S/M No. : TWP895BEF0 Service Manual Colour Television CHASSIS WP-895 WP-895F CP-885 CP-885F DAEWOO ELECTRONICS CO., LTD http : //svc.dwe.co.kr AUG.
Service manual WP-895/895F. CP885/885F Contents 1 - Main features ........................................................................................................................................................ 4 1-1 Specifications .................................................................................................................................................. 4 1-2 Channel table .......................................................................................................
Service ma nual WP-895/895F. CP885/885F 4-5-2 TDA8358J .............................................................................................................................................. 33 4-6 TDA6107Q .......................................................................................................................................................... 34 4-7 24C16 - 16 Kb EEPROM ..................................................................................................................
Service manual WP-895/895F. CP885/885F 5-4-1 Introduction........................................................................................................................................... 49 5-4-2 CPU ...................................................................................................................................................... 49 5-4-3 -Controller I/O pin configuration and function ...............................................................................
Service manual WP 895/895F, CP885/885F 1- Main Features 1-1 Specifications TV standard Sound system Power consumption Sound Output Power Speaker Teletext system Aerial input Channel coverage Tuning system Visual screen Channel indication Program Selection Aux. terminal Remote Control Unit PAL - SECAM B/G D/K, PAL I/I, SECAM L/L’ NICAM B/G, I, D/K, L, FM 2Carrier B/G, D/K 21” Real Falt : 59 W approx. 28” 4:3, FST : 69 W approx. 29" 4:3, REAL FALT : 74 W approx. 28” 16:9, WIDE : 69 W approx. 21” : 4.
Service manual WP 895/895F, CP885/885F Specification matrix CHASSIS NAME WP895 WP895F CP885 CP885F VCT VERSION 3834 3834 3832 3834 SOFTWARE VERSION A A B A REMOTE CONTROL R46G22 R46G22 R46G22 R46G22 PCB SERIAL NUMBER 4859805093 4859805193 4859805093 4859805193 TUBE 16:09 16:9 REAL FLAT 4:03 4:3 REAL FLAT AUTO / 4:3 / 14:9 / ZOOM 14:9 / ZOOM 16:9 / FULL SCREEN AUTO / 4:3 / 14:9 / ZOOM 14:9 / ZOOM 16:9 / FULL SCREEN AUTO / FULL SCREEN / 14:9 / 16:9 AUTO / FULL SCREEN / 14:9 /
Service manual WP 895/895F, CP885/885F 21 Pin EURO-SCART 1 : Pin 1 2 3 4 5 6 7 8 Signal Description Audio Output Right Audio Input Right Audio Output Left Audio Earth Blue Earth Audio Input Left Blue Input Slow Switching 9 10 11 12 13 14 15 16 17 18 19 20 21 Green Earth N.C. Green Input N.C. Red Earth Blanking Earth Red Input Fast Switching Video Out Earth Video In Earth Video Output Video Input Common Earth Matching value 0.5 Vrms, Impedance < 1 , ( RF 54% Mod ) 0.5 Vrms, Impedance > 10 0.
Service manual WP 895/895F, CP885/885F 19 20 21 Video Output Video Input, Y In.
Service manual WP 895/895F, CP885/885F 1-2 Channel table FREQUENCY TABLE CH C01 C02 C03 C04 C05 C06 C07 C08 C09 C10 C11 C12 C13 C14 C15 C16 C17 C18 C19 C20 C21 C22 C23 C24 C25 C26 C27 C28 C29 C30 C31 C32 C33 C34 C35 C36 C37 C38 C39 C40 C41 EUROPE CCIR 46.25 48.25 55.25 62.25 175.25 182.25 189.25 196.25 203.25 210.25 217.25 224.25 53.75 82.25 183.75 192.25 201.25 471.25 479.25 487.25 495.25 503.25 511.25 519.25 527.25 535.25 543.25 551.25 559.25 567.25 575.25 583.25 591.25 599.25 607.25 615.25 623.25 631.
