Figure 1 D25960 d a b e f c D25961 d a b e f c g 1
Figure 2B Figure 2A b b f Figure 3 2
d Figure 4A d e h Figure 4B d e d Figure 4C i e h 3
Figure 5 k l m n Figure 5 k m, n l 4
EN G LIS H Definitions: Safety Guidelines The definitions below describe the level of severity for each signal word. Please read the manual and pay attention to these symbols. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
E N GL I SH e) f) the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.
EN G LIS H • Hold power tools by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord. Cutting accessory Contacting a “live” wire may make exposed metal parts of the tool “live” and shock the operator. Markings on Tool The following pictograms are shown on the tool: Read instruction manual before use. Wear ear protection.
E N GL I SH DO NOT let children come into contact with the tool. Supervision is required when inexperienced operators use this tool. ASSEMBLY AND ADJUSTMENT WARNING: To reduce the risk of injury, turn unit off and disconnect machine from power source before installing and removing accessories, before adjusting or changing set-ups or when making repairs. Be sure the trigger switch is in the OFF position. An accidental start-up can cause injury.
EN G LIS H 5. To remove a chisel pull back the retainer (d) and pull the chisel out of the tool holder (e). IMPORTANT: The tool must be held with two hands at all times when in use. D25961 Horizontal applications (fig. 2A): TO FIT A CHISEL WITH GROOVE IN THE SHANK (FIG. 4C) Proper hand position requires one hand on the side handle (f) and the other hand on the main handle (b). 1. Pull the retainer bolt (i) and turn it by 180° to the unlock position. Vertical applications (fig. 2B): 2.
E N GL I SH WARNING: Ensure that the cutting edge does not show discolouration caused by too much pressure. This may impair the hardness of the accessory. For the best results only use sharp chisel bits. Sharpening chisel bits frequently will guarantee long life of the chisel bits and the best performance results. GRINDING Optional Accessories WARNING: Since accessories, other than those offered by DEWALT, have not been tested with this product, use of such accessories with this tool could be hazardous.
EN G LIS H GUARANTEE DEWALT is confident of the quality of its products and offers an outstanding guarantee for professional users of the product. This guarantee statement is in addition to and in no way prejudices your contractual rights as a professional user or your statutory rights as a private non-professional user. The guarantee is valid within the territories of the Member States of the European Union and the European Free Trade Area.
