E Handheld Terminal Series User’s Guide Be sure to read “Safety Precautions” inside this guide before trying to use your Handheld Terminal. Illustrated operating instructions in this user’s guide use laser model of DT-X7 series.
• This Product is equipped with the Brycen BL-RAPPORE Stack and My Wirefree Network Bluetooth User Interface Application, the use of which is governed by a license granted by Brycen Co., Ltd. • BLUETOOTH is a registered trademark owned by Bluetooth SIG, Inc. and licensed to CASIO COMPUTER CO., LTD. • Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
Contents Safety Precautions .........................................................................................E-3 Operating Precautions ...................................................................................E-8 Important ........................................................................................................E-9 Regulatory Information ...............................................................................E-10 Checking in the Box .....................................
DT-X7 Specifications ...................................................................................E-40 Using the USB Cradle (HA-F60IO) ...............................................................E-44 General Guide .................................................................................................... E-44 Connecting the USB Cradle Power Supply .......................................................E-46 Specifications ......................................................................
Safety Precautions Congratulations upon your selection of this CASIO product. Be sure to read the following Safety Precautions before trying to use it for the first time. Your neglect or avoidance of the warning and caution statements in the subsequent pages causes the danger of fire, electric shock, malfunction and damage on the goods as well as personal injury. Markings and Symbols The following are the meanings of the markings and symbols used in these Safety Precautions.
Warning Dust and Moisture • Though the Handheld Terminal is dust and water splash resistant, its options including the battery pack are not. Keep loose metal objects and containers filled with liquid away from your Handheld Terminal and the options. Also, never handle the Handheld Terminal and the options while your hands are wet. Laser Light • The products (Laser Scanner and C-MOS Imager models) scan bar codes using laser light.
Caution Foreign Objects • Take care to ensure that metals or combustible objects are not inserted into the openings of the Handheld Terminal or its options, and not to allow moisture to get inside of them. Location • Install the cradle properly on a flat and stable surface so that it cannot fall down onto floor. • Do not leave the Handheld Terminal and its options for a long period in a car parked in direct sunlight. LCD Screen • Never apply strong pressure to the screen or subject it to strong impact.
Optional Lithium-ion Battery Pack Danger • Never use the Handheld Terminal and its option including the battery pack and battery next to open flame, near a stove, or any other area exposed to high heat, or leave them for a long period of time in a vehicle parked in direct sunlight. • Never use the battery pack with any device other than the Handheld Terminal. • Never dispose of the battery pack by incinerating it or otherwise expose it to heat.
Power Supply / AC Adaptor Warning • Do not use the Handheld Terminal at a voltage other than the specified voltage. Also, do not connect the Handheld Terminal to a multi-plug power strip. • Never modify, sharply bend, twist, or pull on the power cord. • Never use a detergent to clean AC adaptor and its power cable, especially on the plug and the jack. • When using the battery chargers and the cradles, be sure to use the respective AC adaptors. Caution • Never pull on the power cord when unplugging it.
Operating Precautions Your Handheld Terminal and its options are precision. Improper operation or rough handling can cause problems with data storage and other problems. Note and observe the following precautions to ensure proper operation. • Do not continue operating the Handheld Terminal when battery power is low. Doing so can cause data to be lost. When the battery goes low, charge it as soon as possible. • Do not leave dead battery pack in the Handheld Terminal for a long period.
Important • This guide does not include any information about programming and download procedures. See the applicable separate documentation for information about the procedures. After Service • Should this product ever malfunction, contact your original retailer providing information about the product name, the date you purchased it, and details about the problem. This mark applies to EU countries and Turkey only.
Regulatory Information The USA and Canada GUIDELINES LAID DOWN BY FCC RULES FOR USE OF THIS UNIT IN THE U.S.A. (not applicable to other areas). NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
L’utilisation de ce dispositif est autorisée seulement aux conditions suivantes : (1) il ne doit pas produire de brouillage et (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
Standard EN 300 328 EN 50371 (for DT-X7M10R2, DTX7M30R) lssue date v1.7.1: 2006.10 2002 and therefore comply with the essential requirements and provisions of the Directive 1999/5/EC of the European Parliament and of the council of March 9, 1999 on Radio equipment and Telecommunications Terminal Equipment and the mutual recognition of their conformity and with the provisions of Annex III (Conformity Assessment procedure referred to in article 10).
