Info Sheet

ASW10CM
Pure and Simple
Wrapped in an exquisitely veneered cabinet, the 10 inch dual voice coil paper/
Aramid Fibre driver is driven and controlled by the mega efficient 500W
audiophile standard Class D amplifier and switch mode power supply,
delivering immense power when the signal demands.
T
www.bowers-wilkins.com
Copyright © B&W Group Ltd. E&OE
B&W Group Ltd reserves the right to amend details of the
specification without notice in line with technical developments
Description
Drive units
Frequency range
Frequency response
Bass Extension
Functions:
Inputs:
Dimensions
Net weight
Finish
Active closed-box subwoofer system
ø250mm (10 in) paper/Aramid Fibre cone long-throw driver
ø76mm (3 in) dia voice coil - dual suspension diecast chassis
-6dB at 18Hz and 25/140Hz adjustable (EQ at A)
±3dB 25Hz – 40/140Hz adjustable (EQ at A)
-6dB at 18Hz (position A)
-6dB at 23Hz (position B)
-6dB at 28Hz (position C)
500W
Rated power consumption: 94W
Standby: 0.8W
Idle (ON no signal) 11.8W
Input impedance: 33kΩ
Signal / noise: >80dB
Input level (line in)
Input level (speaker in)
Low-pass filter frequency
Low-pass filter bypass (line in only)
Bass extension
Bass roll-off alignment
Auto sense on/standby
Phase switch
Line In (RCA Phono)
Speaker in (Binding post)
12v trigger (3.5mm jack)
Active 4th-order, variable cut-off frequency
Height: 325 mm (12.8 in) not including feet
Width: 325 mm (12.8 in) Depth: 362mm (14.3 in)
including grille and
controls 19.5kg (43 lb)
Cabinet: Gloss Black
Satin White
