2WX_Manual.fm Page 0 Wednesday, August 29, 2007 10:38 AM Wacom Cintiq® 12WX Installation Guide & Hardware Manual for Cintiq 12WX (DTZ-1200W) English version 1.0, August 29, 2007 Copyright Wacom Co., Ltd, 2007 All rights reserved. No part of this manual may be reproduced except for your express personal use. Wacom reserves the right to revise this publication without obligation to provide notification of such changes. Wacom does its best to provide current and accurate information in this manual.
12WX_Manual.fm Page 1 Wednesday, August 29, 2007 10:38 AM INTRODUCTION AND OVERVIEW Wacom® Cintiq® The 12WX pen display combines the benefits of a Liquid Crystal Display (LCD) with the control, comfort, and productivity of Wacom’s cordless, battery-free pen technology. This gives you a direct pen-on-screen interface for your computer. Cintiq’s basic components include a Wacom pen tablet internally mounted behind a 12.1" wide format TFT color display, and Wacom’s Grip Pen.
12WX_Manual.fm Page 2 Wednesday, August 29, 2007 10:38 AM PRECAUTIONS To ensure the safe usage of your product, be sure to follow all instructions, cautions, and warnings found within this manual. Failure to do so could cause the loss of data or damage to your computer. Failure to do so could also void your warranty, in which case Wacom shall have no responsibility to repair or replace the product.
12WX_Manual.fm Page 3 Wednesday, August 29, 2007 10:38 AM USAGE WARNING Only use the converter unit and power adapter that came with Cintiq. If a different type of converter or power adapter are used, Cintiq will not work properly or may be damaged. Using a different type of converter or power adapter also has the potential to result in fire. Use of a different converter or power adapter will void your warranty. CAUTION Be sure to use a grounded power source when applying power to Cintiq.
12WX_Manual.fm Page 4 Wednesday, August 29, 2007 10:38 AM CAUTION Do not put heavy articles on the pen display or push against it with a strong force; this may break the stand mechanism or damage the display screen. Do not overload the unit when the stand is open or the stand may break. CAUTION When opening or closing the stand, hold the stand carefully as you adjust it to prevent injury or damage to the product. Be careful to not let your fingers get caught in the moveable gap of the stand mechanism.
12WX_Manual.fm Page 5 Wednesday, August 29, 2007 10:38 AM CONTENTS Introduction and overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Physical location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12WX_Manual.fm Page 6 Wednesday, August 29, 2007 10:38 AM Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Testing Cintiq . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Testing controls and input tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Testing the ExpressKeys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Testing the Touch Strips . . . . . . . .
12WX_Manual.fm Page 7 Wednesday, August 29, 2007 10:38 AM YOUR NEW CINTIQ PACKAGE CONTENTS Carefully unpack all items and place them on a desktop or stable work surface. Verify that your package contents are complete.
12WX_Manual.fm Page 8 Wednesday, August 29, 2007 10:38 AM CINTIQ PEN DISPLAY COMPONENTS Your product has many features and components with which you will want to become familiar. FRONT VIEW The display and tablet sensor function as an integrated output and input device. The display supports resolutions up to 1280 x 800 pixels at 16,777,216 colors. The tablet sensor reports pen coordinates, pressure, tilt, switch, eraser, and other information.
12WX_Manual.fm Page 9 Wednesday, August 29, 2007 10:38 AM REAR VIEW Rotation pivot Allows rotating the Cintiq. See page 26. Power switch Turns power on or off. (Located on upper edge of unit.) Kensington security slot Allows easy attachment of a security cable. (Located on upper edge of unit.) Integrated cable Connects to the converter unit. Carries all data, video, and power signals to and from the pen display.
12WX_Manual.fm Page 10 Wednesday, August 29, 2007 10:38 AM CONVERTER UNIT The converter unit provides an interface for all video and data signals passing between the Cintiq pen display and your computer. The unit also routes input power from the supply adapter to your pen display. DVI/VGA (digital/analog) switch Set this switch for the video connection you will be using. For DVI, move switch left (toward the connector). For VGA, move switch right.
