User’s manual FLIR MR77 Pinless moisture psychrometer with infrared thermometer and Bluetooth METERLiNK®
User’s manual FLIR MR77 #T559822; r.
Table of contents 1 Disclaimers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.1 Copyright. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.2 Quality assurance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.3 Documentation updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.
Table of contents 8.3 8.4 8.5 Moisture specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Thermal measurement range specifications. . . . . . . . . . . . . . . . .25 Vapor pressure specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 9 Technical support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 10 Warranties . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1 Disclaimers 1.1 Copyright 1.3 Documentation updates © 2013, FLIR Systems, Inc. All rights reserved worldwide. No parts of the software including source code may be reproduced, transmitted, transcribed or translated into any language or computer language in any form or by any means, electronic, magnetic, optical, manual or otherwise, without the prior written permission of FLIR Systems.
2 Safety information Note Before operating the device, you must read, understand, and follow all instructions, dangers, warnings, cautions, and notes. Note FLIR Systems reserves the right to discontinue models, parts or accessories, and other items, or to change specifications at any time without prior notice. WARNING Do not look directly into the laser beam. The laser beam can cause eye irritation. WARNING Do not use the laser pointer near explosive gases or in other possible explosive areas.
2 Safety information provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
3 Introduction Congratulations on your purchase of the FLIR MR77 with METERLiNK® Bluetooth capabilities for use with FLIR infrared (IR) cameras. This pinless moisture meter incorporates a patented built-in IR thermometer and 20-point memory.
4 Description 4.1 Meter description Figure 4.1 Front view 1. 2. 3. IR sensor. Laser pointer diode. Humidity sensor and thermometer. Note Protect the sensor with the protective cap when not in use. #T559822; r.
4 Description 4. 5. 6. LCD display. Function buttons, see section 4.2 Function buttons, page 7. External pin probe connection jack (RJ45). Figure 4.2 Rear view 1. 2. Internal moisture sensor. Battery compartment. #T559822; r.
4 Description 4.2 Function buttons • • • • • • • • • Press the button to enter Hygrometer mode, see section 5.3 Hygrometric measurements, page 13. Press the button repeatedly to cycle through the display of relative humidity, dew point temperature, and mix ratio. Press and hold the button for 2 seconds to enter Humidity alarm set mode, see section 5.9 Alarm settings, page 18. Press the button to enter Condensation mode, see section 5.5 Condensation measurements, page 15.
4 Description • • Press and hold the button for 2 seconds to change the unit setting. For more information, see section 5.7 Selecting measurement units, page 17. When in View data mode, press the button to step through the datalogger memory locations. When in View data mode, press the button to step through the datalogger memory locations. Press the button to capture and store the current readings. For more information, see section 5.8 Storing and recalling measurements, page 17.
4 Description Indicates that the meter is displaying relative moisture measurements (solid indicator) or absolute moisture measurements (flashing indicator). Indicates that the meter is in Hold mode. Indicates that the reading is lower than the Low alarm threshold. Indicates that the reading is higher than the High alarm threshold. Indicates that the meter is in Locked mode. Indicates that the internal moisture sensor is active. Indicates that the external pin probe is active.
4 Description Indicates that the meter is displaying relative humidity in percent (%) units. Indicates that the meter is displaying temperature in degrees Celsius (℃) units. Indicates that the meter is displaying temperature in degrees Fahrenheit (℉) units. High/low calibration point. #T559822; r.
5 Operation 5.1 Powering the meter 1. Remove the protective cap from the humidity sensor/thermometer assembly. 2. 3. Press the button to switch on the meter. If the battery indicator shows that the battery voltage is low or if the meter does not power on, replace the battery. See section 6.2 Battery replacement, page 21. 4. Press the button to switch off the meter. 5.1.1 Auto power off The meter enters sleep mode after 30 minutes of inactivity.