The CASIO DT-X7M10E, DT-X7M10R2, DT-X7M30E, DT-X7M30R and DT-X7M10U models are designed, tested and found to meet the relevant regulatory standards described below. DT-X7M10E, DT-X7M10R2, DT-X7M30E, DT-X7M30R International standards: IEC 60825-1 IEC 60529, IP54 level Europe standards: EN 60950-1 EN 60825-1 EN 300 328 EN 301 489-17 China standards: GB 4943 GB 9254 GB 17625.1 GB 7247.
Checking in the Box Please check the contents of the box before using the Handheld Terminal for the first time. Open the box and make sure that all the items shown here are included. Handheld Terminal Large-capacity Battery Pack Cover Bumper* Hand Strap * This is attached to the main body of C-MOS Imager models.
Handheld Terminal System Configuration Options USB Cradle HA-F60IO DT-X7 Series Ethernet Cradle HA-F62IO Cradle-type Battery Charger HA-F30CHG The illustration shows the USB Cradle (HA-F60IO).
Options Battery Pack HA-F20BAT (Battery Pack) HA-F21LBAT (Large-capacity Battery Pack) Dual Battery Charger HA-F32DCHG AC Adaptor for USB Cradle/Ethernet Cradle/ Dual Battery Charger AD-S42120B AD-S42120B-N AC Adaptor for Cradle-type Battery Charger AD-S15050BE E-16 AD-S15050B-N
Options AC Adaptor for Cradle-type Dual Battery Charger AD-S60160BE AD-S60160BU AD-S60160B-N Cable DT-380USB Power Cord for Europe Power Cord for North America Power Cord for Taiwan Power Cord for Korea Power Cord for Australia AC-CORD-EU AC-CORD-US AC-CORD-TW AC-CORD-KR AC-CORD-AU Hand Belt HA-F95HB E-17
General Guide TOP 17 17 DT-X7M10E DT-X7M10R2 DT-X7M30E DT-X7M30R Left 17 DT-X7M10U Front 12 3 Right Back 4 16 16 23 22 5 14 15 24 7 24 7 6 8 11 25 9 10 12 13 21 20 21 Bottom 18 19 19 1 Indicator 1 Orange: Charging the battery pack. Green: Charging the battery pack is complete. Red: Battery pack error or the surrounding temperature is out of the charging temperature range. 2 Indicator 2 Flashes in blue when operating via Bluetooth or in orange when operating via WLAN.
7 Cursor Keys Perform the same functions as the up and down arrow keys on a PC keyboard. 8 Enter Key Press when finishing entering numerical values or when moving to the next step. 9 Numeric Keys Used to enter numeric values and decimal points. 10 Fn Key Used to make various settings in combination with the function keys or numeric keys or when starting a pre-registered application. 11 CLR Key Used to clear one letter to the left of the cursor.
21 Strap Holes Used to attach the hand strap. Also used for the hand belt. 22 Reset Switch Used to reset the Handheld Terminal. 23 Hand Belt Holes Used to attach the hand belt. 24 Battery Pack Cover Lock Switch Used to lock the battery cover and to release. 25 Battery Pack Cover Used to cover the battery compartment that holds the battery pack inside.
Loading and Removing the Battery Pack Your Handheld Terminal uses two types of battery: a battery pack and a memory backup battery. The battery pack is used to power normal operations and to store data, while the memory backup battery provides the power required to maintain memory contents when the battery pack power is unable to supply power for some reason. The operating power is supplied by a battery pack. You can choose between a battery pack (HA-F20BAT) and a large-capacity battery pack (HA-F21LBAT).
Loading 1. Turn over the Handheld Terminal. 2. Remove the rechargeable battery pack cover as follows: Slide the left and right lock switches for the rechargeable battery pack cover simultaneously in the direction indicated by the arrows. While holding the switches back, hook your fingertips into the notches in the rechargeable battery pack cover and lift the cover up in the direction indicated by the arrow. Notch Notch 3. Load a battery pack (HA-F20BAT) or large-capacity battery pack (HA-F21LBAT).