WX_Manual.fm Page 11 Wednesday, August 29, 2007 10:38 AM INSTALLATION SYSTEM REQUIREMENTS Before installing Cintiq, be sure your computer meets the following minimum system requirements: • PC. Windows Vista™, Vista x64, XP, XP x64, or 2000. DVI or VGA video connector, available USB port, and CD-ROM drive. • Macintosh. OS X, v10.3.9 or greater. DVI or VGA video connector, available USB port, and CD-ROM drive. ADC connectors require an ADC to DVI-D adapter, not included.
12WX_Manual.fm Page 12 Wednesday, August 29, 2007 10:38 AM STEP 1: DISPLAY INSTALLATION In this step, Cintiq is installed as a display on your system. Important: Do not connect the USB data cable until instructed to do so. • Turn off your computer. Caution: Never connect or disconnect the video or power cables while your computer or Cintiq are powered on – this can damage the display or video card. • If your computer has only one video connector, you will need to unplug your previous display.
12WX_Manual.fm Page 13 Wednesday, August 29, 2007 10:38 AM DISPLAY CABLING DIAGRAM CAUTION Make sure your video card has a DVI or VGA connector, and that you correctly set the Cintiq DVI/VGA switch for the video connection you are using. Do not attach the USB data cable until instructed to do so.
12WX_Manual.fm Page 14 Wednesday, August 29, 2007 10:38 AM • Next, turn on your computer. For Windows systems, Cintiq will automatically install as a default display. If you want Cintiq to be identified as a Cintiq display and if you want to install the color calibration profile for Cintiq, follow the instructions below to update the display driver for Cintiq: 1. Open the CONTROL PANEL folder. • For Windows Vista, under APPEARANCE AND PERSONALIZATION select ADJUST SCREEN RESOLUTION.
12WX_Manual.fm Page 15 Wednesday, August 29, 2007 10:38 AM For Macintosh systems, a Cintiq color profile will be added to your computer’s color management system during the tablet software driver installation process. To activate this color profile for use with Cintiq, you may need to select the Cintiq 12WX profile in the system’s ColorSync Utility control panel. For more details, see the color management information in your operating system and application documentation.
12WX_Manual.fm Page 16 Wednesday, August 29, 2007 10:38 AM STEP 2: PEN TABLET INSTALLATION USB CABLE INSTALLATION • First plug the USB cable into the USB connector located on the converter unit. • Plug the other end of the cable into an available USB port on your computer or into a USB hub. • Next, move on to the Software installation on page 17.
12WX_Manual.fm Page 17 Wednesday, August 29, 2007 10:38 AM SOFTWARE INSTALLATION IMPORTANT: You MUST install the Wacom pen tablet driver software for correct pen-on-screen functionality. To install the tablet software: • • Save your work and close all open applications. Temporarily disable any virus protection programs. • • • Click on the INSTALL TABLET link and follow the prompts to install the driver software. • Be sure to check the Read Me file for late-breaking news.
12WX_Manual.fm Page 18 Wednesday, August 29, 2007 10:38 AM WORKING WITH YOUR CINTIQ USING THE GRIP PEN The pen is cordless, battery-free, and sensitive to the tilt and pressure you exert upon it. Hold the Grip Pen as you would a normal pen or pencil. As you work, you can rest your hand lightly on the Cintiq display screen, just as if it were a drawing board or sheet of paper. You can tilt the pen in any way that feels most comfortable for drawing.
12WX_Manual.fm Page 19 Wednesday, August 29, 2007 10:38 AM BASIC PEN OPERATIONS Pointing and selecting: Move the pen slightly above the Cintiq display screen to position the screen cursor; you do not need to touch the tablet surface. The cursor jumps to the location where you place the pen. Press the pen tip on the display screen to make a selection. Note: You must calibrate the pen display tablet to correctly align the screen cursor with the pen tip. (See Calibrating Cintiq on page 29.
