Graphical User Interface Use this manual in combination with the operating guide displayed on the GUI screen.
SAFETY INSTRUCTIONS n SAFETY PRECAUTIONS 1. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
FCC Information (For US customers) n NOTE ON USE / OBSERVATIONS RELATIVES A L’UTILISATION 1. COMPLIANCE INFORMATION Product Name: AV Surround Receiver Model Number: AVR-5308CI This product contains FCC ID: BV2- MPGBR052. This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this product may not cause harmful interference, and (2) this product must accept any interference received, including interference that may cause undesired operation.
Contents Getting Started Accessories······················································································3 Cautions on Handling······································································3 Cautions on Installation··································································3 About the Remote Control Unit·····················································3 Inserting the Batteries································································3, 4 Operating Range of the Remot
Parameter Audio······························································································50 a Surround Parameters·······················································50 ~ 52 s Tone·························································································52 d Room EQ·················································································53 f Dynamic EQ·············································································53 g RESTORER·······················
Getting Started Connections Cautions on Handling • Before turning the power switch on Check once again that all connections are correct and that there are no problems with the connection cables. Getting Started Thank you for purchasing this DENON product. To ensure proper operation, please read this owner’s manual carefully before using the product. After reading them, be sure to keep them for future reference. Setup Accessories Playback Check that the following parts are supplied with the product.
For buttons not explained here, see the page indicated in parentheses ( ). Front Panel Q0 o i u y Setup Playback Remote Control Operating Range of the Remote Control Unit Part Names and Functions Getting Started Connections NOTE • Replace the batteries with new ones if the set does not operate even when the remote control unit is operated close to the unit. • The supplied batteries are only for verifying operation.
Getting Started Connections GWith the door openH W9 W8 W7 W6 Display W5 W4 W3 W2 W1 W0 Q9 Q8 Q7 Q6 Q5 Q4 Q3 Q9 Q8 Q7 Q6 Q5 Q4 Q3 Q2 Q0 Q1 o i u y Setup Playback q w er t y u Remote Control Multi-Zone Information Troubleshooting q DIRECT/STEREO button····························· (49) w Headphones jack (PHONES)················· (56, 72) e CINEMA button··········································· (48) r RESTORER button······································· (53) t MUSIC button·······
u Q9 Q8 Q7 Q6 Q5 Q4 Q3 Q2 Q1 Q0 o i Getting Started Connections Rear Panel u Setup Playback Remote Control Multi-Zone W0 W1 W2 Information Troubleshooting q q RS-232C connector······································ (24) w Analog audio connectors (AUDIO)············ (13) e PRE OUT connectors····························· (19, 23) r EXT.
Getting Started Connections Remote Control Unit n Main remote control unit (RC-1067) Q5 q Setup w Playback e Q6 Q7 Remote Control Multi-Zone o Q2 Monitor select (M.
Connections Cables Used for Connections Select the cables according to the equipment being connected. Audio cables Component video connections (Green) (Orange) (Y) (Blue) Coaxial digital (75 Ω/ohms pin-plug) cable (PB/CB) (Red) (PR/CR) Playback Optical digital connections Setup Component video cable (Green) Optical cable (Y) (Blue) BNC digital connections (PB/CB) (Red) Remote Control • Do not plug in the power cord until all connections have been completed.
Getting Started GFlow of video signals for ZONE3H Video Conversion Function ZONE3 Connections • This function automatically converts various formats of video signals input to the AVR-5308CI into the format used to output the video signals from the AVR-5308CI to a monitor.
Speaker Installation Getting Started Speaker Connections Example: 9.3-channels and ZONE2 use Speaker Layout Front speaker (R) Subwoofer Center speaker Center speaker Subwoofer 1 b L : Left R : Right Subwoofer with built-in amplifier (R) w Surround back speakers Front speaker (L) w q q Connections The illustration below shows a basic example of installation of the amplifier combined with 8 speakers and a monitor.
Getting Started Connecting the Speaker Cables Carefully check the left (L) and right (R) channels and + (red) and – (black) polarities on the speakers being connected to the AVR-5308CI, and be sure to interconnect the channels and polarities correctly. Connections Setup Playback Remote Control 1 Peel off about 0.03 ft/10 mm of sheathing from the tip of the speaker cable, then either twist the core wire tightly or terminate it. 2 3 4 Turn the speaker terminal counterclockwise to loosen it.
With HDMI connections, the video and audio signals can be transferred with a single cable. Monitor )%.* 065 )%.* */ Compatible audio format Details Discs (examples) Multi-channel linear PCM 8ch 32-192 kHz 16/20/24 bits DVD-Audio Dolby Digital, DTS Bitstream DVD-Video DSD 2/5.1ch 2.
Getting Started Connecting the Monitor Connecting the Playback Components • Connect the cables to be used (vpage 9 “Video Conversion Function”). • With HDMI connections, the video and audio signals can be transferred with a single cable. • To output the audio signals to the monitor with HDMI connections, set GUI menu “Manual Setup” – “HDMI Setup” – “Audio” to “TV” (vpage 33). Connections Monitor 7*%&0 7*%&0 */ 4 7*%&0 */ $0.10/&/5 7*%&0 */ : 1# 13 )%.
CD Player Turntable (MM cartridge) iPod® Connect the cables to be used. CD player "6%*0 $0"9*"065 Example : iPod L R Setup "6%*0 065 (/% "4% 3 R L Playback L Connections "6%*0 065 3 Use a DENON Control Dock for iPod (ASD-1R, sold separately) to connect the iPod to the AVR-5308CI. For instructions on the Control Dock for iPod settings, refer to the Control Dock for iPod’s operating instructions.
Getting Started TV/CABLE Tuner Satellite Receiver Connect the cables to be used. Connect the cables to be used. TV tuner DBS / BS tuner 7*%&0 Connections 7*%&0 065 4 7*%&0 065 $0.10/&/5 7*%&0 065 : 1# 13 7*%&0 "6%*0 015*$"065 "6%*0 065 3 7*%&0 065 4 7*%&0 065 $0.10/&/5 7*%&0 065 : 1# 13 "6%*0 )%.
Getting Started Connecting the Recording Components Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect correctly. Connect the cables to be used. Digital video recorder 7*%&0 065 4 7*%&0 065 "6%*0 $0.10/&/5 7*%&0 065 : 1# 13 )%.
Getting Started Video Cassette Recorder CD Recorder / MD Recorder / Tape Deck Connect the cables to be used. Make analog connections if you wish to record analog audio signals, or digital connections if you wish to record digital audio signals, depending on the types of connectors on the components being used. Video cassette recorder 7*%&0 Connections 4 7*%&0 065 "6%*0 7*%&0 065 "6%*0 065 3 Setup L Playback L R R 015*$"065 7*%&0 )%.
Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect correctly.
Getting Started External Power Amplifier USB Port n Front panel Power amplifier n Rear panel "6%*0 '30/5 Connections - 3 46# 800'&3 $&/5&3 463306/% " - 3 463306/% #"$, - 3 USB memory device 463306/% # - USB memory device 3 R L R L R L R L R L R L R L R Setup L Playback Remote Control Multi-Zone Information Troubleshooting • In the initial status, USB memory devices can be used by connecting them to the USB port on the front panel.