After putting back the cover, firmly press the cover so that it is locked in the position by the two Battery Pack Cover Lock Switches. • Ensure that both the switches returned all the way down to the home positions as indicated by the two arrows. If the switches are lackadaisically positioned, it causes the switches not to activate. When loading a large-capacity battery pack, use the large-capacity battery cover instead of the standard battery cover. Battery Pack Cover Lock Switches Removing 1.
4. Remove the battery pack by pulling up the removal tape as shown in the illustration. Loading the large-capacity battery pack into the Handheld Terminal After loading the large-capacity battery pack, you need to use the special large-capacity battery pack cover in place of the standard battery pack cover. “Loading and Removing” of the large-capacity battery pack cover is the same as those for the standard battery pack cover.
Attaching the Hand Strap The hand strap can be used to prevent the Handheld Terminal from dropping when carrying it around. Since there are two strap holes where the hand strap can be attached, use the hole that affords the ease of use. Attach the hand strap according to the procedure described below. To attach the hand strap 1. Pass the thin cord of the hand strap through the hand strap hole on the back of the Handheld Terminal. 2.
Setting up Using the Mouse Emulator Function The mouse emulator function lets you make settings and adjustments by using a mouse cursor. To use the mouse cursor, first set up the mouse emulation mode by following the below procedure. In the emulation mode, the numeric keys and Trigger R key are used to manipulate the mouse cursor. (In the emulation mode, the numeric keys and Trigger R key cannot be used for entering numerics and scanning bar codes respectively.
Right click (calling up a menu) • Move the mouse cursor to the position where you want to click, and press the Trigger R key. Left double click Performing this action while the mouse cursor is on an icon starts an application, opens a file, etc. • Move the mouse cursor to the position where you want to double click, and press the “5” key twice. * The double click timing follows the double tap setting of Windows CE. The setting can be changed by accessing the “Mouse” icon in the Control Panel.
Adjusting Display Brightness You can use the following procedure to adjust display brightness to make it easier to read under different lighting conditions. • Press the “Fn” key and then press the “5” key or “6” key after confirming that “F” is displayed in the lower right corner of the screen. Pressing the “5” key adjusts brightness for a darker display, while pressing the “6” key adjusts brightness for a lighter display.
Using the Laser Scanner (DT-X7M10E/DT-X7M10R2) 1. After turning on the power, position the laser scanner close to a bar code and then press the trigger key. 2. The laser emits light and scans the bar code. If scanning is completed normally, Indicator 2 displays a green light and a buzzer sounds. Important! • If you are unable to scan a bar code, try changing the angle at which the scanner is held or distance from the scanner to the bar code, and then try scanning again.
Warning Label • This label is a warning and caution label for Class 2 laser products that comply with IEC60825-1:1993+A1:1997+A2:2001. • Although Class 2 laser light is only emitted momentarily, never look directly into the beam light. • The laser light emitted by this laser scanner has a maximum output of less than 1 mW and a wavelength of 650 nm. • Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.
Adjusting the Laser Light Emission Width The emission width of the laser light emitted by the Handheld Terminal can be adjusted. Adjust the emission width when it has been changed. * The mouse emulator function can also be used to make the adjustment. 1. Use the “ ”/“ ” keys to move the focus to the [Start] icon and press the Enter key. Then navigate to Settings ➝ Control Panel with the Enter key to bring up the Control Panel. 2. Move the focus to the [Scanner Setting] icon and press the Enter key.
4. Use the “ ”/“ ” keys to move the focus to [Calibration] and press the Enter key. The message appears as shown at right. 5. Press the Trigger Key to emit laser light, and align the light with the barcode for adjusting emission width. • Align the laser light with the narrow bars on both sides. • The message appears as shown at right when adjustment is completed. • Repeat the setting if “Setting failed” message appears.