12WX_Manual.fm Page 20 Wednesday, August 29, 2007 10:38 AM Using the side switch: The pen is equipped with a DuoSwitch. This switch has two programmable functions that can be selected by rocking the switch in either direction. You can use the DuoSwitch whenever the pen tip is within 5 mm (0.2 inch) of the tablet surface; you do not need to touch the pen tip to the tablet in order to use the switch. By default, the upper switch is set to DOUBLE CLICK and the lower switch is set to RIGHT CLICK.
12WX_Manual.fm Page 21 Wednesday, August 29, 2007 10:38 AM TABLET CONTROLS The customizable ExpressKeys and Touch Strips enable you to speed up many common tasks in graphics or other applications. While using the pen with your dominant hand, you can simultaneously use your other hand to operate the ExpressKeys or Touch Strip. Touch Strip Slide your finger up or down to zoom, scroll, or issue an assigned keystroke function. See Using the Touch Strips on page 23.
12WX_Manual.fm Page 22 Wednesday, August 29, 2007 10:38 AM USING THE EXPRESSKEYS As you work with your pen on the display tablet surface, press an ExpressKey to toggle between tools or change tool properties. You can work with the default settings, or choose from any of the other available functions. The default settings were chosen to optimize your workflow in Photoshop and other graphics applications using the following modifier functions: Button 1: CTRL modifier key for Windows.
12WX_Manual.fm Page 23 Wednesday, August 29, 2007 10:38 AM USING THE TOUCH STRIPS The customizable Touch Strips can be operated in several different ways: • Standard operation: Slide your finger up or down to zoom, scroll, or issue the assigned function. You can do this with your secondary hand while using your primary hand to work with the Grip Pen. By default, the Touch Strips enable you to zoom in most graphics applications and to scroll in other applications.
12WX_Manual.fm Page 24 Wednesday, August 29, 2007 10:38 AM SETTING UP YOUR WORK AREA To minimize fatigue, organize your work area so you can work comfortably. Position Cintiq, the Grip Pen, and your keyboard so they are easily accessible without unnecessary reaching. The pen display tablet and any other displays should be positioned so you can view them comfortably with a minimum of eyestrain.
12WX_Manual.fm Page 25 Wednesday, August 29, 2007 10:38 AM ADJUSTING DISPLAY INCLINE • To open the display stand, locate and slide the stand latch to release the stand. Unfold the stand from the pen display casing. • To close the stand, gently fold the stand back into the closed position until the latch catches the stand. Cushion CAUTION Please hold the stand carefully as you adjust it to prevent injury or damage to the product.
12WX_Manual.fm Page 26 Wednesday, August 29, 2007 10:38 AM ROTATING THE TABLET When the pen display stand is in the closed position, the unit can be rotated. As you work, position Cintiq by the main body; it will move on the rotation pivot. ATTACHING THE ACCESSORY FEET If you do not want to use the rotation pivot, you can install the optional rubber feet that came with your product at any time.
12WX_Manual.fm Page 27 Wednesday, August 29, 2007 10:38 AM CUSTOMIZING After you master the basics of using your Grip Pen on the Cintiq pen display, you may want to customize the way the pen or pen display works. The Wacom Tablet control panel makes it easy to customize Cintiq and the pen. OPENING THE CONTROL PANEL To open the control panel, use the Cintiq pen on the pen display tablet: Windows. Click on the Windows START button and choose ALL PROGRAMS. (For Windows 2000, choose the PROGRAMS group.
12WX_Manual.fm Page 28 Wednesday, August 29, 2007 10:38 AM CUSTOMIZATION BASICS This manual describes only the basics of customizing Cintiq. For detailed information see the Cintiq Software User’s Manual. Open the Wacom Tablet control panel to customize your product. When you open the control panel, an icon for the Grip Pen is displayed in the TOOL list and the appropriate tabs are displayed. To customize the pen, make changes to the tab controls.
