All about the Important Safety Instructions..........................2-3 Installation Instructions...................................7-8 Product Registration..........................................4 Air Conditioner Features....................................9 Normal Sounds..................................................4 Operating Instruction....................................9-15 FCC Statement..................................................5 Care and Cleaning................................
Important Safety Instructions NOTE: NOTE: WARNING WARNING WARNING WARNING SAFETY PRECAUTIONS
Important Safety Instructions SAFETY PRECAUTIONS Provide ventilation per installation instructions. Do not direct airflow at fireplaces or other heat related sources as this could cause flare ups or make units run excessively. NOTE: fails manufacturer. manufacturer.
Product Registration & Normal Sounds Product Registration Record Your Model and Serial Numbers Record in the space provided below the mode and serial numbers. On all models, the serial plate is located on the side of the cabinet. Model No. Serial No. Register Your Product The self-addressed PRODUCT REGISTRATION CARD should be filled in completely, signed and returned to the Frigidaire Company.
FCC Statement FCC Interference Statement 7KLV HTXLSPHQW KDV EHHQ WHVWHG DQG IRXQG WR FRPSO\ ZLWK WKH OiPLWV IRU D &ODVV % GLJLWDO GHYLFH SXUVXDQW WR SDUW RI WKH )&& 5XOHV 7KHVH OLPLWV DUH GHVLJQHG WR SURYLGH UHDVRQDEOH SURWHFWLRQ DJDLQVW KDUPIXO LQWHUIHUHQFH LQ D UHVLGHQWLDO HQYLURQPHQW 7KLV HTXLSPHQW JHQHUDWHV XVHV DQG FDQ UDGLDWH UDGLR IUHTXHQF\ HQHUJ\ DQG LI QRW LQVWDOOHG DQG XVHG LQ DFFRUGDQFH ZLWK WKH instructions, may cause harmful interference to radio communications.
Unit Description & Accessories Included Unit Description Air Outlet Grill Control Panel Carrying Handle Signal Receiver Air Exhaust Remote Control Continuous Drain Outlet Air Intake Power Cord Bottom Drain Outlet Castor Accessories Included PARTS: PARTS NAME: QUANTITY: Window Kit Connector A Exhaust hose connector B Window Kit Exhaust Hose ( Screws Safety Lock Bolts Foam seal A Foam seal B Remote Control Battery Drain hose ( + ) )
Installation Instructions Installation Instructions EXHAUSTING HOT AIR In the Cool Mode the appliance must be placed close to a window or opening so that the warm exhaust air can be ducted outside. First position unit on a flat floor and is within the vicinity of a single circuit outlet power source. Make sure there’s a minimum of 31.5" clearance in the front/back of the unit, and a minimum of 19.7" clearance in the left/right sides of the unit. 31.5" 19.7" 1. Extend both side of the exhaust hose(Fig.1) 2.
Installation Instructions Installation Instructions(continued) Installation in a double-hung sash window 1.Cut the foam seals A(adhesive type) to the proper lengths and attach them to the window and stool.(Fig.6) 2.Open the window sash and place the window slider kit on the window stool (Fig.7). Attach the window slider kit to the window stool. Adjust the length of the window slider kit according to the width of window. Screw down the two screws on the window slider kit. See Fig.7.
Air Conditioner Features & Operating Instructions Control Panel Display Temperature/Timer Scheduler Swing indicator Sleep Mode Selection Adjust Temperature or Timer Fan Speed Filter Reset Power onÂoff WIFI Button* *Note: Refer to the Quick Start Guide that came with your Smart Air Conditioner for detailed instructions on setting up your air conditioner for connected operation from your smart phone or tablet.
Operating Instructions Dry mode Press the “mode” button until the Dry mode indicator lights. In this mode, the “ í ” or “ + ” button is disabled and the screen displays the room temperature. The unit will continuously drain moisture from the room. Note: In this mode, the fan speed will be set as “low” automatically, which cannot be changed. In this mode, condensate drainage are required, refer to the "Drainage Instructions" on Page 15 for more instructions to drain the excess condensate.
Operating Instructions Sleep mode When the unit is in Cool or Auto mode, you can press the “sleep” button to make the unit run in Sleep mode. In this mode, the fan speed will be set as “Auto” automatically, which cannot be changed. In Cool mode the selected temperature will increase by 2 °F 30 minutes after the mode is selected. The temperature will then increase by another 2 °F after an additional 30 minutes.
Operating Instructions °F/°C function Press the “ í ” and“ + ” button the same time for more than 3 seconds to switch between degree Fahrenheit and degrees Celsius. Note: Under Dry/Fan mode, you can not select °F/°C. Ionizer function The unit is equipped with a device called an ionizer. This device can only be activated and deactivated via the Frigidaire app, which can be downloaded onto your smart phone device. By activating this device, it will ionize air molecules.
Operating Instructions Remote Control 6 2 3 5 4 Fan Speed Display Fan Speed Button Temp Setting Display On/Off Button Temp Setting Button Sending Signal Battery Installation and Important Instructions Remove the cover at the back of the remote control. Insert the provided batteries correctly(see the instructions inside the battery compartment). Close up the cover. To replace the old batteries(which have been used up) with two new R03 “AAA” 1.5V batteries, repeat the steps above. Fig.
Operating Instructions How to Use the Remote Control TURNING THE UNIT ON Plug in the unit, then press the “ ” button (when turned on, the unit will operate as the last setting before shutdown. To switch the unit off, press “ ” button again, then remove the plug. Do NOT switch the unit off by removing the plug. Always switch the unit off by pressing the “ ” button and wait for few minutes before removing the plug.
Operating Instructions Drainage Instructions Continuous Drainage During the Dry mode, you will need a garden hose (sold separately) to drain the condensate from the unit. Follow the steps below: Unscrew the drain cap of continuous drain outlet(Fig.20). Connect one end of the garden hose (sold separately) to the drain outlet then lead the other end into a drain that is lower than the unit(Fig.21).
Care and Cleaning Cleaning Clean your air conditioner occasionally to keep it looking new. Be sure to unplug the unit before cleaning to prevent shock or fire hazards. CLEANING THE UNIT The cabinet and front may be dusted with an oil-free cloth or washed with a cloth dampened in a solution of warm water and mild liquid dishwashing detergent. Never use harsh cleaners, wax or polish on the cabinet front. Be sure to wring excess water from the cloth before wiping around the controls.
Before You Call Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. OCCURRENCE SOLUTION Air conditioner will not operate. :DOO SOXJ GLVFRQQHFWHG 3XVK SOXJ ILUPO\ LQWR ZDOO RXWOHW 3OXJ &XUUHQW 'HYLFH 7ULSSHG 3UHVV WKH 5(6(7 EXWWRQ House fuse blown or circuit breaker tripped. Replace fuse with time delay type or reset circuit breaker.
Major Appliance Limited Warranty
