17.1 Universal Real Time System Exclusive Message
Message Format: F0H 7FH....F7H
17.1.1 Master Volume
Message Format: F0H 7FH 7FH 04H 01H llH mmH F7H
ll: LSB Value(Send:00H, Receive:Ignored)
mm: MSB Value
Send This message is not sent by this Instrument.
Receive Receipt changes the Master Volume.
17.1.2 Master Fine Tuning
Message Format: F0H 7FH 7FH 04H 03H llH mmH F7H
ll: LSB Value(Note1)
mm: MSB Value(Note1)
Note1 : For information about the relationship between setting values and send/receive values, see “18.4 Fine Tune Setting
Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Send This message is sent when the tuning setting is changed.
Receive Receipt changes the tuning setting.
17.1.3 Master Coarse Tuning
Message Format: F0H 7FH 7FH 04H 04H llH mmH F7H
ll: LSB Value(Send:00H, Receive:Ignored)
mm: MSB Value
Send Sent when Transpose is changed.
Receive Receipt changes the Transpose parameter.
17.1.4 Reverb Type
Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H 00H vvH F7H
vv: Value(Note1)
Note1 : For information about the relationship between setting values and send/receive values, see “18.5 Reverb Type
Setting Value Table” in “IV Setting Values and Send/Receive Values” of this document.
Send Sent when the Reverb Type is changed or the Hall function is turned on/off.
Receive Receipt changes the Reverb Type or the Hall function state.