Using the C-MOS Imager (DT-X7M30E/DT-X7M30R) 1. Turn on the Handheld Terminal, position its C-MOS Imager reader port near the bar code or 2D code, and then press the Trigger Key. 2. The Handheld Terminal reads the code by emitting laser and red lights. Indicator 2 (read operation indicator lamp) lights in green when the reading is successful. Bar code and stacked 2D code Reading Guide When you press the Trigger key, LEDs in the Handheld Terminal emit laser and red lights.
Warning Label DT-X7M30E DT-X7M30R DT-X7M30R-CN • This label is a warning and caution label for Class 2 laser products that comply with IEC60825-1:1993+A1:1997+A2:2001. • Although Class 2 laser light is only emitted momentarily, never look directly into the beam light. • The laser light emitted by this laser scanner has a maximum output of less than 1 mW and a wavelength of 650 nm.
Using the Linear Imager (DT-X7M10U) 1. After turning on the power, position the reader port close to a bar code and then press the Trigger key. 2. The LED emits light and scans the bar code. When scanning is completed normally, Indicator 2 displays a green light and a buzzer sounds. Important! • If you are unable to scan a bar code, try changing the angle at which the Handheld Terminal is held or distance between the reader port and the bar code, and then try scanning again.
Performing Communications IR Communication IR communication can be used to transmit data between two Handheld Terminals. When performing IR communication, orient the IR ports of both Handheld Terminals so they are pointing directly at each other. The ports can be in direct contact with each other, or they can be separated by up to 30cm (1113⁄16") (up to 20cm (7 7⁄8") for communication between units). Important! • A high-sensitivity communication element is used during IR communication.
Bluetooth® Communication Bluetooth® interface can also be used to transmit data between two Handheld Terminals. With Bluetooth® the two Handheld Terminals should be located within about three meters (9'103⁄8") (Laser Scanning and C-MOS Imager models) or 100 meters (328'1") (DTX7M10U) from each other, as long as there is nothing blocking the path between them. Important! Observe the following precautions to help ensure that Bluetooth communication is successful.
Resetting the Handheld Terminal Resetting the Handheld Terminal is the same as restarting a PC. Performing a reset causes all unsaved inputs and edits to be lost, but data that is already stored in the memory as well as all settings should be unaffected. Use reset to restore normal operation whenever the Handheld Terminal operates abnormally due to misoperation or some other reason. Use a stylus to press the reset switch on the back of the DT-X7. This starts the reset operation.
Performing a Full Reset (Initialization) Performing a full reset initializes memory. This means that all data stored in the memory (RAM) is deleted and all the settings are returned to their initial factory settings. Perform a full reset whenever any one of the following conditions exists. • When you want to delete all memory contents and return the settings to their initial factory settings. • When you are no longer able to use the Handheld Terminal because you forgot your password.
DT-X7 Specifications Model: DT-X7M10E, DT-X7M10R2, DT-X7M10U, DT-X7M30E, DT-X7M30R CPU: Marvell® PXA270 416MHz Memory: 64MB RAM, 64MB Flash ROM (user area: approx. 28MB) OS: Microsoft® Windows® CE5.0 operating system, English Version Display: 2.
WLAN(DT-X7M10R2, DT-X7M30R): Standards: Complies with IEEE 802.11b/g Diffusion Modulation: DS: 802.11b DS/OFDM: 802.11g Frequency: 802.11b/g: 2.400-2.4835 GHz Transmission Rate: 802.11b: Max. 11 Mbps 802.11g: Max. 54 Mbps Communication Range: 50 m indoors, 150 m outdoors (varies according to usage environment and transmission rate) Power Requirements: Power Source: HA-F20BAT Battery Pack HA-F21LBAT Large-capacity Battery Pack Memory Backup: Rechargeable Lithium Battery (Built-in) Consumption Current: DC 1.
Dimensional Drawings Approx. 52.5mm (21/16") (Display) Approx. 51mm (2") (Grip) E-42 Approx. 23.5mm (15/16") (Display) Approx. 30.5mm (13/16") (Grip) Approx.
Approx. 52.5mm (21/16") (Display) Approx. 51mm (2") (Grip) Approx. 23.5mm (15/16") (Display) Approx. 30.5mm (13/16") (Grip) Approx.
