Dimensions Guide

DSP-B-226032AL00 Rev. B
20-1/2"
19-1/2"
17"
56-1/2"
ENCLOSURE
OPENING
73-1/2"
FLANGE
HEIGHT
2X SHELF
7-1/2” x 6”
APPROX.
2X SHELF
7-1/2” x 6”
APPROX.
74-1/2"
O.A.
14-1/4"
OF OVERFLOW
2-3/4"
DRAIN BOTTOM
30-7/8” O.A.
C
L
2X 32
"
16"
8"
10"
60" OPENING
13-1/8"
27-3/4"
42-3/8"
57"
10-1/2"
59-7/8" O.A.
57-1/8"
ENCLOSURE OPENING
14-1/4"
OF DRAIN
8-1/4" OF DRAIN
TEXTURED BOTTOM
SOAP DISH (2X)
C
L
C
L
COMPLIES WITH:
• CSA B45.5/IAPMO Z 124
226032AL00 / 226032AR00
Left or Right Drain
60" X 32" X 74" SHOWER
■ Acrylic with Innovex
®
Technology
■ High Gloss Acrylic Surface
■ Smooth, easy-to-handle backing
■ Built-In Screw Guides
■ One-Piece Bathtub and Shower
■ 10 Year Limited Residential Warranty
■ 1 Year Limited Commercial Warranty
STYLA
®
BATHTUB
AND SHOWER
GREENGUARD Certied products
are certied to GREENGUARD
standards for low chemical
emissions into indoor air during
product usage. For more
information, visit ul.com/gg
55 E 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, ON N5P 4L1
© 2018 Masco Corporation of Indiana
