OWNER’S GUIDE PLHV42P8KC READ AND SAVE THESE INSTRUCTIONS Contents Product Registration .................................................................................... 2 Important Safety Instructions ..................................................................... 3 Installation ................................................................................................4-7 Use and Care ................................................................................................
Product Registration Register your Product The self-addressed P R O D U C T REGISTRATION CARD should be filled in completely, signed and returned to the Frigidaire Canada. Thank you for choosing this appliance. The information contained within this Owner’s Guide will instruct you on how to properly operate and care for your range hood. Please read through the information contained in your literature pack to learn more about your new appliance.
Important Safety Instructions READ AND SA VE THESE INSTRUCTIONS SAVE Take care when using cleaning agents or detergents. Suitable for use in household cooking area CAUTION - To reduce risk of fire and to properly exhaust air, be sure to duct air outside – Do not vent exhaust air into spaces within walls or ceilings or into attics, crawl spaces, or garages. CAUTION - For General Ventilating Use Only. Do Not Use To Exhaust Hazardous Or Explosive Materials And Vapors.
Installation FOR RESIDENTIAL USE ONLY NOT TO BE INSTALLED OVER GAS GRILLS PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING. INSTALLATION MUST COMPLY WITH ALL LOCAL CODES. IMPORTANT: Save these Instructions for the Local Electrical Inspector’s use. INSTALLER: Please leave these Instructions with this unit for the owner. OWNER: Please retain these instructions for future reference. Safety Warning: Turn off power circuit at the service entrance and lock out panel, before wiring this appliance.
Installation Tools required for installation Screw driver (pozidrive n°2 , torx 10 and 20) Allen spanner 4mm Shifting spanner 10mm pipe wrench 3/8 Electric drill with twist bit Ø 10 mm K = Kitchen Height C = Counter Height (36" standard) P = Prefered Height of Hood Bottom above counter (recommended 30”-36”) A = Canopy Height H = Hood height your installation H= K–C–P S = Chimney Structure Height, your installation. S= H–A S H A K P C (36"std.) Pre-Installations Calculations (see Figure 2) 1.
Installation Appliance Installation (Note: two people may be required for proper installation of model FIJI). Figure 6 8. Install transition to top of hood (if removed for shipping). Snap damper into transition, foam tape up , with firm pressure at either end. Mark onto exterior of transition the 'V' location of the damper within. See Figure 6. Note: Duct screws can ONLY go below this line. 9. Adjust chimney mounting structure to S dimension as determined in Step 1, page 5.
Installation Wiring to Power Supply WARNING! ELECTRICAL GROUNDING INSTRUCTIONS THIS APPLIANCE IS FITTED WITH AN ELECTRICAL JUNCTION BOX WITH 3 WIRES, ONE OF WHICH (GREEN/YELLOW) SERVES TO GROUND THE APPLIANCE. TO PROTECT YOU AGAINST ELECTRIC SHOCK, THE GREEN AND YELLOW WIRE MUST BE CONNECTED TO THE GROUNDING WIRE IN YOUR HOME ELECTRICAL SYSTEM, AND IT MUST UNDER NO CIRCUMSTANCES BE CUT OR REMOVED. Warning: Turn off power circuit at the service panel before wiring this unit.
Use and Care Control Pad Functions READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE HOOD. For satisfactory use of your hood, become familiar with the various functions of the hood as described below Suction power 3 LED, this led is ON when suction power 3 is selected. Suction power 2 LED, this led is ON when suction power 2 is selected. Light OFF button Motor OFF button Light ON button ON button and motor suction power selection button 1, 2, 3, 1,....
Hood Cleaning Be sure lights are cool before cleaning the hood. To Clean Filters • The metal grease filters will last forever. They are made of anodized aluminum • It is recommended that the filters be washed at least once a month; they can be washed by hand or in the dishwasher. • Drain water through edge holes and let each filter dry thoroughly before replacing it. To Remove The Metal Grease Filters • Turn blower and lights off. • Push each handle towards the center and pull downwards Figure 13.
Lights replacement NOTE: Turn blower and lights off. Make sure the lights are cool. If new lights do not operate be sure lights are inserted correctly before calling service. Replace Lights (Figure 14) • Remove lens cover by removing screw and pulling cover down. • Pull out fluorescent tube and replace with Philips Type PL-S 9 Watt maximum. • Replace cover and secure with screw. NOTE: Disconnect the hood from the electricity before checking or replacing fuses.
RANGE HOOD WARRANTY Your range hood is protected by this warranty In the U.S.A., your appliance is warranted by Electrolux Home Products North America, a division of White Consolidated Industries, Inc. We authorize no person to change or add to any of our obligations under this warranty. Our obligations for service and parts under this warranty must be performed by us or an authorized Electrolux Home Products North America servicer. In Canada, your appliance is warranted by WCI Canada, Inc.