Keep the power cord unplugged until the XM Mini-Tuner and Home Dock connection have been completed. • The XM name and related logo are registered trademarks of XM Satellite Radio Inc. All rights reserved. • XM Ready is a registered trademark of XM Satellite Radio Inc. All rights reserved. Connections Setup Playback • The AVR-5308CI is an XM Ready® receiver.
Getting Started HD Radio™ broadcast Antenna terminals HD Radio broadcast is a service that is only available within the United States. An F-type FM antenna cable plug can be connected directly. Direction of broadcasting station AM/FM Connections Direction of broadcasting station FM antenna FM antenna AM loop antenna (small, supplied) Setup Playback (White) AM loop antenna (large, for HD Radio broadcasting, supplied) • To prevent interference, install at least 3.
n Broadband Internet connection [Wired LAN] Computer n Modem This is a device that is connected to the broadband line to communicate with the Internet. Some are integrated with the router. Internet To LAN port n Ethernet cable (CAT-5 or greater recommended) Computer To WAN side Rod antenna (supplied) Router with access point Turn clockwise.
Getting Started NOTE Multi Zone ZONE2 or ZONE3 Pre-out Connections Connections Setup • If another power amplifier or pre-main (integrated) amplifier is connected, the ZONE2 or ZONE3 pre-out (variable or fixed level) connectors can be used to play a different program source in ZONE2 or ZONE3 the same time (vpage 85 ~ 90). • When using a component video cable to connect the AVR-5308CI and input device, connect the ZONE2 monitor output to the component video connectors.
Getting Started Connecting the Power Cord External Controller Wait until all connections have been completed before connecting the power cord. Power cord (included) This connector is used for an external controller. • These outlets supply power to external audio devices. • The power supplied from these outlets turns on and off together with the set’s power switch. • Audio equipment with a total power consumption of 120 W (1 A) can be connected.
Getting Started Examples of GUI Screen Displays GUI Menu Operations Connections With the AVR-5308CI, settings and operations for most functions can be performed by operating while looking at the GUI menus displayed on the monitor screen. Some typical examples are described below. Setup Playback Remote Control Multi-Zone Optimize settings for speakers in use.
Information (vpage 54, 55) n PHONO • Video · Video Select · i/p Scaler · Resolution • Input Mode • Rename • Source Level Surround Mode n Option • Room EQ • Direct Mode • Mic Select n Parameter Check • Speaker Configuration Check • Distance Check • Channel Level Check • Crossover Check • EQ Check • Restore Manual Setup (vpage 30 ~ 43) n Network Setup (vpage 35 ~ 38) • Network Setup • Other · Power Saving · Character · PC Language · Rhapsody Account • Network Information n Zone Setup (vpage 39) • ZONE2,
Getting Started Preparations 1 Auto Setup Connect the included calibrated setup microphone to the SETUP MIC jack on the main unit. The “Auto setup” screen appears automatically. Auto Setup Optimize settings for speakers in use. F Menu tree F Connections Auto Setup Setup Playback Remote Control • Audyssey MultEQ® XT automatically measures the acoustical problems in the listening environment to create the best audio experience for your home theater.
Start Auto Setup. The Audyssey MultEQ XT Auto Setup process automatically calculates the size, level, distance, bass management crossover frequency, and optimal settings for each speaker and subwoofer. Audyssey MultEQ XT corrects acoustical distortions within the listening area. Before starting, connect and position all your speakers. Once started, MultEQ XT will play a series of test tones through each speaker. [Selectable items] 9.1 9.2 9.3 7.1 z2 z3 7.2 7.3 5.1 z2 z3 5.2 5.
Getting Started Error Messages s Option If the auto setup procedure could not be completed due to speaker installation, the measuring environment, etc., an error message is displayed. If this happens, check the relevant items, be sure to take the necessary measures, then perform the auto setup procedure over again. Select settings for room EQ, mic, etc. Room EQ Connections Error messages (examples) No microphone or speaker Cause • Included setup microphone is not connected.
s Subwoofer Setup Select subwoofer use. [Selectable items] Manual Setup Speaker Setup No Surround A Configuration Select surround speakers A use and size. Select number of subwoofers and configuration. [Selectable items] Large [Selectable items] Small None F Menu tree F [Selectable items] Large Select surround speakers B use and size. Small None Manual Setup a Speaker Configuration Select surround back speaker use and size.
Getting Started d Distance f Channel Level Set distance from listening position to speakers. Before making the settings, measure the distance from the listening position to the different speakers. Adjust channel levels to obtain equal volume from all speakers. Mode Connections Setup Playback Feet / Meters Select test tone playback method. Select unit for distance. [Selectable items] Auto Step Surround Select step. (smallest distance) Select surround speaker from which test tone is output.
• If the bass sound seems too strong: Set “BGC” to “ON”. This activates a filter that gently reduces very deep bass below 55 Hz to provide the flattest overall deep bass response. Select “ON” or “OFF” according to how strong you prefer the deep bass response to be. • This can be set when the “THX Ultra2 Subwoofer” setting is set to “Yes”.
Getting Started HDMI Setup Make settings for HDMI video/audio output. f Audio h HDMI Control Select HDMI audio output device. Make settings for HDMI control function. [Selectable items] Amp F Menu tree F Control TV Connections Set HDMI control function ON/OFF. Manual Setup HDMI Setup GUI menu “HDMI Control” – “Control” is “ON”, the “Amp” and “TV” will switch with the operation of any television not related to this setting.
Make settings for audio playback. s 2ch Direct/Stereo d Downmix Option Make speaker settings for 2-channel mode playback. Set dynamic range for downmix playback of Dolby Digital sources. [Selectable items] Setting F Menu tree F To change the settings, select “Custom”. z Audio Setup [Selectable items] Basic a EXT.IN Setup Front f Auto Surround Mode Select front speaker size. [Selectable items] Large a EXT. IN Setup Make speaker settings for EXT. IN mode playback. Select subwoofer use.
Getting Started g Manual EQ Adjust tonal quality for each speaker using graphic equalizer. Adjust CH Network Setup Make network settings. F Menu tree F Connections Select speaker adjustment method. Select the speaker and frequency band and adjust the level.
Select when access points cannot be searched automatically. Set the access point at the GUI menu “Manual Setup” – “Network Setup” – “Network Setup”. When searching access points to connect automatically, refer to “Automatic settings”. When searching access points to connect manually, refer to “Manual settings”. n Automatic settings b If the access points are repeat search, use the i button to select the “Search” and press the ENTER button. q Select “Search”. Select when searching access points again.
Getting Started Use the uio p button to input the “Key” (encryption key) and press the ENTER button. Enter the same encryption key as used for the access point. Connections When no security settings have been used in the Internet connection settings, this step is not necessary. n Manual settings r Use the ui button to select the Security and press the i button. [Selectable items] [Characters that can be input] A~Z a~z 0~9 None : ! “ # % & ’ ( ) * + , - .
