Release Notes for Cisco 7000 Family for Cisco IOS Release 12.1 T December 06, 2000 Note You can find the most current Cisco IOS documentation on Cisco.com. These electronic documents may contain updates and modifications made after the hardcopy documents were printed. These release notes for the Cisco 7000 family describe the enhancements provided in Cisco IOS Release 12.1(5)T1. These release notes are updated as needed. For a list of the software caveats that apply to Release 12.
Contents Contents These release notes describe the following topics: • System Requirements, page 2 • New and Changed Information, page 48 • MIBs, page 88 • Important Notes, page 89 • Caveats, page 93 • Related Documentation, page 93 • Obtaining Documentation, page 98 • Obtaining Technical Assistance, page 99 System Requirements This section describes the system requirements for Release 12.
System Requirements Table 1 Images and Memory Requirements for Cisco IOS Release 12.
System Requirements Table 1 Images and Memory Requirements for Cisco IOS Release 12.
System Requirements Table 2 Images and Memory Requirements for Cisco IOS Release 12.
System Requirements Table 2 Images and Memory Requirements for Cisco IOS Release 12.
System Requirements Table 2 Images and Memory Requirements for Cisco IOS Release 12.
System Requirements Note A Hardware-Software Compatibility Matrix is available on Cisco.com for users with Cisco.com login accounts. Using this matrix, you can search for supported hardware components by entering a Cisco platform and IOS Release. The Hardware-Software Compatibility Matrix tool is also available at the following URL: http://www.cisco.com/cgi-bin/front.x/Support/HWSWmatrix/hwswmatrix.
System Requirements Feature Set Tables The Cisco IOS software is packaged in feature sets consisting of software images—depending on the platform. Each feature set contains a specific set of Cisco IOS features. Release 12.1 T supports the same feature sets as Release 12.1, but Release 12.1 T can include new features supported by the Cisco 7000 family.
System Requirements Table 4 Feature List by Feature Set for the Cisco 7100 Series (continued) Software Images by Feature Sets Features In IP IPSec 56 IPSec 3DES IP/FW/IDS NAT—Support for NetMeeting Directory (Internet Locator Service—ILS) (5) Yes Yes Yes Yes NAT—Support of H.
System Requirements Table 5 Feature List by Feature Set for the Cisco 7100 Series, Part 2 (continued) Software Images by Feature Sets In IP/FW IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 AutoInstall Using DHCP for LAN Interfaces (5) Yes Yes Yes Yes Expression MIB Support of Delta, Wildcarding and Aggregation (3) No No Yes No Interface Index Persistence (5) No No Yes No NTP MIB (5) Yes Yes Yes Yes Parser Cache (5) Yes Yes Yes Yes NAT—Enhanced H.225/H.
System Requirements Table 5 Feature List by Feature Set for the Cisco 7100 Series, Part 2 (continued) Software Images by Feature Sets Features In IP/FW IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 (5) Yes Yes Yes Yes WAN CUG Selection Facility Suppress Option Table 6 Feature List by Feature Set for the Cisco 7100 Series, Part 3 Software Images by Feature Sets In Enterprise IPSec 3DES Enterprise/ FW/IDS Enterprise/ FW/IDS IPSec 56 Enterprise/ FW/IDS IPSec 3DES Bridging
System Requirements Table 6 Feature List by Feature Set for the Cisco 7100 Series, Part 3 (continued) Software Images by Feature Sets Enterprise/ FW/IDS Enterprise/ FW/IDS IPSec 56 Enterprise/ FW/IDS IPSec 3DES Features In Enterprise IPSec 3DES IP DSCP Marking for Frame-Relay PVC (5) Yes Yes Yes Yes Network-Based Application Recognition (5) Yes Yes Yes Yes Quality of Service Device Manager Command-Line Interface Commands (5) Yes Yes Yes Yes Quality of Service for Virtual Private N
System Requirements Table 7 Feature List by Feature Set for the Cisco 7200 Series (continued) Software Images by Feature Sets In IP IP IPSec 56 IP IPSec 3DES IP FW/IDS PPPoE on ATM (1) Yes Yes Yes Yes PPP Over Fast Ethernet 802.1Q (5) Yes Yes Yes Yes FastEther Channel Enhancements on Cisco 7200 Series (5) Routers Yes Yes Yes Yes Features Connectivity/Scalability Interfaces IP Addressing and Services HSRP support for MPLS VPNs (3) Yes Yes Yes Yes NAT—Enhanced H.225/H.
System Requirements Table 7 Feature List by Feature Set for the Cisco 7200 Series (continued) Software Images by Feature Sets In IP IP IPSec 56 IP IPSec 3DES IP FW/IDS CEF Switching for Routed Bridge Encapsulation (5) Yes Yes Yes Yes PPPoE Radius Port Identification (5) Yes Yes Yes Yes Interworking Signaling Enhancements for H.323 and SIP VoIP (5) Yes Yes Yes Yes T.38 Fax Relay for Voice over IP H.
System Requirements Table 7 Feature List by Feature Set for the Cisco 7200 Series (continued) Software Images by Feature Sets In IP IP IPSec 56 IP IPSec 3DES IP FW/IDS CEF Support for IP Routing between IEEE 802.
