DA14531MOD

SmartBond TINY

Module

Error! Unknown document

property name.

Datasheet

CFR0011-120-00

1 of 4

RF Specification

Operating Frequency:

2402 MHz – 2480MHz

Type of Modulation:

GFSK

Number of Channels:

40 Channels

Channel Separation:

2 MHz

Antenna Type:

Integral

Antenna Gain:

-0.5 dBi

Speciality:

Bluetooth 5.1 with BLE (Bluetooth Low Energy)

Function:

Bluetooth 5.1 with BLE (Bluetooth Low Energy)

Power Supply:

DC 3.3V

Power cord:

N/A

1. Requirement of FCC KDB 996369 D03 for module

certification:

1.1 List of applicable FCC rules and Canada rules:

The module complies with FCC Part 15.247, and Canada RSS-247.

1.2 Summarize the specific operational use conditions:

The module has been certified for Portable applications. This transmitter must not be co-located

or operating in conjunction with any other antenna or transmitter.

1.3 Limited module procedures:

Not applicable.

1.4 Trace antenna designs:

Not applicable.

1.5 RF exposure considerations:

This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth for an

Summary of content (4 pages)

PAGE 1
DA14531MOD SmartBond TINYTM Module Error! Unknown document property name. RF Specification Operating Frequency: 2402 MHz – 2480MHz Type of Modulation: GFSK Number of Channels: 40 Channels Channel Separation: 2 MHz Antenna Type: Integral Antenna Gain: -0.5 dBi Speciality: Bluetooth 5.1 with BLE (Bluetooth Low Energy) Function: Bluetooth 5.1 with BLE (Bluetooth Low Energy) Power Supply: DC 3.3V Power cord: N/A 1. Requirement of FCC KDB 996369 D03 for module certification: 1.
PAGE 2
DA14531MOD SmartBond TINYTM Module Error! Unknown document property name. uncontrolled environment. The antenna(s) used for this transmitter must not be collocated or operating in conjunction with any other antenna or transmitter. DÉCLARATION D’IC SUR L’EXPOSITION AUX RADIATIONS: Cet appareil est conforme aux limites d’exposition au rayonnement RF stipulées par la FCC et l’IC pour une utilisation dans un environnement non contrôlé.
PAGE 3
DA14531MOD SmartBond TINYTM Module Error! Unknown document property name. - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. ‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help.
PAGE 4
DA14531MOD SmartBond TINYTM Module Error! Unknown document property name. 1.8 Information on test modes and additional testing requirements: When testing host product, the host manufacture should follow FCC KDB Publication 996369 D04 Module Integration Guide for testing the host products. The host manufacturer may operate their product during the measurements.
