General Specification VP4726 / VP4726F RoHS Compliant PROPRIETARY NOTE APPROVAL THIS DOCUMENT CONTAINS INFORMATION CONFIDENTIAL AND PROPRIETARY TO D&T CORPORATION AND SHALL NOT BE REPRODUCED OR TRANSFERRED TO OTHER DOCUMENTS OR DISCLOSED TO OTHERS OR USED FOR ANY PURPOSE OTHER THAN THAT FOR WHICH IT WAS OBTAINED WITHOUT THE EXPRESSED AND WRITTEN CONSENT OF D&TCORPORATION. General Specification 1 DRAWN CHECKED APPROVED 09.01.20 09.01.20 09.01.
TABLE OF CONTENTS 1. Overview ----------------- ------------------------------------------------------------------------------ 3 1.1 Scope 1.2 Revision History 2. General Features ------------------------------------------------------------------------------------- 4 2.1 General Description 3. Product Specifications ------------------------------------------------------------------------------ 5 3.1 Electrical Specifications 3.2 Entire System Block Diagram 3.3 Signal connector PIN assignments 3.
1. Overview 1.1 Scope VP4726 / VP4726F product has been specifically designed to use the professional applications. This system has been integrated ADC/TMDS Rx/Video decoder and SDI as well. Features include high-quality, motion-adaptive deinterlacing up to 1080p with enhanced low-angle processing, improved low-motion detection, advanced 3D noise reduction, and excellent 3D comb filter performance for PAL and NTSC. 1.2 Revision History Date Paragraph Change Description 08.10.13 1.
2. General Features 2.
3. Product Specification 3.1 Electrical Specifications 3.1.1 Panel Item Description Unit Description LM260WU2-SLA2 (LG Philips) - Size 26” Diagonal Inch Pixel Pitch 0.2865(W) x 0.2865(H) mm Active area 582.0 X 375.
3.1.2 Power supply Item Specification Min Typ Model No JMW1150KA2400F09 Description AC/DC Adapter Input Output Max Unit Rated Voltage 100 240 Vac, Normal Voltage Range 90 264 Vac Rated Line Frequency 50 60 Hz Line Frequency Range 47 63 Hz Current 3.00A max at 90Vac input Protection Dual internal primary current fuse: 250Vac / 5.0A Inrush limiting : 50A PEAK @ 90~264Vac, 50~60Hz Configuration Inlet type : IEC320-C14,C8 Voltage /Current +24Vdc at 6.
3.1.3 Power management This monitor saves energy by switching your monitor into a low power mode when it has not detected a video signal for approximately 45 seconds. State Normal Operation DPMS Standby DPMS suspend POWER Off Horizontal Sync Active Inactive Active Inactive Vertical Sync Active Active Inactive Inactive Video Active Blanked Blanked Blanked Power Indicator Green Green Flashing (5 sec. Interval) Green Flashing (5 sec.
3.1.4 Input Signal Input Signal Video VGA Sync DVI Optical DVI CVBS SVHS Y/C Type Description Type Analog RGB Connector DSUB-15 Level 0.
3.1.5 Output Signal Output Signal DVI Type Type Digital RGB Signal Format TMDS single link Connector DVI-D SMPTE-274M SDI Description 1080i (60 / 59.94 / 50) 1080p (30 / 29.97 / 25 / 24 / 24sF / 23.98 / 23.98sF) SMPTE-296M 720p (60 / 59.94 / 50) SMPTE-260M 1035i (60 / 59.94) SMPTE-125M 480i (59.94) ITU-R BT.656 576i (50) 3.1.6 Input Signal Timing Resolution Horizontal frequency (KHz) Vertical frequency (Hz) Pixel clock (MHz) 640 x 350 @60Hz 31.469 59.941 25.
Resolution Horizontal frequency (KHz) Vertical frequency (Hz) Pixel clock (MHz) 1024 x 768 @60Hz 48.363 60.004 65.000 1024 x 768 @70Hz 56.476 70.069 75.000 1024 x 768 @75Hz 60.023 75.029 78.750 1024 x 768 @85Hz 68.677 84.997 94.500 1152 x 864 @60Hz 54.348 60.053 80.000 1152 x 864 @70Hz 63.955 70.016 94.200 1152 x 864 @75Hz 67.500 75.000 108.000 1280 x 960 @60Hz 60.000 60.000 108.000 1280 x 960 @85Hz 85.938 85.002 148.500 1280 x 1024 @60Hz 63.974 60.013 108.
3.
3.
3.4 GPIO specification P,S Swap Pressing the swap button. Swaps the primary and secondary images. 1 3 Record Indicator The record indicator is displayed while a contact closure to the ground pin is present, the indicator is removed when the contacts are opened. The record indicator is displayed in the monitor’s top left corner. S REC P PIP,PBP1,PBP2 Select The selection of secondary Image position button is pressed.
