The love of sound is Biamp’s reason for being, and has been since the company was founded, over 30 years ago. Biamp has grown to be an acknowledged international leader in professional installed audio electronics. The company’s employees still share a passion for sound that resonates through every product and every decision the company makes.
Contents Amplifiers Record and Replay TOA, Rolls, Denon, Peavey, Niles, Biamp Denon, Denon Professional, TOA, Marantz Mixer Amplifiers 5 CD Players 51 Powered Mixers 8 Solid State Playback Devices 52 Vehicle Amplifiers 9 Solid State Recorder / Players 54 Power Amplifiers - Single Channel 9 DVD Playback 55 Power Amplifiers - Two Channel 10 Power Amplifiers - Four Channel 13 Mixers Power Amplifiers - Eight Channel 14 Rolls, Biamp, TOA, Peavey Power Amplifiers - Twelve Channel 15
Contents Speakers Network Systems Niles, TOA, Tannoy, Peavey TOA, Biamp Ceiling 82 IP Intercom 121 Speaker Software 87 Audio Transmission 124 Niles In-Wall Loudspeakers 89 In-Wall 90 Cables Pendant and Projector 91 Peavey, Key Digital, ProAV Cabinet 92 Bulk Cables 125 Column/Array 104 Terminated Audio Cables 127 Horn Speakers 108 Terminated Video Cables 128 Portable PA Megaphones 111 Test Equipment 129 Portable PA TOA, Rolls Peavey Powered Mixers 113 All-in-one 114
www.toa.com.au Mixer Amplifiers Amplifiers Mixer Amplifiers - Single Channel TOA A2000 Series • 3 mic and 2 aux inputs • 30, 60, 120, 240 watt models • 240 watt power amp with 100 volt line input See also P2240 Power Amps Page 7 Optional Accessories MB25B rack brackets Power Speaker Output Inputs Dimensions (mm) Weight (Kg) A2030 30 watts 100 volt, 70 volt, 4 ohm 3 x Bal. XLR Mic, 2 x Un-Balanced Aux 420 (W) × 100.9 (H) × 280.3 (D) 5 A2060 60 watts 100 volt, 70 volt, 4 ohm 3 x Bal.
www.toa.com.
www.audioproducts.com.au www.audioproducts.com.au Mixer Amplifiers Amplifiers Mixer Amplifiers - Single Channel ROLLS PA71Plus Micro Mix Power Amplifier A single microphone preamp and line level signal can be mixed together. Built-in 7 watt amp makes the PA71 the perfect amplifier for a small board room or classroom.
Powered Mixers www.peavey.com.au Amplifiers Powered Mixers Since 1968, with the introduction of the PA-3 system, Peavey has paved the way for portable sound. Following this tradition, the latest XR series powered mixers exhibit clever and unique features in powerful yet lightweight, easy to use packages.
www.toa.com.au Amplifiers Amplifiers Vehicle Amplifiers TOA CA SERIES • • • • Mobile amplifiers for car, bus etc Two phone jack (6.5mm) mic inputs AUX input for external equipment connection. Unidirectional dynamic microphone with talk switch Amplifier Power Speaker Output Inputs Dimensions (mm) Power Supply Weight (Kg) CA115 15 watts 4 or 8 ohms 1 x Auxiliary 178 (W) x 50 (H) x 132 (D) 10 – 16 VDC - 2.2 AMP 0.
Power Amplifiers www.peavey.com.au Amplifiers Power Amplifiers - Two Channel Low Impedance Peavey PV series amplifiers Featuring Peavey’s DDT™ distortion detection technique (which virtually eliminates distortion caused by over-driving the amplifier), the PV series is rugged, value-priced family of hardworking analogue amplifiers.
www.peavey.com.au www.niles.com.au Power Amplifiers Amplifiers Power Amplifiers - Two Channel Low Impedance Peavey IPR amplifiers Boasting a net weight as low as 3.2kg, the ground-breaking IPR Series utilises an advanced design that allows the engineers to dramatically reduce weight while increasing output power, reliability and thermal efficiency.
Power Amplifiers Amplifiers Power Amplifiers - Two Channel Low Impedance TOA DA250D • • • • • • • Two channel low impedance digital power amplifier 2 x 250 watt (4 ohm), 2 x 170 watt (8 ohm) Bridgeable output (1 x 500 watt 8 ohm) Input 1 can be sent to both outputs - switchable Independent power supply to each channel High efficiency 80 to 90% Compact design (1RU) only 5.
www.toa.com.
Power Amplifiers www.biamp.com.au Amplifiers Power Amplifiers - Eight Channel High/Low Impedance Biamp MCA Series Biamp Systems’ MCA Series amplifiers offer 8 channels of amplification within one chassis. All models in the MCA series include contractor friendly features that allow for total flexibility in system design. Add to this Biamp Systems’ now legendary bulletproof reliability and the MCA series becomes the perfect fit for your next project. All backed by a 5 year warranty.
www.niles.com.au www.denon.com.au Power Amplifiers Power Amplifiers - Twelve Channel Low Impedance Niles SI1230 Niles Systems Integration Amplifiers® deliver superb sound and reliability with features specifically tailored to the needs of the custom installer, including multiple turn-on modes, adjustable input level controls, cascade outputs, 12V triggers, and removable IEC power cords.
Microphones Microphones Handheld stage/performance AKG CCS D55S / D44S • Vocal/general-purpose microphones • Sturdy die-cast metal body • Rugged wire mesh cap with internal protective basket Easy to use microphone for applications ranging from hi-fi recording to karaoke and other speech recording applications. A good all-round basic microphone.
www.peavey.com.au Microphones Microphones Handheld stage/performance Peavey PVi2XLR • • • • • • • • high quality, cost effective on/off switch in handle clean, natural sound cardioid unidirectional polar response low pop and handling noise Rugged, die cast steel case Low-gloss black finish 6 meter XLR cable included Product Technology Pattern Frequency response Impedance Weight Special features Peavey PVi2 Dynamic Cardioid Unidirectional 50Hz - 16kHz 500 Ohms 0.