Service manual WP 895/895F, CP885/885F CH C42 C43 C44 C45 C46 C47 C48 C49 C50 C51 C52 C53 C54 C55 C56 C57 C58 C59 C60 C61 C62 C63 C64 C65 C66 C67 C68 C69 C70 C71 C72 C73 C74 C75 C76 C77 S01 S02 S03 S04 S05 S06 S07 S08 S09 EUROPE CCIR 639.25 647.25 655.25 663.25 671.25 679.25 687.25 695.25 703.25 711.25 719.25 727.25 735.25 743.25 751.25 759.25 767.25 775.25 783.25 791.25 799.25 807.25 815.25 823.25 831.25 839.25 847.25 855.25 863.25 69.25 76.25 83.25 90.25 97.25 59.25 93.25 105.25 112.25 119.25 126.25 133.
Service manual WP 895/895F, CP885/885F CH S10 S11 S12 S13 S14 S15 S16 S17 S18 S19 S20 S21 S22 S23 S24 S25 S26 S27 S28 S29 S30 S31 S32 S33 S34 S35 S36 S37 S38 S39 S40 S41 EUROPE CCIR 168.25 231.25 238.25 245.25 252.25 259.25 266.25 273.25 280.25 287.25 294.25 303.25 311.25 319.25 327.25 335.25 343.25 351.25 359.25 367.25 375.25 383.25 391.25 399.25 407.25 415.25 423.25 431.25 439.25 447.25 455.25 463.25 FRANCE 212.75 224.75 236.75 248.75 260.75 272.75 284.75 296.75 136.00 160.00 303.25 311.25 319.25 327.
Service manual WP 895/895F, CP885/885F 1-3 ATSS sorting method The TV set sweeps all the TV bands from beginning of VHF to end of UHF. The TV controlling software for each program checks if a VPS CNI code is transmitted ( this system exists for German, Swiss and Austrian transmissions). If no VPS CNI code is found, then the system check if a CNI code is transmitted as part of the teletext transmission ( Packet 8/30 format 1 ).
Service manual WP 895/895F, CP885/885F The sor ting order within group II, III, and IV is based on the channel frequency. The Pro gram with the lo west frequency is allocated the first rank in its group, and so f orth until the last program of the group which has the highest fr equency.
Service manual WP 895/895F, CP885/885F 2 - Safety instruction WARNING: Only competent service personnel may carry out work involving the testing or repair of this equipment. X-RAY RADIATION PRECAUTION 1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high voltage must not exceed the specified limit. The nominal value of the high voltage of this receiver is 26 KV (25” - 28”) at max beam curr ent.
Service manual WP 895/895F, CP885/885F 3 - Alignment instructions 3-1 Microcontroller con figuration : Service mode To switch the TV set into service mode please see instruction below. 1 - Select pr. number 91 2 - Adjust sharpness to minimum and exit all menu. 3 - Quickly press the key sequence : RED - GREEN - menu To software version is displayed beside the word Service, e.g. “ SERVICE V1.00A ”. To exit SERVICE men u press men u key or Std By key.
Service manual WP 895/895F, CP885/885F 3-3 Microcontroller con figuration : Option bits These option bits are availa ble from Service mode. First find the OPTION control, and then use keys 0...7 on the remote keypad to control bits 0 to 7 respect ively.
Service manual WP 895/895F, CP885/885F 3-4-6- Horizontal picture centring Adjust HOR CEN(Horizontal center) to have the picture in the center of the screen. 3-4-7- Eau/West comection Adjust the PARABOLA, HOR WIDTH, CORNER, HOR PARAL, EW TRAPEZ, H BOW, to compensate for geometrical distorrin, HOR PARAL H BOW HOR WIDTH PARAROLA - 16 - For HOR WIDTH, adjust for 91% overscan.
Service manual WP 895/895F, CP885/885F CORNER EW TRAPEZ 3-4-8- AGC - Adjust the antenna signal level at 70 dB V 2 - Tune a colour bar pattern. - Find the “AGC” item in service mode. - Adjust AGC volume ( RB10 ) to bring the cursor to central position : 32.
Service manual WP 895/895F, CP885/885F 4 - IC description 4-1 VCT383XA TV signal processor - Teletext decoder with embedded 8 bit - Controller.
Service manual WP 895/895F, CP885/885F • Horizontal scaling ( 0.
Service manual WP 895/895F, CP885/885F • High-level command language • FLOF (Fastext), and TOP support • 10 pages memory on chip (10kB) 4-1-5- Display OSD Features • 3kB OSD RAM on chip • WST level 1.