System Requirements Table 8 Feature List by Feature Set for the Cisco 7200 Series, Part 2 Software Images by Feature Sets In IP/FW/IDS IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 Bridging Between IEEE 802.
System Requirements Table 8 Feature List by Feature Set for the Cisco 7200 Series, Part 2 (continued) Software Images by Feature Sets Features In IP/FW/IDS IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 PIM Dense Mode State Refresh (5) Yes Yes Yes Yes Router-Port Group Management Protocol (5) Yes Yes Yes Yes Source Specific Multicast (3) Yes Yes Yes Yes HSRP Support for ICMP Redirects (3) Yes Yes Yes Yes Minimum Masking Ability for NetFlow Router-Based Aggregat
System Requirements Table 8 Feature List by Feature Set for the Cisco 7200 Series, Part 2 (continued) Software Images by Feature Sets Features In IP/FW/IDS IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 Network-Based Application Recognition (5) Yes Yes Yes Yes Quality of Service Device Manager Command-Line Interface Commands (5) Yes Yes Yes Yes Quality of Service for Virtual Private Networks (5) Yes Yes Yes Yes RSVP Support for Frame Relay (5) Yes Yes Yes Yes R
System Requirements Table 8 Feature List by Feature Set for the Cisco 7200 Series, Part 2 (continued) Software Images by Feature Sets IP/FW/IDS IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 PRI and BRI QSIG Protocol Support on the Cisco (2) 2600, 3600 and MC3810 Series Routers and PRI QSIG on the Cisco 7200 Yes Yes Yes Yes Transparent Common Channel Signaling (3) Yes Yes Yes Yes Voice Over Frame Relay Configuration Enhancements (2) Yes Yes Yes Yes Features In WAN CUG
System Requirements Table 9 Feature List by Feature Set for the Cisco 7200 Series, Part 3 (continued) Software Images by Feature Sets Enterprise MCM Enterprise Wireless Enterprise Wireless IPSec 56 Features In Enterprise IPSec 3DES NTP MIB (5) Yes Yes Yes Yes Parser Cache (5) Yes Yes Yes Yes WCCP Redirection on Inbound Interfaces (3) No Yes Yes No PPPoE on ATM (1) Yes Yes Yes Yes PPP Over Fast Ethernet 802.
System Requirements Table 9 Feature List by Feature Set for the Cisco 7200 Series, Part 3 (continued) Software Images by Feature Sets Enterprise MCM Enterprise Wireless Enterprise Wireless IPSec 56 Features In Enterprise IPSec 3DES Virtual Switch Interface Master MIB (3) Yes No Yes Yes VPN Accelerator Card Enhancements (5) Yes No No Yes (3) No No Yes Yes CEF Switching for Routed Bridge Encapsulation (5) Yes Yes Yes Yes PPPoE Radius Port Identification (5) Yes Yes Yes Yes
System Requirements Table 9 Feature List by Feature Set for the Cisco 7200 Series, Part 3 (continued) Software Images by Feature Sets Enterprise MCM Enterprise Wireless Enterprise Wireless IPSec 56 Features In Enterprise IPSec 3DES IKE Extended Authentication (1) Yes Yes No Yes Secure Shell, Version 1 Integrated Client (3) Yes No No Yes SSH, Version 1 Support for T Train (1) Yes Yes Yes Yes Wildcard Pre-Shared Key Enhancement (1) Yes No No Yes CEF Support for IP Routing betw
System Requirements Table 9 Feature List by Feature Set for the Cisco 7200 Series, Part 3 (continued) Software Images by Feature Sets Enterprise MCM Enterprise Wireless Enterprise Wireless IPSec 56 Features In Enterprise IPSec 3DES Low Latency Queueing for Frame Relay (2) Yes Yes Yes Yes PPP over ATM SVC (3) Yes Yes Yes Yes Table 10 Feature List by Feature Set for the Cisco 7200 Series, Part 4 Software Images by Feature Sets In Enterprise/ FW/IDS Enterprise/ FW/IDS IPSec 56 Enterp
System Requirements Table 10 Feature List by Feature Set for the Cisco 7200 Series, Part 4 (continued) Software Images by Feature Sets Enterprise/ FW/IDS IPSec 56 Enterprise/ FW/IDS IPSec 3DES Enterprise/ SNASW Features In Enterprise/ FW/IDS NAT—Support for NetMeeting Directory (Internet Locator Service—ILS) (5) Yes Yes Yes Yes NAT—Support of H.
System Requirements Table 10 Feature List by Feature Set for the Cisco 7200 Series, Part 4 (continued) Software Images by Feature Sets Enterprise/ FW/IDS IPSec 56 Enterprise/ FW/IDS IPSec 3DES Enterprise/ SNASW Features In Enterprise/ FW/IDS Class-Based Marking (3) Yes Yes Yes Yes Class-Based Ethernet CoS Matching and Marking (5) Yes Yes Yes Yes Class-Based Policer for the DiffServ AF PHB (5) Yes Yes Yes Yes Class-Based QoS MIB (5) Yes Yes Yes Yes Class-Based Shaping (3) Y
System Requirements Table 10 Feature List by Feature Set for the Cisco 7200 Series, Part 4 (continued) Software Images by Feature Sets In Enterprise/ FW/IDS Enterprise/ FW/IDS IPSec 56 Enterprise/ FW/IDS IPSec 3DES Enterprise/ SNASW Answer Supervision Reporting (1) No No No No Cisco H.323, Version 2, Phase 2 (1) Yes Yes Yes Yes Configurable Timers in H.