Microphones Microphones Head Worn AKG C520L / C555L • Head-worn microphone with continuously adjustable behind-the-neck headband • External shock mount for high mechanical-noise rejection • Miniature gooseneck for precise positioning near the user’s mouth AKG C577L • Premium flesh tone head worn microphone • Designed to be invisible and disappear on stage and on camera • Superior omnidirectional transducer as per CK77 Product Technology Polar Pattern Frequency response Dimensions Weight Special fea
Microphones Microphones Lapel AKG CK99L • Low-profile, cost efficient clip on microphone • Slight rise above 10kHz for added clarity • Bass roll off to suppress unwanted ambient noise AKG C417(L) • Affordable miniature condenser microphone • Broadband and flat audio reproduction • Available with standard XLR or Mini XLR giving flexibility for all broadcast, theatre and wireless applications AKG CK77WRL / C577WR • • • • Extremely small omnidirectional lavalier microphone Patented dual-diaphragm capsule f
Microphones Microphones Hanging mics AKG CHM99B (W) • • • • • • • Condenser Hanging Microphone Cardioid polar pattern 10 m (33 ft.
Microphones Microphones Goosenecks AKG Modular Series The AKG Modular Series is used worldwide and has proven its worth over many years. Bringing together a flexible array of gooseneck lengths, connectors, and interchangeable capsules, the Modular Series addresses three main needs of Installed Sound Contractors: Flexibility: With a range of 12 goosenecks (and hangers) and a selection of five capsules, the Modular Series offers unparalleled flexibility and can meet virtually and need.
Microphones Microphones AKG GN/HM Series Mics Series GN series GN E series GN ESP series GN E 5pin series GN 155 Set HM 1000 Integrated 5-pin XLR and enlarged LED ring. The LED ring is powered by an external supply and can, therefore, be controlled by external processors. For permanent or temporary installation into 5-pin XLRequipped bases or compatible shock mounts. Elegant, floor-standing, low profile gooseneck for use on stage, in TV studios or houses of worship.
www.toa.com.
Microphones Microphones Gooseneck AKG CGN 99 Series • • • • • • All the same price Planning simplified Budgets met and time saved Gooseneck and microphone capsule inseparable Rugged metal front grille protects the capsule and contacts Standard XLR connector with gold plated contacts Product Technology Polar Pattern Frequency response Dimensions Weight AKG CGN99C/S Condenser Cardioid 70Hz - 18kHz 380 x 13.
Microphones Microphones Boundary TOA EM600 • Electret condenser, omnidirectional “button style” boundary microphone • Freq response 30 Hz – 20 kHz • 120 ohm balanced • 9 – 52V DC phantom power required TOA EM700 • • • • Electret condenser, cardioid boundary microphone Freq response 35 Hz – 20 kHz 120 ohm balanced 9 – 52V DC phantom power required AKG CBL99 • Extremely small and inconspicuous, lightweight yet rugged • Delivers superior sound combined with outstanding ease of use • High sensitivity and lo
Microphones Microphones Boundary Crown MB3/MB4 • Supercardioid polar pattern for extended reach and clarity • PCC® technology (phase coherent cardioid) for clear and natural sound • Miniature design, virtually disappears when installed • LED indicator illuminates when mic is active • Mounts easily into tabletops, walls and ceilings Crown PZM10(LL) • Hemispherical polar pattern; clear, intelligible pickup of speech • Low profile, cylindrical design, perfect for discreet wall or tabletop installations • PZM
Microphones Microphones Desktop / Paging AKG D58 • • • • Hypercardioid microphone for use in noisy environments Small and inconspicuous Noise cancelling close-talking microphone Extremely rugged AKG DGN99 / 99E • • • • PA microphone with rugged, all-metal body Frequency response optimised for intelligibility Long useful life even in tough day-to-day usage Suppression of unwanted ambient noise AKG DST 99S • • • • DGN99 mounted on a table stand with on/off switch Fixed coiled XLR cable Optimized for int
www.toa.com.au Microphones Microphones TOA Hand Held Paging Mics TOA PM306 • Omnidirectional unbalanced barrel type paging microphone • Curled cable and 5 pin DIN plug TOA PM120 • Handheld unbalanced unidirectional paging microphone C • Curled cable and a 6.35mm phono plug • 250 ohm impedance TOA PM222 • Handheld unbalanced unidirectional paging microphone • Curled cable and a 6.
Microphones Microphones Accessories Rolls PB23 Rolls PB224 • Phantom power supply for single microphone • Small compact design • Utilises switching regulators for stable voltage performance • +48 volt phantom power; 12-18 VDC power supply • Phantom power supply for two microphones • Operates on two 9V batteries or 12-18VDC input • Utilises switching regulators for stable voltage performance • +48 volt phantom power AKG ST45 AKG ST46 Low-profile table stand w/off-centre threaded stub.
Wireless Microphones www.toa.com.au Microphones Wireless Microphone Receivers TOA 5000 Wireless Microphone System The TOA 5000 Series wireless microphone system provides a full range of wireless microphones optimised for both general and specific applications, all compatible with accompanying tuner units and ancillary equipment. Up to 14 channels can be used simultaneously with a line of sight range of up to 120 metres.
Wireless Microphones www.toa.com.