Service manual WP 895/895F, CP885/885F • Inventory of transmitted Teletext pages stored in the Page Table • Signal quality detector for WST data • Comprehensive Teletext language coverage • Full Field Vertical Blanking Interval (VBI) data capture of WST data 4-1-10- TV processor version and -Controller capacity IC version VCT 3832A VCT 3834A 96k 1k 96k 1k 10 pages X 10 pages 8 bit -controller ROM size RAM size PAL decoder SECAM decoder NTSC decoder Picture improvement Teletext page memory Adaptive Co
Service manual WP 895/895F, CP885/885F PSDIP 64-pin 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 Pin Name GNDAF VSUPAF CBIN CIN1 CIN2/CRIN VIN1 VIN2 VIN3 VIN4 TEST HOUT VSUPD GNDD FBLIN RIN GIN BIN VPROT SAFETY HFLB VERTQ/ INTLC VERT EW SENSE GNDM RSW1 RSW2 SVMOUT ROUT GOUT BOUT VSUPAB GNDAB VRD XREF AIN3 AIN2 AIN1 AOUT2 AOUT1 VSUPS GNDS XTAL1 XTAL2 RESQ SCL SDA Mute LED KB OCP Type SUPPLY SUPPLY IN
Service manual WP 895/895F, CP885/885F Power 64 OCP 2 AGC 63 KB 3 S/B 5V 62 LED 4 Gnd 61 MUTE 5 MOD SW 60 SDA 6 SECAM L’ 59 SCL 7 AFC/RES 58 RESET 8 IR 57 XTAL in 9 SC1 SW 56 OSC GND 10 SC2 SW 55 GND 11 Vout 54 S/B 3.
Service manual WP 895/895F, CP885/885F 4-2 MSP341x Multistandard Sound Processor The MSP 341x is designed as a single-chip Multistandard Sound Processor for applications in analogue and digital TV sets, video recorders, and PC cards. The MSP3411 has all functions of MSP3410 with the addition of a virtual surround sound feature. A Surround sound affect ccan be rproduced with two loudspeakers.
Service manual WP 895/895F, CP885/885F - high deviation FM-mono mode (max. deviation: approx.
Service manual WP 895/895F, CP885/885F TV standards TV system B/G B/G Position of sound carrier (MHz) 5.5 / 5.7421875 5.5 / 5.85 L I D/K 6.5 / 5.85 6.0 / 6.552 6.5 / 6.2578125 D/K1 6.5 / 6.7421875 D/K2 6.5 / 5.85 D/K-NICAM Sound modulation Color system Country FM Stereo FM-Mono / NICAM PAL PAL AM-Mono / NICAM FM-Mono / NICAM FM Stereo SECAM-L PAL SECAM-East Germany Scandinavia, Spain France UK USSR FM-Mono / NICAM Architecture of MSP341x Pin connections and short description Pin No.
Service manual WP 895/895F, CP885/885F Pin No.
Service manual WP 895/895F, CP885/885F Pin No. 59 60 61 62 63 64 Pin Name ANA_IN1NC TESTEN XTAL_IN XTAL_OUT NC Type In In In Out Short description IF common Not Connected Test pin Crystal oscillator Crystal oscillator Test pin 4-3 TDA 4470-Multistandard Video-IF and Quasi Parallel Sound Processor 4-3-1- Description The TDA 4470 is an integrated bipolar circuit for multi-standard video/sound IF (VIF/SIF) signal processing in TV/VCR and multimedia applications.
Service manual WP 895/895F, CP885/885F Pin 19 20, 21 22 23 24 25 26 27, 28 Symbol VSW VVCO VAFC VS VO, FM VO, AM RCOMP Vi,SIF2 Function AFC switch VCO circuit AFC output Supply voltage Intercarrier output AF output-AM sound Offset compensation SIF2 input (symmetrical) 4-3-4 Block diagram Loop filter Offset comp. (optional) 26 18 l' switch VCO 21 20 VCO + phase shift FPLL 14 Control 19 AFC 6 VIF AFC switch 22 AFC VIF amp Video 7 CAGC Video det.