System Requirements Table 11 Feature List by Feature Set for the Cisco 7200 Series, Part 5 (continued) Software Images by Feature Sets Features In Enterprise/ SNASW IPSec 56 Enterprise/ SNASW IPSec 3DES Desktop/ IBM/ Desktop/IBM IPSec 56 SNMP Support for IOS vLAN Subinterfaces (3) Yes Yes Yes Yes TN3270 Server Connectivity Enhancements (5) Yes Yes Yes Yes AutoInstall Using DHCP for LAN Interfaces (5) Yes Yes Yes Yes Configuration though SNMP (3) No No Yes No Event MIB (3)
System Requirements Table 11 Feature List by Feature Set for the Cisco 7200 Series, Part 5 (continued) Software Images by Feature Sets In Enterprise/ SNASW IPSec 56 Enterprise/ SNASW IPSec 3DES Desktop/ IBM/ Desktop/IBM IPSec 56 HSRP Support for ICMP Redirects (3) Yes Yes Yes Yes Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes (2) Yes Yes Yes Yes OSPF Flooding Reduction (2) Yes Yes Yes Yes (1) Yes Yes Yes Yes H.
System Requirements Table 11 Feature List by Feature Set for the Cisco 7200 Series, Part 5 (continued) Software Images by Feature Sets Features In Enterprise/ SNASW IPSec 56 Enterprise/ SNASW IPSec 3DES Desktop/ IBM/ Desktop/IBM IPSec 56 Quality of Service for Virtual Private Networks (5) Yes Yes Yes Yes RSVP Support for Frame Relay (5) Yes Yes Yes Yes RSVP Support for Low Latency Queuing (3) Yes Yes Yes Yes Set ATM CLP Bit (5) Yes Yes Yes Yes (1) Yes Yes No No AAA Broa
System Requirements Table 11 Feature List by Feature Set for the Cisco 7200 Series, Part 5 (continued) Software Images by Feature Sets Features In Enterprise/ SNASW IPSec 56 Enterprise/ SNASW IPSec 3DES Desktop/ IBM/ Desktop/IBM IPSec 56 Transparent Common Channel Signaling (3) Yes Yes Yes Yes Voice Over Frame Relay Configuration Enhancements (2) Yes Yes Yes Yes WAN CUG Selection Facility Suppress Option (5) Yes Yes Yes Yes Frame Relay ELMI Address Registration (3) Yes Yes Yes
System Requirements Table 12 Feature List by Feature Set for the Cisco 7200 Series, Part 6 (continued) Software Images by Feature Sets Desktop/ IBM/FW/IDS IPSec 56 Desktop/ IBM/FW/IDS IPSec 3DES Features In Desktop/ IBM/FW/IDS WCCP Redirection on Inbound Interfaces (3) Yes No No PPPoE on ATM (1) Yes Yes No PPP Over Fast Ethernet 802.1Q (5) Yes Yes Yes (5) Yes Yes Yes HSRP support for MPLS VPNs (3) Yes Yes Yes NAT—Enhanced H.225/H.
System Requirements Table 12 Feature List by Feature Set for the Cisco 7200 Series, Part 6 (continued) Software Images by Feature Sets In Desktop/ IBM/FW/IDS Desktop/ IBM/FW/IDS IPSec 56 Desktop/ IBM/FW/IDS IPSec 3DES (3) No No No CEF Switching for Routed Bridge Encapsulation (5) Yes Yes Yes PPPoE Radius Port Identification (5) Yes Yes Yes Interworking Signaling Enhancements for H.323 and SIP VoIP (5) Yes Yes Yes T.38 Fax Relay for Voice over IP H.
System Requirements Table 12 Feature List by Feature Set for the Cisco 7200 Series, Part 6 (continued) Software Images by Feature Sets Desktop/ IBM/FW/IDS IPSec 56 Desktop/ IBM/FW/IDS IPSec 3DES Features In Desktop/ IBM/FW/IDS Secure Shell, Version 1 Integrated Client (3) No Yes Yes SSH, Version 1 Support for T Train (1) No Yes Yes Wildcard Pre-Shared Key Enhancement (1) No Yes Yes CEF Support for IP Routing between IEEE 802.
System Requirements Table 12 Feature List by Feature Set for the Cisco 7200 Series, Part 6 (continued) Software Images by Feature Sets Desktop/ IBM/FW/IDS IPSec 56 Desktop/ IBM/FW/IDS IPSec 3DES Features In Desktop/ IBM/FW/IDS Low Latency Queueing for Frame Relay (2) Yes Yes Yes PPP over ATM SVC (3) Yes Yes Yes Table 13 Feature List by Feature Set for the Cisco 7500 Series Software Images by Feature Sets In IP IP IPSec 56 IP IPSec 3DES IP/FW/IDS Bridging Between IEEE 802.
