OPERATING INSTRUCTIONS Read Me First Personal Computer series Read Me First Safety Precautions.......................................... 2 Regulatory Information.................................... 7 Getting Started First-time Operation...................................... 15 Detaching the tablet from the keyboard base..... 20 Attaching the tablet to the keyboard base..... 22 n Terms and illustrations in these instructions In these instructions, the names and terms are referred as follows.
Safety Precautions To reduce the risk of injury, loss of life, electric shock, fire, malfunction, and damage to equipment or property, always observe the following safety precautions. Explanation of symbol word panels The following symbol word panels are used to classify and describe the level of hazard, injury, and property damage caused when the denotation is disregarded and improper use is performed. Read Me First DANGER Denotes a potential hazard that will result in serious injury or death.
Precautions on the Built-in Bridge Battery (for disposal) When disposing the battery, generation of heat, ignition or rupture of the Built-in Bridge Battery may result.
Safety Precautions WARNING Read Me First If a Malfunction or Trouble Occurs, Immediately Stop Use If the Following Malfunction Occurs, Immediately Unplug the AC Plug and the Battery Pack • This product is damaged • Foreign object inside this product • Smoke emitted • Unusual smell emitted • Unusually hot ÖÖAfter the above procedure, contact your technical support office for repair.
Hold the Plug When Unplugging the AC Plug Use Only the Specified AC Adaptor With This Product ÖÖDo not use an AC adaptor other than the one supplied (supplied with the unit or one sold separately as an accessory). This product may fall over or drop, resulting in an injury. Do Not Place This Product on Unstable Surfaces Avoid Stacking When Carrying the Computer, Attach the Main Unit To the Keyboard Base Tightly Until Red Signs Under the Detach Lock And Release Lever Are Concealed.
Read Me First Safety Precautions 6 NOTE l The battery pack may become warm during recharging or normal use. This is completely normal. l Recharging will not commence if internal temperature of the battery pack is outside of the allowable temperature range (0 °C to 50 °C {32 °F to 122 °F}). (è OPERATING INSTRUCTIONS - Reference Manual “Basic Operation” “Battery Power”) Once the allowable range requirement is satisfied, charging begins automatically.
Regulatory Information This product and your Health This product, like other radio devices, emits radio frequency electromagnetic energy. The level of energy emitted by this product however is far much less than the electromagnetic energy emitted by wireless devices like for example mobile phones. Because this product operates within the guidelines found in radio frequency safety standards and recommendations, we believe this product is safe for use by consumers.
Regulatory Information Lithium Battery / Pile au lithium Lithium Battery! This computer contains a lithium battery to enable the date, time, and other data to be stored. The battery should only be exchanged by authorized service personnel. Warning! A risk of explosion from incorrect installation or misapplication may possibly occur. Pile au lithium! Le micro-ordinateur renferme une pile au lithium qui permet de sauvegarder certaines données, notamment la date et l’heure.
Information for Users on Collection and Disposal of Old Equipment and used Batteries These symbols are only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. 53-M-1 As an ENERGY STAR® Partner, Panasonic Corporation has determined that this product meets ENERGY STAR® guidelines for energy efficiency.
Read Me First Regulatory Information Do not operate Personal Computer or Handheld Computer incorporating wireless WAN modem in the presence of flammable gases or fumes. Switch off the cellular terminal when you are near petrol stations, fuel depots, chemical plants or where blasting operations are in progress. Operation of any electrical equipment in potentially explosive atmospheres can constitute a safety hazard.
* Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certifi ed power level in all tested frequency bands. Although the SAR is determined at the highest certifi ed power level, the actual SAR level of the device while operating can be well below the maximum value. This is because the device is designed to operate at multiple power levels so as to use only the poser required to reach the network.
Regulatory Information This product contains a Coin Cell Lithium Battery which contains Perchlorate Material special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate/ 38-M-1 For Canada Read Me First Canadian ICES-003 CAN ICES-3(B)/NMB-3(B) 7-M-2 ISED Canada This product complies with ISED Canada’s licence-exempt RSSs.
l This computer complies with ISED Canada radiation exposure limits set forth for an uncontrolled environment. l This PC with WLAN and/or Bluetooth transmitters installed, has been approved for portable operation and does not require any minimum spacing be provided between antennas and all person’s body. FOR USE WITH MODEL NO.