Service manual WP 895/895F, CP885/885F 4-4 TDA894xJ Stereo Audio Amplifier The TDA8944J( TDA 8946J) is a dual-channel audio po wer amplifier with an output power of 2 x 7W (2 X 15W) at an 8 load and a 12V supply. The circuit contains two Bridges Tied Load(BTL) amplifiers with an all-NPN output stage and standby/mute logic. The TDA8944J comes in a 17-pin DIL power package.
Service manual WP 895/895F, CP885/885F Block diagram TDA8944J - 31 -
Service manual WP 895/895F, CP885/885F 4-5 TDA835xJ Vertical Amplifier The TDA835xJ are power circuit for use in 90o and 110o colour deflection systems for field frequencies of 25 to 200Hz and 16/9 picture tubes. The circuit provides a DC driven vertical deflection output circuit, operating as a highly efficient class G system. Due to the full bridge output circuit the deflection coils can be DC coupled. The IC is constructed in a Low Voltage DMOS process that combines Bipolar, CMOS and DMOS devices.
Service manual WP 895/895F, CP885/885F 4-5-2 TDA8358J An East-West output stage is provided that is able to sink current from the diode modulator circuit.
Service manual WP 895/895F, CP885/885F - 34 -
Service manual WP 895/895F, CP885/885F 4-6 TDA6107Q The TDA6107Q includes three video output amplifiers in one plastic DIL-Bent-SIL 9-pin medium power package, using high voltage DMOS technology, and is intended to drive the three cathodes of a colour CRT directly. To obtain maximum performance, the amplifier should be used with black-current control. Features - Typical bandwidth of 5.
Service manual WP 895/895F, CP885/885F Block diagram TDA6107Q - 36 -
Service manual WP 895/895F, CP885/885F 4-6 24C16 - 16 Kb EEPROM features : - 16 Kbit serial I2C bus EEPROM - Single supply voltage : 4.5 V to 5.5 V - 1 Million Erase/Write cycles (minimum) - 40 year data retention (minimum) Pin description Pin No. 1, 2, 3 5 6 7 8 4 Name E0, E1, E2 SDA SCL WC Vcc Vss Description Device address - not used Serral Data/Address Input/Output Serial clock Write control Supply voltage Ground The memory device is compatible with the I2C memory standard.
Service manual WP 895/895F, CP885/885F 4-8 STR - F6653 4-8-1 General description The STR-F6653 is an hybrid IC with a build-in MOSFET and control IC, designed for flyback converter type switch mode power supply applications.
Service manual WP 895/895F, CP885/885F 4-8-4 Pins description pin 1 name Overcurrent / feedback symbol O.C.P./ F.B.
Service manual WP 895/895F, CP885/885F 4-7-6 MOSFET electrical characteristics DESCRIPTION Drain-to-source break voltage Drain leakage current On-resistance Switching time Thermal resistance IC PINS NUMBER 3-2 3-2 3-2 3-2 - SYMBOL VDSS IDSS RDS (on) tf OCH -F - 40 - MIN. 650 RATING TYPE - MAX - - -2 - 300 1.95 50 0.
Service manual WP 895/895F, CP885/885F 5 - Circuit description 5-1 Block diagram - 41 -
Service manual WP 895/895F, CP885/885F 5-2 IF section 5-2-1 Block diagram 5-2-2 Vision IF Amplifier The video IF signal (VIF) is fed through a SAW filter to the differential input (Pin 6-7) of the VIF amplifier. This amplifier consists of three AC-coupled amplifier stages. Each differential amplifier is gain controlled by the automatic gain control circuit (VIF-AGC). The output signal of the VIF amplifier is applied to the FPLL carrier generation and the video demodulator.
Service manual WP 895/895F, CP885/885F SAW filters Ref. K3953M Standard B/G - D/K - I - L/L’ K9650M B/G - D/K - I - L/L’ Features - IF filter for video application - TV IF filter with Nyquist slopes at 33.9 MHz and 38.9 MHz - Constant group delay - IF filter for audio application - TV IF audio filter with two channels - Channel 1 (L’ ) with one pass band for sound carrier at 40.40 MHz - Channel 2 ( L, D/K, I, B/G) with one pass band for sound carriers between 32.40 MHz and 33.
