.INTRODUCTION Package Contents POWER ADAPTOR User’s Manual BASE Unit Wireless Headset EAR-HOOK HEADSET & HEADBAND TELEPHONE CONNECTION CORD USB CABLE (Optional) 2.
- Fit the headband or ear-hook on the headset - Adjust the boom arm of your headset so that the microphone is positioned in the direction of your mouth, as close as possible to your mouth. 3. Base Unit Base Top PC/TEL Selection Base Bottom Microphone Volume Compatibility Switch Microphone Mute Button Microphone Volume Switch When installed, adjust volume level for the best level of Compatibility Switch Select ‘1’ or ‘2’ until a dial tone is heard via the telephone microphone volume. connection.
4. LED indicator Diagram 2 ( Desk phone without HEADSET port) Battery indicator In-use indicator Mute indicator PC/TEL indicator Charging Status LEDs status Charging Battery Indicator : ‘Blinking’ 3 sec-ON, 1sec-OFF Full Charged Battery Indicator : ‘ON’ Low Battery Battery Indicator : ‘Blinking’ 0.5 sec-ON, 0.
6. Operational Instruction 8. Trouble Shooting - Plug the Power Adapter cord on the Base unit.(Note 1) - Press Hook On/Off switch to make a call - Select compatibility switch ‘1’ or ‘2’ position until you can hear the dial tone ☞ Please check the cable connection between Base unit and Phone. - Adjust speaker and microphone volume ☞ Check that the power adapter is plugged in and has power - Press Hook On/Off switch to end a call ☞ Please check the compatibility switch.
FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