System Requirements Table 13 Feature List by Feature Set for the Cisco 7500 Series (continued) Software Images by Feature Sets Features In IP IP IPSec 56 IP IPSec 3DES IP/FW/IDS PIM Dense Mode State Refresh (5) Yes Yes Yes Yes Router-Port Group Management Protocol (5) Yes Yes Yes Yes Source Specific Multicast (3) Yes Yes Yes Yes HSRP Support for ICMP Redirects (3) Yes Yes Yes Yes Minimum Masking Ability for NetFlow Router-Based Aggregation Schemes (2) Yes Yes Yes Yes O
System Requirements Table 13 Feature List by Feature Set for the Cisco 7500 Series (continued) Software Images by Feature Sets Features In IP IP IPSec 56 IP IPSec 3DES IP/FW/IDS PGM Host (1) No No No No IKE Extended Authentication (1) No Yes Yes No Secure Shell, Version 1 Integrated Client (3) No Yes Yes No SSH, Version 1 Support for T Train (1) No Yes Yes No Wildcard Pre-Shared Key Enhancement (1) No Yes Yes No CEF Support for IP Routing between IEEE 802.
System Requirements Table 14 Feature List by Feature Set for the Cisco 7500 Series, Part 2 (continued) Software Images by Feature Sets Features In IP/FW/IDS IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 AutoInstall Using DHCP for LAN Interfaces (5) Yes Yes Yes Yes Circuit Interface Identification MIB (3) Yes Yes Yes No Event MIB (3) Yes Yes Yes Yes Interface Index Persistence (5) Yes Yes Yes Yes Interface Range Specification (5) Yes Yes Yes Yes MSDP MIB
System Requirements Table 14 Feature List by Feature Set for the Cisco 7500 Series, Part 2 (continued) Software Images by Feature Sets In IP/FW/IDS IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 Interworking Signaling Enhancements for H.
System Requirements Table 14 Feature List by Feature Set for the Cisco 7500 Series, Part 2 (continued) Software Images by Feature Sets In IP/FW/IDS IPSec 56 IP/FW/IDS IPSec 3DES Enterprise Enterprise IPSec 56 ISDN Network Side for PRI for ETSI Net5 PRI (1) Yes Yes Yes Yes Transparent Common Channel Signaling (3) Yes Yes Yes Yes (5) Yes Yes Yes Yes (3) Yes Yes Yes Yes (2) Yes Yes Yes Yes Frame Relay Switching Enhancements (2) Yes Yes Yes Yes PPP over ATM SVC (3) Yes
System Requirements Table 15 Feature List by Feature Set for the Cisco 7500 Series, Part 3 (continued) Software Images by Feature Sets Enterprise/ FW/IDS Enterprise/ FW/IDS IPSec 56 Enterprise/ FW/IDS IPSec 3DES Features In Enterprise IPSec 3DES NAT—Enhanced H.225/H.245 Forwarding Engine (5) Yes Yes Yes Yes NAT—Support for NetMeeting Directory (Internet Locator Service—ILS) (5) Yes Yes Yes Yes NAT—Support of H.
System Requirements Table 15 Feature List by Feature Set for the Cisco 7500 Series, Part 3 (continued) Software Images by Feature Sets Enterprise/ FW/IDS Enterprise/ FW/IDS IPSec 56 Enterprise/ FW/IDS IPSec 3DES Features In Enterprise IPSec 3DES Distributed Traffic Shaping (5) Yes Yes Yes Yes IP DSCP Marking for Frame-Relay PVC (5) Yes Yes Yes Yes Quality of Service Device Manager Command-Line Interface Commands (5) Yes Yes Yes Yes RSVP Support for Frame Relay (5) Yes Yes Yes
System Requirements Table 16 Feature List by Feature Set for the Cisco 7500 Series, Part 4 Software Images by Feature Sets In Enterprise/ SNASW Enterprise/ SNASW IPSec 56 Enterprise/ SNASW IPSec 3DES Desktop/IBM Bridging Between IEEE 802.
System Requirements Table 16 Feature List by Feature Set for the Cisco 7500 Series, Part 4 (continued) Software Images by Feature Sets Enterprise/ SNASW IPSec 56 Enterprise/ SNASW IPSec 3DES Desktop/IBM Features In Enterprise/ SNASW OSPF Flooding Reduction (2) Yes Yes Yes Yes (1) Yes Yes Yes Yes Inter-Autonomous Systems MPLS VPN Support (5) Yes Yes Yes No MPLS Traffic Engineering and Enhancements (3) Yes Yes Yes No Virtual Switch Interface Master MIB (3) Yes Yes Yes No
System Requirements Table 16 Feature List by Feature Set for the Cisco 7500 Series, Part 4 (continued) Software Images by Feature Sets In Enterprise/ SNASW Enterprise/ SNASW IPSec 56 Enterprise/ SNASW IPSec 3DES Desktop/IBM CEF Support for IP Routing between IEEE 802.
