Quick Start Guide Model 3350
KEYS, DISPLAYS AND FUNCTIONS Laser emitter Area/Volume/ Pythagoras display Measuring plane display Receiver lens Battery symbol Secondary Display Fractions/ Exponents Units Addition/ Subtraction display Fractions/ Exponents Units Main Display (Key 1) On / Measure distance (Key 5) Add/Subtract (Key 2) (Key 4) Measuring Plane / Units (Key 3) Clear/Off 2 — PREXISO X2 QUICK START GUIDE Area/ Volume/ Pythagoras
GENERAL SAFETY RULES DANGER! Do not aim light at persons or animals. Do not stare into the laser light source. Laser light can damage your eyes. Read the instructions carefully before using the device. Safe Practices for Using the Prexiso X2 • • • • • • • • Do not use as a pointing device. Make sure that the safety settings are not disabled. Make sure that warning labels and caution labels are not removed. Do not open the device with tools (screwdriver, etc.). Make sure that the device is not modified.
HOW TO USE Measuring conditions The quality of the measurement depends on the surfaces to which you are measuring. Strongly reflecting targets deflect the laser beam and cause measuring errors. Non-reflecting, dark surfaces increase the measuring time. Always begin by making a control measurement. Measurement errors Measuring errors are possible in case of: • Colorless fluids (e.g.
Adjusting measuring units Metric system is the standard setting. • To change the unit, hold Measuring Plane/Units seconds. (key 4) for several Possible units: • meters • feet-inch-fractions ─ main display up to 1/16 inch ─ secondary display up to 1/8 inch • inch-fractions ─ main display up to 1/16 inch ─ secondary display up to 1/8 inch Measuring (Key 1) • Press and release On/Measure • Aim active laser at target area. • Press and release On/Measure (Key 1) to light the laser.
Area • Press Area/Volume/Pythagoras (key 2) once. The Area symbol appears on the display. • Press On/Measure (Key 1) and measure the first distance (e.g., length). • Press On/Measure (Key 1) and measure the second distance (e.g., width). The Area measured is shown in the Main Display and the last distance measured is in the Secondary Display. L W L x W = Area W Area or Volume L H • Press Area/Volume/Pythagoras (key 2) twice. The Volume symbol appears on the display.
TROUBLESHOOTING • If the laser remains lit, or the value in the Main Display keeps changing, flashing, or showing “trc” you are in Continuous Measure mode. Press On/ Measure (Key 1) once to exit this mode. • If the message Error does not disappear after switching on and off the device repeatedly, contact Calculated Industries. • If the message InFo appears with a number, follow the instructions in the following table. No.
LIMITED WARRANTY This product has a 2-year Limited Warranty. For complete details, view warranty information on our website, www.calculated.com/warranty. HELPFUL USER HINTS a. To clean your Prexiso PX2 (PX2) use a soft, damp cloth. Do not immerse in, or spray with water. Avoid all liquid or abrasive cleaners. b. The electronic module in your PX2 was sealed after factory calibration; therefore, no user serviceable parts or adjustments are required. c. Your PX2 is temperature compensated.
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
To obtain warranty service in the U.S., please go to the website. A repaired or replacement product assumes the remaining warranty of the original product or 90 days, whichever is longer. Non-Warranty Repair Service – U.S.A. Non-warranty repair covers service beyond the warranty period, or service requested due to damage resulting from misuse or abuse. Contact Calculated Industries at the number listed above to obtain current product repair information and charges. Repairs are guaranteed for 90 days.
KEYS, DISPLAYS AND FUNCTIONS Laser emitter Area/Volume/ Pythagoras display Measuring plane display Receiver lens Battery symbol Secondary Display Fractions/ Exponents Units Addition/ Subtraction display Fractions/ Exponents Units Main Display (Key 1) On / Measure distance (Key 5) Add/Subtract (Key 2) (Key 4) Measuring Plane / Units (Key 3) Clear/Off Area/ Volume/ Pythagoras PREXISO X2 QUICK START GUIDE — 11
