Avi-on Product Specifications
!
Works With All Avi-on Fixture & Zone Controllers
Direct Connect™ Microwave Occupancy &
Daylighting Sensor
Part Number
Product Name
Application
Color
AVI-DC-MW
Direct Connect™ Microwave Occupancy & Daylighting Sensor*
In-fixture, tile mount, indoor
White
AVI-DC-10FTCBL
10ft (3m) Direct Connect™ Cable**
Ceiling mount, indoor
Gray
AVI-DC-MW-MAG
Microwave Magnetic Mount**
In-fixture, indoor
Gray
To order please contact Avi-on sales at (877) AVION-US, (877) 284-6687 or prosales@avi-on.com
for information on becoming an Avi-on partner and order details.
Product Overview
Easy to Connect to
Avi-on Fixture & Zone Controller
3ft and 10ft cable options make it easy to install
inside or outside the xture
Flexible Mounting Options
• In-xture via magnet or bracket,
behind the lens
• Acoustic tile
Microwave Motion & Daylighting Sensor
Fully adjustable parameters
Description
The Direct Connect™ Microwave Occupancy & Daylighting
Sensor provides motion detection and/or daylight
harvesting in a highly compact unit. Microwave sensing
technology works with any Avi-on Fixture & Zone Controller.
The sensor is an integral part of the Avi-on Bluetooth® with
Mesh product ecosystem including the ability to support
Luminaire Level Lighting Control (LLLC) and/or groups of
xtures. The network automatically detects the sensor
locations and adds them to the system with their associated
xtures. Commissioning can be done using the Avi-on
mobile apps or installer web tools. Sites that subscribe to
Avi-on IoT Cloud Services using an Avi-on Remote Access Bridge
can be commissioned remotely.
Operation
The sensor receives communication and power from any
Avi-on load controller via an Avi-on standard low voltage
cable. The motion sensor supports a wide array of control
strategies including occupancy, vacancy, bi-level, scheduled
operation, even safety presence detection for UV-C lighting.
Daylight sensing can apply to zones of xtures as required
by code.
Applications
The versatile design and mounting options make this sensor
a great solution for commercial and institutional
applications such as offices, schools, or common areas. as
well as behind a lens of sealed xture low bay applications.
The sensor can be mounted in many different ways
including behind a lens using an innovative magnetic
mounting clip, screwed on using elbow or ush brackets, or
clipped to acoustic tile rail on the edge of the xture with
the supplied tile clip. The microwave pattern can be tuned
to a variety of applications up to 15 feet using the mobile
app or remote setup tools. Best of all, the low-power unit
will not shine through oors, walls, or windows.
Ordering Information
High Resolution, Low Power
• Covers office and open areas up to 15ft
• Will not trigger through oors, door,
windows
*Includes acoustic tile rail mount clip and 3ft cable.
**Accessory