12WX_Manual.fm Page 29 Wednesday, August 29, 2007 10:38 AM CALIBRATING CINTIQ You must calibrate the pen display tablet in order to align the screen cursor with the position of the pen on the display screen. This is required to adjust for parallax caused by the display screen cover glass and coating. Set Cintiq in its working position, then follow the procedure below. Important: When using a VGA connection, make sure the Cintiq is properly adjusted before calibrating the tablet.
12WX_Manual.fm Page 30 Wednesday, August 29, 2007 10:38 AM ADJUSTING THE DISPLAY FACTORY PRESETS, AUTO-SYNC, AND COLOR CALIBRATION Factory presets: For optimal display quality, set your video card to Cintiq’s native resolution of 1280 x 800 pixels (WXGA). See page 56 for signal specifications. Auto-sync: The auto-sync function automatically sets the horizontal and vertical screen position, as well as clock and phase.
12WX_Manual.fm Page 31 Wednesday, August 29, 2007 10:38 AM ON SCREEN DISPLAY (OSD) SETTINGS The Cintiq OSD function enables you to adjust and optimize a variety of display settings at the touch of a button. Make adjustments using the OSD controls located on the converter unit. 1. MENU button Press to open the OSD menu and to accept changes you make to the OSD settings. ENTER button Press to choose the highlighted menu option. (up) (down) 2.
12WX_Manual.fm Page 32 Wednesday, August 29, 2007 10:38 AM The basic process for working with the OSD is as follows: • • Press the MENU button to open the OSD main menu. Press the up or down buttons to toggle between the main menu icons. Then press the ENTER button to choose the highlighted icon. The Main Control icon displays a DVI or VGA identifier, depending on which video interface is currently in use. • Press the up or down buttons to toggle between menu options.
12WX_Manual.fm Page 33 Wednesday, August 29, 2007 10:38 AM When you open the On Screen Display, the main menu icons are displayed. Main Control. Provides options (DISPLAY, IMAGE, POSITION, and COLOR) that enable you to fine tune your display settings. See below for details. Reset. Returns the display parameters of the current mode to their factory default settings. OSD Control. Provides options that enable you to customize the OSD menu. See next page. Language.
12WX_Manual.fm Page 34 Wednesday, August 29, 2007 10:38 AM POSITION menu options (VGA only) are as follows: • VERTICAL. Changes the vertical position of the image. To automatically adjust, use the AUTO ADJUST option. • HORIZONTAL. Changes the horizontal position of the image. To automatically adjust, use the AUTO ADJUST option. COLOR menu options are as follows: • COLOR TEMPERATURE. Enables you to adjust the pen display color temperature.
12WX_Manual.fm Page 35 Wednesday, August 29, 2007 10:38 AM ADJUSTING CLOCK AND PHASE (VGA ONLY) Some computers and video cards may not allow the auto-sync function to fully work when Cintiq is first connected. If some portion of text appears blurred, open the OSD menu, go to the VGA IMAGE menu, and select AUTO ADJUST. If the image is still blurred, adjust the clock and phase manually by following the procedure below.
12WX_Manual.fm Page 36 Wednesday, August 29, 2007 10:38 AM TROUBLESHOOTING Most of the time your pen display tablet will work flawlessly. But if you are having trouble, Wacom recommends you do the following: 1. If the Wacom tablet driver failed to load properly, first perform the recommended action in any error message that may appear on your screen. If that does not solve the problem, continue with the troubleshooting procedures in this chapter. 2.
12WX_Manual.fm Page 37 Wednesday, August 29, 2007 10:38 AM 2. If there is no display: • Make sure that your computer is turned on. The power LED will light blue when the proper video signal is received, and orange if there is no video signal or if the computer is in a power saving mode. • Verify that the Cintiq converter unit is properly connected to an active DVI-I, DVI-D, or VGA connector and that the DVI/VGA switch on the converter unit is set to the correct video setting.