System Requirements Table 17 Feature List by Feature Set for the Cisco 7500 Series, Part 5 (continued) Software Images by Feature Sets Desktop/ IBM/FW/IDS IPSec 56 Desktop/ IBM/FW/IDS/ IP Sec 3DES Features In Desktop/IBM Desktop/ IPSec 56 IBM/FW/IDS Interface Range Specification (5) Yes Yes Yes Yes MSDP MIB (5) Yes Yes Yes Yes Parser Cache (5) Yes Yes Yes Yes WCCP Redirection on Inbound Interfaces (3) No Yes No No PPPoE on ATM (1) Yes Yes Yes No PPP over Fast Ethernet 9
System Requirements Table 17 Feature List by Feature Set for the Cisco 7500 Series, Part 5 (continued) Software Images by Feature Sets In Desktop/IBM Desktop/ IPSec 56 IBM/FW/IDS Desktop/ IBM/FW/IDS IPSec 56 Desktop/ IBM/FW/IDS/ IP Sec 3DES Class-Based Ethernet CoS Matching and Marking (5) Yes Yes Yes Yes Class-Based QoS MIB (5) Yes Yes Yes Yes Class-Based Shaping (3) No Yes No No COPS for RSVP (1) Yes No No No Diffserv Compliant WRED (5) Yes Yes Yes Yes Distributed CRT
New and Changed Information Table 17 Feature List by Feature Set for the Cisco 7500 Series, Part 5 (continued) Software Images by Feature Sets In Desktop/IBM Desktop/ IPSec 56 IBM/FW/IDS Desktop/ IBM/FW/IDS IPSec 56 Desktop/ IBM/FW/IDS/ IP Sec 3DES CUG Selection Facility Suppress Option (5) Yes Yes Yes Yes Frame Relay ELMI Address Registration (3) Yes Yes Yes Yes Frame Relay PVC Interface Priority Queueing1 (2) Yes Yes Yes Yes Frame Relay Switching Enhancements: Shaping and Policin
New and Changed Information interfaces. Prior to this release, IP addresses for LAN interfaces were obtained using BOOTP during the AutoInstall process. The AutoInstall Using DHCP for LAN Interfaces feature also enables the routing device to recognize IP address allocation messages coming from regular BOOTP servers, providing a seamless transition for those devices already using BOOTP servers for AutoInstall. Additionally, this feature enables uploading of configuration files using unicast TFTP.
New and Changed Information Class-Based Ethernet CoS Matching & Marking Platforms: Cisco 7200 series and Cisco 7500 series routers The Class-Based Ethernet Class of Service (CoS) Matching & Marking extends IOS capabilities to match packets by looking at the CoS value of the packet and mark packets with user defined CoS values. This feature can be used for L2 CoS to L3 TOS mapping. CoS Matching & Marking can be configured via the IOS QoS Mod CLI framework.
New and Changed Information probabilities to those packets. This feature adds two new commands, random-detect dscp and dscp. It also adds two new arguments, dscp-based and prec-based, to two existing WRED-related commands—the random-detect (interface) command and the random-detect-group command.
New and Changed Information Distributed Traffic Shaping Platforms: Cisco 7500 series routers The DTS feature is one element used to manage the bandwidth of an interface to avoid congestion, to meet remote site requirements, and to conform to a service rate that is provided on that interface. DTS uses queues to buffer traffic surges that can congest a network. Data is buffered and then sent into the network at a regulated rate.
New and Changed Information Frame Relay Fragmentation with Hardware Compression Platforms: Cisco 7200 series routers The Frame Relay Fragmentation with Hardware Compression feature introduces the following functionality: Frame Relay Fragmentation and Hardware Compression Interoperability This new feature enables FRF.12, FRF.
New and Changed Information In deployment cases where IGMP v3 cannot be used (for example, if it is not supported by the receiver host or its applications), there are two other mechanisms to enable Source Specific Multicast (SSM): URL Rendezvous Directory (URD) and IGMP v3 lite. Both of these features were introduced with SSM in Cisco IOS Release 12.1(5)T.
New and Changed Information IP DSCP Marking for Frame-Relay PVC Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers The functionality of configuring a policy on a main or a subinterface to match and set IP type of service (ToS) and differentiated services code point (DSCP) bits has existed in Cisco IOS Release 12.0S and Cisco IOS Release 12.0(7)XE. This feature was introduced to Cisco IOS 12.1(2)T with the added support of configuring a policy on an ATM PVC.
New and Changed Information MPLS Scalability Enhancements for LSC and ATM LSR Platforms: Cisco 7200 series and Cisco 7500 series routers The MPLS label switch controller (LSC), combined with slave ATM switch, supports scalable integration of IP services over an ATM network.
New and Changed Information NAT—Support of IP Phone to Cisco Call Manager Platforms: Cisco 7200 series and Cisco 7500 series routers Cisco IP Phones use the Selsius Skinny Station Protocol to connect with and register to the Cisco Call Manager (CCM). Messages flow back and forth that include IP address and Port information which is used to identify other IP Phone users with which a call can be placed.
New and Changed Information NTP MIB Platforms: Cisco 7100 series and Cisco 7500 series routers The Network Time Protocol (NTP) is used to synchronize timekeeping among a set of distributed time servers and clients. The Cisco NTP MIB enables users to remotely monitor an NTP server using the Simple Network Management Protocol (SNMP), provided the MIB itself is implemented on that server.
