USER MANUAL Dragon Touch K4W10 HD NVR KIT v1.
EN CONTENTS What's in the Box 2 Introduction 3 Specifications 4 Installation and Connections 5 Menu Operation 8 Legal Disclaimer 30 Regulatory Information 30 EU Conformity Statement 31 Safety Instructions 32 Preventive and Cautionary Tips 33 Contact Us 33 1
EN WHAT'S IN THE BOX NVR × 1 Security Camera × 4 Mouse × 1 Power Adapter × 5 Network Cable × 1 Antenna Extension Cable × 1 Quick Start Guide Dragon Touch K4W10 HD NVR KIT V1.
EN INTRODUCTION 1. NVR Front Panel Antenna Alarm Indicator Power Indicator REC Indicator ESC Menu OK Button 2.
EN SPECIFICATIONS 1. NVR (Network Video Recorder) Type NVR Chip Video Input 3MP Wireless NVR HISILICON chip 8 channels Audio Compression G.711 Video Compression H.265/H.
EN 2. Camera Image Sensor: HISILICON 3MP image sensor Video Compression: H.265/H.264 Recording Mode: Manual/Motion Detection/Schedule/Alarm/Human Recognition Input: DC 12V Antenna: Built-in professional enhanced wireless reception INSTALLATION AND CONNECTIONS 1. Installation Connect the monitor Connect the mouse Connect the NVR and IPC antenna Connect to power (IPC and NVR) Connect the router (LAN or Wifi) LAN/Wifi USB Note: • Internet connection is required for remote viewing.
EN Correct method Incorrect method 2. Hard Disk Installation The NVR system requires a 3.5" or 2.5" SATA internal hard drive or mobile hard disk drive for video recording. Without installing a hard drive, the system can display real-time video, but cannot record or play back video footage. The system supports a hard drive of up to 8TB. Note: • Hard disk drive sold separately. • Installing a 2.5-inch SATA hard drive may require a bracket (sold separately).
EN ③ Connect the data wire ④ Connect the power wire ⑤ Secure the screws of the hard drive ⑥ Put the cover back, and secure the screws of the cover Note: • Please power off the NVR before you install the hard drive. • The system cannot record or play back video without a hard drive.
EN MENU OPERATION 1. Startup Wizard After booting up the NVR, the Startup Wizard will be displayed on the screen. If you don't want to see the Startup Wizard next time, you can check and enable "No more hints", then click [Next]. 2. Modify Password The first time you run the NVR, you must log in and set a new password. There is no need to enter a password when you log in for the first time. Just click [OK] to log in and click [OK] to set a new password. [New]: Input a new password.
EN 3. Safety Question Set a safety question to reset the NVR password if you forget it, then click [Next]. [Question]: Select a security question. [Answer]: Enter the answer. [Way to receive verification code]: Supports monitor APP or email.
EN 4. Time-Language Configuration Enter Startup Wizard and click [Next] to go to this interface. [Time Zone]: Set and select the time zone. [System Time]: Set the system date and time. [Date Format]: Choose the date format: YMD, MDY or DMY. [Date Separator]: Choose the separator of the date format. [Time Format]: Choose the time format: 24-hour or 12-hour. [Language]: Select your preferred language. 5. Wireless Device List Click "Wireless" in the shortcut menu to add a camera.
EN [NETIP]: Select network protocol. [Search]: Search IP cameras in the same LAN. [Add]: Add a camera to the list. [Quick set]: System auto search and add cameras. [Delete]: Delete an IP camera in the same LAN. [Clear]: Delete all added cameras. [Encode]: Pair a camera in the same LAN.
EN 6. Install the Mobile App [Serial Number]: Scan the QR code to add a device to the app. [APP]: Scan the QR code to download the HOMEVIZ app, which is available on the App Store and Google Play (for Android and iOS mobile phones). 7. Exit Startup Wizard Click "OK" to exit the Startup Wizard.
EN 8. Access by Mobile Phone For Android Devices 1) Install the HOMEVIZ app for free from Google Play. Tap the app icon to open the app. 2) Tap [Register] to create a new account, then log in by inputting the user name and password. 3) Tap [+] to add a new device.
EN 5) Tap OK to add your device to the app. 6) Whenever you open the HOMEVIZ app, the Device List window will pop up first. From here, you can access video from all connected cameras. Just tap the device you want to view. Device List 30b70c42c6583362 Device D01 Online D02 Online D03 Online D04 Online D05 Online D06 Online D07 Online D08 Online Cloud event Album My 9. Share Access with Your Friends You can share access to your camera with your friends via your mobile phone.
EN Step 2: On your friends' mobile phone, open the app, tap [ code that you sent. ] and scan the QR Scan QR code Device List 30b70c42c6583362 D01 Online D02 Online D03 Online D04 Online Please scan the QE code in the desktop system of the video recorder device To add or reuieve the password , or add other devices, please tap Turn...flash Device Cloud event Album Alarm My Then your friends can access your camera. 10. Recording Settings 1.
EN [Channel]: Select the corresponding channel number to set the channel. [Redundancy]: Click and check this option to double backup the file. If your system supports the installation of two hard drives, every video file will be duplicated to be saved on each. Make sure that two hard disks are installed. One is the read-write disk and the other is the redundant disk. [Length]: Set the time length of each video file. 60 minutes is the default value. [Mode]: Set video state: schedule, manual or stop.
EN 11. Playback There are two methods for playing back video files on the hard drive. ① Right-click the mouse and select [Playback] in the menu list. ② Enter [Main Menu] → [Main Menu] → [Playback]. Playback mode includes Common Playback, Sync Playback, Dayparting, Smart Express and Smart Search.