12WX_Manual.fm Page 38 Wednesday, August 29, 2007 10:38 AM TESTING CONTROLS AND INPUT TOOLS If the Grip Pen, or the Cintiq ExpressKeys or Touch Strips do not work as you expect, it is a good idea to first check the assigned functions or reset them to their default conditions. A quick way to reset a pen to its default settings is to remove it from the TOOL list by clicking on the list’s [ – ] button.
12WX_Manual.fm Page 39 Wednesday, August 29, 2007 10:38 AM TESTING A PEN 1. While observing the POINTING DEVICE INFO column, bring your pen within 5 mm (0.2 inch) of the display screen. A value for PROXIMITY, the DEVICE NAME, DEVICE TYPE, and a DEVICE S/N (serial number) should be displayed. If you have more than one Cintiq unit connected to your system, be sure to select the unit for which you are testing a pen in the TABLET INFO column. 2. Move your tool along the tablet surface.
12WX_Manual.fm Page 40 Wednesday, August 29, 2007 10:38 AM DISPLAY TROUBLESHOOTING If you encounter problems with the Cintiq display, see the following tables; your problem may be described here and you can try the solution offered. For more information about color issues, see the documentation that came with your operating system or applications. GENERAL DISPLAY PROBLEMS No display. The power LED is off.
12WX_Manual.fm Page 41 Wednesday, August 29, 2007 10:38 AM An “invalid mode” message briefly appears on your display screen. The image appears multiple times on the display. When a still image is displayed for a long period of time without refreshing the screen, an afterimage remains for a short period of time. Color quality is inaccurate. The color white does not display as white. • The input signal frequency is incorrectly set or not compatible with Cintiq.
12WX_Manual.fm Page 42 Wednesday, August 29, 2007 10:38 AM VGA PROBLEMS The display ripples or flickers. The display is not clear. Text or other portions of the screen appear blurred. • Open the OSD menu, go to the IMAGE menu, and select the AUTO ADJUST option. If necessary, manually adjust the clock and phase settings. • Verify that the display adapter or video card matches the specifications for Cintiq. • • • • Adjust the refresh rate in the Display Properties control panel.
12WX_Manual.fm Page 43 Wednesday, August 29, 2007 10:38 AM PEN TABLET TROUBLESHOOTING If you encounter problems with the Cintiq pen, see the following tables. Your problem may be described here, and you can try the solution offered. Be sure you refer to the Cintiq Read Me file for the latest information. For additional information, visit Wacom’s web site at http://www.wacom.com/productsupport GENERAL PROBLEMS The computer does not have an available USB port. The pen display power LED is off.
12WX_Manual.fm Page 44 Wednesday, August 29, 2007 10:38 AM Double-clicking is difficult. The eraser selects everything or will not stop erasing. You notice a delay at the beginning of pen strokes. You have to press hard with the pen when clicking or drawing. The pen tip does not function. Changing the function settings for an input tool has no effect. Troubleshooting Page 44 Be sure you are quickly tapping the display screen twice in the same place on the pen display tablet’s active area.
12WX_Manual.fm Page 45 Wednesday, August 29, 2007 10:38 AM The pen side switch does not work. The pen tip and screen cursor do not properly line up. The screen cursor moves but does not jump to the pen tip location on the display screen, and does not follow the pen tip when the pen is moved across the display. When using Cintiq on a multiple display system, you cannot use the pen to control the other display(s).
12WX_Manual.fm Page 46 Wednesday, August 29, 2007 10:38 AM The line you are drawing does not line up with the location of the screen cursor in paint applications. You suspect the pen tablet preferences may be corrupted, or want to make certain that all settings are at their factory defaults. To function properly, some applications require that the pen is set to PEN mode. Make sure the pen has not been toggled to MOUSE mode.