[Selectable items] b For details, see page 35, 36 “Wired LAN settings” in step 3. Address : Select when inputting by address. ara chi (smpl) chi (trad) t Use the ui p button to input the proxy server address or domain name and press the ENTER button. When “Address” is selected in step r : Input the address When“Name” is selected in step r : Input the domain name fre ger por por (BR) [Characters that can be input] a~z 0~9 ! “ # % & ’ ( ) * + , - .
Getting Started Rch Level Zone Setup Make settings for audio playback in a multi-zone system. F Menu tree F d OSD Adjust the right channel output level. [Variable range] –12dB ~ Set ZONE2 monitor as onscreen display Zone. ~ +12dB 0dB [Selectable items] Connections Channel Manual Setup Zone Setup ZONE2 Switch between stereo and mono output. a ZONE2 [Selectable items] Stereo s ZONE3 ZONE2/ZONE3 : Display ZONE2 and ZONE3 operations.
d Source Delete Define how the amplifier for the surround and/or surround back speaker channels is used. Remove input sources that are not used from the display. ON Delete NOTE Setup • Input sources being used in the various zones cannot be deleted. • Input sources set to “Delete” cannot be selected from GUI menu “Source Select” or using the SOURCE SELECT knob on the main unit or SOURCE SELECT button on the remote control unit.
Getting Started Setting with Respect to the Monitor h Trigger Out 1 Connections Select the conditions to turn on the trigger out 1 with respect to the zone, input source, surround mode, HDMI monitor, etc. For details about the trigger out function, see page 24. When the HDMI monitor set to on is selected, the trigger out turns on.
A7 Firmware Update Adjust display brightness of the receiver. Update the firmware of the receiver. [Selectable items] Bright Dim Dark OFF Press the DIMMER button. Bright Dim Dark Protect settings from inadvertent change. ON OFF Execute the update process. When updating starts, the power indicator becomes red and the GUI screen is shut down. The amount of update time which has elapsed is displayed during the update process.
Getting Started Operating from the main unit or main remote control unit Language This sets the language used on the display screens. F Menu tree F Source Select Connections Manual Setup Use this procedure to select the input source and make the settings related to playing input sources. Language [Selectable items] English Français Setup Operating from the main unit Playback Remote Control b The GUI menu is not displayed when performing this setting.
a Play d Preset Skip Source Select A~G Select the preset channel(s) you do not want to display. g Video a Play [Input source] h Input Mode s Auto Preset j Rename d Preset Skip HD Radio g Video 2 [Selectable items] All 1 [Selectable items] ON Skip 6 7 8 h Input Mode h Input Mode f Preset Name j Rename j Rename z : “Play” and “Playback Mode (iPod)” are displayed for input sources for which “iPod dock” is assigned.
Getting Started Aspect g Video Setting the video source. Video Select Connections Switch video input source while listening to audio signal. Setup Operating from the main unit [Selectable items] DVD HDP TV/CBL DVR-2 V.AUX SAT VCR DVR-1 SOURCE Make settings for resolution of HDMI video output signal. Playback Remote Control Multi-Zone • It is not possible to select HDMI input signals.
Press the INPUT MODE button on the main unit or the INPUT button on the main remote control unit. HDMI EXT. IN Digital SAT VCR DVR-1 DVR-2 V.AUX TV/CBL SAT VCR DVR-1 DVR-2 V.AUX [Selectable items] All One NOTE OFF This cannot be set for input sources for which “iPod dock” is assigned. Shuffle Digital Make settings for shuffle mode. Select digital input connector to assign to this source. [Input source] CD DVD HDP [Input source] TV/CBL SAT VCR DVR-1 DVR-2 CD V.
Getting Started Component Select component video input to assign to this source. [Input source] DVD HDP TV/CBL SAT VCR DVR-1 DVR-2 V.AUX Connections [Selectable items] 1 ~ 5 – RCA Input source Default setting DVD 1 – RCA HDP 2 – RCA TV/CBL 3 – RCA SAT 4 – RCA Setup Input source Default setting VCR None DVR-1 5 – RCA DVR-2 None V.AUX None 6 – BNC None Playback NOTE This cannot be set for input sources for which “iPod dock” is assigned. Make settings for still picture (JPEG) playback.
Dolby Digital Source Surround Mode THX surround mode to recreate authentic movie soundtracks. Surround Playback of 2-channel Sources PLgx CINEMA PLg CINEMA Pro Logic NEO:6 CINEMA HOME THX CINEMA : For details, see page 98. [Selectable items] DOLBY PLgx or DOLBY PLg DOLBY PLg DTS NEO:6 neural : The signals are decoded in DOLBY PLgx or DOLBY PLg for playback. Cinema : This mode is suited for movie sources. Music : This mode is suited for music sources. Game : This mode is suited for games.
Getting Started Playing Multi-channel Sources (Dolby Digital, DTS, etc.) [Selectable items] Connections STANDARD : This mode is for decoding the input signals according to their format and playing surround sound. The display when the STANDARD mode is selected depends on the input signal and surround back output playback mode.
Direct Playback This is the mode that recreates the original sound most faithfully, providing extremely high quality sound. [Selectable items] DIRECT : Adjust various audio parameters. F Menu tree F Parameter Audio DSD DIRECT (z) MULTI CH DIRECT M DIRECT + PLgx CINEMA M DIRECT + PLgx MUSIC M DIRECT 7.
Getting Started n In the THX mode (for 2-channel sources) [Selectable items] Surround Back ON Surround Back OFF THX Games Mode DRC Dimension Compress dynamic range (difference between loud and soft sounds). Shift sound image center to front or rear, to adjust playback balance. [Selectable items] Auto [Variable range] Low Middle High OFF n In the THX mode (for Multi-channel sources) Connections ES DSCRT ES MTRX 7.
Subwoofer Att. Front Auto-select surround mode by source. This function only works for software containing a special identification signal. If the software being played is recorded in Dolby Digital EX or DTS-ES, it is played in 6.1-channels. If not, it is played in 5.1-channels. Attenuate subwoofer level when using EXT. IN mode. Adjust each front channel tone. ON ON OFF [Variable range] Set this to “ON” if the subwoofer channel level seems too high when playing Super Audio CD.
Getting Started About the RESTORER function d Room EQ f Dynamic EQ Select room equalizer for current environment. Make Dynamic EQ settings. [Selectable items] Connections Audyssey [Selectable items] Audyssey Byp. L/R : Optimize frequency response of speakers except front L and R speakers. : Optimize frequency response of all speakers to flat response. Manual : Apply frequency response set with “Manual EQ” (vpage 35). Setup Audyssey Flat Playback OFF : Turn equalizer off.
s Brightness Compensate for mismatched timing between video and audio. Adjust picture brightness. Delay audio. This sets the delay time for audio signals. 0 ~ Information +12 Connections [Variable range] [Variable range] Getting Started j Audio Delay ~ 200 ms 0 ms d Chroma Level b The GUI menu is not displayed when carrying out this setting. [Variable range] –6 ~ ~ 0 Shows information about current settings. +6 F Menu tree F Information f Hue Status a MAIN ZONE Adjust color hue.
