Page 1 of 21 2002-08-05 Release: 1.
ScanID Release 1.0 1 Page 2 of 21 2002-08-05 ID: ID020058 INTRODUCTION 1.1 SYSTEM DESCRIPTION 3 3 2 IMPORTANT NOTES 4 3 HARDWARE 5 3.1 3.2 3.3 3.4 3.5 4 MEMBRANE KEYBOARD TECHNICAL DATA READING RANGES CHARGE STATION LICENSES AND CERTIFICATES / DECLARATION OF CONFORMITY SOFTWARE 4.1 STANDARD SOFTWARE 4.2 ENTER THE MENU 4.2.1 Menu Settings 4.2.2 Brightness of the Display 4.2.3 Read Mode 4.2.4 Code Type 4.2.5 Page Select 4.2.6 HERMOS Menu 4.2.
ScanID Release 1.0 1 Introduction 1.1 System Description Page 3 of 21 2002-08-05 ID: ID020058 The ScanID hand held System is a high frequency identification system using the FM-transmission. The basic item is a transponder working as a forgery-proof electronic identity disc. The reading unit of the system sends an energy impulse via the antenna. The capacitor of the passive, battery-less transponder is charged by this impulse. After that, the transponder returns a signal with the stored data.
ScanID Release 1.0 2 Page 4 of 21 2002-08-05 ID: ID020058 Important Notes This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference , and 2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
ScanID Release 1.0 3 Page 5 of 21 2002-08-05 ID: ID020058 Hardware Membrane keyboard Graphic display Load contacts The three load contacts are used to load the ScanID in the load station. The charging activity is shown on the display during the battery charging. The message ‘battery charged’ is shown in case of a full charged battery.
ScanID Release 1.0 3.1 Page 6 of 21 2002-08-05 ID: ID020058 Membrane Keyboard On/Off: This key switches on and off the reader. Push the key for more than 3 seconds to switch off. Read: The ‘Read’ button is used to start the reading of the RF-tag data. In case of an unsuccessful reading, the handheld tries to read the RF tag up to 5 times (default setting). In menu mode this key applies the entered code to enter the HERMOS menu.
ScanID Release 1.0 3.2 Page 7 of 21 2002-08-05 ID: ID020058 a1 Technical Data Parameter Operation temperature Stock temperature Permissible humidity @ 50C° Transmitter frequency LF Typical period of charging impulse Max. repeat of reading Protection mode Housing material Weight Li-Ion Accu Value 0 to +50°C -25 to +70 °C 25 - 80 % 134.2 kHz 50ms 8/s IP 40 ABS about 300g 7,2 V / 1450 mAh The accumulator is designed to read more than 2500 tags before you have to reload the ScanID.
ScanID Release 1.0 3.3 Page 8 of 21 2002-08-05 ID: ID020058 Reading Ranges The reading range is only valid for the transponder types Read only, Read/Write and for the first page of the multipage transponder. If you want to read another page than page 1 of a multipage transponder, the transponder requires the page number. In this case the reading range can be reduced. Rod Antenna: Frame Antenna: 3.
ScanID Release 1.0 4 Page 9 of 21 2002-08-05 ID: ID020058 Software The software of the ScanID is designed for a wide range of customer applications. It can also be developed for special applications and it is possible to update the firmware. ! The red colored modes are not available for this type ! 4.1 Standard Software After switching on the ScanID the start page with the current software version is shown. SCANID 1.5 LF press Read Press the ‚Read’ button to start the reading process of the ScanID.
ScanID Release 1.0 4.2 Page 10 of 21 2002-08-05 ID: ID020058 Enter the Menu To switch into the menu mode press the two arrow buttons for more than 3 seconds. 4.2.1 Menu Settings The menu items can be selected by the two cursor buttons. To activate a selected menu item press the ‚Select’ button. Settings Brightness Read Mode Code Type Page Select HERMOS menu 4.2.2 Brightness of the Display Select the wanted option (light or dark) with the cursor buttons.
ScanID Release 1.0 Page 11 of 21 2002-08-05 ID: ID020058 4.2.3 Read Mode The current mode is shown in the last line. To change the mode, select the requested mode with help of the cursor buttons and activate the mode by pressing the ‚Select’ button. The active mode is shown under item ‚active’. Read Mode auto. send trig. send not send active: not send auto. send: After reading the FOUP-ID the ScanID establishes a connection to a host data base automatically and sends the FOUP-ID in message S3F81. trig.
ScanID Release 1.0 Page 12 of 21 2002-08-05 ID: ID020058 4.2.4 Code Type The display of the current mode and the possibly change is similar to the described ‚Read Mode’. Code Type HEX ASCII active: ASCII If the current setting is ‚ASCII’, the FOUP-ID is shown in ASCII characters. In case of the setting is ‚HEX’, the 8 bytes of the ID are shown in hexadecimal format on the display. Example: ASCII: 00123456 Hex: 3030313233343536 4.2.
ScanID Release 1.0 Page 13 of 21 2002-08-05 ID: ID020058 Scan: The first page of a any transponder will be read. (RO - Tags, RW - Tags, Multipage) R/O Transponder: R/W Transponder: Multipage all: Read a R/O transponder Read a R/W transponder all pages of a multipage transponder will be read (only available in single device mode!) 1. page of multipage will be read Multipage 1: ... Multipage 17: 17.
ScanID Release 1.0 4.2.6 Page 14 of 21 2002-08-05 ID: ID020058 HERMOS Menu The menu item ‚announce to base’ initialize the DECT module of the ScanID to the address of the base station. Should the ScanID after an aborted firmware upload still be configured to the download station, this menu item can be used to configure the DECT module of the ScanID again to the base station. The ‚Download mode’ is used for the update of the ScanID software.
ScanID Release 1.0 4.2.7 Page 15 of 21 2002-08-05 ID: ID020058 HERMOS Setup Select the wanted parameter with the cursor buttons. To change the value of the parameter, use the ‚Select’ button. Readmode: Typemode: Pagemode: Codemode: Testmode: Language: MaxRepeat: Baudrate: TimeOut5 : 1 = read mode changeable, 0 = read mode fix 1 = ScanID type adjustable, 0 = ScanID type fix (dummy) 1 = type/page adjustable, 0 = typ/page fix 1 = display mode adjustable, 0 = display mode fix 0 .. 2; 0 = Off, 1 = test msg.
ScanID Release 1.0 HERMOS Informatik GmbH Gartenstrasse 19, 95490 Mistelgau, Germany Page 16 of 21 2002-08-05 ID: ID020058 Tel. +49-9279/991-910 Fax +49-9279/991-900 info@carmas.
