AVerTV 6.2 User Manual English DISCLAIMER All the screen shots in this documentation are only example images. The images may vary depending on the product and software version. Information presented in this documentation has been carefully checked for reliability; however, no responsibility is assumed for inaccuracies. The information contained in this documentation is subject to change without notice. COPYRIGHT © 2007 by AVerMedia TECHNOLOGIES, Inc. All rights reserved.
Table of Contents Chapter 1 Device Introduction ......................................................................................1 Chapter 2 AVerTV 6 Introduction ..................................................................................2 Chapter 3 Introducing the AVerTV Application ...........................................................3 3.1 Launching the AVerTV 6 Application.............................................................................................................
4.2.6 Enabling Subtitle Function ....................................................................................................................... 31 4.3 Adding and Deleting Program Lists ................................................................................................................. 32 4.4 Selecting a TV/Radio Channel.......................................................................................................................... 33 4.5 Creating Channel Groups.........
7.4 Playing the Recorded Programs........................................................................................................................ 52 7.5 Picture-in-Picture Display................................................................................................................................. 53 Chapter 8 Image Capture .............................................................................................54 8.1 Before Capturing ............................................
Chapter 1 Device Introduction Thanks for purchasing AVerMedia’s product. The table below lists an overview of the product you purchased. From this table, you can quickly learn about your product features and know which chapter you need to read. Please do read this table before using AVerTV 6 application. Product Name AVerTV Hybrid + FM PCI Model No.
Chapter 2 AVerTV 6 Introduction Now, with this product, you can watch TV, listen to the radio, record your favorite programs and enjoy other features on your PC. Turn your computer system into a real multimedia entertainment center. You’ll never miss your favorite ball games, soaps or game shows anymore because the TimeShift function performs background recording of a TV program. This means you can return and watch from the part of the program where you left off.
Chapter 3 Introducing the AVerTV Application The AVerTV 6 application allows you to watch TV or video, and record still or motion video on your PC while you work on your computer. 3.1 Launching the AVerTV 6 Application Run the AVerTV 6 application from the Programs menu. Quick TV Launcher To run the application, click Start, point to Programs, choose AVerMedia, AVerTV 6, and ”on then click AVerTV 6. Another way is to double-click the AVerTV 6 program icon “ the desktop.
2. Then you need to select the TV option to search for air channels, or select CATV to scan for cable channels if your choice is “Analog TV” in step 1. 3. Click New and the Program List dialog box will appear. Type in the desirable name and click OK. 4. Click Program Scan to search for available channels/programs in your area. 5. After scanning, the active TV channels will be listed inside the box. Click Apply to save the scanned channels.
7. If you choose FM Radio or Digital TV in step 1, just repeat step 3-6 to complete the program scanning.
3.3 Introducing the User Interface The TV monitor allows you to watch live TV or video. 1 2 3 4 5 6 7 Panel On / Off Playback Seek Slider Play / Pause Stop TimeShift Record Volume 8 9 10 11 12 13 Channel Up/Down Resize Window Show / Hide Video Frame Minimize Full Screen Exit The Control Panel provides button controls for selecting channels, adjusting volume, capturing images, and more. It has a panel display that shows the current channel number and channel name.
3.4 The Control Panel (This picture is only for reference) The table below describes the functions of the buttons on the Control Panel. BUTTON 1 Signal Status / Repeat Play Status FUNCTION TV/Radio mode: Right click on the info area of the control panel to switch signal sources. Playback mode: Right click on the info area of the control panel and enable the Repeat function. The system will continuously playback the files in the playlist. 2 Signal Strength Display signal strength.
14 Full Screen Show TV/Video programs in full screen. 15 Program List Display the program list and adjust color, volume and so on. 16 Audio Mode Switch between available audio modes. 17 Scheduler Display Scheduler dialog box. 18 Play List Create a playlist of video files to playback. 19 Show/ Hide Numeric Panel Toggle between displaying or hiding the Numeric Panel. 20 Radio Source 21 Change Video Source Switch between FM radio and DVB-T radio.