Using the USB Cradle (HA-F60IO) The optionally available USB Cradle (HA-F60IO) makes it possible to transmit data and files between the Handheld Terminal and a PC via a USB connection (download or upload). You can also use the USB Cradle to charge the battery pack installed in the Handheld Terminal.
1 USB Client Port This port is used to transmit data and files (download, upload) by connecting the Cradle to a PC using a USB cable (DT-380USB). A dedicated driver must be installed in the PC before connecting the Cradle to the PC. 2 USB Host Port This port is used to connect a corresponding USB peripheral device. 3 Selector Switch This switch is used to switch between the USB host port and USB client port. 4 AC Adaptor Jack Connect the AC adaptor here.
Connecting the USB Cradle Power Supply Use the separately sold AC adaptor (AD-S42120B) for the power supply of the USB Cradle. Always make sure to connect the AC adaptor to the USB Cradle before performing communication with the Handheld Terminal. Power to the Handheld Terminal is supplied from the USB Cradle. 1. Plug the AC adaptor into the AC adaptor jack on the back of the USB Cradle. 2. After connecting the power cable to the AC adaptor, plug the other end of it into an electrical outlet. 3.
4. Connect the USB cable (DT-380USB) to the USB client port on the back of the USB Cradle, and then connect it to the PC. The USB host port is used when connecting the cradle with other USB peripheral device. PC USB peripheral device 5. Align the contacts on the bottom of the DT-X7 with the power contacts of the USB Cradle when inserting the unit. The power LED on the front of the USB Cradle will light green if the Handheld Terminal has been properly mounted.
• Do not subject the Handheld Terminal and USB Cradle to vibration or impact during communication. This can cause communication to be interrupted. • When placing the DT-X7, make sure that it is seated properly and that the power LED at the front of the USB Cradle is lit in green. Charging and communication will not proceed properly if the Handheld Terminal is not seated properly. • Always cap ports that are not being used. Using the USB Cradle while the ports are uncapped can cause damage.
Using the Ethernet Cradle (HA-F62IO) The optionally available Enthernet Cradle (HA-F62IO) makes it possible to transmit data and files between the Handheld Terminal and a PC via a USB or LAN connection (download or upload). You can also use the Ethernet Cradle to charge the battery pack installed in the Handheld Terminal.
1 USB Client Port This port is used to transmit data and files (download, upload) by connecting the Ethernet Cradle to a PC using a USB cable (DT-380USB). The dedicated driver must be installed in the PC before connecting the Ethernet Cradle to the PC. 2 USB Host Port This port is used to connect a corresponding USB peripheral device. 3 Selector Switch This switch is used to switch between a USB connection and a LAN connection.
Connecting the Ethernet Cradle Power Supply Use the separately sold AC adaptor (AD-S42120B) for the power supply of the Ethernet Cradle. Always make sure to connect the AC adaptor to the Ethernet Cradle before performing communication with the Handheld Terminal. Power to the Handheld Terminal is supplied from the Ethernet Cradle. 1. Plug the AC adaptor into the AC adaptor jack on the back of the Ethernet Cradle. 2.
4. Before using the cradle ports, remove the caps from the ports. When using a LAN, connect one end of the LAN cable to the LAN port and the other end to the PC or hub. When using a USB connection, connect one end of the USB cable (DT-380USB) to the USB port and the other end to the PC. The USB host port is used for connecting the cradle with other USB peripheral device. PC PC or hub 5. Align the contacts on the bottom of the DT-X7 with the power contacts of the Ethernet Cradle when inserting the unit.
• When placing the DT-X7, make sure that it is seated properly and that the power LED at the front of the Ethernet Cradle is lit in green. Charging and communication will not proceed properly if the Handheld Terminal is not mounted properly. • Always cap ports that are not being used. Using the Ethernet Cradle while the ports are uncapped can cause damage. Specifications 1. LAN Specifications Communications protocol: Media type: 2. USB Protocol: Transmission rate: 3.