Getting Started Audio Input Signal HDMI Information Quick Select Shows information about audio input signals. Shows information about HDMI input/output signals and monitor. Shows information about quick select settings. F Menu tree F F Menu tree F F Menu tree F Connections Information Information Setup Playback Format Quick Select 1 s Monitor1 Surround Mode : The currently set surround mode is displayed.
SOURCE SELECT MASTER VOLUME Playback Turning the Power On To operate the AVR-5308CI using the main remote control unit, set the remote control unit to the AMP mode (vpage 76 “Remote Control Unit Operations”). MASTER VOLUME SOURCE SELECT NOTE Power continues to be supplied to some of the circuitry even when the power is in the standby mode. When leaving home for long periods of time or when traveling, either press to turn off the power, or unplug the power cord from the power outlet.
Getting Started Listening to FM/AM Broadcasts Presetting Radio Stations (Preset Memory) Basic Operation Your favorite broadcast stations can be preset so that you can tune them in easily. Up to 56 stations can be preset. Connections 1 Either turn or press [TUNER] (AMP mode) to select “TUNER”.
Operation on the Main Unit n Default settings Auto tuner presets B1 ~ B8 520 / 600 / 1000 / 1400 / 1500 / 1710 kHz, 90.1 / 90.1 MHz 90.1 MHz E1 ~ E8 90.1 MHz F1 ~ F8 90.1 MHz G1 ~ G8 90.1 MHz NOSTALGA JAZZ CLASSICL R&B SOFT R&B LANGUAGE REL MUSC REL TALK PERSNLTY PUBLIC COLLEGE WEATHER Nostalgia Jazz Classical R&B Soft R&B Language Religious music Religious talk Personality Public College Weather Traffic Program (TP) 3 4 Press [SEARCH] to select “RDS”.
Getting Started Connections Setup Playback uio p Remote Control Multi-Zone [ ( TU] mode) [ ( TU] mode) Information [d f] Troubleshooting [SAT TU] (AMP mode) [TUNER] (AMP mode) About the button names in these explanations < > : Buttons on the main unit [ ] : Buttons on the remote control unit Button name only: Buttons on the main unit and remote control unit 59 TP Search Use this function to find RDS stations broadcasting a designated program type (PTY).
About XM Radio 3 Use [d f] to select the channel. (vpage 76 “Remote Control Unit Operations”) When the channel is tuned in, the name of the song and artist are displayed. • The channel switches continuously when [d f] is pressed and held. • XM Radio channels can be preset using the same procedure as for FM/AM stations (vpage 57, 58 “Presetting Radio Stations (Preset Memory)” and “Listening to Preset Stations”).
Listening to HD Radio™ Stations Getting Started Searching Categories 1 HD Radio stations offer higher sound quality than conventional FM/AM broadcasts. It is also possible to receive data services and select broadcasts from among up to eight multicast programs. Press o p. Connections Channel category 2 Use o p to select the category, then use ui to select the desired channel.
1 Either turn or press [DTU] (AMP mode) to select “HD Radio”. : “Source Select” (vpage 43, 44) Press [BAND] to select “FM” or “AM”. If the station you are listening to has multiple audio programs, “HD1” is indicated on the display. If it only has one audio program, “HD” is indicated. B1 ~ B8 C1 ~ C8 D1 ~ D8 E1 ~ E8 F1 ~ F8 G1 ~ G8 87.5 / 87.9 / 89.1 / 93.3 / 97.9 / 98.1 / 98.9 /100.1 MHz 101.9 / 102.7 / 107.9 / 90.1 / 90.1 / 90.1 / 90.1 / 90.
Getting Started iPod® Playback The music on an iPod can be played by using the Control Dock for iPod (ASD-1R, sold separately). The operation can also be performed using the buttons on the main unit or remote control unit while watching the GUI menus. Connections iPod is a trademark of Apple Inc., registered in the U.S. and other countries.
During playback, either press and hold ENTER or press [2]. Playing repeatedly Press [CHANNEL –] or [REPEAT] on the sub remote control unit. [Selectable items] All One OFF GSlide show functionH : ”Source Select” – “(input source)” – ”Playback Mode (iPod)” – “Repeat” (vpage 46) OFF : ”Source Select” – “(input source)” – ”Playback Mode (iPod)” – “Shuffle” (vpage 46) To switch between the Browse and Remote modes Either press and hold [SEARCH]. 1 2 3 Press and hold [SEARCH] to set the Remote mode.
Getting Started [Compatible formats] Connections Setup WMA (Windows Media Audio) MP3 (MPEG-1 Audio Layer-3) WAV MPEG-4 AAC FLAC (Free Lossless Audio Codec) JPEG Internet radio Music serverb S S Sz S S S – – S Sz S Sz – S S – S S USBb Playback A server or server software compatible with distribution in the corresponding formats is required to play music files via a network. Remote Control z: Only files that are not protected by copyright can be played on the AVR-5308CI.
During playback, press ENTER. Press again to resume playback. To stop During the play or pause mode, press and hold ENTER. Press [SEARCH], then press o (down) or p (up). To cancel, press ui or [SEARCH]. n Recently Played Internet Radio Stations Use or 1 2 Use ui to select “Internet Radio”, then press ENTER or p. 3 Use ui to select the station, then press ENTER or p. Use ui to select the item you want to play, then press ENTER or p. The station list is displayed.
Getting Started Playing Files Stored on a Computer Use this procedure to play music files, image files or playlists. Connections 1 2 Setup 3 4 Playback uio p ENTER Remote Control [ Use ui to select the host name of the computer on which the music file you want to play is located, then press ENTER or p. Use ui to select the search item or folder, then press ENTER or p. Use ui to select the file, then press ENTER or p. Playback starts once buffering reaches “100%”.
Use ui to select “Rhapsody”, then press ENTER or p. Use ui to select “I have a Rhapsody account” or “Start 30-day free trial”, then press ENTER or p. [Input characters] a~z A~Z 0~9 n Password : [Input characters] 1 2 Use ui to select “Search”, then press ENTER or p. Use ui to select the search item, then press ENTER or p. The search display appears. b You can search by artist name, album name or track name. 3 Enter the characters, then press ENTER.
Getting Started Search From the Rhapsody Internet Radio Station Connections 1 2 Use ui to select “Rhapsody Channels”, then press ENTER or p. Use ui to select radio station, then press ENTER or p. Registering Tracks in My Library 1 2 ENTERui Setup Press p while the track you wish to register is playing. Playback uio p ENTER Use Operating the AVR-5308CI Browser (Web control) Using a This function lets you operate the AVR-5308CI using Internet Explorer.
After entering characters, click “Set” to set, or click “Def” to return to initial setting. Click to change zone name. (vExample 3) Enter figures or click “<” or “>” to make the setting, and then click “Set”. Operate. [Example 1] Main zone control screen Click to add a setting to the “Favorites” in your browser. (*3) Click “SAVE” when you want to save settings, and click “LOAD” when you want to call settings. Becomes each operation screen.
