www.ebodeelectronics.eu Audio to Analog Converter CV30RL User guide 2 Bedienungsanleitung 5 Gebruikershandleiding 8 Guide utilisateur 11 Before using our product, please read this document carefully.
User guide Contents 1. CONFORMITY OF USE 2. INTRODUCTION 3. SPECIFICATIONS 4. AUDIO SPEC 5. SET CONTENT 6. ADVANTAGES 7. PRODUCT OVERVIEW 8. OPERATION 9. WARNING 1. Conformity of Use For carefree and safe use of this product, please read this manual and safety information carefully and follow the instructions. The unit is registered as a device that does not cause or suffer from radio-frequency interference. It is CE approved and it conforms with the Low Voltage Directory.
2. Introduction Thank you for purchasing the ebode CV30RL. The CV30RL offers a solution for connecting digital and analogue audio sources. With the CV30RL you can listen to your modern digital TV with digital output, on your analog sound system with analogue input. It converts S/PDIF or TOSLINK digital audio to L/R analogue audio with a digital interpolation filter and digital to analogue converter. A perfect solution that supports up to 6 channels (up to 5.
Item 1 2 3 4 Name R L DC5V Switch 5 6 SPDIF COAX Description Right channel output Left channel output Power input (+5V) Digital audio signal switch. Switch to left: Coaxial signal input Switch to right: Fiber signal input Fiber signal input Coaxial signal input 8. Operation Figure 1.2 9. Warning To reduce the risk of fire, electric shock or product damage: 1.
Bedienungsanleitung Inhalt 1. KONFORMITÄTSBESTIMMUNGEN 2. EINLEITUNG 3. TECHNISCHE DATEN 4. AUDIO SPEZIFIKATION 5. LIEFERUMFANG 6. VORTEILE 7. PRODUKTÜBERSICHT 8. INBETRIEBNAHME 9. WARNUNG 1. Konformitätsbestimmungen Für unbeschwerte und sichere Verwendung dieses Produktes lesen Sie bitte diese Bedienungsanleitung und Sicherheitshinweise sorgfältig durch und folgen Sie den Anweisungen.
3. Einleitung Vielen Dank, dass Sie sich für den ebode CV30RL entschieden haben. Der CV30RL ist ein Konverter der es möglich macht, digitale und analoge Audiogeräte miteinander zu verbinden und deren Signale umzuwandeln. Mit dem CV30RL können Sie Ihren modernen Fernseher mit Digitalausgabe an eine Soundanlage mit analogem Input anschließen. Der Konverter wandelt die digitalen S/PDIF oder TOSLINK Signale in L/R analoge Audio-Signale mit einem digitalen Interpolationsfilter um.
Nummer 1 2 3 4 Name R L DC5V Switch 5 6 SPDIF COAX Beschreibung Ausgang Rechts Ausgang Links Netzeingang (+5V) Schalter zum Wechseln des digitalen Signals Schalter auf links: Analoges Eingangssignal Schalter auf rechts: Digitales Eingangssignal Digitales Eingangssignal Analoges Eingangssignal 8. Inbetriebnahme Darstellung 1.2 9. Warnung Um das Risiko von Feuer, elektrischem Stromschlag oder Produktschäden zu verringern, beachten Sie bitte Folgendes: 1.
Gebruikershandleiding Inhoud 1. GEBRUIKSVOORSCHRIFT 2. INTRODUCTIE 3. SPECIFICATIES 4. AUDIO SPEC 5. INHOUD 6. VOORDELEN 7. PRODUCTOVERZICHT 8. WERKING 9. WAARSCHUWING 1. Gebruiksvoorschrift Voor een zorgeloos en veilig gebruik van dit product, dient u deze handleiding en veiligheidsinformatie zorgvuldig te lezen en de instructies op te volgen. Het apparaat is geregistreerd als een apparaat dat geen verstoring door radiofrequentie veroorzaakt of hier hinder van ondervindt.
2. Introductie Bedankt voor de aankoop van de ebode CV30RL. De CV30RL biedt een oplossing voor het aansluiten van digitale en analoge audiobronnen. Met de CV30RL kunt u naar uw moderne digitale TV met digitale uitgang luisteren, op uw analoge geluidssysteem met analoge ingang. De CV30RL zet S/PDIF of TOSLINK digitale audio om in L/R analoge audio met een digitaal interpolatie filter en digitaal naar analoog converter. Een perfecte oplossing met ondersteuning voor maximaal 6 kanalen (tot 5.
Item 1 2 3 4 Naam R L DC5V Schakelaar 5 6 SPDIF COAX Beschrijving Rechter kanaal uitgang Linker kanaal uitgang Ingangsvermogen (+5V) Digitale audio signaal schakelaar Naar links: coaxiale signaalingang Naar rechts: fiber signaalingang Fiber signaalingang Coaxiale signaalingang 8. Werking Figuur 1.2 9. Waarschuwing Om het risico van brand, elektrische schokken of schade aan het product te beperken: 1.
Guide utilisateur Contents 1. CONFORMITÉ D’UTILISATION 2. INTRODUCTION 3. CARACTÉRISTIQUES 4. AUDIO SPEC 5. CONTENU 6. AVANTAGES 7. APERÇU PRODUIT 8. OPERATION 9. ATTENTION 1. Conformité d’utilisation Pour une utilisation correcte et sans danger de ce produit, veuillez lire attentivement ce manuel et suivre ses instructions. Ce produit est conforme aux normes en vigueur et au marquage CE.
2. Introduction Nous vous remercions d’avoir acheté le CV30RL de Ebode. Merci d’avoir acheté le module Ebode CV30RL. Le CV30RL est une solution permettant la connexion des sources audio analogiques et numériques. Avec le CV30RL vous pouvez écouter votre TV avec sortie numérique sur un système sonore avec entré analogique. Il convertit S/PDIF ou les signaux numériques TOSLINK à un signal audio numérique L/R avec un filtre et un convertisseur numérique-analogique à interpolation numérique.
Item 1 2 3 4 Name R L DC5V Switch 5 6 SPDIF COAX Description Sortie canal droit Sortie canal gauche Alimentation (+5V) Commutateur de signal audio numérique. Basculer à gauche: entrée du signal coaxial Basculer à droite: Entrée signal filaire Entrée signal filaire Entrée signal coaxial 8. Operation Image 1.2 9. Attention Pour réduire les risques d’incendie, de choc électrique ou dommages sur le produit: 1.