Wireless Microphones www.toa.com.au Microphones Wireless Microphone Transmitters TOA WM5220 • • • • • • Electret condenser cardioid microphone 64 selectable channels (14 used simultaneously) Maximum input level: 126 dB SPL ON/OFF switch prevents the microphone from rolling Single AA battery operation, low-battery indicator Built-in antenna TOA WM5270 • • • • • • Dynamic cardioid microphone designed for vocal use 64 selectable channels (14 used simultaneously) Max.
Wireless Microphones www.toa.com.
Wireless Microphones Microphones Wireless AKG Perception Wireless • • • • • • 30 MHz tuning bandwidth (depending on local frequency plans) 8 hours of operation on a single AA size battery Gain control on handheld transmitter Smallest and lightest bodypack transmitter in its class Compatible with all AKG MicroMics Low battery indicator System Trans type Technology Pattern Frequency bandwidth Output connector Trans power Battery type Battery life (NiMH) simultaneous channels per installation Incl
AKG WMS4500 The WMS4500 true diversity system provides maximum ease of use and the widest range of functions in its class. Its accurate battery life readout is a previously unavailable, invaluable advantage in live sound applications. A complete line of accessories makes the WMS4500 series your first choice for every application. Auto Setup and Environment Scan functions automatically analyse the local RF environment, find usable frequency groups, and set frequencies.
Wireless Microphones Microphones AKG WMS4500 AKG HT4500 • 50mW RF output for maximum immunity to interference and dropouts • Operates for up to 15 hours on AA size dry batteries, 12 hours on optional BP 4000 battery pack with integrated Smart Battery Management System • • • • 30 MHz wide UHF band Choice of six interchangeable microphone capsules Backlit display and jog switch for ease of use Charging contacts for easy battery charging on optional CU4000 drop-in charger Capsules D5WL1 System Type SR45
Wireless Microphones Microphones AKG Wireless Microphone Management System AKG HUB 4000Q The HUB 4000 Q enables you to connect up to eight AKG devices to any Harman Professional HiQnet system. It is a true plug and play device, so all you need to do to install the HUB 4000 Q is connect it to your computer via a commercial CAT-5 network cable. For large wireless systems, you can of course add several HUB 4000 Qs using standard Ethernet switches (or routers, wireless hubs, etc.
Wireless Microphones Microphones AKG DMS700 V2 AKG’s revolutionary DMS 700 is designed to deliver the very best audio quality, channel quantity and quick and easy operation. Up to 155 MHz frequency range of transmitters and receiver gives the user the necessary flexibility even in a crowded RF environment, and the state of the art encryption offers security for sensitive audio transmissions. Ideal for broadcast applications, conferences, courtrooms, houses of worship, stage and music performances.
Wireless Microphones Microphones AKG Wireless Accessories CU400 Charger CU4000 Charger • • • • • • Charger with two charging compartments for two HT 4500, PT 4500 transmitters, or BP 4000 battery packs • Smart current management system permanently monitors battery parameters to prevent over charging and suggest recovery cycle • Microprocessor controlled charge/discharge monitoring function • One-hour quick charging of two transmitters Drop-in charging Two universal charging slots Charging time <2 hours
Wireless Microphones Microphones Revolabs Revolabs delivers innovative wireless audio systems for both enterprise collaboration and professional audio applications. Revolabs products are used throughout the world and across a wide range of industries including houses of worship, corporations, financial services, education, medical, legal and more.
Wireless Microphones Microphones Revolabs Receivers Revolabs HD Single and HD Dual receivers The HD Single and HD Dual receivers are compact, table-top units designed for use where just one or two microphones are required: in a classroom, lecture theatre or small conference room. These receivers support the full range of Revolabs HD microphones, and offer a return audio channel from receiver to microphone, that can be used for translation, prompting or any other application.
Wireless Microphones Microphones Revolabs Receivers Revolabs HD Executive receivers The Revolabs HD Executive receivers support either four (HDEXEC4) or eight (HDEXEC8) microphones simultaneously from a slim 1RU receiver. These receivers, which are supplied with matching fourmicrophone or eight-microphone charging docks, support the full range of HD microphones. A linking bus allows up to six receivers to operate simultaneously in a coverage area: up to 48 microphones, with no complex frequency planning.
Wireless Microphones Microphones Revolabs HD microphones All mics share the following features: • Single button controls muting and pairing • LED indicator shows mute and pairing status • Return audio available on 3.5mm connector • Simple drop-in battery charging on the charging dock • 50Hz – 20kHz audio bandwidth • Impervious to GSM phone interference • 128-bit encryption • Wireless frequency: 1.88GHz – 1.
Wireless Microphones Microphones Revolabs HD microphones - Accessories Revolabs extension antennas • Extend antennas up to two metres from the front of the receiver • Use to overcome physical or RF obstructions • Supplied with cables, connectors, rack panel to mount antennas (use antennas supplied with the receiver) • Available for four-channel receiver (HDEXEC4) and eight-channel receiver (HDEXEC8) Revolabs Always-On adaptor • Plug-in adaptor that delivers full-time power to a Revolabs HD microphone • Us
Revolabs FLX - Available late 2011 The Revolabs FLX™ is designed specifically for mid- to small-sized conference rooms, executive offices and SoHo environments. Unlike traditional conference phones, the wireless Revolabs FLX is composed of several distinct components, giving unprecedented freedom with respect to placement and accessibility of the speaker, microphones and dial pad. Microphones and speaker can be placed throughout an office to optimise sound quality.
Wireless Microphones www.toa.com.au Microphones Wireless Infra-Red TOA’s new wireless microphone system uses infrared transmission, thereby eliminating the problems associated with RF (VHF/UHF) type systems.
Wireless Microphones www.toa.com.
