EGC3313 ................................................ .............................................
www.electrolux.com CONTENTS 1. 2. 3. 4. 5. 6. 7. 8. 9. SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 DAILY USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ENGLISH 3 1. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability.
www.electrolux.com • Never try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket. • Do not store items on the cooking surfaces. • Do not use a steam cleaner to clean the appliance. • Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot. • If the glass ceramic surface is cracked, switch off the appliance to avoid the possibility of electric shock. 2.
ENGLISH • Make sure not to cause damage to the mains plug (if applicable) or to the mains cable. Contact the Service or an electrician to change a damaged mains cable. • The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.
www.electrolux.com • Do not install a flame diffuser on the burner. 2.3 Care and Cleaning WARNING! Risk of damage to the appliance. • Clean regularly the appliance to prevent the deterioration of the surface material. • Do not use water spray and steam to clean the appliance. • Do not clean the burners in the dishwasher. • Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects. 2.
ENGLISH 4.1 Ignition of the burner WARNING! Be very careful when you use open fire in kitchen environment. Manufacturer decline any responsibility in case misuse of the flame Always light the burner before you put cookware. To light the burner: 1. Turn the control knob counterclockwise to the maximum position ( ) and push it down. 2. Keep the control knob pushed for approximately 5 seconds; this will let thermocouple to warm up. If not, the gas supply will be interrupted. 3.
www.electrolux.com • When the liquid starts to boil, turn down the flame to barely simmer the liquid. Use cookware with diameters applicable to the size of burners. Burner Diameters of cookware Triple Crown 160 - 240 mm WARNING! Do not use cast iron pans, potstones, grill or toaster plates on gas burners. WARNING! Make sure that the handles of the cookware do not extend past the front edge of the hob.
ENGLISH 9 6.1 Cleaning of the spark plug 6.2 Periodic maintenance This feature is obtained through a ceramic ignition candle with a metal electrode. Keep these components well clean to prevent difficult lighting and check that the burner crown holes are not obstructed. Periodically speak your local Service Force Centre to check the conditions of the gas supply pipe and the pressure adjuster, if fitted. 7.
www.electrolux.com 1 2 3 MOD. MOD. PROD.NO. PROD.NO. SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY MODEL MOD. PROD.NO. SER.NO. 0049 TYPE 230V-50Hz IP20 MODEL 1 Stick it on Guarantee Card and send this part 2 Stick it on Guarantee Card and keep this part 3 Stick it on instruction booklet 8. INSTALLATION WARNING! Refer to the Safety chapters.
ENGLISH volume greater than 20 m³), but not in a bathroom or shower room. The minimum distance combustible material can be fitted above the hob in line with the edges of the hob is 400 mm. If it is fitted below 400 mm a space of 50 mm must be allowed from the edges of the hob. For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Installation I.S 813 Current Edition Section 7- Permitted Locations of Appliance. come in touch with mobile parts or they are not squeezed.
www.electrolux.com A A) The by-pass screw • If you change from natural gas G20 20 mbar to liquid gas, fully tighten the adjustment screw in. • If you change from liquid gas to natural gas G20 20 mbar, undo the by-pass screw approximately 1/4 of a turn. WARNING! Make sure the flame does not go out when you quickly turn the knob from the maximum position to the minimum position. 8.5 Electrical connection • Do not pull the mains cable to disconnect the appliance.
ENGLISH To replace the connection cable use only H05V2V2-F T90 or equivalent type. Make sure that the cable section is applicable to the voltage load and the working temperature. The yellow/green earth wire (B) must be approximately 2 cm longer than the live and neutral wire (A). A 13 8.7 Building in min. 650 mm min.
www.electrolux.com 8.8 Possibilities for insertion Kitchen unit with door The panel installed below the hob must be easy to remove and let an easy access in case a technical assistance intervention is necessary. Kitchen unit with oven The hob recess dimensions must obey the indication and the kitchen unit must be equipped with vents to let a continuous supply of air.
ENGLISH 15 Gas burners BURNER Triple Crown NORMAL POWER REDUCED POWER kW kW 3.8 NORMAL POWER NATURAL GAS G20 (2H) 20 mbar inj. 1/100 mm m³/h 146 0.362 1.4 LPG (Butane/Propane) G30/G31 (3+) 28– 30/37 mbar inj. 1/100 mm 98 g/h G30 G31 28– 37 30 mb mbar ar 276 271 10. ENVIRONMENT CONCERNS Recycle the materials with the symbol . Put the packaging in applicable and electronic appliances. Do not dispose appliances marked with the symbol containers to recycle it.
397266303-A-452012 www.electrolux.
