External Power Supply Installation Dell EMC PowerSwitch N2200-ON and N3200-ON Series Switches January 2020 Rev.
Notes, cautions, and warnings NOTE: A NOTE indicates important information that helps you make better use of your product. CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2020 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries.
1 N-Series EPS installation These instructions explain the external power supply (EPS) installation for the Dell EMC PowerSwitch N2200-ON and N3200ON full-width and half-width switches. You can use the optional EPS on a desktop, wall mount, or in a rack. ● The model name of the EPS Shelf with one PSU is MPS-1S. ● The model name of the EPS Shelf with three PSUs is MPS-3S. NOTE: For switch installation instructions, see the switch-specific Dell EMC PowerSwitch Installation Guide at www.dell.com/support.
MPS-3S 5. Turn the switch over and place on a desktop. MPS-1S two-post installation This installation procedure describes how to install an MPS-1S self in a two-post rack. Use L-brackets for front, five-inch-offset, or rear-mount two-post installation. These mounting supplies ship with the MPS-1S. 1. Remove the two L-brackets and screws from the shipping box.
2. Screw one L-bracket to the switch using the four M4 screws (length 6.8 mm). Install the brackets to the switch in front, five-inch-offset, or rear mounting positions, as shown. ● For front-mount: The mounting bracket and bracket ears face the front of the EPS. ● For five-inch-offset mount: The mounting bracket is at the front of the EPS with the bracket ears facing the back of the EPS. ● For rear-mount: The mounting bracket and bracket ears face the back of the EPS. Torque the screws to 10 inch-lbs.
Front mount 5-inch offset mount Rear mount 4. Screw the single-switch L-bracket to the two-post rack using two M4 screws (length 6.8 mm) for each bracket. Torque the screws to 10 inch-lbs. To remove the switch from the two-post rack, remove the four screws from the two-post rack and slide the switch from the rack. MPS-3S two-post installation This installation procedure is for the three-slot EPS shelf. Use mounting brackets for front, 5-inch offset, or rear-mount twopost installation.
Front-mount Five-inch-offset mount 4. Slide the EPS into the two-post rack until the mounting bracket ears line up with the rack. Front-mount Five-inch-offset mount 5. Attach the switch to the two-post rack using two #12-24 screws on each side. To remove the switch from the rack, unscrew the four #12-24 rack-mounting screws.
MPS-1S wall mount Use the four wall-mount brackets to attach an external power supply (EPS) to the wall. You need a drill and a pencil to complete this procedure. This procedure applies to one EPS. 1. Remove the wall-mount brackets, wall anchors, and screws from the shipping bag. This procedure uses four wall mount anchors, four M5 screws (length 16 mm), and eight M4 screws (length 6.8 mm). 2. Screw two brackets to the left side of the EPS using the M4 screws (length 6.8 mm) for each bracket, as shown.
5. Drill four 0.3 in (8 mm) holes in the wall at the pencil marks. 6. Install four wall-mount anchors into the four holes. 7. Screw four M5 screws into the four wall-mount anchors leaving approximately 0.20 in (5 mm) gap between the anchor and the screw. 8. Slide the EPS onto the screws and tighten the screws to secure the EPS in place. Torque the screws to 24 in-lbs.
Installation WARNING: This equipment must be earthed. Connect the power plug to a properly wired earth ground socket outlet. NOTE: Install the switch equipment in restricted access areas. A restricted access area is one in which service personnel can only gain access using a special tool, lock, key or other means of security. The authority responsible for the location controls access to the restricted area. Ground cable To attach a ground cable to the switch, use the included M4 screws (length 6.8 mm).