Headphones AKG Headphones K702 • Open-back dynamic reference headphones ideal for monitoring, mixing and mastering applications • Award winning flat wire voice coil • Patented Varimotion two-layer diaphragm • “3D Form” ear pads for perfect fit • Individually tested and numbered K271MKII • Professional circumaural hi-fi stereo studio headphones for onstage and studio use • Leatherette and velvet ear pads • High noise attenuation • Automute feature mutes headphones when they are taken off • Patented Varimo
Headphones AKG Headphones K141MKII • • • • • • Professional hi-fi stereo studio headphones Undistorted sound even at high volume levels Leatherette and velvet ear pads Semi-open supraaural earphones Patented Varimotion speakers Single-sided, detachable 3 m cable and 5 m coiled cable K121S • • • • • Semi-open Supraaural headphones Self-adjusting headband Entry level professional headphones for various applications Equipped with a 3.5/6.
Headsets AKG Headsets HSC 171 / HSD 171 • • • • • • Professional headset derived from K 171 Studio headphones Closed-back earphones Shock mounted condenser (HSC) or dynamic (HSD) microphone Switchable bass cut filter Noiseless microswitch for automatic microphone muting Lightweight design for long usage periods HSC 271 / HSD 271 • • • • • • Cable 50 HSD 171 HSD 271 HSC 171 Professional headset derived from K 271 Studio headphones Closed-back earphones for optimum ambient-noise attenuation Shock mo
Record and Replay Record and Replay CD Players Denon Professional DNC615 CD player • • • • • Professional quality single tray CD player Shock proof memory (approx 10 sec) Auto cue (preset selectable) Pitch control (+/- 12%) MP3 playback Denon Professional DNC620 CD player • • • • • • Next generation broadcast CD player WAV and MP3 playback Cue to music (with dedicated button) Pitch control +/- 12% Slot load mechanism RS232 control Denon Professional DNC635 CD player • • • • • • Installation grade sing
Record and Replay www.toa.com.
Record and Replay Record and Replay Solid State Playback Devices Denon Professional DNF300 Digital Audio Player • Plays uncompressed CD-quality WAV (44.
Record and Replay Record and Replay Solid State Recorder / Players Denon Professional DNF450R Digital Audio Recorder • • • • • • • Records/Plays WAV and MP3 files to/from SD/SDHC cards Balanced and unbalanced audio input, unbalanced (RCA) output Serial Remote (RS232) Contact closure remote control (foot pedal remote) Connecting to PC via USB Power on auto play Optional RCF400 controller Denon Professional DNF650R • Records and plays back WAV and MP3 files to/from SD/SDHC cards/USB drives • +20%/–40% Pitc
Record and Replay Record and Replay DVD Playback Denon Professional DNV310 DVD player • • • • • Defeatable on screen icons User-definable wallpaper NTSC/PAL conversion HDMI input RS232 control Tuners HR78/ HR31 Digital AM/FM Tuner with rack brackets • • • • • 18 presets (12 FM and 6 AM) Large LCD digital display Auto search up and down Output Level control RCA and 1/8” (3.
Mixers Mixers Strip Mixers Rolls RM65B 6 Channel Hex Mix Mixer • • • • • • 6 x XLR microphone inputs and 6 x 1/4” line input jacks Individual phantom power switches for each microphone Front panel headphone output Monitor, effects send and pan pots on each channel Treble and bass tone controls for each channel Right and left master volumes and FX return master channel Rolls RM67 Microphone/Line Mixer • 3 x microphone XLR inputs with phantom power • 4 x stereo source inputs • Tone controls for each mic i
www.biamp.com.au Mixers Mixers Strip Mixers Biamp 301 and 601 Mixer The 301 & 601 are single rack space, three input and six input mic/ line mixers. Each input channel uses a differentially balanced, discrete transistor mic/line preamplifier for low noise and low distortion performance. Special features, including limiters and remote level control, make the 301 and 601 extremely versatile.
Mixers Mixers Strip Mixers TOA M633D Pristine digital audio quality with 24bit - 48kHz A/D & D/A Inputs: • 6 mono mic/line (Phoenix) and 3 stereo unbalanced line (RCA) Outputs: • 2 balanced mono and 1 stereo (phoenix) plus 1 recording (RCA) Easy operation: • Analogue user interface, no PC setting is required. No more feedback: • • • • Intelligent feedback suppressor (FBS) built in. Feedback suppressor automatically searches out and reduces sensitive frequencies that contribute to acoustic feedback.
www.peavey.com.au Mixers Peavey PV Series Mixers The PV® Series compact mixers offer durable construction and excellent sound quality at an unbelievably low price. The PV Series has long been the benchmark of performance and value in audio, and the new PV mixers reinforce this legacy. With the same reference-quality microphone preamps used in Peavey RQ™ Series mixers and an astonishingly low THD (Total Harmonic Distortion) of 0.
www.toa.com.au Mixers Mixers Console Mixers TOA D2000 Series Digital Mixing System The TOA D-2000 Series Digital Mixer is designed to provide highly flexible mixing for small to medium-sized applications. Up to four Digital Mixing Processor Units and Remote Control Units can be connected to suit the actual size of the venue. The D2000 accepts the D901 series modules and control options.