Getting Started Surround mode INPUT MODE Other Operations and Functions Connections Other Operations Setup Playing Super Audio CD Playback 1 2 SELECT] Remote Control The “ AMP] Multi-Zone Surround mode Information INPUT MODE Troubleshooting SOURCE SELECT About the button names in these explanations < > : Buttons on the main unit [ ] : Buttons on the remote control unit Button name only: Buttons on the main unit and remote control unit 71
When REC OUT mode is set to “SOURCE”, with the AVR-5308CI it is possible to output signals encoded in the Dolby Headphone mode from the recording output terminal and record them on a separate recorder. 1 The Dolby Headphone play mode is set when headphones are connected to during playback in the STANDARD (DOLBY/DTS Surround) mode.
Getting Started Convenient Functions Operations HDMI Control Function Connections When connecting the AVR-5308CI to a television or player compatible with the HDMI control function, the following operations are possible. • Turn power ON/OFF (Synchronize with television) • Switch to sound output equipment (TV and AVR-5308CI) • Adjust volume • Switch input source Setup When using these functions set as follows: GUI menu “Manual Setup” – “HDMI Setup” – “HDMI Control” (vpage 33).
Quick Select Function You can adjust the channel level either according to the playback sources or to suit your taste, as described below. With this function, the currently playing input source, input mode, surround mode, room EQ settings and volume can be stored in the memory. 3 Use o p to adjust the volume. Use ui or CH SELECT to select the speaker. The speaker that can be set switches each time one of the buttons is pressed.
Getting Started Connections Personal Memory Plus Function Resetting the Microprocessor This function sets the settings (input mode, surround mode, HDMI output mode, Picture Adjust, Audio Delay etc.) last selected for the individual input sources. When you switch to an input source, the settings are automatically set to the ones that were set the last time that input source was used. Perform this procedure if the display is abnormal or if operations cannot be performed.
Remote Control Unit Operations 1 : AMP / ZONE2 / ZONE3 / ZONE4 / SYSTEM CALL : iPod : TUNER (FM/AM) / XM : DVD player (recorder) / CD player (recorder) : NETWORK/USB / DIGITAL TUNER (HD Radio) : VCR / TAPE : Satellite Receiver / Cable TV : TV 1 2 3 GAMP modeH GZONE2 modeH GZONE3 modeH Press [NUMBER] and input the 5-digit number of the brand of the component to be preset. The numbers are shown in the Preset Code Table (vEnd of this manual).
Getting Started Functions of Buttons by Component EL Display EL Display Connections [MODE SELECTOR] Setup Playback [MENU] Remote Control [SETUP/ SEARCH] [CH + / SHUFFLE], [CH – / REPEAT] Multi-Zone Buttons MODE SELECTOR [1], [8 9], [6 7], [3], [2], [SOURCE ON], [SOURCE OFF] [ENTER] [uiop] [RETURN] DVD VCR iPod Device Mode Device operated 1 8 9 6 7 DVD (Default setting) Playback Auto search (cue) Manual search (fast-reverse/ fast-forward) CD Recorder VCR TAPE iPod Playback Auto search (c
[MODE SELECTOR] [0 ~ 9, +10] [TV/VCR] SAT Punch through Punch through Punch through Punch through Power on Power off Power on Power off Power on Power off MENU u i o p ENTER SETUP DISPLAY CH + / – 0 ~ 9, +10 TV/VCR Special Remarks Menu/guide Cursor Enter setting Set up Display Switch channels Channel selection Switch inputs q, e Power on Power off Buttons Menu/guide Cursor Enter setting Set up Display Switch channels Channel selection Switch inputs q, e Menu/guide Cursor Enter setting Set up Di
Getting Started Signal transmission indicator Connections [ [ AMP] [ TU] NET/DTU] [MODE SELECTOR] [SYSTEM CALL] Setup [POWER ON] Setting the Remote ID Learning Function When using multiple DENON AV receivers in the same room, make this setting so that only the desired AV receiver operates.
Registering The signal transmission indicator flashes twice. Press [9], [7] and [8], in that order. The signal transmission indicator flashes twice and the system call registration mode is set. 6 Press and hold in [RC SETUP] for at least 3 seconds. The signal transmission indicator flashes twice and the setting is completed. 1 2 3 Press [MODE SELECTOR] for the device you want to punch through (CD, DVD or VCR). 4 5 6 7 Press [MODE SELECTOR] for the device you want to punch through (CD, DVD or VCR).
Getting Started Adjusting the Backlight’s Brightness Signal transmission indicator [ AMP] The display’s brightness can be adjusted in 5 steps. (Default: Step 3) Connections [MODE SELECTOR] [SYSTEM CALL] Setup Playback 3 Press [RC SETUP] to complete the setting. The signal transmission indicator flashes twice. Press [CHANNEL +] or [CHANNEL –]. The display gets one step brighter when [+] is pressed. The display gets one step darker when [–] is pressed.
– – – – Tuning – Tuning – b3 – b3 – b3 – b4 – b4 – b4 – b5 – b5 – b5 – b1: Affects the currently selected zone. b2: In ZONE4, it is not possible to select “XM”, “HD Radio”, or sources with no digital input signals (“TUNER”, “PHONO”, “iPod”, etc.). Network audio signals (Internet radio, music server, USB) can be played as long as they are not copyright-protected. b3: The input source switches to “NET/USB” and the files on the USB memory device are played.
Getting Started Device operated [ZONE OFF] [ZONE SELECT] [ZONE ON] Connections [SOURCE SELECT] Zone selection ZONE SELECT ZONE OFF ZONE ON SOURCE SELECT CHANNEL + / – SHIFT Setup Playback Remote Control [CHANNEL +/–] [MUTE] [MENU] [uiop] [SEARCH] [REPEAT] Multi-Zone [RANDOM] [VOLUME +/–] [SHIFT] [ENTER] [RETURN] [8 9], [2], [1/3], [TUNING d f] [ALL MUSIC], [FAVORITES] [USB] VOLUME + / – MUTE MENU u i o p ENTER SAT TU (XM) M Z2 Z3 Z4 Zone operation mode selection Power turned off (b1) Power turn
We recommend always using the sub remote control unit for the same room. When this is done, the unit can be set so that the zone does not switch when buttons are operated. The selected multi-zone indicator lights. While the multi-zone indicator is light, press [ZONE to select the zone to be operated. The currently selected multi-zone indicator lights. While pressing [MENU], press [ADVANCED SETUP] with the tip of a pen. Use the tip of a pen to press [ADVANCED SETUP].
Getting Started Setting 1: With this setting it is possible to switch between the following two playback modes. Amp Assign / Multi Zone Connections and Operations Connections Setup The AVR-5308CI is compatible with the following types of playback: • Multi-zone playback (ZONE2 & ZONE3) • Bi-amp playback (front speaker) • Bi-wiring playback (front speaker) NOTE Playback • For bi-amp and bi-wiring playback, use speakers compatible with that type of connection.
