196
Display format Refresh rate (in Hz) Resolution (in pixels)
HDTV (1080i) 50/60 1920 × 1080
HDTV (1080p) 24/30/50/60 1920 × 1080
EX5260/Pro EX7260/Pro EX9210/Pro EX9220/VS350/VS355
Display format Refresh rate (in Hz) Resolution (in pixels)
Computer signals (analog RGB)
VGA 60/72/75/85 640 × 480
SVGA 60/72/75/85 800 × 600
XGA 60/70/75/85 1024 × 768
WXGA 60 1280 × 768
60 1366 × 768
60/75/85 1280 × 800
WXGA+ 60/75/85 1440 × 900
WXGA++ 60 1600 × 900
SXGA 70/75/85 1152 × 864
60/75/85 1280 × 1024
60/75/85 1280 × 960
SXGA+ 60/75 1400 × 1050
WSXGA+
1
60 1680 × 1050
UXGA 60 1600 × 1200
WUXGA
2
60 1920 × 1200
Composite video
TV (NTSC) 60 720 × 480
TV (SECAM) 50 720 × 576
TV (PAL) 50/60 720 × 576
Component video