EN [Common Playback]: In Common Playback mode, you can select the channel, period and date. [Sync Playback]: Play back multiple channels of video at the same time.
EN [Dayparting]: Play back multiple videos of the same channel at the same time. [Smart Express]: Intelligently fast forward the specified file type.
EN [Smart Search]: Intelligently play back the specified file type. 11. Alarm Settings Go to the NVR's [Main Menu] → [Alarm] to enter the Alarm interface. Alarm functions include Intelligent Alert, Abnormality and Traditional Alarm.
EN 13. Intelligent Alert ① Go to the NVR's [Main Menu] → [Main Menu] → [Record] → [Record Configuration] and check [Detect]. ② Go to the NVR's [Main Menu] → [Alarm] → [Intelligent Alert] to enter the Intelligent Alert interface. The human body motion detection function is enabled by default. If you only need motion detection, disable "Human Detect". Set Period/Record Channel/Tour/Snapshot/Mobile Reported and other functions according to your needs, then click [OK] to save. 14.
EN [Smart Alert]: If the preview image is in black and white, human motion detected in the camera's field of view will trigger a human detection alarm and an alarm sound will be heard, the infrared light will go out and the white light will illuminate, and the preview image will switch to a color image. If the preview image is in color, human motion detected in the camera's field of view will trigger a human detection alarm and an alarm sound will be heard.
EN 15. Email Settings ① Make sure your NVR is successfully connected to the router and Internet. You can go to the NVR's [Main Menu] → [Advanced] → [Version] to confirm that [Nat status] shows "Connected". ② Go to the NVR's [Main Menu] → [Alarm] → [Intelligent Alert] to click [Set] and check [Send Email].
EN ③ Go to the NVR's [Main Menu] → [Main Menu] [Network] → [Net Service] → [EMAIL] to enter the Email Settings interface, then double-click [EMAIL]. ④ Login to your Gmail mailbox on the website and enter https://myaccount.google.com/security?pli=1#connectedapps. Allow less secure apps: ON Some apps and devices use less secure sign-in technology, which could leave your account vulnerable. You can turn off access for these apps (which we recommend) or choose to use them despite the risks.
EN ⑤ Please check [Enable] and select ''TLS" in the [Encryption] option, then input the information as required. For example, [SMTP Server] is [smtp.gmail.com] (you must enable [Less secure on] on the web page), [Port] is [587], [User Name] and [Sender] are your Gmail account details, [Password] is your Gmail account password and [Receiver] can be any email. Change [Title] according to your needs, then click [OK] to save. Ensure your [Mail Testing] succeeds, then click [OK] to save.
EN 16. Video Blind ① Go to the NVR's [Main Menu] → [Record] → [Record Configuration] to check [Detect]. ② Go to the NVR's [Main Menu] → [Alarm] → [Traditional Alarm] → [Video Blind] to enter the Video Blind interface. Check [Enable] and select [Channel], [Sensitivity], [Period], [Record Channel], [Snapshot], [Send Email] or [Mobile reported] according to your needs, then click [OK] to save. 17. Video Loss ① Go to the NVR's [Main Menu] → [Record] → [Record Configuration] to check [Detect].
EN 18. Abnormality ① Go to the NVR's [Main Menu] → [Record] → [Record Configuration] to check [Alarm]. ② Go to the NVR's [Main Menu] → [Alarm] → [Abnormality] to enter the Abnormality interface. Click and select [Event Type] (No Storage/Storage Device Error/Storage No Device/Net Disconnection/IP Conflict can be selected), [Enable], [Show Message], [Mobile Reported] or [Send Email] according to your needs, then click [OK] to save.
EN 19. Network Settings Go to the NVR's [Main Menu] → [Main Menu] → [Network] and check [DHCP Enable]. You will then receive an IP Address as shown in the figure below. Note: Ensure that you have a router and high-speed network connection. Connect your NVR to the router by using the Ethernet cable. Ensure that your network speed reaches at least 1Mbps for the best video recording. Go to the NVR's [Main Menu] → [Network] → [Net Service] → [Cloud], ensure that your NVR has a high-speed network connection.
EN Go to the NVR's [Main Menu] → [Main Menu] → [Network] → [Wireless Channels] to check the NVR's wireless channels, including region and channel options. The NVR has been set completely before leaving the factory. Please contact technical support before resetting. 20. Backup Go to the NVR's [Main Menu] → [System] → [Backup] to backup video files to external storage. Plug a USB drive into the USB 2.0 port, as shown in the figure below. Click [Backup] and a dialog box will pop up.
EN [Type]: Select the corresponding type ([All], [Alarm], [MD], [Alarm/MD], [Manual] and [General]) to back up. [Channel]: Select the corresponding channel to back up. [Start Time]: Select time to start backup. [End Time]: Select time to end backup. Click [OK] when you receive the message [Backup finished], then you can remove the USB drive. You need to install the player to play the video on the PC.
EN Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
EN SAFETY INSTRUCTIONS These instructions are intended to ensure that users can use the product correctly and avoid danger and property loss. The precaution measures are divided into [Warnings] and [Cautions]. Warnings: Serious injury or death may occur if any of the warnings are neglected. Cautions: Injury or equipment damage may occur if any of the cautions are neglected. Cautions: Follow these precautions to prevent potential injury or material damage.
EN PREVENTIVE AND CAUTIONARY TIPS Before connecting and operating your device, please be advised of the following tips: • Ensure that the device is installed in a well-ventilated, dust-free environment. • The device is designed for indoor use only. Keep all liquids away from the device. • Ensure that the environmental conditions meet the factory specifications. • Ensure that the device is properly secured to a rack or shelf.