MAIN ZONE FL SW C 3.1ch + “OFF” ZONE3 Z3L Z3R Stereo Stereo Z2 Z3 Mono Mono FL SW ZONE2/3 (MONO) SL A C 7.1ch FL/FR Bi-Amp B MAIN ZONE Amp Assign mode: SR A B FL C SURR. BACK R R L SURR-B / AMP ASSIGN L SR-A SL-A SBR SBL AMP ASSIGN-2 L R L Z3R Z3L Z2R Z2L Z3 (MONO) Z2 (MONO) ZONE2/3 (MONO) ZONE2/3 ZONE2/3 (MONO) Status ZONE2 & ZONE3 ON OFF FRONT SURR-A CENTER R FR FR L FL FL R C C – L – SURR.
Getting Started Setting 5: With this setting it is possible to switch between the following two playback modes. Connections F 7.1-channel playback F Multi-zone playback • 5.1-channel playback + ZONE2 or ZONE3 stereo playback with bi-wiring connections • 5.1-channel playback + ZONE2 monaural playback + ZONE3 monaural playback with bi-wiring connections Switching················· ZONE2 ON/OFF button, ZONE3 ON/OFF button MAIN ZONE FL SW Setup Playback SL-A C FL SW FR 7.
F 9.1-channel Setting 8: playback F Free MAIN ZONE FL SW C Speaker terminal 9.
Getting Started Multi-Zone Settings and Operations • For ZONE2, it is necessary to set in sequence with the signal connected to either the power amplifier or bit stream amps. The amp should be the power amplifier in the case of ZONE3, and the bit-stream for ZONE4. • If the signal inputted to ZONE2 is analog, change to PCM(2-channel) signal, and output it from ZONE2 optical output connectors.
Multi-Zone Operations Turning the Power On and Off Press , or for the zone to be operated. When the power turns on, the multi-zone indicator lights on the display. GOperation on the remote control unitH Selecting the Input Source AMP] [Z2 ON] [ON] [OFF] [OFF] VOLUME [MUTE] [MENU] In the zone mode you want to operate, press [SOURCE SELECT].
Getting Started Change of positioning and acoustic image with 6.1-channel systems '- Other Information Connections About Speaker Installation 48 $ 4- DI '3 43 DI Surround back speakers Setup Playback Remote Control The THX Surround EX format adds new “Surround Back” (SB) channels to the conventional 5.1 channel system.
Front speakers Center speaker The AVR-5308CI is equipped with a digital signal processing circuit that lets you play program sources in the surround mode to achieve the same sense of presence as in a movie theater.
Getting Started Dolby Pro Logic g Connections Dolby Pro Logic g is a matrix decoding technology developed by Dolby Laboratories. Regular music such as that on CDs is encoded into 5-channels to achieve an excellent surround effect. The surround channel signals are converted into stereo and full band signals (with a frequency response of 20 Hz to 20 kHz or greater) to create a “three-dimensional” sound image offering a rich sense of presence for all stereo sources.
The human ear changes our perception of a sound depending on the direction from which the sound is coming. In a movie theater, there is an array of surround speakers so that the surround information is all around you. In a home theater, only two speakers located to the side of your head are used. The Timbre Matching feature filters the information going to the surround speakers so that they more closely match the tonal characteristics of the sound coming from the front speakers.
Getting Started THX and Ultra2 are trademarks of THX Ltd. THX may be registered in some jurisdictions. All rights reserved. Surround EX is a trademark of Dolby Laboratories. Used with permission. Connections Neural Surround Setup Playback Remote Control Multi-Zone Neural Surround™, a breakthrough in audio technology, will bring the excitement of surround music to more of America’s listening audience.
Deep Color Signals and adjustability in the different modes Channel output Surround Mode Parameter (default values are shown in parentheses) Cinema EQ.
Getting Started Signals and adjustability in the different modes Parameter (default values are shown in parentheses) Surround Mode PRO LOGIC g/gx MUSIC mode only Mode Decoder Room Size Effect Level Delay Time Subwoofer Dimension EXT. IN only Center Image Subwoofer Att.
Input signals Button Surround mode Note ANALOG DTS DTS ES DSCRT (With Flag) DTS ES MTRX (With Flag) DOLBY DTS (5.1ch) DOLBY DIGITAL DTS 96/24 DOLBY TrueHD DOLBY DIGITAL Plus DVD-AUDIO DOLBY DOLBY DOLBY DOLBY DIGITAL DIGITAL DIGITAL DIGITAL EX (With EX (With (5.
Input signals Getting Started Button Surround mode Note ANALOG Connections DTS-HD WMA (Windows LINEAR Media Audio) DTS-HD DTS-HD PCM / High / MP3 / Master WAV Resolution MPEG-4 Audio Audio AAC / FLAC DTS DOLBY DTS ES DSCRT (With Flag) DTS ES MTRX (With Flag) DTS (5.1ch) DTS 96/24 DOLBY TrueHD DOLBY DIGITAL DOLBY DIGITAL Plus DVD-AUDIO DOLBY DOLBY DOLBY DOLBY DIGITAL DIGITAL DIGITAL DIGITAL EX (With EX (With (5.
Surround mode Note ANALOG DTS DOLBY DOLBY DIGITAL DTS ES DSCRT (With Flag) DTS ES MTRX (With Flag) DTS (5.1ch) DTS 96/24 DOLBY TrueHD DOLBY DIGITAL Plus DVD-AUDIO DOLBY DOLBY DOLBY DOLBY DIGITAL DIGITAL DIGITAL DIGITAL EX (With EX (With (5.
Getting Started About Networks Windows Media Player Ver.11 Connections This is a media player distributed free of charge by Microsoft Corporation. It can be used to play playlists created with Windows Media Player Ver. 11 as well as files in such formats as WMA, DRM WMA, MP3 and WAV. Setup Playback vTuner Remote Control This is a free online contents server for Internet radio. Note that usage fees are included in upgrade costs. For inquiries about this service, visit the vTuner site below.
Getting Started WPA (Wi-Fi Protected Access) This is a security standard established by the Wi-Fi Alliance. In addition to the conventional SSID (network name) and WEP key (network key), it also uses a user identification function and encrypting protocol for stronger security. Connections WPA2 (Wi-Fi Protected Access 2) This is a new version of the WPA established by the Wi-Fi Alliance, compatible with more secure AES encryption.
