Specification

L
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue models, both without notice or obligation.
Dimensions are for reference only. See current full-line price book or www.specselect.com for finish options and product availability.
MultiChoice
®
Universal Rough Valve
Body For Push Button Diverter
DSP–R10300-HDFRev.A Page2.C.27
n R10300-UNWS
STANDARD SPECIFICATIONS:
•Forgedbrassbody.
•Back-to-Backinstallationcapabilities.
•Canbetestedwithair(200PSI)orwater(300PSI)
without valve using supplied test cap.
•Squareplasterguardallowsforrightanglecuts.
•ForusewithMultiChoice
®
Universalsingleor
dual function trim with push button diverter.
Cartridgeshipswithtrim.
COMPLIES WITH:
• ASMEA112.18.1/CSAB125.1
R10300-UNWS
4"
(102 mm)
5.04"
(128 mm)
4"
(102 mm)
Finished Wall
Stringer
2.13"
(54 mm)
2.73"
70 mm)
1.85"
(47 mm)
5.55"
(141 mm)
5.2"
(132 mm)
R10300-UNWS
Submitted Model No.: __________________________________________________
Specific Features: _____________________________________________________
