EN BORA Classic 2.0 system installation instructions Cooktop extractor and cooktops C2XIMEN-004 www.bora.
Installation instructions: Original Translation Manufacturer BORA Vertriebs GmbH & Co KG Innstraße 1 6342 Niederndorf Austria Contact T +43 (0) 5373/62250-0 mail@bora.com www.bora.com The distribution and duplication of this document, as well as the use and disclosure of its contents are prohibited unless expressly authorised. Great care was taken when devising these operating and installation instructions.
EN Table of Contents 1 1.1 1.2 1.3 1.4 1.5 General information Target group......................................................... 4 Validity................................................................. 4 Other applicable documents................................ 4 Data protection.................................................... 4 Presentation of information.................................. 5 4 2 Safety 6 2.1 2.2 2.3 2.4 2.5 3 General safety instructions..............................
General information EN 1 General information 1.2 INFO 1.1 Target group These installation instructions apply to the following target groups: Target group Requirements Ambitious DIYers Ambitious DIYers can independently conduct all joinery and installation work providing they possess the necessary skills and expertise. They must never attempt to connect the electricity and gas themselves.
General information 1.5 EN Presentation of information We use standard formatting, numbering, symbols, safety instructions, terms and abbreviations so that you can work quickly and safely when using this manual. Instructions are indicated with an arrow. XX Always follow all instructions in the prescribed order. Enumerations are indicated with a square bullet point at the start of the line.
Safety EN 2 Safety 2.1 General safety instructions INFO QQ The The appliance complies with the stipulated safety requirements. The user is responsible for appliance cleaning and maintenance as well as its safe use. Improper use can lead to personal injury and damage to property. operating and installation instructions contain important information about installation and operation. These enable you to protect yourself against injuries and prevent damage to the appliance.
Safety DANGER! Risk of asphyxiation! Packaging components (e.g. film, polystyrene) can be life-threatening for children. XX Store all packaging components out of reach of children. XX Dispose of the packaging properly and immediately. CAUTION! Lifting heavy loads can cause back injuries! If not handled correctly, removing and installing the appliance can cause injuries to the limbs or torso. XX Removing the cooktop from the packaging is a two-person job.
Safety EN 2.2.2 Safety instructions – cooktop extractor installation DANGER! Risk of poisoning caused by combustion gases! When the cooktop extractor is used in exhaust mode, it draws in air from the room it is installed in and from neighbouring rooms. Without sufficient air, there will be a drop in air pressure. Toxic gases could be drawn out of the chimney or extraction ducting on a fireplace that depends on the room air and back into the room. XX Make sure that there is always a sufficient air supply.
Safety 2.4 Safety instructions – spare parts WARNING! Risk of injury and damage to property! Incorrect components can lead to personal injury or damage to the appliance. Modifications, additions or alterations to the appliance can lead to safety risks. XX Only use original spare parts for repairs. INFO 2.
Technical data 3 Technical data 3.1 CKA2 Device dimensions CKA2 439 116 220 - 240 V Frequency 50/60 Hz Power consumption (including external BORA Universal article fans) max. 550 W Fuse protection (internal) TR 3.15 A Dimensions (width x depth x height) 439 x 515 x 190 mm Weight (incl. accessories/packaging) 7.5 kg Surface material SSG glass/1.
Technical data CKFI Device dimensions CKFI Parameter Value Supply voltage 220 - 240 V Frequency 50/60 Hz Power consumption 3.68 kW Fuse protection 1 x 16 A Dimensions (width x depth x height) 327 x 515 x 58 mm 327 48,5 230 230 27,5 3.2 EN Weight 7.9 kg (incl.
Technical data 3.3 CKI Device dimensions CKI 327 Value Supply voltage 220 - 240 V Frequency 50/60 Hz Power consumption 3.68 kW Fuse protection 1 x 16 A Dimensions (width x depth x height) 327 x 515 x 58 mm Weight (incl. accessories/packaging) 7.
Technical data 3.4 CKIW Device dimensions CKIW Parameter Supply voltage Value 220 - 240 V Frequency 50/60 Hz Power consumption 3.0 kW Fuse protection 1 x 16 A Dimensions (width x depth x height) 327 x 515 x 116 mm Weight (incl. accessories/packaging) 9.8 kg Cooktop Power levels 1 - 9, P Warming levels 3 Cooking zone power setting Ø 250 mm Tab. 3.4 EN 515 Ø2 50 327 2400 W 3000 W Technical data CKIW CKIW device dimensions top view 116 47 Fig. 3.11 Fig. 3.12 Fig. 3.13 www.
Technical data 3.5 CKCH Device dimensions CKCH 327 Value Supply voltage 220 - 240 V Frequency 50/60 Hz Power consumption 3.68 kW Fuse protection 1 x 16 A Dimensions (width x depth x height) 327 x 515 x 75 mm Weight (incl. accessories/packaging) Cooktop 7.
