FN-LINK TECHNOLOGY LIMITED F88EUUD15-B3 series user 's manual http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED Index How to install the driver Put the product plug into the USB port of PC……………………..3 Copy the driver into the PC……………..………….…...................3 Install the driver……….……………………………..…...................4 Install driver successfully………...…...........................................4 connect to external wireless network………………......................6 How to set the device to “access point mode” Set to “access point mode”……………………...…...….................
FN-LINK TECHNOLOGY LIMITED 1. Put the product plug into the USB port, the "device manager" of PC is shown below: 2. Copy the corresponding driver "RTLWlanU_WindowsDriver_1019.0.0518.2012_ UI_1.00.0191_EU" into the PC, and install driver, the installation methods: open the file "RTLWlanU_WindowsDriver_1019.0.0518.2012_UI_1.00.0191_EU", double click "Setup" installation program, guide to install. http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED 3. After install driver successfully. the "device manager" of PC is shown below: http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED The USB icon and wireless network adapter displaying in the lower right of the screen. Shown as below: http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED 4. The default settings is "station mode", we can connect to external wireless network. (i.e. it is regarded as a wireless adapter) http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED 5. Set the device to “access point mode” (1). Click the device icon “ ” on the lower right of the screen. It will display “REALTEK 11n USB Wireless LAN Utility” configuration interface. (2). Click on the "mode" button, then select "access points", the screen appears "Switching from station to AP mode…", then enter the "access point mode", and the lower right of the screen will show "access points" icon. http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED At the same time also shows the name of the access point in the "REALTEK 11n USB Wireless LAN Utility" configuration interface, the default no secret key, as shown below: http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED (3).Right now. Switch mode successfully, then select "Setting Internet Connection Sharing(ICS)", as shown below: http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED (4). After select " Setting Internet Connection Sharing(ICS)", as shown below: http://www.fn-link.
FN-LINK TECHNOLOGY LIMITED (5).It can be connected to the access by mobile phone or other mobile device to surf the Internet. http://www.fn-link.
FCC ID: 2AATL-F88EUUD15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