Service manual WP 895/895F, CP885/885F 5-2-5 Video Demodulation and Amplifier The video IF signal, which is applied from the gain controlled IF amplifier, is multiplied with the in-phase component of the VCO signal. The video demodulator is designed for low distortion and large bandwidth. The demodulator output signal passes an integrated low pass filter for attenuation of the residual vision carrier and is fed to the video amplifier.
Service manual WP 895/895F, CP885/885F 5-3 Video - VCT description 5-3-1 Introduction The VCT 38xxA includes complete video, display, and deflection processing. All processing is done digitally, the video front-end and video back-end are interfacing to the analogue world. Most functions can be controlled by software via I 2 C bus slave interface.
Service manual WP 895/895F, CP885/885F 5-3-8 Adaptive Comb Filter (VCT3834A only) The adaptive comb filter is used for high-quality luminance/chrominance separation for PAL or NTSC signals. The comb filter improves the luminance resolution (bandwidth) and reduces interferences like cross-luminance and cross-color artefacts. The adaptive algorithm can eliminate most of the mentioned errors without introducing new artefacts or noise.
Service manual WP 895/895F, CP885/885F 5-3-11 Video Sync Processing To extract the sync information from the video signal, a linear phase low-pass filter eliminates all noise and video contents above 1 MHz. The sync is separated by a slicer; the sync phase is measured. A variable window can be selected to improve the noise immunity of the slicer. The phase comparator measures the falling edge of sync, as well as the integrated sync pulse.
Service manual WP 895/895F, CP885/885F 5-3-15 CRT Measurement and Control The display processor is equipped with an 8-bit ADC for all measuring purposes. The ADC is connected to the SENSE input pin. Cutoff and white-drive current measurement are carried out during the vertical blanking interval. 5-3-16 Average Beam Current Limiter The average beam current limiter (BCL) uses the SENSE input for the beam current measurement.
Service manual WP 895/895F, CP885/885F 5-3-20 EHT Compensation The vertical waveform can be scaled according to the average beam current. This is used to compensate the effects of electric high-tension changes due to beam current variations. EHT compensation for East/West deflection is done with an offset corresponding to the average beam current. 5-3-21 Reset Function Reset of all VDP functions is performed by the RESQ pin. When this pin becomes active, all internal registers and counters are lost.
Service manual WP 895/895F, CP885/885F 5-4-3 - Controller I/O pin configuration and function There exist different kinds of ports. The universal ports serve as digital I/O and have additional special input and output functions. A subset of the universal ports serves as input for the analogue-to-digital converter.
Service manual WP 895/895F, CP885/885F 23, in each frame. This is bi-phase encoded using a clock frequency of 5 MHz. In total, 14 data bits are available, in 4 groups. Group 1 contains the codes for the received format. The mode chosen is defined by the following table. In effect the default mode is full screen. The table below gives a summary of the FORMAT modes available (for WP895 and WP895F), and their given properties.
Service manual WP 895/895F, CP885/885F The following schematic, illustrates the logic of control for the two SCART connectors. The terms used in the schematic are described below ; 1. AUTO represents a situation where the television has self-selected its picture source. This could be when the SCART SLOW SWITCHING pin has gone to a high state, and the AV 1 input is selected without the intervention of the user. 2.
Service manual WP 895/895F, CP885/885F can always be overridden by the user after the event. Each line on the diagram, with its associated text, represents the exact conditions under which the change of state will occur. Sometimes this will be accompanied by another action which will be automatically performed by the television, being to either ENABLE or DISABLE F/SW 1. 5-4-7 Over Current Protection In case of overload, the SMPS secondary voltages will drop.
Service manual WP 895/895F, CP885/885F OSD Language C 12 English, French, 0 German, Italian, 0 Spanish, Dutch, 0 Danish, Finnish, 0 1 Norwegian, Swedish, Greek 1 1 1 0 Polish, 0 Hungarian, 0 Czech, 0 Slovakian, 1 Rumanial 1 1 1 0 Russian 0 0 0 1 1 1 1 C 13 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1 C 14 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 0 1 Teletext Language English German Swedish/Finnish Italian French Spanish Turkish English Polish German Hungarian Lettish/Lithuanian French Serb/Croat/S
Service manual WP 895/895F, CP885/885F 5-6-4 NICAM decoder In case of NICAM - mode, the phase samples are decoded according the DQPSK - coding scheme. The output of this block contains the original NICAM bitstream. 5-6-5 DSP section All audio baseband functions are performed by digital signal processing (DSP). The DSP section controls the source and output selection, and the signals processing.