New and Changed Information PPP Over Fast Ethernet 802.1Q Platforms: Cisco 7200 series and Cisco 7500 series routers The PPPoE over IEEE 802.1Q Encapsulation feature adds support for running PPP over Ethernet over IEEE 802.1Q encapsulation. IEEE 802.1Q encapsulation enables you to interconnect a VLAN capable router with another VLAN capable device.
New and Changed Information The RSVP support for Frame Relay feature allows RSVP to work with per VC (data link connection identifier (DLCI)) queueing for voice-like flows. Traffic shaping must be enabled in a Frame Relay environment for accurate admission control of resources (bandwidth and queues) at the congestion point; that is, the VC itself. Specifically, RSVP can work with VCs defined at the interface and subinterface levels.
New and Changed Information TN3270 Server Connectivity Enhancements Platforms: Cisco 7200 series and Cisco 7500 series routers The TN3270 Server Connectivity Enhancements feature, an enhancement to the existing TN3270 Server feature, provides the following new functions: • Dynamic LU naming • Inverse DNS nailing • TN3270 Server security enhancements Traceroute Enhancement for MPLS Platforms: Cisco 7200 series and Cisco 7500 series routers The traceroute enhancements for MPLS feature introduces two ne
New and Changed Information Turbo Access Control Lists Platforms: Cisco 7200 series routers Access control lists (ACLs) are normally searched sequentially to find a matching rule, and ACLs are ordered specifically to take this factor into account. Because of the increasing needs and requirements for security filtering and packet classification, ACLs can expand to the point that searching the ACL adds a significant amount of time and memory when packets are being forwarded.
New and Changed Information VPN Accelerator Card Enhancements Platforms: Cisco 7100 series and Cisco 7200 series routers The VPN Accelerator Card Enhancements feature displays the packet statistics of the VPN accelerator card and controller. It is available on the Cisco 7100 series router with the ISA and the ISM. It is available on the Cisco 7200 series router only if an ISA is installed. The ISA is a single-width service adapter and the ISM is a single-width service module.
New and Changed Information MIX-Enabled 2/4/8 Port Multichannel T1/E1 Port Adapter with CSU/DSU Platforms: Cisco 7200 series routers The Multiservice Interchange (MIX) port adapter adds time-division multiplexing (TDM) connection capabilities that enable you to combine types of traffic traveling through Cisco 7200 VXR series routers. On the Cisco 7200 VXR series router, MIX enables TDM connections between two ports on the same MIX-enabled port adapter.
New and Changed Information NPE-400 Platforms: Cisco 7200 VXR routers NPE-400 is a new version of network processing engine for Cisco 7200 VXR routers with the following enhancements: • RM7000 microprocessor that operates at an internal clock speed of 350 MHz • Up to 512 MB ECC SDRAM • 100 MHz SysAD and memory bus speed • 4 MB Layer 3 cache The NPE-400 leverages technology from the NPE-225 and NSE-1 to provide a higher performance NPE card.
New and Changed Information PA-GE Gigabit Ethernet Port Adapter Platforms: Cisco 7200 series routers The single port Gigabit Ethernet Port Adapter (PA-GE) provides a Gigabit Ethernet connection for the Cisco 7200 series router. This port adapter, which offers moderate performance, is suitable for campus, enterprise edge and wide-area network (WAN) aggregation applications.
New and Changed Information New Software Features in Release 12.1(3)T The following new software features are supported by the Cisco 7000 family for Cisco IOS Release 12.1(3)T: Bridging Between IEEE 802.1Q vLANs Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers The Bridging Between IEEE 802.1Q vLANs feature provides the ability to connect a network of hosts over a simple bridging-access device to a remote access concentrator. This feature supports the following IEEE 802.
New and Changed Information row is created successfully, the cciStatus is active(1). When creating a new row, set the cciDescr object along with the cciStatus in a single snmp set pdu command. If the row is already active, only the cciDescr object can be modified. The other option is to delete the row first by setting the cciStatus to destroy(6), and then recreate the row with a new value for cciDescr. When creating a new row, the ifIndex is validated first.
New and Changed Information Event MIB Platforms: Cisco 7200 series and Cisco 7500 series routers The Event MIB is an asynchronous notification mechanism standardized for use by network management systems using Simple Network Management Protocol (SNMP). The Event MIB provides the ability to monitor the Cisco Management Information Base (MIB) objects on the local or remote system using SNMP and take simple action whenever a trigger condition is met.
New and Changed Information General Packet Radio Service Release 1.4 Platforms: Cisco 7200 series routers Note General Packet Radio Service (GPRS) Release 1.4 is a specially licensed feature that is available only through a controlled image release in Cisco IOS Release 12.1(3)T. GPRS Release 1.4 is the recommended upgrade for both GPRS Release 1.2 (available in Cisco IOS Release 12.1(1)GA) and GPRS Release 1.3 (available in Cisco IOS Release 12.1(2)GB).
