., 10/90 ...
USING SETUP MODE Table 5.6 ADJUST Items and Options (Cont.) NOTE: Underlined options are the factory defaults. HARDWRE Items Options -14/360, -9/360, 4/360, 0/360 4/360, 9/360, 14/360, GRAPHIC(*1) -14/360, -9/360, 4/360, 0/360 4/360, 9/360, 14/360, GRAPHIC(*1) -14/360, -9/360, 4/360, 0/360 4/360, 9/360, 14/360, GRAPHIC(*1) Description Compensates for the forms feed error accumulated through feeding of rear continuous forms.
USING SETUP MODE Table 5.6 ADJUST Items and Options (Cont.) NOTE: Underlined options are the factory defaults. HARDWRE Items <==END==> Options Description (LED only) Indicates the end of MENU1 items. Press the button to print the first item, . Press the button to print the previous item, . Press the ONLINE button to reprint the <> menu. *1: When printing graphics, selecting “GRAPHIC” may result in the printing of clearer graphics.
USING SETUP MODE CHANGING CONFIGURATION OPTIONS • Tear off for continuous forms • Auto loading of single sheets • Direct decoding of certain commands • Enabling of the AREA OVER indicator Table 5.6 describes the CONFIG items and options. Items are listed in the order they are printed. The procedure for changing the configuration options is described after Table 5.7. Table 5.7 CONFIG Items and Options NOTE: Underlined options are the factory defaults.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options Description Tearoff position. VISIBLE Select this option when your software positions forms to the next topofform after printing the last data. The printer performs tearoff feed without adding a form feed when data transfer has stopped. ALWAYS Select this option when your software stops after printing the last data.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options (continued) Description In some application programs, data transfer may stop temporarily due to internal processing. This setting can avoid an undesired tearoff feed by waiting for up to six seconds each time data transfer stops. Single sheet autoloading. AUTO Single sheet paper is automatically loaded a certain time after you set the paper.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options Description Area-over detection control. ENABLE Detects the left and right edges of paper when loading the paper. The printer does not print data beyond the edges. DISABLE Does not detect the edges. Select this option when you are using colored or preprinted paper. Printer status after loading paper in offline mode for single sheets.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options Description Effectiveness of the Cut Sheet Selection command (//S//). DISABLE Makes the command ineffective. ENABLE Makes the command effective. Note: The Cut Sheet Selection command (//S//) changes the paper source to the paper table and waits for manual insertion of a cut sheet. Detection of end of front continuous forms.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options GATHER Description Setting of ribbon protective control at a line feed on continuous forms ENABLE The protective control is executed. DISABLE The protective control is not executed. CUT-CTL Setting of retracting control at canceling TEAR OFF of continuous forms. PRCISIN The precision-prioritized retracting control is executed.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options SKIP-PR Description Setting of printing speed change processing (skip) ENABLE The skip processing is executed. When a certain amount of blank spaces are found in a line, it changes the printing speed for the blank spaces. DISABLE The skip processing is not executed. It does not change the printing speed for the blank spaces.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options TOF-CTL Setting of priority on TOF control to a printer driver specification or a setup specification. TOF control determines the amout of the top margin when paper is fed to the home position. DRIVER Driver specification is given priority. SETUP Setup specification is given priority.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options Selection of the print carrier position when paper is fed via a front path (with feeding of continuous forms paper from the rear and use of a rear CSF) POSN1 Position 1: Column 31 POSN2 Position 2: Column 42 Detection of paper feed skew ENABLE Enables paper feed skew detection. DISABLE Disables paper feed skew detection.
USING SETUP MODE Table 5.7 CONFIG Items and Options (Cont.) NOTE: Underlined options are the factory defaults. CONFIG Items Options Selection for the paper feeding of continuous forms paper PRCISIN Gives a higher priority to precision. SPEED Gives a higher priority to speed. Selection of the method of feeding from the CSF NORMAL Feeds paper directly from the CSF hopper.