Signal Processing Signal Processing Equalizers Peavey PV215EQ • • • • • • • • 1 RU dual channel (15 bands per channel) 12dB boost/cut per band 80 Hz 24 dB low cut filter XLR balanced inputs and outputs bypass switch with status LED centre-detent control sliders five year warranty Peavey PV231EQ • • • • • • • 2RU dual channel (31 bands per channel) switchable 6dB or 12dB boost/cut per band variable low cut and high cut filters per band output level LEDs per band XLR balanced inputs and outputs five year
Signal Processing Signal Processing Speaker processors Peavey VSX26 • • • • • • • • • • • • • • • • • • • 2 input/6 output loudspeaker DSP management system 48 kHz sample rate, 24-bit 256x over-sampled Delta-Sigma AD, DA USB A port for load/save of storage parameters from USB key XLR inputs and outputs, AES-EBU digital input +24dBu inputs and outputs uilt-in signal generator (white, pink, sine) fully adjustable crossover points easy-to-read LCD screen features per input: 27-band Graphic EQ Autograph®algor
Signal Processing Signal Processing Ducker Rolls DU30B Mic Preamp Audio Ducker • • • • Ducks signal on RCA line input under signal on the mic or aux input Mic preamp with level control +12 VDC phantom power Variable sensitivity, duck depth, and duck release time Stereo Converter Rolls MB15B ProMatch Stereo Converter • • • • • Stereo direct box Stereo RCA to stereo XLR Stereo 3.
www.toa.com.au DSP Systems DSP Systems TOA M9000M2 The TOA M9000M2 Digital Matrix Mixer combines a modular matrix mixer and digital signal processor (DSP) in a compact 2RU package. This versatile modular unit is ideal for multi-zone paging, music distribution and room-combining applications. Setup is achieved via the GUI software which enables easily configured, custom systems with up to eight mic/line inputs and eight outputs.
Networked Media Systems Tesira Tesira changes the scale of possibilities for the way AV systems are designed, installed, networked and experienced. And by changing the scale of what’s imaginable, Tesira gives you the power to succeed like never before. Tesira, the first truly scalable media system for digital audio networking using Audio Video Bridging (AVB), delivers smarter system modularity and breakthrough performance.
Networked Media Systems www.biamp.com.au Networked Media Systems Tesira Servers Server I/O The Tesira SERVER-IO is a digital network server. It is factory configured with one DSP-2 card and is capable of handling up to two additional DSP-2 cards. The SERVER-IO can be configured with one 420 x 420 channel AVB card or one AVB card and one or two 32 x 32 channel SCM CobraNet cards. The SERVER-IO can support up to 12 Standard Tesira I/O cards for up to 48 channels of audio I/O (e.g.
Networked Media Systems www.biamp.com.
Networked Media Systems www.biamp.com.au Networked Media Systems Tesira Expanders EX-IN – 4 Mic/line input AVB expander The Tesira EX-IN is a half-rack expander box for use with Tesira SERVER and SERVER-IO devices. The EX-IN is a 4 channel mic/line input expander. The expander communicates with the Tesira AVB network for audio networking, configuration and control and is powered by PoE+.
Networked Media Systems www.biamp.com.au Networked Media Systems Tesira Expanders EX-MOD The Tesira EX-MOD is a modular expander device that is designed for use with Tesira SERVER and SEVER-IO devices. It can be configured with up to three 4-channel input and/or output cards for a maximum of 12 channels. The EX-MOD expander communicates with the Tesira AVB network for audio networking, configuration and control.
Networked Media Systems www.biamp.com.au Networked Media Systems Nexia Processors The entire Nexia® digital sound processor lineup is designed with a network-friendly open architecture to help you create economical, intuitive solutions. You’ll save time, effort and ultimately money.
Networked Media Systems Audia Processors Biamp’s revolutionary Audia® Digital Audio Platform seamlessly integrates powerful hardware and intelligent software for unheard of design and networking potential. In fact, Biamp is one of the first manufacturers to make use of CobraNet® by integrating it into our Audia DSPs, pioneering its use in high profile installations. A single Audia unit can provide the power of an entire rack of processors at your fingertips.
Networked Media Systems www.biamp.com.
Networked Media Systems AudiaFUSION AudiaFUSION is a product so innovative we had to create a completely new category to describe it: Networked Amplified Processor. A full-featured DSP with enough power to drive a system of its own, AudiaFUSION is a leap forward in audio technology. It allows you to configure systems that are decentralized, placing components close to speakers for reduced labor and material costs.
Networked Media Systems www.biamp.com.au Networked Media Systems Biamp Systems Control software The core power of Biamp Systems’ products lies in its software. Be it the intuitive design interfaces, the extensive processing library, the logic engine or the incredible power of Biamp’s adaptive algorithms. Whichever platform you choose for your next project rest assured that Biamp’s software packages will unlock your systems full potential.
Networked Media Systems CobraNet Expansion Units A convenient and cost-effective way to expand the power of an Audia system. Using Audia’s highly evolved CobraNet® features, now you can create systems you never even dreamed were possible. The range of Mini-Expanders stretch dollars and Audia systems even further by adding inputs or outputs exactly where they’re needed. The option to use Power over Ethernet (PoE) or local power makes them even more versatile.
Networked Media Systems www.biamp.com.au Networked Media Systems Control Devices RED-1/RED-1F Remote Ethernet Devices Offers a simple, intuitive interface for end users and can be installed and configured to fit the unique needs of a particular application • Connects via standard CAT-5/6/7 cabling and is powered over Ethernet (PoE) • Adjustment and/or initiation of 32 selectable system volumes and actions • Volumes control capabilities including inputs, outputs, matrix cross-points, etc.
Networked Media Systems Vocia - Networked Paging and Voice Evacuation Distributed networked smarts. Flexible, scalable features. No-nonsense Biamp quality. Move forward with confidence – with Vocia. Your paging and voice evacuation system simply has to work. With Vocia®, the work to install and maintain your system becomes simple. Gone are precarious centralised processing and routing. Instead, every Vocia component contains memory and processing resources that communicate intelligently across your network.