3.5 Environmental specification Item Operating Conditions Description Temperature 0℃~ 40℃ Humidity 5% ~ 85%, non-condensing Transportation Conditions Temperature -20℃~ 60℃ Humidity 5% ~ 95%, non-condensing Storage Conditions Temperature -20℃~ 60℃ Humidity 10% ~ 85%, non-condensing 3.6 Reliability specification MTBF : more than 30,000 hours at 90% confidence level, excluding LCD panel. Reliability items : 3.6.
4. Regulatory 4.1 EMC & Safety Agency Approvals CB Compliance: This LCD monitor is investigated to EN 60601-1: 1990 + A1:1993 + A2:1995 UL Safety Compliance: This LCD monitor is investigated to UL60601-1, 1st Edition, 2006-04-26 (Medical Electrical Equipment, Part 1:General Requirements for Safety)CAN/CSA-C22.2 No. 601.
5. OSD specification VP4726 / VP4726F gives various and very easy graphic user interface. User can easily access function. 8 button keypad, located on the front of monitor, allows the user to make adjustments to various display parameters using on screen menus easily. Be sure that your system power and LED is turned on before operating key board. 5.1 OSD User functions/ Messages 5.1.1 OSD indicator Key Name Description Power Soft power Turns ON/OFF the monitor.
5.2 OSD representation 5.2.
5.2.
5.2.
5.2.
5.2.
5.3 OSD overview Menus BRIGHTNESS CONTRAST Function Descriptions Press the BRIGHTNESS button to display the ADJUST menu or UP,DOWN hot key. Setting the brightness too high or too low will decrease the amount of visible grayscales. Press the CONTRAST button to display the ADJUST menu or +,- hot key. Setting the Contrast too high or too low will cause loss of some grayscales. CLOCK Do not adjust freely. It will adjust fine state automatically after auto adjustment.
Menus Function Descriptions H POSITION Adjusts the horizontal position of the image. It will return to the default state when executing AUTO ADJUST or RESET SETTINGS V POSITION Adjusts the horizontal position of the image. It will return to the default state when executing AUTO ADJUST or RESET SETTINGS GAMMA Adjusts the gamma curve of video image. 1.8 2.0 2.2 2.4 2.
Menus IMAGE SETTING ZOOM / PAN Function Descriptions Save the 5 user’s setting about BRIGHTNESS,CONTRAST,COLOR TEMP,FILTER value separately. (PRESET 1~2, USER 1~3) Controls the zoom in/out of the image. 0 step : 4 step : 9 step : 13 step : 18 step : 22 step : 26 step : 30 step : Controls the PAN in/out of the image. FREEZE FRAME LANGUAGE OSD POSITION Freeze the main image.
Menus OSD DURATION RESET SETTINGS AUTO SOURCE SELECT USER NAME ENTRY Function Descriptions Adjust the time until the OSD Menu will disappear after adjusting the menu Reset the unit to factory outgoing status. When AUTO SOURCE SELECT is on, the monitor automatically search input source except PIP sub Source. Put user’s name or etc into set. PIP LAY OUT Change sub window layout (SINGLE,PIP,PBP1,PBP2) PIP : Main/Sub window doesn’t change aspect ratio. PBP1 : Main/Sub window doesn’t change aspect ratio.
Menus Function Descriptions SWAP Change main window and sub window position on PIP,PBP1,PBP2.
6. Mechanical Specifications 6.
6.2 Label dimension 6.2.1 Connector (Function) label 6.2.2 Product label Brand Logo ConMed Linvatec Model NO. VP4726 / VP4726F Rating Label (This may vary based on the Customer's request, and the changed contents of the Rating Label shall not be specified in this specification.
6.2.3 AC ADAPTOR Label Location The center of rear-cover Tilt Label shall not be tilted more than 1mm Size 57.5 x 64.
6.2.4 BOX label Location The left and right center side Tilt Shall not be tilted more than 1mm Size 161X63.5(mm) Material Art paper Base Color White 6.2.5 Membrane switch Location The center bottom side of front bezel Tilt Shall not be tilted more than 1mm Size 185X38.
6.3 Filter dimension 6.3.1 General specification Item Size Average reflectance Coating Description (576 +0/-1mm) x (356 +0/-1mm) x (3±0.
7. Packing 7.1 Packing 7.1.1 Carton Dimension Width Depth Height Weight 750 mm 230 mm 657 mm 14.5Kg This unit conforms to all specifications in the "General Specification VP4726 / VP4726F ” document, dated 09.01.
7.1.