3.5 Remote Control You can use remote control to turn on/off the programs, select channels, adjust volume and so on. Please be noted that you have activated Quick TV. 3.5.1 Remote Control Buttons (Model 1) 1 2 6 3 4 5 7 Button 1. Power 2. VOL +/3. Source 4. Numeric Buttons 5. MUTE 6. CH ▲/▼ 7. CH RTN Description Turn on/off the application Volume up/down. Switch between available signal sources. Select a TV channel. Turn on/off the sound. Go up or down to the next active channel.
3.5.2 Remote Control Buttons (Model 2) Button 1. POWER 2. NUMERIC BUTTONS 12. MENU Description Turn on/off the application. - Select a TV channel. - Under the 16-Channel Preview mode, use ← ↑ → ↓ to highlight the intended channel. Go to the previously selected channel. 16-Channel Preview. Volume up/down. Display TV in full screen. Switch between available audio modes. Play the last recorded or played file. - End the playback or recording. - End the TimeShift mode and return to real-time TV or Radio mode.
19. MUTE Freeze the playback. Switch from real-time TV or Radio to TimeShift mode. Rewind the playback. Jump to the Teletext page of the corresponding color according to this button. Switch to DVR mode and record the current program or video into your hard drive. Turn on/off the sound. 20. CH ▲/▼ Go up or down to the next active channel. 21. SNAPSHOT Capture the on-screen image to a bitmap file. 22. DISPLAY Display information. 23. SOURCE Switch between available signal source. 16.
3.5.3 Remote Control Buttons (Model 3) Button Description 1.Power 2.Numeric Buttons Turn on/off the application - Select a TV channel. - Under the 16-channel preview mode, use↑↓← → to highlight the intended channel. 3.CH RTN Go to the previously selected channel. 4.16-CH PREV 16-channel preview. 5. VOL▲/▼ Increase/decrease the volume. 6.FULL SCREEN Display TV or video in full screen. 7. AUDIO Switch between available audio modes. 8. ► (Play) Play the last recorded or played file.
3.6 Resizing the TV Monitor Window To enlarge or reduce the size of the TV Monitor window, click and drag the lower right corner of the window. Double-click the TV Monitor window to display it in full screen or click the Full Screen button on the Control Panel. When in full screen mode, just double-click anywhere on the screen to revert to the normal TV window size. 3.7 Always on Top To make the TV monitor window float over the top of other program windows, right-click on the TV monitor.
3. Then press the Sleep button on the remote control repeatedly to set the execution time. OR, 1. Right-click on the TV monitor, point to Sleep and select the desired mode. 2. Right-click on the TV monitor again, point to Sleep and choose an execution time. 3. The time setting will be displayed on the TV monitor. For details, please see the description below.
Note: The system will detect if your VGA card supports DXVA. If yes, enable the “DXVA Support” to activate the video acceleration of the VGA card. To watch HDTV, it is strongly recommended to execute “DXVA Support”. 3.9 Minimize the Application To minimize AVerTV application to the system tray (notification area), click the Setup and in the Setup dialog box, click Miscellaneous icon on the left pane. Then Select button the Minimize to Tray check box.
3. Click Apply to save the settings. 4. Click Clear All to delete all definitions of the remote control or click Default to revert to the factory setting. 3.11 Customize the Remote Control Source Button On the Remote Source Control page, you may customize the remote control “Source” button to switch on the selected item. 1. and in the Setup dialog box, click on the Remote Remapping → Click the Setup button Remote Source Control icon on the left pane. 2. Select the signal source that you want. 3.
3.12 Changing the OSD Attributes Click the Setup button and in the Setup dialog box, click the Personalise icon on the left pane. On this page, you can customize the curtain effect, LCD speed or change the appearance of the TV monitor and the control panel (Skins). Click the Setup button and in the Setup dialog box, click the Personlise → OSD icon on the left pane. On this page, you can determine the OSD information, display duration and adjust OSD color. Then, click Apply to save the settings.