Networked Media Systems www.biamp.com.au Networked Media Systems Vocia Audio Inputs Paging Stations All Vocia paging stations feature embedded DSP and on-board memory, standard and advanced public address functionality. All devicespecific configuration information is stored locally, which means the DS-4 does not rely on a centralised controller for processing and page routing. All microphones are completely monitored ensuring system reliability and performance with comprehensive logging and reporting.
Networked Media Systems Vocia Amplifiers The VA series is a range of multi-channel digitally networked amplifiers. These units are smart enough and tough enough to make sure your messages get heard. Each model has embedded DSP and on-board memory to process and store messages and configuration information locally. They also include comprehensive fixed-chain digital signal processing and receive audio and control signals over standard IP and CobraNet® networks.
Networked Media Systems www.biamp.com.au Networked Media Systems Vocia Controllers ANC1 The ANC-1 allows automatic, adaptive volume adjustment based on ambient noise sensing in reaction to changes in the environment. The ANC-1 is a networked device for use with the Vocia amplifier range. The Vocia software interface permits comprehensive adjustment of ANC parameters and utilizes IEEE compliant Power over Ethernet (PoE) technology.
Networked Media Systems www.biamp.com.au Networked Media Systems Vocia Servers MS1 The MS-1 is a networked message server that supports multiple paging functions within a Vocia system—including message playback, event scheduling, VoIP paging interface, logging and remote access. The MS-1 is the gatekeeper to the Vocia world, unlocking the full capabilities of the Vocia platform.
www.niles.com.
www.toa.com.au Speakers Speakers Ceiling, High Impedance TOA PC648R/PC658R • Entry level 100 volt line ceiling speakers • Spring clamp mechanism for easy speaker mounting to the ceiling • PP Resin frame and metal mesh grille Impedance Power Handling Sensitivity (1W/1M) Frequency Response PC648R 100 volt line 6W 89dB 120 Hz - 18kHz PC658R 100 volt line 6W 90dB 70Hz - 16kHz Cutout (mm) Depth (mm) Weight (kg) 120 mm single Cone 145 70 0.465 150 mm single cone 170 70 0.
www.toa.com.
Speakers Speakers Ceiling, Switchable High/Low Impedance Tannoy CVS Series Medium Format Ceiling Speakers The Tannoy CVS series has been developed to deliver the best possible performance / price balance. CVS speakers are specifically designed for applications requiring the combination of sound quality for music and speech reinforcement with reliability, intelligibility and value for money.
Speakers Speakers Ceiling, Switchable High/Low Impedance Tannoy CMS Series Premium Quality Discrete In-Ceiling Loudspeakers CMS401DCE CMS401E CMS501 CMS601 CMS501DC CMS601DC CMS801DC CMS801SUB The CMS (Ceiling Monitor System) series provides the premium audio solution for a high performance ceiling loudspeaker installation.
www.toa.com.au Speaker Software TOA Speaker Placement Software TOA Speaker Placement Viewer is the easy way to simulate the amount of speakers necessary in a room. In addition to all TOA Public Address and ProSound speakers the latest version 2.0 includes the possibility to simulate the TOA Line Arrays as well.
Speakers Speakers Speaker Software Ease Address for Tannoy EASE Address is a design verification software package that enables system designers to accurately position, model and confirm ceiling distributed speaker systems utilising Tannoy loudspeaker products. Unlike conventional 2D ceiling speaker software, EASE Address allows for complex room shapes with varying ceiling heights.
www.niles.com.
Speakers Speakers Tannoy In-Wall Tannoy In-wall Series Many in-wall and ceiling loudspeakers are designed simply to reproduce sound without any consideration for ultimate audio quality and vocal articulation. Not so with Tannoy installation products. Tannoy speakers are monitor quality systems based on the company’s expertise in the manufacture of premium quality cabinet loudspeakers and studio monitors.
Speakers Speakers Pendant and Projector TOA PE64/PE304 Pendant Speakers TOA PJ64/PJ304 Projection speakers • • • • Repaintable enclosure designed to mimic the look of a light fitting Sturdy cable extendable up to 5 meters with the pendant models Adjustable wall bracket for the projector models 100 volt line with an 8 ohm option on the PE and PJ 304 PJ64 PE64 PJ304 PE304 Colour Impedance Power Handling Sensitivity (1W/1M) Frequency Response Drivers Dimensions (mm) Weight (Kg) PE64 White 100
www.toa.com.
www.toa.com.
www.toa.com.
www.peavey.com.au Cabinet Peavey PV Series Hartley Peavey founded Peavey Electronics on the principle of making high-quality, professional gear that sounds great but won’t break the bank. Peavey has been honing that art since 1965, and no sound reinforcement line combines performance and value like the PV Series. A full range of enclosures, subwoofers and monitors, the PV Series stacks up with heavy-duty loudspeakers, titanium compression drivers and impressive high-power handling.
www.peavey.com.au Speakers Speakers Cabinet Peavey PR Series Available in passive and active (powered) versions, the PR Series delivers superior sound quality by utilising advanced materials, like the light weight, roadworthy, moulded polypropylene exteriors. The PR family features black powder-coated steel grilles that provide driver protection and a professional appearance. These speakers can be used on the floor, be pole mounted or flown via top and bottom flying inserts.
www.peavey.com.au Cabinet Peavey SP Series Peavey’s reputation for reliability and innovation starts with the SP Series, and with good reason: for more than three decades, these renowned loudspeaker enclosures have been the proving ground for many of the company’s enduring innovations in sound reinforcement. SP Series enclosures are built to last in the U.S.A.