12WX_Manual.fm Page 47 Wednesday, August 29, 2007 10:38 AM WINDOWS-SPECIFIC PROBLEMS After changing right- and left-handed settings in the computer’s mouse control panel, the pen tip no longer functions properly. Restart Windows for your Wacom tool settings to be correctly recognized. MACINTOSH-SPECIFIC PROBLEMS At startup, a dialog box appears telling you that either the driver failed to load or the tablet preferences have not yet been created. Inkwell does not work correctly with Cintiq.
12WX_Manual.fm Page 48 Wednesday, August 29, 2007 10:38 AM TECHNICAL SUPPORT OPTIONS If you have a problem with your Cintiq pen display, first check the Installation section in this guide to make sure the unit is installed correctly. Then review the Troubleshooting procedures. If you cannot find the answer in this guide, you may find updated information about your problem in the appropriate Read Me file for your platform (located on the Wacom Pen Tablet Driver CD).
12WX_Manual.fm Page 49 Wednesday, August 29, 2007 10:38 AM OBTAINING DRIVER DOWNLOADS Wacom periodically updates the pen tablet software driver to maintain compatibility with new products. If you are having a compatibility problem between your Cintiq pen display and a new hardware or software product, it may be helpful to download a new Wacom tablet software driver (when available) from the Internet. USA, Canada, Central and South America Worldwide Web: http://www.wacom.
12WX_Manual.fm Page 50 Wednesday, August 29, 2007 10:38 AM APPENDIX CARING FOR CINTIQ Keep the Grip Pen and your Cintiq LCD screen surface clean. Dust and dirt particles can stick to the pen and cause excessive wear to the display screen surface. Regular cleaning will help to prolong the life of your LCD screen surface and pen. Keep Cintiq, the converter unit, and the Grip Pen in a clean, dry place and avoid extremes in temperature. Room temperature is best.
12WX_Manual.fm Page 51 Wednesday, August 29, 2007 10:38 AM REPLACING THE PEN TIP The pen tip (nib) will wear with normal use. Excessive pressure will cause the nib to wear sooner. When the nib gets too short or develops a sharp edge, replace it with one of the extra nibs that came with the pen. To remove the old nib: Clasp it with a Wacom nib extractor, pair of tweezers, needle-nosed plier, or similar instrument and pull the old nib straight out of the pen.
12WX_Manual.fm Page 52 Wednesday, August 29, 2007 10:38 AM USING A MOUNTING FIXTURE Cintiq can be attached to any mounting fixture conforming to the VESA 75 standard. This requires four M4 Regular screws (4 mm diameter with 0.7 mm pitch) with a clearance depth of no more than 6 mm. Exceeding the screw length may result in damage to the display. Attaching to a fixture: 1. Turn off your computer and power off Cintiq.
12WX_Manual.fm Page 53 Wednesday, August 29, 2007 10:38 AM PEN AND DIGITAL INK CAPABILITIES IN WINDOWS VISTA Microsoft Windows Vista provides extensive support for pen and touch input. When using Cintiq with a computer running Windows Vista, your experience is enhanced by powerful note taking, handwriting recognition, fast navigation, and other digital inking options designed to give you quick, intuitive results with the Wacom pen. • Note taking.
12WX_Manual.fm Page 54 Wednesday, August 29, 2007 10:38 AM ABOUT THE WINDOWS VISTA TABLET PC INPUT PANEL The Windows Vista Tablet PC Input Panel enables you to use handwriting or an on-screen keyboard to directly enter text with your Wacom pen. There are a number of ways to launch the Input Panel: • Click on the Input Panel icon which appears when you move the screen cursor into a text entry area. • • Click on the Input Panel tab, located by default on the left edge of the display screen.
12WX_Manual.fm Page 55 Wednesday, August 29, 2007 10:38 AM UNINSTALLING CINTIQ Follow the appropriate procedure below to remove the Wacom tablet software and Cintiq pen display from your system. Important: When you remove the Wacom tablet software from your system, your Wacom tablet will no longer operate with full tablet functionality but will continue to function as a mouse device. Windows: 1. Click on the Windows START button and open the CONTROL PANEL. 2.
