Specification

ManualsBrandsDelta ManualsBathFoundations 4 in. Centerset 2-Handle Bathroom Faucet in Polished Chrome (2-Pack)

Submitted Model No.:

Specific Features:

Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue models, both

without notice or obligation. Dimensions are for reference only. See current full-line price book or www.deltafaucet.com for

finish options and product availability.

Delta Faucet Company

55 E. 111th Street, Indianapolis, IN 46280

350 South Edgeware Road, St. Thomas, ON N5P 4L1

DSP-L-B2511LF-PPU Rev. F

BATHROOM FAUCET

■ Foundations

Collection

■ Two Handle Centerset Deck Mount

STANDARD SPECIFICATIONS:

• Maximum 1.5 gpm @ 60 psi, 5.7 L/min @ 414 kPa

• Max flow rate (ECO models only): 1.2 gpm @ 60 psi,

4.5 L/min @ 414 kPa

• Three hole mount

• Solid brass end valves and spout body

• Hot and cold stems are interchangeable

• 1/4 turn handle stops

• Control mechanism is a rotating cylinder type with

stainless steel plate and 90° rotation, with replaceable

non-metallic seats

• Models have drain with pop-up type fitting with plated

flange and stopper

• RP76691 thick deck mounting kit adds 1 1/4" (25 mm)

to maximum deck thickness

WARRANTY:

• Parts and Finish - Lifetime limited warranty; or for

commercial purchasers, 10 years for multi-family

residential (apartments and condominiums) and 5 years

for all other commercial uses, in each case from the

date of purchase.

• Electronic Parts and Batteries (if applicable) -

5 years from the date of purchase; or for commercial

purchasers, 1 year from the date of purchase.

No warranty is provided on batteries.

Certified by

CSA Group

COMPLIES WITH:

• ASME A112.18.1 / CSA B125.1

• ASME A112.18.2 / CSA B125.2

Indicates compliance to

ICC/ANSI A117.1

• EPA WaterSense

B2511LF-PPU

B2511LF-PPU-ECO

B2514LF-PPU-ECO

3 1/2"

(86 mm)

2 5/16"

(59 mm)

1 1/4"

(32 mm)

Max. Deck

Thickness

4 7/16"

(112 mm)

Min. 2 1/2" (64 mm)

Clearance to Back Splash

Recommended

1/2"-14

NPSM

2 1/8"

(54 mm)

Dia.

1 5/8" (42 mm)

2 3/8" (61 mm)

3 1/2"

(89 mm)

4 7/8"

(124 mm)

1 1/4"

(32 mm)

Dia.

8 13/16"

(224 mm)

(102 mm)

3x 1 1/8" to

1 1/2" (29 mm

to 38 mm)

hole size

3 5/8"

(92 mm)

(51 mm)

2 1/4"

(58 mm)

6 1/8"

(155 mm)