Speakers Speakers Cabinet Tannoy DVS SERIES STYLISH SURFACE MOUNT LOUDSPEAKERS Designed for a wide variety of discrete small scale sound reinforcement applications, DVS Series is an ultra-compact surface mount loudspeaker of exceptional value and acoustic performance, designed for commercial, professional and residential applications where environmental durability and high quality sound reproduction are required. DVS Series products are rated IP64.
Cabinet Tannoy DI SERIES ALL WEATHER / GENERAL PURPOSE SURFACE MOUNT The Tannoy Di Range is a high performance, ultra compact, full bandwidth series of passive surface mount loudspeakers. They are fully optimised for indoor or outdoor use in professional or residential applications where environment durability and high quality sonic performance are required. All the passive models in the range are weather resistant; rated IP64 to EN60529.
Speakers Speakers Cabinet Tannoy VX SERIES Passive Sound Reinforcement Loudspeaker Range Conceived, engineered and built with precision in the United Kingdom, the VX Series represents the latest evolution of Tannoy’s core philosophies in professional loudspeaker design. There are 10 passive models in the range, combining next-generation Dual Concentric™ driver technology with smart, ergonomic, portable and install-friendly cabinet designs.
Speakers Speakers Cabinet Tannoy VXP SERIES LAB.GRUPPEN POWERED SOUND REINFORCEMENT LOUDSPEAKERS VXP Series combines the class-leading performance of the passive VX Series with Lab.gruppen’s latest green star rated Integrated IntelliDrive Energy Efficient Amplifier module, bringing ultra reliable and perfectly matched power to the equation for audible superiority in a self-powered box. • • • • • • • • • Full range powered installation / transportable loudspeaker Integrated Lab.
Speakers Speakers Cabinet Tannoy VQ SERIES PASSIVE SOUND REINFORCEMENT SPEAKERS Industry leading pattern control and sensitivity are just the tip of the iceberg with VQ. Hifi sound at concert volumes is the real story. These systems just need to be heard to be believed. Infinitely modular and powerful, these audiophile PA building blocks can be scaled to offer precise sound coverage of virtually any venue.
Speakers Speakers Cabinet Tannoy VQ LIVE Active, Dsp And Road-Ready Live Sound Reinforcement VQ LIVE offers significant and tangible benefits over many existing live sound systems: sonic superiority, fewer boxes required, lower costs and full VNET implementation (allowing system setup and ongoing venue network control).
www.toa.com.
www.toa.com.au Speakers Speakers Column/Array TOA Type H Column Line Array Column line array available in long or short models either, straight or with a 20 degree bottom curve Multiple 70mm wide range drivers provide narrow dispersion and constant SPL levels Bass reflex slim-line design (84mm wide) Mounting options include wall mount, pan/tilt, flying and pole mount options Two straight models can be joined for larger rooms FB120 (B/W) sub-woofer can be used if required.
www.toa.com.au Speakers Speakers Column/Array TOA Type S Column Line Arrays • Two-way bass reflex column line array available as either straight or curved design • Each unit contains 32 speaker elements (eight bass/mid drivers and 24 dome tweeters) • Multiple units can be joined for larger venues • Also available in sealed weather resistant version • Mounting options include wall mount, pan/tilt, flying and pole mount options • FB120 (B/W) sub-woofer can be used if required.
Column/Array Tannoy QFLEX DIGITAL BEAM-STEERING ARRAY LOUDSPEAKERS QFlex is an award winning range of digitally steerable, multi-channel, array speaker systems for the professional installation market.
www.toa.com.au Speakers Speakers Horn Speakers TOA CS Series Music Horns CS64 CS154 Impedance Wide-range paging horn for voice paging, background music and tone signalling distribution Weather-resistant to withstand demanding environmental conditions • Constant directivity coverage (CS-154/CS-304) • High Sensitivity: up to 98 dB (1 W/1 m) • Moisture-resistant 120 mm speaker component (4.
www.toa.com.au Speakers Speakers Horn Speakers TOA TC Series Paging Horns • Aluminium paging horn speakers for voice paging and tone distribution in larger areas • High Sensitivity (1W/1M): up to 110 dB (1 W/1 m) • Built-in 100 V transformer (“M” models) with screwdriveradjustable power tap, 8 ohm models also available • IEC IP-65 compliant for dust and moisture-resistance • Wide temperature range: –20°C to +55°C • Phenolic loudspeaker diaphragm prevents deformation from heat and moisture.
www.toa.com.au Speakers Speakers Horn Speakers TOA DH110/DH120 Straight Horns • Long throw straight horn designed for long distance applications • Available as either a single throat (DH110) or twin throat (DH120) version • Accepts either one or two TU series drivers DH120 DH110 Impedance Power Handling Sensitivity (1W/1M) Freq. Response Dimensions (mm) Weight (kg) DH110 - - 110dB * 180 Hz - 6 kHz* 518 dia - 968 (D)* 5.3* DH120 - - 110dB * 180 Hz - 6 kHz* 518 dia - 884 (D)* 5.
www.toa.com.
www.toa.com.au Portable PA Portable PA Portable PA Megaphones TOA 30 watt Megaphones ER2230W/2930W • • • • • • ER2230W Shoulder strap type Built in whistle tone 30 watt rated output power, range up to 800 metres Auxiliary line level and mic inputs ER2930W accepts WTU4800 for wireless applications “D” cell batteries or 12 VDC power supply ER2930W Model Colour Type Power Whistle UHF Capable Aux Line Input Mic Input Weight (kg) Power Supply ER2230W Grey Shoulder Strap 30 W Y N 1 1 3.
www.peavey.com.au Powered Mixers Since 1968, with the introduction of the PA-3 system, Peavey has paved the way for portable sound. Following this tradition, the latest XR series powered mixers exhibit clever and unique features in powerful yet lightweight, easy to use packages.
www.peavey.com.au Portable PA Portable PA All-in-one Peavey Audio Performer Pack A single box solution for portable audio needs. Ideal for schools, function centres, etc.