Service manual WP 895/895F, CP885/885F 5-7-2 Mode selection The TDA894xJ has several functional modes, which can be selected by applying the proper DC voltage to pin MODE. Mute : In this mode the amplifier is DC biased but not operational (no audio output). This allows the input coupling capacitors to be charged to avoid pop-noise. The device is in mute mode when 2.5 V < VMODE < (Vcc-1.5 V). Operating : In this mode the amplifier is operating normally. The operating mode is activated at VMODE < 0.5 V.
Service manual WP 895/895F, CP885/885F 5-9 Power supply (STR F6654) 5-9-1 STR-F6654 general description The STR-F6654 is an hybrid IC with a build-in MOSFET and control IC, designed for flyback converter type switch mode power supply applications. 5-9-2 Power supply primary part operations An oscillator generates pulses signals which turn on and off a MOSFET transistor.
Service manual WP 895/895F, CP885/885F When the power switch is pushed on, VIN increases slowly. During this time, C806 is charged through R802. As soon as VIN reaches 16V, the STR-F6654 control circuit starts operating. Then, VIN is obtained by smoothing the winding voltage which appears between pin6 and pin7 of the SMPS transformer. As this winding voltage does not increase to the set voltage immediately after the control circuit starts operating, VIN starts dropping.
Service manual WP 895/895F, CP885/885F 5-9-2-2 STR-F6654 oscillating operation - 59 -
Service manual WP 895/895F, CP885/885F When the MOSFET is ON, the STR-F6654 internal capacitor C1 is charged at the constant voltage 6.5V. At the same time, the voltage at pin 1 (OCP / FB) increases with the same waveform as the MOSFET drain current. When the pin 1 voltage reaches the threshold voltage VTH1 = 0.73V, the STR-F6654 internal comparator 1 starts operating. The STR-F6654 internal oscillator is inverted and the MOSFET turns OFF.
Service manual WP 895/895F, CP885/885F 5-10 TV start-up, TV normal run and stand by mode operations 5-10-1 TV start-up operations * Schematic diagram for start-up operations * TV start-up and microcontroller initialisation - When SW801 power switch is pushed, main AC voltage is applied to T801 transformer (after rectification by D801... D804 diodes). Then, T801 SMPS transformer starts operating and supplies DC voltage to I823 (5V regulator). - This regulator provides 5V / 3.
Service manual WP 895/895F, CP885/885F . If the TV set was on normal run mode before switching off, the microcontroller delivers horizontal drive voltage at pin 24 and picture appears on screen. . If the TV set was on stand-by mode before switching off, the microcontroller switches TV set to stand-by mode, decreasing power pin voltage (pin 1).
Service manual WP 895/895F, CP885/885F On normal run mode, I501 microcontroller pin 1 (power) is set to high • So, I810 controlled rectifier is not conducting - Q809 is conducting.
Service manual WP 895/895F, CP885/885F * power supply functioning during TV set normal run mode - I801 transmits controlled pulses to T801 which generates DC voltages after rectifications by secondary part diodes and electro capacitors (by example by D820 and C813 on 143V supply voltage line). - 8V, 5V, 3.3V supply voltage lines have stabilized voltages obtained by I820, I822, I823 voltage regulators.
I810 CONDUCTING controlled rectifier 1 D821 I823 3.3V REGULATOR 3 C840 HIGH C841 AROUND 3.
Service manual WP 895/895F, CP885/885F I810 CONTROLLED RECTIFIER 6V DC HIGH R829 R830 R820 C830 HIGH Q807 Q808 LOW HIGH Q809 POWER LOW Fig : I810 controlled rectifier switching circuit * TV set stand-by mode operations - On stand-by mode, I501 microcontroller pin 1 (power) is set to low. - So, Q809 collector is set to high. - Then, I810 controlled rectifier gate pin is set to high and I810 is conducting.
