Specification
Foundations
®
Toilet
C01913
▲
Technical Information
Fixture conguration Two-piece, round bowl
Water per ush 1.28 gpf (4.8 lpf)
Passageway 2" (51mm)
Water area 8 31/32" X 6 21/32"
(228 mm x169 mm)
Water depth from rim 7 7/32" (183 mm)
Seat post hole centers 5 1/2" (140 mm)
Included Components:
Bowl C21913
▲
Tank Assembly
C11913
▲
Tank Cover RP82448
▲
Trip Lever RP82450
▲
Mounting Hardware – Tank to
bowl
RP82451
STANDARD SPECIFICATIONS:
• Vitreous China
• 27 1/16" (687 mm) in length, 17 1/2" (445 mm) in
width, 30 13/16" (783 mm) in height.
• Round front bowl with chair height design 16 1/2"
(419 mm) to top of the bowl.
•12" (305 mm) rough-in.
• High ef iciency 1.28 gpf (4.8 lpf).
• 3" ( 76 mm) lush valve.
• 2" (51mm) ully glazed trapway.
• Includes polished chrome trip lever.
WARRANTY
• Chinaware parts warranted to original consumer purchaser
for as long as the original consumer purchaser owns the
home in which the toilet was first installed.
• 1 year warranty on mechanical components, ill valve,
lush valve, lush lever handle, and mounting bolts will apply.
• The toilet seat & lid will have a 1 year warranty.
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, Ontario Canada N5P 4L1
© 2016 Masco Corporation of Indiana
USA / Canada: 1-855-345-1345
www.deltatoilet.com
DSP-S-C01913 Rev. A
Installation Notes
• Install this product according to the installation guide.
• This model complies with the American Disabilities Act (ADA) when installed per
the requirements of the Accessibility Guidelines, Section 604 Water Closets, of
the Act, which includes the installation of an open front seat (not included).
• This model complies with CSA B651 when installed per Clause 4.3.6 of the
standard.
C01913
▲
▲
Designate proper nish sufx (-WH for white)
COMPLIES WITH
• ADA / ANSI A117.1
• ASME A112.19.2 / CSA B45.1
• ASME A112.19.5
• EPA WaterSense
®
High Ef iciency Toilet
• CalGreen
RECOMMENDED ACCESSORIES:
• RP71196
▲
Toilet seat
• 800902
▲
Toilet seat
• 801902
▲
Toilet seat
• RP71146 Wax ring / bowl-to-floor mounting hardware
