MULTILINGUAL EN DE FR NL ES PT USER MANUAL P70 © 2017 SMANOS HOLDING LTD. All Rights Reserved. Printed in China PA: P70-QG-ML-V1.
EN EN Overview • Side View • Back View • Front View Reset button Camera microSD Card Slot LED Indicators Microphone Heat Vent Power Jack Bracket microSD Card (Not included) Red LED Indicator Blinks once per second Realtime View Red LED Indicator Blinks every 2 seconds Searching for Network Blue LED Indicator Constantly Blinking Connected to a Network Blue LED Indicator Solid Privacy Mode Red & Blue LED Indicator Solid WiFi Pairing State Support 32GB microSD card maximum; please do n
EN EN What is inside the box Pairing Camera with WiFi through App Download the App by searching “P70 camera” from App Store or Google Play.
EN EN Installation Important: This camera should be placed where the WiFi signal is strong for optimal performance. Specifications Image sensor Sony 1/2.9" CMOS sensor Min. illumination Color: 0.01Lux@ (F1.2, AGC ON) Black and white : 0.001Lux@ (F1.2, AGC ON) 1. Separate the mounting template on the bottom of this camera from the bracket by pressing the snap as picture shows 2. Mount the template on the wall by using the supplied screws 3.
FCC Warning： Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) this device must accept any interference received, including interference that may cause undesired operation.