18
Chapter 4 TV In this chapter, we will introduce methods to scan programs, select a TV/Radio program, create a group and so on. 4.1 Analog TV 4.1.1 Scanning Channels If you didn’t complete the channel scanning when you first ran the application, please follow these steps to complete this procedure. 1. Click the Setup button the left pane. and in the Setup dialog box, select an available Avermedia device in Note: Make sure that your Country/Region is correct. a.
The application comes with a default frequency table therefore the application will use this table to search for active channels/programs. If you want to terminate the searching process, just click Stop. 5. You can check the scanning progress from the progress bar. After scanning, the active TV/Radio channels will be listed inside the box. Click Apply to save the scanned channels. 4.1.2 Scanning Channels (For Advanced Users) 1. Click Advance located at right-lower corner in the Program Information section.
3. When a warning message appears, click Yes to continue the procedure or click No to abort this operation. 4. After scanning, new active channels/programs will be memorized and listed in the left pane of the dialog box. 5. Click Apply to save the scanned channels. Note: Here you can modify the channel name, select the video and audio system. If you want to revert to factory setting, simply click Default button. 4.1.
5. Click New and the Format dialog box appears. In the Format dialog box, select the file format you want and enter the desired name in the text box. Click Next. 6. In the Video dialog box, you can set the video format and audio format. Click Finish.
7. If you want to change the settings of your own file format, click Modify. Or click Delete to remove the unwanted file format that you created. 8. Click Apply to save the setting and click OK to exit the current dialog box. To abort this operation, click Cancel. Note: To determine the length of recording and to choose a destination folder in which to save the recorded audio, please refer to the section titled Record Settings in Chapter 6.
WMV WMV stands for Window Media Video, which is defined by Microsoft. This file targets audiences with high speed Internet or LAN connections. MP3 An audio format compressed with a standard defined by Motion Picture Experts Group offers near-CD quality sound. 4.1.4 Fine Tuning Color of the Display If the color or picture quality of the TV display needs to be adjusted, please do the following. 1. Right click on the TV monitor. When a pop-up menu appears, select Individual Channel Setting.
4.1.5 Enhancing the Video Quality This function can reduce noise. Choose an appropriate option listed below. z Video Quality Enhancement Enable: Activate to improve the video quality. z Video Quality Enhancement Disable: Disable the video quality enhancement function. z Video Quality Enhancement Automatic: Automatically adjust video quality depending on the video screen size. OR, 1. Right click on the TV monitor.
3. From the De-Interlace drop down list, try all the options to compare which can give you the best quality. 4.2 Digital TV 4.2.1 Scanning Channels If you didn’t complete the channel scanning when you first ran the application, please follow these steps to complete this procedure. 1. Click the Setup button device in the left pane . and in the Setup dialog box, select an available Avermedia Note: Make sure that your Country/Region is correct. a.
4. Then Click Program Scan to start the scanning process. The application comes with a default frequency table therefore the application will use this table to search for active channels/programs. If you want to terminate the searching process, just click Stop. 5. You can check the scanning progress from the progress bar. After scanning, the active TV/Radio channels will be listed inside the box. Click Apply to save the scanned channels.
2. When there are channels missing from the channel memory, select All Frequencies or Single Frequency. Note: All Frequencies Scanning may take you a while. Please be patient. 3. Once you select Single Frequency, you need to specify the correct Frequency, for example 533000 (KHz), and Bandwidth. 4. Then click Scan. 5. After scanning, new active channels/programs will be memorized and listed in the left pane of the dialog box. 6. Click Apply to save the scanned channels. 4.2.
4. Click Apply to save the setting and click OK to exit the current dialog box. To abort this operation, click Cancel. Note: To determine the length of recording and to choose a destination folder in which to save the recorded audio, please refer to the section titled Record Settings in Chapter 6. 4.2.4 Using the EPG Function Electronic Program Guide (EPG) is a service that allows you to check the next succeeding program schedule and even the program schedules of the whole week.