Getting Started Relationship Between Video Signals and Monitor Output n MAIN ZONE Video Convert Connections Setup Playback Remote Control ON With HDMI monitor Multi-Zone Information Troubleshooting Without HDMI monitor or with HDMI monitor off HDMI A A A A A A A A A A A A A A A A S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S S Input signal COMPONENT S-VIDEO A A A A A S A S S (1080p) A S (480p ~ 720p) A S (480i/576i) A S (1080p) A S (480p ~ 720p) A S (480i/576i) A S (1080p) S S (480p
Monitor output (when GUI menu displayed) COMPONENT S-VIDEO VIDEO HDMI COMPONENT S-VIDEO VIDEO HDMI COMPONENT S-VIDEO VIDEO A A A A A A A A S S S S A A A S A A A S (VIDEO) S S S S A A S A A A S (S-VIDEO) A S S S S A A S S A A S (S-VIDEO) S (VIDEO) S S S S A S A A A S (COMPONENT) A A S S S S A S A S A S (COMPONENT) A S (VIDEO) S S S S A S S A A S (COMPONENT) S (S-VIDEO) A S S S S A S S S A S (COMPONENT) S (S-
Getting Started Relationship Between Amp Assign Setting and Speaker Output STEREO or DIRECT (2ch) Mode Connections Setting 2CH Bi-Wiring Setup 2CH Bi-Amp Status Surround mode SURROUND A STEREO/DIRECT Other STEREO/DIRECT Other – SLA/SRA – SLA/SRA Speaker terminal SURROUND B/ SURROUND BACK ASSIGN – FL/FR SBL/SBR – – FL/FR SBL/SBR – ASSIGN-2 FL/FR – FL/FR – Playback Multi-Zone Power On/Off Remote Control Status Setting ZONE2 ZONE2 ON OFF Multi-Zone ZONE3 Information ZONE (MONO) Troublesho
Troubleshooting Page 24 11 – GRemote Control UnitH 10 56 • Insert the batteries in the proper direction, following the polarity marks in the battery compartment. • Move the set to a place in which the remote control sensor will not be exposed to strong light. 3, 4 • Set the same remote IDs for the main unit and remote control unit. 41, 79 4 4 42 50 – 106 Troubleshooting 45 Page 3 4 Information 56 56 46 Countermeasure • Replace with new batteries. • Operate within the specified range.
Getting Started GAudioH Symptom No sound is produced from center speaker. Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting Cause • You are playing a monaural source (TV, AM radio broadcast, etc.) in the “STANDARD” (Dolby/ DTS Surround) or “HOME THX CINEMA” mode. No sound • The surround mode is set to is produced “STEREO”, “DIRECT” or “PURE from surround DIRECT”. speakers. • The surround speaker’s power amplifier is assigned to a different channel.
Symptom iPod cannot be played. Cause Countermeasure 43, 47 GNET/USB/RhapsodyH 47 – – – – 64, 65 64, 65 – 64, 65 – – – – 38 – – – Troubleshooting The file names are not displayed properly (“...”, etc.). • Files are stored in a noncompatible format. • You are attempting to play a file that is copyright protected. • Characters that cannot be displayed are used. – 38 64, 65 Information • USB memory device is divided into multiple partitions.
Getting Started Connections Setup Playback Remote Control Symptom Cannot login to Rhapsody. (“Username or Password is incorrect” is displayed) Cause • Login information is incorrect. Cannnot play. • When the trial period has finished, • Get a full account. there is a limit to the playing time www.rhapsody.com/denon/signup and number of tracks that can be played. • When the trial period has finished, • Get a full account. there is a limit to the playing time and number of tracks that can be played.
Page – – – n Audio section • Power amplifier Front: Rated output: 150 W + 150 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.) 170 W + 170 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) Center: 150 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.) 170 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.) Surround (A + B): 150 W + 150 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.) 170 W + 170 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.
Getting Started n Video section Connections Setup • Standard video connectors Input / output level and impedance: Frequency response: • S-Video connectors Input / output level and impedance: Frequency response: • Color component video connector Input / output level and impedance: Frequency response: n Tuner section Playback Remote Control Receiving Range: Usable Sensitivity: 50 dB Quieting Sensitivity: S/N (IHF-A): Total harmonic Distortion (at
List of preset codes Denon Amp D Denon 81001, 82001, 83001, 84001 G Denon Tuner D Denon (Analog) Denon (XM Radio) 52863, 52795, 52800, 52805 52864, 52812, 52813, 52814 Denon Digital Tuner D Denon (NET) Denon (HD Radio) 62865, 62837, 62838, 62839 62840, 62841, 62842, 62843 I J Denon iPod D Denon 72815, 72816, 72817, 72818 Cable A B C D E F A-Mark ABC Accuphase Acorn Action Active ADB Aichi Denshi Americast Amstrad Archer Auna Austar BCC Bell South Bestlink Birmingham Cable Communications B
U V W Teac Technics Techwood Thomson Thorens Thule Audio Tokai Universum Victor Wadia Wards Y Yamaha Yorx 40490, 40393, 40420 40029, 40303 40303 40053 40157 40157 40420 40157, 40053 40072 40393 40000, 40032, 40157, 40053, 40087, 40179 40490, 40868, 40032, 40036 40000 CD Recorder D J R S T Denon JVC RCA Sony Teac Thomson C D F G H I J K L M O 2 Aiwa Akai Arcam Audiolab Carver Denon Fisher Garrard Genexxa GoldStar Grundig Harman/Kardon Inkel JVC Kenwood LG Luxman Magnavox Marantz Memorex Mitsubishi
F G H Eurocrypt EuroLine Europa Europhon Eurosky Eurostar Eutelsat Expressvu Fenner Ferguson Finlandia Finlux Flair Mate FMD Force Fortec Star 00455 01251 00863 00299 00262, 00299 00818 00713 00775, 01775 00713 00455, 01291, 01743 00455 00455 00713 01251, 01413, 01457 01101 01083 00455, 00497, 00795, 00879, Foxtel 01162, 01176, 01356 Fracapro Planet 00871 Fracarro 00125, 00871 France Telecom 00871 Freesat 00882 FTE 00863 FTEmaximal 00713, 00863 00173, 00262, 00299, 00394, Fuba 01214, 01251, 01801 Fugion
Satstation Schaub Lorenz Schneider 01083 01214 00710, 01206, 01251 00394, 00504, 00863, 01075, Schwaiger 01083, 01111, 01317, 01334, 01412, 01457 SCS 00299 Sedea Electronique 00125, 01206, 01283, 01626 SEG 01075, 01087, 01251, 01626 Seleco 00871 Septimo 01375 Serd 01412 Serino 00610 Servimat 01611 ServiSat 00713, 01251 Sharp 01517 Siemens 00173, 01334, 01429 Silva 00299 Skantin 00713 SKR 00713 00856, 00099, 00847, 00887, SKY 01014, 01175, 01662, 01693, 01847, 01848, 01850 SKY Italia 00853, 01693, 01847, 01