New and Changed Information HSRP Support for MPLS VPNs Platforms: Cisco 7200 series and Cisco 7500 series routers The HSRP support for Multiprotocol Label Switching (MPLS) VPNs feature enables ICMP redirection on interfaces configured with the Hot Standby Router Protocol (HSRP). The Internet Control Message Protocol (ICMP) is a network layer Internet protocol that provides message packets to report errors and other information relevant to IP processing.
New and Changed Information • Determines the routes for traffic flows across a network based on the resources the traffic flow requires and the resources available in the network • Employs “constraint-based routing,” in which the path for a traffic flow is the shortest path that meets the resource requirements (constraints) of the traffic flow • Recovers from link or node failures by adapting to the new constraints presented by the changed topology • Transports packets using MPLS forwarding crossing
New and Changed Information • SVCs with ingress and egress (AAL5) common part convergence sublayer (CPCS) service data unit (SDU) maximum size of at least 1506 bytes when supporting LLC/SNAP encapsulation, and 1502 bytes when supporting virtual circuit multiplexed encapsulation. • Maximum Transmission Unit (MTU) negotiation as described in RFC-1626, “Default IP MTU size for use over ATM AAL5”.
New and Changed Information RSVP provides admission control. However, to provide the bandwidth and delay guarantees for voice traffic and get admission control, RSVP must work with LLQ. The RSVP support for LLQ feature allows RSVP to classify voice flows and queue them into the priority queue within the LLQ system while simultaneously providing reservations for nonvoice flows by getting a reserved queue.
New and Changed Information Transparent Common Channel Signaling Platforms: Cisco 7200 series and Cisco 7500 series routers Transparent CCS allows the connection of two PBXs with digital interfaces that use a proprietary or unsupported CCS protocol without the need for interpretation of CCS signaling for call processing. T1/E1 traffic is transported transparently through the data network and the feature preserves proprietary signaling.
New and Changed Information New Hardware Features in Release 12.1(3)T The following new hardware features are supported by the Cisco 7000 family for Cisco IOS Release 12.
New and Changed Information Bidirectional PIM Platforms: Cisco 7200 series and Cisco 7500 series routers Bidirectional PIM (bidir-PIM) is a variant of the Protocol Independent Multicast (PIM) suite of routing protocols for IP multicast. Bidir-PIM is derived from the mechanisms of Protocol Independent Multicast sparse mode (PIM SM) and shares many of its protocol elements. In short, bidir-PIM is PIM SM with shared tree, but no shortest path tree operations.
New and Changed Information Frame Relay Switching Enhancements Platforms: Cisco 7200 series and Cisco 7500 series routers The Frame Relay Switching Enhancements feature enables a router in a Frame Relay network to be used as a Frame Relay switch. This feature provides the following functionality: Traffic Shaping on Switched PVCs You can now configure Frame Relay traffic shaping on switched permanent virtual connections (PVCs).
New and Changed Information H.323 Support for Virtual Interfaces Platforms: Cisco 7200 series routers With the H.323 Support for Virtual Interfaces feature, you can configure the IP address of the gateway, so that the IP address included in the H.323 packet is deterministic and consistently indicates the same address for the source. In previous releases of the Cisco IOS software, the source address included in the H.323 packet could vary depending on the protocol (RAS, H.225, H.245, or RTP).
New and Changed Information OSPF Flooding Reduction Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers The explosive growth of the Internet has placed the focus on the scalability of Interior Gateway Protocols such as Open Shortest Path First (OSPF). The networks using OSPF are becoming larger every day and will continue to expand to accommodate the demand to connect to the Internet.
New and Changed Information Voice Over Frame Relay Configuration Enhancements Platforms: Cisco 7200 series routers Voice over Frame Relay functionality has been updated in this release, so that configuration on all supported platforms is nearly identical. In Cisco IOS Release 12.0(4)T, when support for Voice over Frame Relay using FRF.11 and FRF.12 was introduced, configuration procedures were different depending on the router platform used.
New and Changed Information With the introduction of this feature, broadcasting is now allowed among groups of servers. The server groups can be either RADIUS or TACACS+. And each server group can define its backup servers for failover independently of other groups. (Failover is a process that may occur when more than one server has been defined within a server group.
New and Changed Information Cisco H.323, Version 2, Phase 2 Platforms: Cisco 7200 series routers Cisco H.323 Version 2, Phase 2 upgrades Cisco IOS software by adding several optional features of the H.323 Version 2 specification and facilitates customized extensions to the Cisco Gatekeeper. Cisco H.323 Version 2, Phase 2 adds the following benefits to Cisco H.323 gatekeepers, gateways, and proxies: • H.
New and Changed Information Ecosystem Gatekeeper Interoperability Enhancements Platforms: Cisco 7200 series routers The Ecosystem Gatekeeper Interoperability Enhancements feature supplements the existing support for alternate gatekeepers and adds support for the alternate gatekeeper field (altGKInfo) to the gatekeeper rejection (GRJ) and registration rejection (RRJ) messages. This allows a gateway to move between gatekeepers during the gatekeeper request (GRQ) and registration request (RRQ) phases.
