Specification Sheet

GENERAL
Wall mounted drinking fountain constructed of #18 gauge,
type 304, stainless steel polished to a satin finish.
Contoured basin minimizes splashing and has exclusive
Flexi-Guard
®
safety bubbler to prevent accidental mouth
injuries. Keyed in location to prevent rotation. Easy to
operate, fully functional push button is vandal-resistant.
Bottom cover plate included. Patented* valve and in-line flow
regulator provides stream from 20 to 105 psi.
ADA COMPLIANT
THIS DRINKING FOUNTAIN COMPLIES WITH THE
REQUIREMENTS OF A.D.A. (AMERICANS WITH DISABIL-
ITIES ACT) FOR CHILDREN’S ENVIRONMENTS WHEN
PROPERLY INSTALLED. PROVIDES A FLOOR TO ORIFICE
HEIGHT OF 30" AND 24" OF KNEE CLEARANCE. CHECK
LOCAL AND STATE CODES.
NO LEAD DESIGN
THIS DRINKING FOUNTAIN COMPLIES WITH THE LEAD-
FREE DEFINITION IN THE SAFE DRINKING WATER ACT
OF 1986 AND LEAD CONTAMINATION CONTROL ACT OF
1988.
Elkay Drinking Fountains are manufactured with a waterway
system utilizing copper components and completely lead-free
material. These waterways have no lead because all leaded
materials, such as leaded brass, have been removed.
This drinking fountain is classified by Underwriters
Laboratories Inc. in accordance with ANSI/NSF61,
Section 9-1997b.
No Lead Child Soft Sides
®
Drinking Fountain
Wall Mount, Fully Exposed
Barrier-Free Access
Model ECDFPW314C
CONSTRUCTION
ECDFPW314C furnished complete with Flexi-Guard
®
, and
easy to operate, vandal-resistant front push button. Patented*
valve and in-line flow regulator provides stream from 20 to
105 psi. Stainless steel wall plate with surface mounting plate
and vandal-resistant bottom cover plate included. Trap fur-
nished by others.
ALSO AVAILABLE
Model ECDFPWVR314C: Includes vandal-resistant bubbler.
Heavy duty, one-piece construction, chrome plated brass.
* Patent #4,481,971
Model ECDFPW314C
Elkay Manufacturing Company
2222 Camden Court
Oak Brook, IL 60523
Printed in U.S.A.
©2001 Elkay Mfg. Co.
(12/01) 14-42
www.elkay.com
SPECIFICATIONS
®
19-3/4"
(502mm)
12-1/8"
(308mm)
1-5/8"
(42mm)
20-3/8"
(518mm)
*24"
(610mm)
30"
(762mm)
4-3/8"
(111mm)
5/8"
(16mm)
18-3/4"
(476mm)
18"
(457mm)
2-15/16"
(75mm)
3-3/16"
(810mm)
FINISHED FLOOR
9"
(229mm)
9"
(229mm)
9-7/8"
(251mm)
12-1/2"
(318mm)
17-1/2"
(445mm)
*Child ADA Requirement
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers’ offerings, be certain these features are not
overlooked.