12WX_Manual.fm Page 56 Wednesday, August 29, 2007 10:38 AM PRODUCT SPECIFICATIONS CINTIQ 12WX (MODEL DTZ-1200W) GENERAL SPECIFICATIONS Dimensions (W x D x H) 405 x 270 x 17 mm (15.96 x 10.64 x 0.67 in), excluding protrusion Weight 2.0 kg (4.
12WX_Manual.fm Page 57 Wednesday, August 29, 2007 10:38 AM PEN TABLET Reading technology Electromagnetic resonance technology Active area 261.1 x 163.2 mm (10.3 x 6.4 in) Resolution 0.005 mm/point (5080 lpi) Accuracy ±0.5 mm (±0.02 in), average Tilt range (all pens) ±60 degrees Reading height 5 mm (0.2 in) Maximum report rate 133 points/sec. ExpressKeys stroke 1 mm (0.04 in), approximately Touch Strips 52 mm (2.0 in) x 12 mm (0.
12WX_Manual.fm Page 58 Wednesday, August 29, 2007 10:38 AM ACCESSORIES Airbrush. A true digital airbrush incorporating a pressure-sensitive tip and eraser, tilt sensitivity, and a fingerwheel that provides an additional degree of control over the application of digital paint. This tool also includes a programmable side switch. ZP-400E 6D Art Pen. This pen provides rotation sensing technology with a unique chisel-shaped nib that emulates brushes, markers, and calligraphic pens.
12WX_Manual.fm Page 59 Wednesday, August 29, 2007 10:38 AM ORDERING PARTS AND ACCESSORIES To purchase parts and accessories, refer to the Cintiq Read Me file and see who to call for your region. You can also do the following: • To purchase parts and accessories in the USA or Canada, call 1.888.884.1870 (toll-free) or visit Wacom’s web site at http://www.wacomdirect.com (USA only). • To purchase parts and accessories in Europe, call +49 (0)180.500.03.75 or send an email to spareparts@wacom.eu.
12WX_Manual.fm Page 60 Wednesday, August 29, 2007 10:38 AM RADIO AND TELEVISION INTERFERENCE The equipment described in this manual generates, uses, and can radiate radio-frequency energy. If it is not installed and used properly – that is, in strict accordance with Wacom instructions – it may cause interference with radio and television reception. FEDERAL COMMUNICATIONS COMMISSION (FCC) NOTICE This device complies with Part 15 of the FCC Rules.
12WX_Manual.fm Page 61 Wednesday, August 29, 2007 10:38 AM INDUSTRY CANADA (CANADA ONLY) Industry Canada, Class B “This Class (B) digital apparatus complies with Canadian ICES-003” “Cet appareil numerique de la classe (B) est conforme a la norme NMB-003 du Canada.
12WX_Manual.
12WX_Manual.fm Page 63 Wednesday, August 29, 2007 10:38 AM WARRANTY SERVICE IN THE U.S.A. AND CANADA To obtain Warranty service within the U.S. or Canada contact: Wacom Technical Support Phone: 1.360.896.9833 Fax: 1.360.896.9724 Inquiry form: http://www.wacom.com/productsupport/email.cfm E-mail: support@wacom.com WARRANTY SERVICE OUTSIDE OF THE U.S.A.
12WX_Manual.fm Page 64 Wednesday, August 29, 2007 10:38 AM This page intentionally left blank.
12WX_Manual.fm Page 65 Wednesday, August 29, 2007 10:38 AM Wacom Technology Corporation Wacom Europe GmbH 1311 SE Cardinal Court Europark Fichtenhain A9 Vancouver, WA 98683 47807 Krefeld U.S.A. Germany Telephone Telephone General: +1.360.896.9833 General: +49.(0)2151.3614.0 Fax: +1.360.896.9724 Fax: +49.(0)2151.3614.111 Wacom Co., Ltd. Wacom Co., Ltd.
