WLM200NX MiniPCI network adapter provides leading 802.11a/ b/

/ n

performance

, supporting up to 300Mbps physical data rates and 200Mbps

of actual user throughput on both the uplink and dow nlink. With the dual-

band desi

n you will en

oy universal connectivity to any 802.11 device

through your w ireless AP or w ireless Router.

Built on Atheros chipset, it can be used w ith all draft I EEE 802.11n

compatible WLANs, and is ideally suited to be inte

rated into a wide

range of OEM devices.

Features

•

2.4/ 5GHz I EEE 802.11a/ b/ g/ n standard

•

Output Power of up to 20dBm @ a/ b/ g/ n Band

•

Support for up to 2x2 MIMO with spatial multiplexing

•

Four times the throughput of 802.11b/ g and 802.11a

•

Wireless Encryption and Authentication Supported

•

Transmission Power Control (TPC)

•

Enhanced performance with Atheros XSPAN technology Optimized for higher throughput

at long range

•

High Performance (up to 300Mbps physical data rates and 200Mbps of actual throughput)

with Low Power Consumption

•

Multi-Country Roaming Support (I EEE802.11d)

•

2 X U.FL Antenna Connector

•

Suitable for Embedded System or OEM Project

•

Affordable and I deal for a Variety of Applications

•

WLM200NX MINIPCI

2 x 2 802.11N MIMO mini-PCI Modules

Summary of content (5 pages)

PAGE 1
WLM200NX MINIPCI 2 x 2 802.11N MIMO mini-PCI Modules WLM200NX MiniPCI netw ork adapter provides leading 802.11a/ b/ g/ n performance, supporting up to 300Mbps physical data rates and 200Mbps of actual user throughput on both the uplink and dow nlink. With the dualband design you w ill enjoy universal connectivity to any 802.11 device through your w ireless AP or w ireless Router. Built on Atheros chipset, it can be used w ith all draft I EEE 802.
PAGE 2
Technical Specifications Chipset AR9220 Host I nterface Operating Voltage Pow er Consumption Antenna Connector PCI I nterface v2.3 (Type I I I -B Mini PCI form factor) 3.3 VDC 2.4W 2 x U.FL Antenna Connector I EEE 802.11a : I EEE 802.11b : 54Mbps 48Mbps 36Mbps 24Mbps 18Mbps 12Mbps 9Mbps 11Mbps 5.5Mbps 2Mbps 1Mbps 54Mbps 48Mbps 36Mbps 24Mbps 18Mbps 12Mbps 9Mbps Fallback to 5.5Mbps, 2Mbps, 1Mbps I EEE 802.11g : Data Rate 6Mbps 6Mbps automatically 20MHZ 1Nss: 65Mbps @ 800GI , 72.2Mbps @ 400GI (Max.
PAGE 3
802.11 a/ n HT20 MCS0 MCS1 MCS2 MCS3 MCS4 MCS5 MCS6 MCS7 MCS8 MCS9 MCS10 MCS11 MCS12 MCS13 MCS14 MCS15 -95/ -91dBm -94/ -90dBm -92/ -88dBm -88/ -84dBm -85/ -81dBm -81/ -77dBm -80/ -76dBm -77/ -73dBm -94/ -90dBm -92/ -87dBm -89/ -85dBm -86/ -82dBm -83/ -79dBm -78/ -74dBm -77/ -73dBm -74/ -69dBm ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB ± 2dB 802.
PAGE 4
COMPLIANCE INFORMATION FCC NOTICE This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
PAGE 5
OEM integration instructions: This device is intended only for OEM integrators under the following conditions： The module is only limited to installation in mobile applications. The antenna must be installed such that 20 cm is maintained between the antenna and users, and the transmitter module may not be co-located with any other transmit or antenna. The module shall be only used with the integral antenna(s) that has been originally tested and certified with this module.