Using the Cradle-type Battery Charger (HA-F30CHG) The optionally available Cradle-type Battery Charger (HA-F30CHG) lets you charge the Handheld Terminal’s battery simply by placing the Handheld Terminal onto the charger. General Guide Top 2 3 Front Left 4 Back 1 1 AC Adaptor Jack Connect the AC adaptor here. 2 Terminal Detect Switch This switch detects when the DT-X7 is mounted correctly on the charger. 3 Power Contacts Power is supplied to the DT-X7 via these contacts.
Connecting the AC Adaptor for Cradle-type Battery Charger Use the separately sold AC adaptor (AD-S15050BE) for the power supply of the Cradle-type Battery Charger. 1. Plug the AC adaptor into the AC adaptor jack on the back of the charger. 2. Next, plug the AC adaptor into a wall outlet. 3. Align the contacts on the bottom of the DT-X7 with the power contacts of the Cradletype Battery Charger when inserting the unit.
Status of Indicator 1 on DT-X7: Orange: Charging the battery pack. Red: Standby due to battery pack error or the surrounding temperature is out of the charging temperature range. (charging begins when the temperature is within the charging temperature range) Green: Charging the battery pack is complete. Important ! • Never short out the power contacts of the Cradle-type Battery Charger. This can damage the Cradle-type Battery Charger.
Specifications 1. Charging Specifications Charging Method: Charge Period: 2. Power Supply Power Source: Consumption Current: Output to Handheld Terminal: 3. AC Adaptor Model: Input: Output: 4. Dimensions and Weight Dimensions: Weight: 5. Operating Environment Temperature: Humidity: Constant current/voltage Approximately 3 hours (battery pack) Approximately 5.5 hours (large-capacity battery pack) AC adaptor (AD-S15050BE) 5V DC 1.6A 5V DC 1.6A (max.) AD-S15050B 100V to 240V AC 50/60Hz 0.4A 5V DC 3.
Using the Cradle-type Dual Battery Charger (HA-F36DCHG) The optionally available Cradle-type Dual Battery Charger (HA-F36DCHG) can be used to simultaneously charge two battery packs. General Guide Left Top 1 2 4 Right 4 Bottom 2 Front 3 1 AC Adaptor Jack This is used to supply power by connecting the AC adaptor (sold separately). 2 Cradle-type Dual Battery Charger Connection Port Use this port to connect multiple Cradle-type Dual Battery Chargers to each other.
Bundled Items Used when linking two or more Cradle-type Dual Battery Chargers.
Charging Battery Pack Use the separately sold AC adaptor (AD-S60160BE/AD-S60160BU) for the power supply of the Cradle-type Dual Battery Charger. 1. Plug the cord from the AC adaptor into the AC adaptor jack of the Cradle-type Dual Battery Charger. 2. Plug the AC cord into a wall outlet. AC Adaptor AC Adaptor Jack 3. Align the contacts on the bottom of the DT-X7 with the power contacts of the Cradletype Dual Battery Charger when inserting the unit. - Check the charging status with Indicator 1 on the DT-X7.
Connecting Multiple Cradle-type Dual Battery Chargers You can connect up to three Cradle-type Dual Battery Chargers. Doing so makes it possible to supply power to all the Cradle-type Dual Battery Chargers using one dedicated AC adaptor. 1. As shown in the illustrations below, remove the connector covers of the Cradle-type Dual Battery Chargers you want to connect to each other. Connector cover 2. Connect the two Cradle-type Dual Battery Chargers as shown below.
Specifications 1. Charging Specification Charging Method: Charge Period: Constant current/voltage Approx. 3 hours (1 standard battery pack) Approx. 5.5 hours (1 large-capacity battery pack) 2. Power Supply Power Source: Consumption Current: AC adaptor (AD-S60160BE/AD-S60160BU) 1.25A, 16V DC (1 unit) 3.7A, 16V DC (3 units) Output to Handheld Terminal: 5V DC 1.6A (max.) 3. AC Adaptor Model: AD-S60160B Input: 100V to 240V AC 50/60 Hz 1.5A Output: 16V DC 3.0A 4.