Akashi Akiba Akira Akito Akura Alaron Alba Albatron Alfide All-Tel Alleron Allorgan Allstar Ambassador America Action American High Amplivision Amstrad Amtron Anam Anam National Andersson Anglo Anhua Anitech Ansonic AOC Aolinpike Apex Digital AR Arc En Ciel Arcam Ardem Aristocrat Aristona ART Arthur Martin ASA Asberg Asora Astra Asuka ATD Atlantic 10009, 10860 10037, 10218, 10455 10418 10037 10171, 10009, 10037, 10163, 10218, 10264, 10668, 10714, 11037, 11498, 11556, 11982 10170 10009, 10036, 10037, 10073,
E F 6 Easy Living Eaton Ecco ECE Edison-Minerva 11248 10060 10773 10037 10487 10037, 10217, 10218, 10362, Elbe 10610 Elcit 10163 Electroband 10000 Electrograph 11755 10154, 10000, 10463, 10150, Electrohome 10178, 10030, 10073 Elekta 10009, 10264 Elfunk 11037, 11208 ELG 10037 Elin 10009, 10037, 10361, 10548 Elite 10037, 10218 Elta 10009, 10264 Emerald 10178 10047, 10017, 10154, 10451, 10236, 10463, 10180, 10150, 10178, 10171, 11944, 11911, Emerson 11909, 10714, 10668, 10623, 10486, 10036, 10371, 10370, 1
JVC K Kaige Kaisui Kambrook Kamp Kangli Kangyi Kapsch Karcher Kathrein Kawa Kawasho KB Aristocrat KDS KEC Kendo Kennedy Kennex Kenwood Khind KIC Kiota Kioto Kiton KLH KLL Kloss Kneissel Kolin Kolster Kongque Konichi Konig Konka Kontakt Korpel Korting Kosmos Koyoda Kreisen KTV Kuaile Kulun Kunlun 10054, 10093, 10463, 10053, 10030, 10070, 10036, 10218, 10371, 10418, 10508, 10606, 10650, 10653, 10683, 10731, 11253, 11923 10009, 10264, 10817 10009, 10037, 10217, 10218, 10455 10217 10017, 10180, 10217 10001,
Panasonic Panavision Panda Pathe Cinema Pathe Marconi Pausa Paxonic PCE Penney Perdio Perfekt Petters Philco Philharmonic Philips Phocus Phoenix Phonola Pilot Pioneer Pionier Plantron Playsonic Polaroid Poppy Portland Powerpoint Prandoni-Prince Precision Premier President Prima Princeton Prinston Prinz Prism 8 10054, 10000, 10156, 10250, 10051, 10236, 10030, 11947, 11946, 11941, 11480, 11310, 11291, 11271, 10853, 10650, 10548, 10508, 10367, 10361, 10226, 10208, 10163, 10108, 10037, 10035 10037 10051, 1
Strong Studio Experience Stylandia Sunkai Sunstar Sunwatt Sunwood Superla Superscan Supersonic SuperTech Supra Supreme Susumu Sutron SV2000 SVA Svasa Swisstec Sydney Sylvania Symphonic Synco T Syntax Sysline T+A Tacico Tai Yi Taishan Tandberg Tandy Targa Tashiko Tatung TCL TCM Teac Tec Tech Line Techica Technica 11149, 11163 10843 10217 10218, 10455, 10487, 10610, 10865 10009, 10037, 10264, 10371 10455 10037 10217 10093, 10864, 11944 10009, 10208, 10455, 10805 10009, 10037, 10218, 10556 10178, 10009, 103
E F G H J K L M N P R S T U V Elfunk Ferguson Finlux Goodmans Hitachi JDV Jensen KLH Lenco Logik Luker Luxor Matsui Maxim Medion Mirror Naiko Narita Panasonic Philips Powerpoint Prima RCA Roadstar Saivod Samsung Schneider SEG Sova Stevison Sylvania Teac Technica Telefunken Thomson Transonic United Vestel 11037 11037 11556 10587, 11037, 11900 11960 11982 11933 11962 10587 11037 11982 11037 11037 11982 11900 11900 11982 11982 11941 11454, 10556, 11961 10698 11933 11948, 11958 11900 11982 11903 11982 11
S T Sharp Sylvania Symphonic Toshiba 11917 11944 11944 11945 b3 S Sharp 20807 Akai Emerson ESA Magnavox Panasonic RCA Sharp Superscan Sylvania Symphonic Toshiba 30899 30821 30821 30821 31362, 31462 31132 30630 30821 30821 30821 31045 b4 A E M P R S T B VCR A A-Mark ABS Admiral Adventura Aiko Aim Aiwa Akai Akura Alba Alienware Allegro Allorgan Allstar America Action American High Amoisonic Amstrad Anam Anam National Ansonic Aristona ASA Asha Astra Asuka 20037, 20240, 20000, 20278, 20046 21972
Luxor M LXI M Electronic Magnadyne Magnasonic Magnavox Magnin Magnum Manesth Marantz Mark Marta Mastec Master’s Matsui Matsushita Media Center PC Mediator Medion MEI Memorex Metronic Metz MGA MGN Technology Micormay Micromaxx Microsoft Midland Migros Mind Minolta Mitsubishi N 12 Motorola MTC MTX Multitec Multitech Murphy Myryad NAD Naiko NAP National 20048, 20047, 20104, 20043, 20046, 20106, 20315 20037, 20000, 20042, 20067 20037, 20240, 20000, 20038 20081 20037, 20240, 20000, 20278, 21278 20035, 2003
TNIX Tocom Tokai Topline Toshiba U Tosonic Totevision Touch Toyoda Tradex Triad Trix Uher Ultra Ultravox Unitech United Universum V W X Y Z Vector Vector Research Victor Video Concepts Video Technic Videomagic Videosonic Viewsonic Villain Voodoo Wards Watson Weltblick Wharfedale White Westinghouse World XR-1000 Yamaha Yamishi Yoko Zenith ZT Group ZX 20037 20240 20037, 20104, 20041 20348 20081, 20240, 20045, 20000, 20042, 20067, 20043, 20209, 20041, 20352, 20432, 20742, 20845, 21008, 21145, 21972, 219
F Entivo Enzer ESA EuroLine Fenner Ferguson Finlux Firstline G Fisher Funai Fusion Gateway GE General Electric Germatic Global Link Global Solutions Global Sphere Go Video GoldStar Goodmans GP Audio GPX Gradiente Graetz Gran Prix Grandin Greenhill Grundig Grunkel H H&B Haaz Haier Hanseatic Harman/Kardon HCM HDT HE Henss HiMAX Hitachi Hiteker Hoeher 14 30503, 30539 30784, 30770, 31228 30821, 31268 30675, 30788, 31115, 31233 30651 30651, 30695, 30713, 30884, 30898, 31695, 31730 30672, 30591, 30741, 307
Salora Sampo Samsung Sansui Sanyo Scan ScanMagic ScanSonic Schaub Lorenz Schneider Schwaiger Scientific Labs Scott Seeltech SEG Sensory Science Shanghai Sharp Sharper Image Sherwood Shinco Shinsonic Siemssen Sigmatek Siltex Silva Silva Schneider SilverCrest Simaudio Singer Sistemas Skantic Skymaster Skyworth Sliding Slim Art SM Electronic Smart Sonai Sonashi Sonic Blue Sony Sound Color Soundmaster 30741 30752, 31321, 31347 30490, 30573, 30744, 30199, 30820, 30899, 31044, 31075, 31635, 31932 30784, 30695, 3
DVD preset codes / Codes préréglés DVD e Model No. / Modéle numéro 32134 (default / défaut) DVD-555 DVD-755 DVD-900 DVD-910 DVD-955 DVD-1000 DVD-1200 DVD-1500 DVD-1710 DVD-1910 DVD-1930CI DVD-2200 DVD-2800 DVD-2800g DVD-2900 DVD-2910 DVD-2930CI DVD-3800 DVD-3910 DVD-3930CI DVD-5900 DVD-5910 DVD-9000 DVM-715 DVM-1800 DVM-1805 DVM-1815 DVM-2815 DVM-4800 30490 DVD-800 DVD-1600 DVD-2000 DVD-2500 DVD-3000 DVD-3300 [ ]z: Preset codes set upon shipment from the factory.
www.denon.com Denon Brand Company, D&M Holdings Inc.