5 Operation 5.2.1 Internal moisture sensor 1. 2. 3. Press the button to enter the Moisture mode. The and indicators are displayed. The indicator is also displayed, indicating that the meter is displaying relative measurements. The ambient temperature is displayed on the secondary display. Place the internal moisture sensor (located on the rear side of the meter) on the surface of the material to be tested. The relative moisture reading is displayed on the main display.
5 Operation 4. The indicator shows the currently selected material group number. Refer to section 7 Material groups, page 22. To change the material group number, do the following: 1. Press and hold the and terial group selection mode. The 5. buttons for 2 seconds to enter the Ma- indicator flashes. 2. Use the numbers. 3. Press the lection mode. and buttons to step through the nine material group button to set the group and exit the Material group se- Press the probe pins into the material.
5 Operation 3. Press the button repeatedly to cycle through the display of relative humidity, dew point temperature, and mixing ratio. • Relative humidity: The displayed in percent (%). • Dew point temperature: The indicator is displayed and the reading is displayed in ℃ or ℉, depending on the unit setting. Mixing ratio: The reading is displayed in grains per pound (GPP) or grams per kilogram (g/kg), depending on the unit setting. • indicator is displayed and the reading is 5.
5 Operation • • Steam, dust, smoke, etc., may obscure measurements. To find a hot spot, aim the meter outside the area of interest, then scan across (in an up and down motion) until the hot spot is located. WARNING Do not look directly into the laser beam. The laser beam can cause eye irritation. WARNING Do not use the laser pointer near explosive gases or in other possible explosive areas. Injury to persons can occur. 1. Press and hold the 2. diode. The indicator is displayed.
5 Operation 3. The dew point temperature is displayed on the main display. The IR temperature of the surface is displayed on the secondary display. The bar graph indicates the level of risk for condensation: • • • 4. If the IR temperature is more than 14℃ (25℉) above the dew point temperature, the bar graph is empty. If the IR temperature is 3–14℃ (5–25℉) above the dew point temperature, the bar graph indicates a percentage of full scale.
5 Operation 5.7 Selecting measurement units There are two sets of units; US and metric. The unit setting can be changed at any time in any mode, by pressing and holding the button for 2 seconds. The unit setting applies to all modes. It is not possible to, for example, display moisture in g/kg while showing temperature in ℉. US unit setting: • • • Temperature is displayed in degrees Fahrenheit (℉). Mixing ratio is displayed in grains per pound (GPP). Vapor pressure is displayed in millibars (mBar).
5 Operation 5.8.3 View data 1. Press and hold the button for 2 seconds to enter View data mode. The indicator flashes, and the data stored in that location is displayed. 2. Press the 3. Press the , different modes. 4. Press and hold the exit View data mode. or button to step through the memory locations. , or button to display the stored data for the button for 2 seconds until a single beep sounds to 5.8.4 Clearing the memory from data 1. Press and hold the 2.
5 Operation 3. Use the 4. 5. To disable the high alarm, simultaneously press the and buttons. When the desired high alarm threshold (or OFF) is displayed, press the and buttons to adjust the high alarm threshold. button to save the value. The current low threshold or OFF (if the alarm is disabled) is now flashing on the main display. 6. To switch from OFF to the numerical display, simultaneously press the and buttons. 7. Use the and buttons to adjust the low alarm threshold.
5 Operation Streaming measurement data is a convenient way to add important information to an IR image. For example, when identifying a water leakage in a wall, you may want to know the humidity in the wall. The Bluetooth range is 10m (32ft) maximum. 5.11.2 Procedure 1. 2. 3. 4. 5. Pair the IR camera with the instrument. Refer to the camera manual for information on how to pair Bluetooth devices. Turn on the camera. Turn on the meter. Press and hold the button on the meter to enable Bluetooth.