Important ! • Never short out the power contacts of the Cradle-type Dual Battery Charger. This can damage the Cradle-type Dual Battery Charger. • Allowing the power contacts become wet can cause an electric shock or fire. In addition, if the contacts become soiled, contact may be impaired resulting in poor charging. For reasons of safety and maintaining charging battery pack(s) in optimum condition, clean the power contacts by wiping with a dry cloth or cotton swab after disconnecting the AC adaptor.
Using the Dual Battery Charger (HA-F32DCHG) The optionally available Dual Battery Charger (HA-F32DCHG) can be used to simultaneously charge two battery packs.
1 Charge Indicator LED This LED indicates the charge status of the battery pack(s). Off: Not charging the battery pack. Red: Charging the battery pack. Red Flashing: Battery pack problem Green Flashing: Standby Green: Charging the battery pack is complete. 2 AC Adaptor Jack This is used to supply power by connecting the AC adaptor (sold separately). 3 Dual Battery Charger Connection Port Use this port to connect multiple Dual Battery Chargers to each other.
Charging Battery Pack Use the separately sold AC adaptor (AD-S42120B) for the power supply of the Dual Battery Charger. 1. Plug the cord from the AC adaptor into the AC adaptor jack of the Dual Battery Charger. 2. Plug the AC cord into a wall outlet. 3.Taking care that the battery pack is oriented correctly, insert it into the Dual Battery Charger. This causes the Charge Indicator LED to light in red, indicating that charging has started.
Connecting Multiple Dual Battery Chargers You can connect up to three Dual Battery Chargers. Doing so makes it possible to supply power to all the Dual Battery Chargers using one dedicated AC adaptor. 1. As shown in the illustrations below, remove the connector covers of the Dual Battery Chargers you want to connect to each other. Connector cover 2. Connect the two Dual Battery Chargers as shown below. 3.
Specifications 1. Charging Specification Charging Method: Charge Period: Constant current/voltage Approx. 3 hours (1 standard battery pack, normal temperature) Approx. 5.5 hours (1 large-capacity battery pack, normal temperature) When charging two battery packs: Approx. 5.5 hours (2 standard battery packs, normal temperature) Approx. 10 hours (2 large-capacity battery packs, normal temperature) 2. Power Supply Power Source: Consumption Current: Output: AC adaptor (AD-S42120B*) 12V DC 3.5A 4.2V DC 1.
Using Rechargeable Battery Pack HA-F20BAT HA-F21LBAT Your Handheld Terminal supports use of two battery pack types, one at a time, of different capacity. You can select the one that best suits your needs in terms of operating time, the type of options you need to use, etc. When using the large-capacity battery pack, you need to use the special large-capacity battery pack cover that comes with the battery pack (HA-F21LBAT).
Battery Pack Specifications Model: HA-F20BAT Rated Capacity: 4.07WH (1100mAh) Rated Voltage: 3.7V Dimensions: Approximately 36(W) × 55(D) × 9(H) mm (17⁄16"W × 23⁄16"D × 3⁄8"H) Weight: Approximately 28g (1oz) Bundled Item: Soft case Large-capacity Battery Pack Specifications Model: HA-F21LBAT Rated Capacity: 6.956WH (1880mAh) Rated Voltage: 3.7V Dimensions: Approximately 36(W) × 55(D) × 14(H) mm (17⁄16"W × 23⁄16"D × 9⁄16"H) Weight: Approximately 46g (1.
Attaching the Hand Belt (HA-F95HB) To use the Hand Belt (HA-F95HB), attach it to the DT-X7 as follows. Items Included • Holdfast • Hand Belt • Screw (2pcs) Attaching the Hand Belt Attach the Hand Belt as described below. 1. Turn the DT-X7 over. 2. Attach the holdfast on the back of the DT-X7 and secure it using the screws supplied.
3. Thread the looped cord on the end of the Hand Belt through one of the strap holes at the bottom of the DT-X7. (You can use either hole.) Strap holes 4. Feed the belt through the wire loop on the mount, fold it back and secure it with the hook-loop fastener. Wire loop Important! • When inserting the DT-X7 with the Hand Belt attached into the USB Cradle, etc., check the Power LED on the cradle and the indicator on the DT-X7 to ensure that the DT-X7 is inserted securely.
CASIO COMPUTER CO., LTD.