Service Manual WP-895/895F, CP885/885F 6. Service Parts List (DWX - 28W5 ) CAUTION “ ” Parts recommended for stock. “ ® ” Safety critical componen, Replace only with genuine Deawoo safety parts. LOC M211 PART CODE PART NAME 4852158911 COVER BACK M211D 4857817611 CLOTH BLACK M541 4855415800 SPEC PLATE M201A 4857818701 CLOTH BLACK M201B 4857818702 M211A 7172401612 DESCRIPTION REMARK HIPS GY LOC PART CODE PART NAME DECSCRIPTION PW001 4857417700 TERM CLAMP PT-01-T3 FELT 200X20X0.
Service Manual WP-895/895F, CP885/885F LOC G900 PART CODE 4SG0D00103 PART NAME DESCRIPTION SPARK GAP S-23 900V-1.
Service Manual WP-895/895F, CP885/885F LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DECSCRIPTION C156 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING) C623 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP C157 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP C624 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP C158 CBXF1H104Z C CERA SEMI 50V F 0.
Service Manual WP-895/895F, CP885/885F LOC Q334 PART CODE T2SC5343Y- PART NAME TR LOC PART CODE 2SC5343Y C161 CZSL1H220J C CERA 50V SL 22PF J (AXIAL) DESCRIPTION REMARK PART NAME DECSCRIPTION Q402 T2SD1207T- TR 2SD1207-T (TAPPING) C163 CCZF1H103Z C CERA 50V F 0.01MF Z Q510 T2SC5343Y- TR 2SC5343Y C500 CCZF1H103Z C CERA 50V F 0.01MF Z Q511 T2SC5343Y- TR 2SC5343Y C501 CCZF1H103Z C CERA 50V F 0.01MF Z Q542 T2SA1980Y- TR 2SA1980Y C503 CBZF1H104Z C CERA SEMI 50V F 0.
Service Manual WP-895/895F, CP885/885F LOC PART CODE 50V B 2200PF K (AXIAL) D840 D1N4148— DIODE 1N4148 (TAPPING) C CERA 50V B 100PF K (AXIAL) D841 D1N4148— DIODE 1N4148 (TAPPING) C CERA 50V B 1000PF K (AXIAL) D850 DUZ2R7B— DIODE ZENER UZ-2.
Service Manual WP-895/895F, CP885/885F LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DECSCRIPTION J072 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J891 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J073 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J896 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J075 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J903 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING J076 85801065GY WIRE COPPER AWG22 1/0.
Service Manual WP-895/895F, CP885/885F LOC PART CODE R162 RD-AZ153J- R CARBON FILM 1/6 15K OHM J R540 RD-AZ101J- R CARBON FILM 1/6 100 OHM J R163 RD-AZ752J- R CARBON FILM 1/6 7.5K OHM J R541 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J R164 RD-AZ752J- R CARBON FILM 1/6 7.5K OHM J R542 RD-AZ223J- R CARBON FILM 1/6 22K OHM J R177 RD-AZ562J- R CARBON FILM 1/6 5.
Service Manual WP-895/895F, CP885/885F LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DECSCRIPTION R621 RD-AZ102J- R CARBON FILM 1/6 1K OHM J R913 RD-AZ101J- R CARBON FILM 1/6 100 OHM J R622 RD-AZ102J- R CARBON FILM 1/6 1K OHM J R921 RC-2Z102K- R CARBON COMP 1/2 1K OHM K 1/6 1K OHM J R922 RC-2Z102K- R CARBON COMP 1/2 1K OHM K 1/6 1K OHM J R923 RC-2Z102K- R CARBON COMP 1/2 1K OHM K RD-4Z472J- R CARBON FILM 1/4 4.
Service Manual WP-895/895F, CP885/885F 7.
Service Manual WP-895/895F, CP885/885F 7.
Service Manual WP-895/895F, CP885/885F 7.
Service Manual WP-895/895F, CP885/885F 7.
Service Man ual WP-895/895F, CP885/885F 7.
Service Man ual WP-895/895F, CP885/885F 7.
Service Manual WP-895/895F, CP885/885F 7.
PRINTED CIRCUIT BOARD PCB MAIN