6 Maintenance 6.1 Cleaning and storage Clean the meter with a damp cloth and mild detergent; do not use abrasives or solvents. If the meter is not to be used for an extended period, remove the battery and store it separately. 6.2 Battery replacement 1. 2. 3. 4. Switch off the meter before attempting to replace the battery. Unscrew and remove the battery compartment cover. Replace the standard 9 V battery. Secure the battery compartment cover. 6.2.
7 Material groups The table below shows the relation between the material group number (1–9), the input (ohms), and the wood moisture equivalent (% WME). #T559822; r.
8 Technical specifications Accuracy specifications for all measurement ranges are applicable under the following ambient conditions: 18 ℃ to 28 ℃ (64.4 ℉ to 82.4 ℉); <80% RH. 8.1 General specifications Display • • • • Controls • • Other indications • • 3-digit 15 mm (0.6″) main display 4-digit 6 mm (0.
8 Technical specifications Operating temperature 0 to 50℃ (32 to 122℉) Storage temperature –10 to 60℃ (14 to 140℉) Operating humidity • • • 90%, 0 to 30℃ (32 to 86℉) 75%, 30 to 40℃ (86 to 104℉) 45%, 40 to 50℃ (104 to 122℉) Storage humidity 90% maximum Dimensions (excluding sensor) 139 mm × 72 mm × 42 mm (5.4″ × 2.8″ × 1.7″) Weight 0.29 kg (0.65 lb.), including batteries Bluetooth range 10m (32ft) maximum Agency approvals FCC Class B 8.
8 Technical specifications 8.4 Thermal measurement range specifications Function IR range Accuracy (of reading) IR temperature (8:1 ratio) –20 to –1℃ (–4 to 31℉) ±5℃ (±9℉) 0℃ (32℉) ±1℃ (±2℉) 1 to 200℃ (33 to 392℉) Greater of ±3.5% or ±5℃ (±9℉) IR Emissivity 0.95 (fixed) Sensor temperature -28 to 77 ℃ (-18 to 170 ℉) ±2 ℃ (3.6 ℉) 8.5 Vapor pressure specifications Function Range Accuracy (of reading) Vapor pressure measurement 0.0–20.0 kPa Greater of ±2.0% or 0.
9 Technical support Website http://www.flir.com/test Technical support T&MSupport@flir.com Repairs Repair@flir.com #T559822; r.
10 Warranties 10.1 FLIR Global Limited Lifetime Warranty A qualifying FLIR Test and Measurement product (the “Product”) purchased either directly from FLIR Commercial Systems Inc and affiliates (FLIR) or from an authorized FLIR distributor or reseller that Purchaser registers on-line with FLIR is eligible for coverage under FLIR’s Limited Lifetime Warranty, subject to the terms and conditions in this document.
10 Warranties FLIR reserves the right to determine, in its sole discretion, whether a returned Product is covered under Warranty. If FLIR determines that any returned Product is not covered under Warranty or is otherwise excluded from Warranty coverage, FLIR may charge Purchaser a reasonable handling fee and return the Product to Purchaser, at Purchaser’s expense, or offer Purchaser the option of handling the Product as a non-warranty return. 7. NON-WARRANTY RETURN.
10 Warranties MAINTENANCE, NEGLECT, ABUSE, IMPROPER STORAGE, FAILURE TO FOLLOW ANY PRODUCT INSTRUCTIONS, DAMAGE (WHETHER CAUSED BY ACCIDENT OR OTHERWISE), OR ANY OTHER IMPROPER CARE OR HANDING OF THE PRODUCTS CAUSED BY ANYONE OTHER THAN FLIR OR FLIR’S EXPRESSLY AUTHORIZED DESIGNEE. THIS DOCUMENT CONTAINS THE ENTIRE WARRANTY AGREEMENT BETWEEN PURCHASER AND FLIR AND SUPERSEDES ALL PRIOR WARRANTY NEGOTIATIONS, AGREEMENTS, PROMISES AND UNDERSTANDINGS BETWEEN PURCHASER AND FLIR.