Regulatory Information For Europe Read Me First Declaration of Conformity (DoC) “Hereby, Panasonic declares that this Personal Computer is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” Hint: If you want to get a copy of the original DoC of our above mentioned products, please contact our web address: http://www.ptc.panasonic.
First-time Operation n Preparation A Check and identify the supplied accessories. If you do not find the described accessories, contact your support office. Model No: CF-AA6413C, CF-AA5713A • Soft Cloth. . . . . . 1 • Digitizer pen. . . . 1 • AC Cord. . . . . . . 1 • Battery Pack . . . 1*1 Model No: C F-VZSU0QW • Tether. . . . . . . . . 1 • Stylus. . . . . . . . . 1 • OPERATING INSTRUCTIONS - Read Me First (This book) . . .
First-time Operation 1 1 A Attaching the pen (included) to the computer Use the tether to attach the pen (included) to the computer so you will not lose it. There are holes (A) to attach it. 1 2 3 4 CAUTION l Do not pull the tether with excessive force. The stylus may hit the computer, person’s body or other objects when released. 2 Getting Started 2 16 Connect your computer to a power outlet A Open the cover. B Connect your computer to a power outlet.
1 3 Open the display A Pull out the handle. l If you do not pull out the handle before opening the display, the computer may fall over due to the weight of the display. B Push down on the latch (B), and pull it out to release it. C Hold the corners with both hands, and lift the display slightly. D Hold the side of the computer with either of your hands and then lift up the display to open.
First-time Operation 5 Setup Windows Follow the on-screen instructions. l The computer restarts several times. l After the computer is turned on, the screen remains black or unchanged for a while, but this is not a malfunction. Wait for a moment until the Windows setup screen appears. l During setup of Windows, use the touchpad and clicking to move the pointer and to click an item. l Setup of Windows will take approximately 5 minutes. Go to the next step, confirming each message on the display.
8 Create a recovery disc A recovery disc allows you to install OS and restore its factory default condition, in case, the recovery partition of the SSD is damaged. We recommend creating a recovery disc before you begin using the computer. Refer to è OPERATING INSTRUCTIONS - Reference Manual “Important Operation/Settings” “Create a Recovery Disc” about creating the disc. NOTE B Click [Add] under “Password”. l Set the key entry mode to English (“ENG”) and enter characters. l Remember your password.
Detaching the tablet from the keyboard base When detaching the tablet from the keyboard base while it is turned on, note the following points. CAUTION l Before detaching the tablet, confirm the following things. - Save the necessary data. - Close files you have opened from removable disks and network drives. - Remove peripheral devices connecting to the tablet. l Do not detach the tablet in the conditions below. When the SD Memory Card indicator is on.
3 2 RELEASE A B D Detach the tablet from the keyboard base. CAUTION The tablet can be attached facing the reverse direction. Getting Started l When detaching the tablet from the keyboard base, hold the position at the locations dashed line circled in the illustration. CAUTION l Depending on the shape of the tablet’s rear, you may not be able to operate the unit with the tablet attached in the direction illustrated. Be sure to verify this before actual use.
Attaching the tablet to the keyboard base A Push the tablet at the locations dashed line circled in the illustration in a downward direction. Release lever (B) will return to the direction of the arrow. B Raise detach the lock (A) above. NOTE Getting Started l Confirm that the red signs near the detach lock and the release lever can not be seen.
MEMO 23
Panasonic Corporation Osaka, Japan Panasonic System Communications Company of North America Two Riverfront Plaza Newark, NJ 07102 Panasonic Canada Inc. 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 Panasonic Australia Pty. Limited ACN 001 592 187 ABN 83 001 592 187 1 Innovation Road, Macquarie Park NSW 2113 Web Site : https://panasonic.