Technical data CKCB Device dimensions CKCB 327 Value Supply voltage 220 - 240 V Frequency 50/60 Hz Power consumption 3.68 kW Fuse protection 1 x 16 A Dimensions (width x depth x height) 327 x 515 x 75 mm Weight (incl. accessories/packaging) Cooktop 7.4 kg Power levels Warming levels 1-9, 2-ring connection, roaster cooking zone connection 3 Front cooking zone (zone 1) Ø 180 mm 1600 W Front cooking zone (zone 1) Ø 180 mm Rear cooking zone (zone 2) Ø 120/180 mm 195.
Technical data CKG Value (measurement taken without cooktop extractor) Tab. 3.7 Fig. 3.20 800 – 3000 W 63.3 % 550 – 2000 W 61.3 % 62.3 % Technical data Fig. 3.21 Fig. 3.22 16 515 CKG device dimensions top view 25 High-power front burner Normal rear burner Total (average) 327 246 40,5 299 14 73 Supply voltage 220-240 V Frequency 50/60 Hz Total burner output 5.0 kW Power rating 20 W Fuse protection 1 x 0.
Technical data CKT Device dimensions CKT Value Supply voltage 220 - 240 V Frequency 50/60 Hz Power consumption 3.5 kW Fuse protection 1 x 16 A Dimensions (width x depth x height) 327 x 515 x 73 mm Weight (incl. accessories/packaging) 13.
Installation EN 4 Installation XX Observe all safety and warning information (see the Safety chapter). XX Follow the enclosed manufacturer’s information. 4.1 General installation information INFO The appliances must not be installed above cooling devices, dishwashers, stoves, ovens, washing machines or dryers. INFO The contact surfaces of the worktops and wall sealing strips must be made of a heat-resistant material (up to approx. 100 °C).
Installation XX Do not under any circumstances install parts which are damaged. XX Dispose of transport packaging in the proper manner (see the Decommissioning, disassembly and disposal chapter). 4.4 EN Assembly instructions 4.4.1 Safety clearances XX Maintain the following safety clearances: 4.2.
Installation EN 4.4.
Installation INFO The hose line must not come into contact with hot surfaces on the cooktop or other devices. INFO The gas hose must be inspected every 5 years and replaced if necessary. The gas hose must meet the requirements of EN14800. INFO If the gas cooktop is used in a model with two cooktop extractors, it is to be installed at the side. If installed between the cooktop extractors, the pull of air on both sides may affect the flames. EN 1 Air supply to gas cooktop CKG 1 2 2 Fig. 4.
Installation 4.5.1 Flush installation 4.5.2 Surface mounting B ±2 ≤ B ±2 R5 R5 ≤ ≥ 50 x Fig. 4.8 Fig. 4.10 ≥ 600 495 ±2 x ≥ 50 ≥ 600 519 ±2 495 ±2 ≤ R5 (≥ 50) A ±2 (≥ 50) EN Cut-out dimensions for surface mounting Cut-out dimensions for flush installation 10 10 - 40 10 - 40 7 +0,5 12 Fig. 4.11 Fig. 4.9 Cooktops/cooktop extractor 1/1 A in mm 448 B in mm 424 2/1 776 752 3/2 1221 1197 4/2 1549 1525 Cooktops/cooktop extractor Tab. 4.4 Tab. 4.
Installation 4.6 Installation dimensions min. 600 min. 50 495 ≥800 190 ≥600 EN ≥900 120 min. 900 max. 480 290 max. 340 Minimum installation dimensions with shallow silencer USDF min. 100 Fig. 4.12 Fig. 4.14 ≥720 ≥800 219 151 430 Appliance installation dimensions with shallow silencer USDF in case of a unit depth of 600 mm min. 700 min. 50 190 ≥870 max. 440 min. 100 290 Minimum installation dimensions with round silencer USDR50 Fig. 4.15 www.bora.com 120 max. 580 min.
Installation EN 4.7 600–750 495 INFO 190 min. 50 min. 900 The BORA Classic 2.0 system offers different installation options. It is necessary to decide which installation option is to be implemented prior to installation. XX Please ensure prior to installation that you have made the correct preparations for the corresponding installation. XX In the event of any queries regarding the planned installation option, please contact your kitchen planner. 120 min. 165 max.
Installation 4.8 Assembling the extraction system INFO Cooktop extractor CKA2 is delivered as individual parts which must be assembled prior to or during installation. INFO The individual components must be assembled according to the installation option. INFO 4.8.1 Assembling cooktop extractor CKA2 There are two different models of cooktop extractor CKA2, depending on the planned airflow: 1 Fig. 4.
Installation EN QQ Cross bars on the kitchen unit in the area of the worktop cut-out may need to be removed. QQ The drawers and/or shelves in the floor unit must be removable for maintenance and cleaning purposes. XX Make sure that the area at the front of the floor unit is sufficiently ventilated with clean air. XX Make sure that the floor unit is not soiled by the ventilation openings. 4.9.1 Fitting and positioning the cooktop extractor 1 4.