Conference Systems Conference Systems AKG CS5 Conference System Communication is a matter of confidence Confidence is the basis of success in everyday life. When it comes to conferencing, confidence in the failsafe quality of the audio system is equally important – after all, the audio system must reliably handle incredible amounts of information for delegates, observers, and interpreters every second.
Conference Systems Conference Systems AKG CS5 Conference System CS5 BU • • • • Digital controller for any system size Complete with all inputs and outputs needed for complex systems Integrated infrared signal modulator Independent or computer controlled operation CS5 DU • Choice of microphones for every kind of system and room acoustics • 3 + 1 language channels independently selectable for two users • Yes/no voting function CS5 VU • • • • • Choice of microphones for every kind of system and room acous
Conference Systems TOA TS770 System TOA’s TS-770 Cabled Conference System is ideal for conferences and meetings in government, corporate, educational and hotel applications. The system provides communications for conferences and boardrooms. The easy to use TS-770 Series is comprised of the TS-770 Central Unit supporting up to 70 chairman/delegate stations. This is expandable to 210 if desired. The TS775 allows connection to a PC or Telephone for participation of external delegates.
Conference Systems www.toa.com.au Conference Systems TOA TS800/TS900 SYSTEM TOA’s TS Series Infrared Conference Systems are ideal for conferences and meetings in corporate, educational and hotel applications. The system provides secure wireless communications between delegates for conferences and boardrooms and the cordless operation eliminates all connecting cables typical of more traditional systems.
Conference Systems www.toa.com.au Conference Systems TOA TS800/TS900 SYSTEM TS901 Chairperson Unit • Voting function • Priority button for automatic over-ride of delegate stations • Built-in speaker automatically turns off when microphone is activated • Adjustable monitor volume, headphone output • Microphone options: - TS903 or TS904 (see below) Power options: • BP900CE rechargeable lithium-ion battery (requires BC-900UL charger) • 7.
Conference Systems www.toa.com.
www.toa.com.au Networked Systems Network Systems IP Intercom - TOA N8000 IP Intercom The newly expanded N-8000 Series IP Network Intercom offers flexible communications for up to 3,072 stations on existing corporate local and wide area data networks. Built on TOA’s proven NX100 network audio technology, the new IP Intercom products occupy minimal network bandwidth (130 kbps maximum) for station-to-station calls and can be controlled and monitored through software or web browser.
Networked Systems www.toa.com.au Network Systems IP Intercom - TOA N8000 IP Intercom TOA N8000DI Direct Select I/O Unit • 32 contact closure I/O • Provides control interface to CCTV, door access and other external systems. • Events may be activated by contact closures or master station dialling commands.
www.toa.com.
Networked Systems www.toa.com.au www.biamp.com.au Network Systems Audio Transmission TOA NX100 Network Audio Adaptor The TOA NX-100 is a reliable and easy to use solution for transporting mic or line-level audio signals over IP-based local and wide area networks (LAN/WAN), as well as the Internet. Applications include wide area paging, background music or messaging audio distribution for airports, convention centres, railway stations and transit systems.
Cables Cable Bulk Cables ProAV CI162 • • • • • • • 2-core speaker cable with overall sheath 16AWG per core 65 strands for flexibility PVC sheath and dielectric UL/CL3 rated for in-wall or in-ceiling use Metre marked (reverse metres) Supplied in 152m pull-through box ProAV CI164 • • • • • • • 4-core speaker cable with overall sheath 16AWG per core 65 strands for flexibility PVC sheath and dielectric UL/CL3 rated for in-wall or in-ceiling use Metre marked (reverse metres) Supplied in 152m pull-through bo
Cables Cable Bulk Cables ProAV Cat6 • • • • • • High speed Cat6 data cable (350MHz) 23AWG bare copper conductors Inner spacer to maintain formation and minimise crosstalk Metre marked on outer jacket Supplied in 305m pull-through box Available in blue ILC100M • Flat copper tape for under-carpet induction loop (hearing aid) installation • Overall size 15mm x 0.45mm • 2.
www.peavey.com.au Cables Cable Terminated Audio Cables Peavey XLR cables • Heavy duty professional cable with industry-standard XLR connector on each end • 10/25/50 foot lengths (3.0/7.6/15.2m) Peavey Speakon cables • 16 gauge professional speaker cable with NL2FC Speakon connector on each end • 25/50 foot lengths (7.6/15.2m) Peavey 6.35mm speaker cables • 16 gauge professional speaker cable with 6.35mm connector on each end • 25/50 foot lengths (7.6/15.
Cables Cable Terminated Video Cables ProAV Component • • • • Precision 24K gold plated connectors Multi-strand copper conductors provide excellent signal transfer Dual-shield design for interference-free pictures 1m, 2m or 4m lengths ProAV HDMI • • • • 24K gold plated connectors High speed with Ethernet (1080p) Dense multi-shield provides optimum isolation Supplied with one 180degree swivel adaptor to allow connection in tight places (behind equipment) • 1m, 2m, 3m and 4m lengths Key Digital Red Iguan
Test Equipment CS1000 Cable Scanner The CS1000 is more than just a cable tester. It also tests phantom power voltage and phase, as well as cable phasing (polarity). It tests NINE different types of cable ends; banana, 1/4”, 1/8” (3.5mm), RCA, XLR, Speak-On, 7-pin MIDI, RJ11 (Telephone), and RJ45 (Ethernet and CAT 5). Features • Tests 9 different types of cable ends: banana, 1/4”, 1/8” (3.
