USER MANUAL YPbPr + SPDIF To HDMI Converter Model No.
HDMI Converter (YPbPr to HDMI) DEAR CUSTOMER Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. 1.0 INTRODUCTION This is a component video (YPbPr) converter that allows older analog devices to be integrated seamlessly into the modern home theater. This adapter connects component video home theater devices to HDMI compliant digital monitors.
HDMI Converter (YPbPr to HDMI) Warranty Limited Warranty Environmental Operating Temperature Operating Humidity Storage Temperature Storage Humidity Power Requirement External Power Supply Power Consumption(max) Regulatory Approvals Converter Unit Power Supply Accessories Adapter AC Power Adapter User Manual 2 Years Parts and Labor 0 ℃ to +70℃ 10% to 85 % RH (no condensation) -10℃ to +80℃ 5% to 90 % RH (no condensation) 5V DC@2A 5W FCC,CE,UL UL,CE,FCC US standard, UK standard and so on English Version No
HDMI Converter (YPbPr to HDMI) 5.0 CONNECTION AND OPERATION Before installation, please make sure all devices you wish to connect have been turned off. 1) Connect the input sources into this product. (Input cables are optional) 2) Connect the HDMI device into the HDMI Output slot in the back of this product. 3) Insert the DC side of 5v power supply into this product and then connect 4) the AC side of the power supply into the wall outlet Attention: Insert / Extract cable gently. 55 Ruta Ct.