New and Changed Information H.323 Version 2 Support Platforms: Cisco 7200 series routers Cisco H.323 Version 2 Phase 2 upgrades Cisco IOS software by adding the following optional features an facilitates customized extensions to the Cisco Gatekeeper. • H.323v2 Fast Connect—The Fast Connect feature allows endpoints to establish media channels without waiting for a separate H.245 connection to be opened. • H.245 Tunneling of DTMF Relay in conjunction with Fast Connect—Through H.245 tunneling, H.
New and Changed Information IKE Extended Authentication Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers IKE Extended Authentication (XAUTH) is a draft RFC developed by the Internet Engineering TaskForce (IETF) based on the Internet Key Exchange (IKE) protocol. XAUTH allows all Cisco IOS authentication methods, including those based on RADIUS or TACACS+ servers, to perform both user and device authentication for remote users and clients.
New and Changed Information solution for multicast applications with basic reliability requirements. PGM has two main parts: a host element (also referred to as the transport layer of the PGM protocol) and a network element (also referred to as the network layer of the PGM protocol). The transport layer of the PGM protocol consists of two main parts: a source part and a receiver part.
New and Changed Information Wildcard Pre-Shared Key Enhancement Platforms: Cisco 7100 series, Cisco 7200 series, and Cisco 7500 series routers A wildcard pre-shared key allows a group of remote users with the same level of authentication to share an IKE pre-shared key. The remote peer pre-shared key must match the local peer pre-shared key for IKE authentication to occur.
Important Notes Table 18 Deprecated and Replacement MIBs (continued) Deprecated MIB Replacement OLD-CISCO-SYSTEM-MIB CISCO-CONFIG-COPY-MIB OLD-CISCO-TCP-MIB CISCO-TCP-MIB OLD-CISCO-TS-MIB To be decided OLD-CISCO-VINES-MIB CISCO-VINES-MIB OLD-CISCO-XNS-MIB To be decided Important Notes The following sections contain important notes about Cisco IOS Release 12.1 T that apply to Cisco 7000 family routers. Image Deferral, Cisco IOS Release 12.
Important Notes ICaveat CSCdr91706 and IOS HTTP Vulnerability A defect in multiple releases of Cisco IOS software will cause a Cisco router or switch to halt and reload if the IOS HTTP service is enabled, browsing to http://router-ip/anytext?/ is attempted, and the enable password is supplied when requested. This defect can be exploited to produce a denial of service (DoS) attack.
Important Notes Note If you wish to avoid risk of having your system affected by the above-identified defect, you may replace it with the replacement image described above. If you do so, the same licenses, terms and conditions that governed your rights and obligations, and those of Cisco, with respect to the deferred image shall govern them with respect to the replacement image. If, on the other hand, you decide not to replace the deferred image, you proceed at your own risk.
Important Notes Image Deferral, Cisco IOS Release 12.1(3)T The c7200-is-mz and c7200-js-mz images were deferred from Cisco IOS Release 12.1(3)T to Cisco IOS Release 12.1(3a)T1 due to the following caveat: CSCdr88376—FR LLQ: data packets appear in voice queue Note If you wish to avoid risk of having your system affected by the above-identified defect, you may replace it with the replacement image described above.
Caveats Cisco IOS Software Product Numbering Change Announcement Starting with releases 12.1(1) and 12.1(1)T, Cisco IOS software product numbers will be modified to fit within an 18-character product number field. Because a Cisco IOS software product number remains at a maximum of 18 alphanumeric characters, the dots that provided delineation of release level have been eliminated to allow product number expansion. This will accommodate more products and features. From Cisco IOS software release 12.
Related Documentation Release-Specific Documents The following documents are specific to Release 12.1 and are located on Cisco.com and on the Documentation CD-ROM: • Cross-Platform Release Notes for Cisco IOS Release 12.1 On Cisco.com at: Technical Documents: Documentation Home Page: Cisco IOS Software Configuration: Cisco IOS Release 12.1 On the Documentation CD-ROM at: Cisco Product Documentation: Cisco IOS Software Configuration: Cisco IOS Release 12.
Related Documentation On Cisco.com at: Technical Documents: Documentation Home Page: Cisco Product Documentation: Core/High-End Routers On the Documentation CD-ROM at: Cisco Product Documentation: Core/High-End Routers Feature Modules Feature modules describe new features supported by Release 12.1 T and are updates to the Cisco IOS documentation set. A feature module consists of a brief overview of the feature, benefits, configuration tasks, and a command reference.
Related Documentation Release 12.1 Documentation Set Table 19 describes the contents of the Cisco IOS Release 12.1 software documentation set, which is available in electronic form and in printed form if ordered. Note You can find the most current Cisco IOS documentation on Cisco.com and on the Documentation CD-ROM. These electronic documents may contain updates and modifications made after the hard-copy documents were printed. On Cisco.
Related Documentation Table 19 Cisco IOS Software Release 12.
Obtaining Documentation Table 19 Cisco IOS Software Release 12.1 Documentation Set (continued) Books Major Topics • Cisco IOS Wide-Area Networking Configuration Guide • Cisco IOS Wide-Area Networking Command Reference • Cisco IOS Configuration Guide Master Index • Cisco IOS Command Reference Master Index • Cisco IOS Debug Command Reference • Cisco IOS Dial Services Quick Configuration Guide • Cisco IOS Software System Error Messages • New Features in 12.
