3-Axis Stabilized Handheld Gimbal for Smartphone Instructions EN V 1.
Catalogue 1. Overview 1 2.1 Charging 2 2. Start to Use 2.2 Positioning Lock 2.3 Smartphone Installation 2.4 Balancing 2.5 Power ON / OFF 3. Function Operation 3.1 Function / Modes Introduction 3.2 Joystick 3.3 Function Button Operation 3.4 Shutter Button Operation 3.5 Focus Button Operation 2 2 3 3 4 4 4 5 5 6 7 3.6 Trigger Button Operation 7 3.8 Trigger Button Operation 8 3.7 Light Indicator Explanation 3.9 Landscape and Portrait Shot Switching 3.10 Gimbal Initialization 3.
Vimble 2S is a three-axis handheld gimbal suitable for mobile phones with joystick, Bluetooth shutter, position lock, extendable bar, etc. The gimbal can stabilize the smartphone intelligently. The gimbal supports landscape and portrait shooting, which can also control phone shooting. Connect with Feiyu ON App to achieve move functions Suggestion Vimble 2S includes below information, please read the information before using the gimbal 1. Quick start guide 2. Online instruction 3.
1. Overview *This product does not include the smartphone Micro USB Port for Smartphone Charging Tilt Axis Cross Arm Roll Axis Tilt Axis Lock Smartphone Holder Vertical Arm Pan Axis Function Button Micro USB Port Roll Axis Lock Handle (Built-in battery) Extendable Bar 1/4 inch Thread Hole Extendable Range 0~183mm Wrist Strap Hole Status Indicator Joystick Function Button Focus Button ON / OFF Shutter Button Accessories Micro-USB Cable a Tripod Wrist Strap b c a.
2. Start to Use ! TIPS (1) Please fully charge the battery before powering on the gimbal for the first time. (2) If the power is too low, the red light will flash three times every five seconds that indicating you should charge it immediately. (3) When not in use, power off the gimbal. (4) Unlock the three axis clamp before powering on the gimbal. 2.1. Charging Connect the USB cable to charge. The indicator light is red when charging, and green when fully charged. Charging Charge complete 2.2.
2.3 Smartphone Installation Place smartphone in holder so that the phone is snug against the back of the holder. It's recommended to remove your smartphone protective case. Smartphone holder width range : 57-84mm. 2.4 Balancing (Balancing before power on) If the smartphone tilts to left or right after installed the smartphone, please slide the cross arm to the opposite direction which the smartphone tilts to to balance. Leftward Rightward Cross arm Balanced Status www.feiyu-tech.
2.5 Power ON / OFF Make sure unlock the roll and pan lock before powering on the gimbal. Power ON Long press the function button and release it when you hear the tone. （Green light will change to blue） Power OFF Long press the function button and release it when you hear the tone. （The red light will turn off） Function Button 3. Function Operation 3.
Lock the tilt position Follow and rotate Follow and rotate Pan Mode Follow and rotate Lock the pan position Lock Mode Default mode 3.2 Joystick Follow Mode Upward Move to left Move to right Downward 3.
3.4 Shutter Button Operation The gimbal can control the photography after only Bluetooth is connected with smartphone. Connect Smartphone Bluetooth connection （1）Power on the gimbal, open smartphone bluetooth. （2）Choose below Bluetooth connection way: a. Choose Vimble 2S Bluetooth to connect like FY_Vimble2S_xx. b. Open Feiyu ON app, logon or register via tips to connect. （3）After Bluetooth connecting successful, the shutter button is activated.
3.5 Focus Button Operation Focus Button Sliding up-down Function Adjust focus Used with Feiyu ON App (Adjust field-of-view) 3.6 Trigger Button Operation Trigger Button Long press Double tap Function Enter follow mode* （Release trigger button enter into previous mode） Reset * The button's operation function can be modified on App, after connecting Feiyu ON App succeeded. 3.7 Light Indicator Explanation The current mode of the stabilizer can be identified by the indicator status.
3.8 Trigger Button Operation Manually move camera to desired position,and hold for half a second, new tilt position is automatically saved. 3.9 Landscape and Portrait Shot Switching Press buttons to switch Effected only when tilt axis on right side. Hold the gimbal horizontally, press and hold the trigger button, and then single tag function button to switch between landscape and portrait mode.
3.10 Gimbal Initialization Initialize gimbal when: Smartphone fails to remain level. Gimbal has no been used for a long period of time. Gimbal is used in extreme temperature variations. STEP (1) Click the function button five times. The motors will stop working. Status indicatorturns solid blue. Status Indicator Function Button (2) Place the gimbal on a flat, horizontal surface. The gimbal will automatically initialize after a few seconds detecting no movement.
3.11 Smartphone Charging Charge the smartphone via cable and choose the corresponding cable according to charging port. Micro USB Port Cables www.feiyu-tech.
4. Connect and Use Feiyu ON App 4.1 Download the App Feiyu ON Photo/Video Timer photography Zooming Path time-lapse Object tracking Face locking Light tracking photography Overlapping images Ultra-wide angle panorama Free panoramic Filter Beauty Video editing Slow motion Firmware upgrade ...... Scan the QR code to download the app, or search for "Feiyu ON" in the App Store or Google Play. * Requires iOS 9.0 or above, Android 6.0 or above.
4.3 Shooting / control interface Face/object tracking Shooting interface Back Album Setting - Advanced settings Gimbal information Control interface Upgrade Tutorial Remote Control FY_PocketV_xx Reset Virtual Joystick Switch between photo/ recording mode Choose photo modes Camera setting Shutter Switch between front and rear camera Lock mode Panning mode 4.4 Firmware Upgrade Upgrade the firmware through the App. (1) Click the icon (2) Select upgrade type.
5. Specifications 118 mm 110.5mm 317mm Max. Tilting Range 320° Max. Panning Range 320° Max. Tilting Range Operation Time Weight Payload Adapter smartphones 320° 12 Hours 272g (Not including the smartphone) 210g (After balanced) iPhone and Android phones (Width range 57-84mm) www.feiyu-tech.
Disclaimer Thanks for using Feiyu Gimbal. The information in this document affects your safety and your legal rights and responsibilities. Read the entire document carefully to ensure proper configuration before use, Failure to read and follow instructions and warnings in this document may result in serious injury to yourself or others, or damage to your products or damage to other objects in the vicinity.
Official Social Media Website Facebook Youtube Facebook: www.facebook.com/feiyutech YouTube Channel: www.youtube.com/c/Feiyu-tech Twitter: www.twitter.com/feiyutech Instagram: www.instagram.com/FeiyuTech YouTube Channel: www.youtube.com/c/Feiyu-tech Online Store: store.feiyu-tech.
Guilin Feiyu Technology Incorporated Company For more information, please visit our official website www.feiyu-tech.com E-mail: service@feiyu-tech.com Tel: +86 773 2320865 Due to software and hardware improvements, your actual product might differ from the descriptions and pictures in this user manual. You can get the latest user manual from the official website.