Installation EN Adapting the 90° bend: 1 2 3 Fig. 4.24 [1] [2] [3] Shortening the 90° bend 90° bend Cut marks Fine saw XX Adapt the 90° bend [1] to the depth of the worktop if necessary by shortening it accordingly at the cut marks [2] using a fine saw [3]. Fig. 4.26 Attach the seal to the plinth fan outlet nozzle. XX Push the seal onto the plinth fan outlet nozzle. The seal will need to be stretched slightly.
Installation EN Example of a standard set-up 1 2 3 XX Ensure that a minimum clearance of 3 m is maintained between the fan units. XX Use only BORA Universal fans. 4 If additional fans are installed at a later date: XX When installing additional fans at a later date, carry out the initial operation procedure (see Initial operation). QQ In the basic configuration, any fans installed at a later date are automatically recognised provided that they have been connected correctly.
Installation Adjusting the installation height (only in the case of flush installation) 1 EN XX Turn the four fixing brackets [2] under the worktop. QQ The fixing brackets are secured against slipping by a ratchet mechanism. XX Tighten the tensioning screws [1] with max. 2 Nm. XX Do not use a cordless screwdriver or similar electrical device to secure the cooktop extractor. XX Check that the cooktop extractor is positioned correctly. 4.11.3 Securing the cooktops 2 Fig. 4.
Installation EN Tepan stainless steel grill CKT 1 2 5 3 2 4 Fig. 4.33 [1] [2] [3] [4] [5] INFO Securing the Tepan stainless steel grill Angled plate Screws Washer Screw (60 mm) Mounting bracket Function 4.12 Connecting external switch contacts The Home In and Home Out external connections must only be connected by a certified specialist. The specialist also assumes responsibility for the proper installation and commissioning.
Installation EN Preparing connection cables for external switching equipment Connection cable Home In H03VV-F 2x 0.5mm² Home Out H03VVH2-F 2x 0.75mm² Tab. 4.6 INFO INFO X 311.1 X 311.2 Contact X 312.1 X 312.2 Use connection cables of the following types and manufacturers to connect external switching equipment.
Installation EN INFO If external switching devices are connected both to the Home In and Home Out interfaces, both cables should be secured with the strain relief clamp. XX Check the correct installation, as well as the firm positioning of the connection cables. XX Close and secure the control unit cover. XX Screw down the lid with the screw provided (max. 2 Nm). XX Make sure that the cable is not damaged or trapped. 4.
Installation EN 4.13.4 Connecting fans to the control unit 1 2 2 Fig. 4.40 [1] [2] Fig. 4.43 [1] [2] Fitting split ferrite sleeves Connection cable Split ferrite sleeve XX Fit the split ferrite sleeve [2] provided in the scope of delivery to the connection cable [1]. 4.13.
Installation EN Cooktop power connection The mains cable to be used (pre-assembled) must be at least Type H05V2V2-F. Connection Fuse protection Minimum cross-section 1-phase connection 1 x 16 A 1.5 mm² Tab. 4.7 INFO Fuse protection and minimum cross-section A damaged mains cable must be replaced by another suitable mains cable. This may only be done by an authorised member of the After Sales Service team. XX Switch off the main switch/automatic circuit breaker before connecting the cooktop.
Installation XX Shut off the gas supply if you determine that gas is escaping and ventilate the room. XX Seal the point from which the gas is leaking. XX Re-check all connections and the gas connection. XX Repeat the leak test until all connections are tight. XX Create a leak test record and give this to the user. XX Switch on the main switch/automatic circuit breaker. XX Start up the system (see the Operation section) XX Check all the functions of the cooktop extractor and cooktop are working correctly.
Installation EN 4.14.4 Gas configuration INFO The burner nozzles, gas type and pressure may only be changed by a certified engineer or BORA service technician. He/she also assumes responsibility for the proper gas installation and commissioning. INFO Gas characteristic curve A must not be used in the case of liquid gas (G30/31). INFO It is important that the gas type, gas pressure and characteristic curve are set correctly to ensure safe, failure-free operation of the gas cooktop.
Installation If all cooktops have been recognised correctly: XX Carry out the basic configuration. 4.16 Sealing the devices 4.15.1 Function test XX Carry out a thorough function test on all devices. XX In the event of error messages, see the “Troubleshooting” chapter in the operating instructions. Function test on gas cooktop CKG XX Switch the cooking zone on.
Decommissioning, d isassembly and disposal EN 5 Decommissioning, disassembly and disposal XX Observe all safety and warning information (see the Safety section). XX Follow the enclosed manufacturer’s information. 5.1 Decommissioning Decommissioning is understood as final shutdown and disassembly. Following decommissioning, the device can either be installed into other units, sold on privately or disposed of. INFO Electricity and gas connections may only be disconnected by qualified specialists.