Note: To use EPG function, please make sure that the EPG GMT settings is correct. a. Click on the control panel to see the Setup window. b. Click Digital TV on the left pane and press Advance located at right-lower corner. c. In the Advance Program Configuration window, click the desired channel. d. In the EPG GMT settings section, select Using customized EPG time to adjust the EPG time according to local time. Or, select Using standard EPG time to adjust the EPG time according to Greenwich Mean Time.
5. Click Default button if you want to revert to the factory settings. 4.2.6 Enabling Subtitle Function If your local broadcasters provide subtitle service, you can view those text by doing the followings: Right click the TV screen, point to Subtitle and choose the desired language. To hide the subtitle, please right click the TV screen, point to Subtitle and choose Close.
4.3 Adding and Deleting Program Lists Selecting a program list allows you to switch between the channels of the selected program list only when pressing the Channel Up/Down button. If you want to add or delete a program list, do the following: To add a new program list: 1. Click the Setup button and in the Setup dialog box, click the Analog TV or Digital TV icon on the left pane. 2. Click New and the Program List dialog box will then appear (as shown at right). 3. Type in a program list name and click OK.
4.4 Selecting a TV/Radio Channel There are three ways of switching between TV/Radio channels: ◆Click the Channel Up/Down buttons ( on the TV monitor window or the Control Panel) repeatedly until reaching your desired channel. on ◆Click to open the Numeric Panel (as shown at right). Then click on the Numeric buttons to get your desired channel number. OR, ◆Click the Program List button . When the Program Panel appears, select the Display Mode button .
3. When a dialog box appears, click New button . 4. Specify the desired name in the text box. 5. Hold down Shift or Ctrl key and click the channels from the list to select your own channel line up, to add your selection to the desired group. Or drag the selected channels and drop them then click to the desired group. 6. Click Save to save the settings or click Cancel to abort without saving. If you want to delete the unwanted group, simply click Delete 4.
4. If you just want to adjust individual volume level, select Individual Channel Setting and repeat step 4 to increase or decrease volume. 5. To apply the converted settings to all channels, click Apply All button 6. Click Default button . if you want to revert the factory settings. 4.7 Specifying a Channel Name or Description To assign a channel name or specify a description: 1. and in the Setup dialog box, click the Analog TV or Click the Setup button Digital TV icon on the left pane. 2.
1. Click the Setup button icon on the left pane. and in the Setup dialog box, click Analog TV or Digital TV 2. Click Advance located at right-lower corner in the Program Information section. Then the Advance Program Configuration dialog box will appear. 3. Type the desired name in the Program List Name text box. 4. Press Apply to save the setting and click OK to exit the dialog box. Or press Cancel to abort the saving. 4.
3. In the Program Information section, select the unwanted channel and then click Delete. This channel will be removed and that means you won’t be able to access these programs anymore. OR, If you just want to skip a certain channel, do the following: 1. First, select the unwanted channel in the Program Information section. 2. Clear the Enable check box so that you will not access that channel when you press Channel Up/Down buttons. 3. However, you can still see the channel in your program list.
4.10 Using the OverScan Function On some broadcast channels, you might see distorted lines or black spaces on the top, sides, or bottom of the screen. These video artifacts derive from the source signal, and can be masked using the OverScan feature. To hide the edges of the picture: z Right-click on the TV Monitor and choose OverScan to enable it. OR, 1. Right click on the TV monitor. When a pop-up menu appears, select Individual Channel Setting.
4.11 16-Channel Preview The 16-channel preview function can display 16 TV channels on-screen at the same time. You can see clearly which TV programs are currently showing on these channels. To preview the channels: to open the Numeric Panel. 1. Click 2. Click the 16-Channel Preview button. 3. The screen will be gradually filled up with 16 TV channels, starting from the currently selected channel. 4.
4.13 Sound Controlling (Optional) This function provides a variety of sound effects. 1. Right click on the TV monitor. When a pop-up menu appears, select Individual Channel Setting. Or click Program List button Individual Channel Setting button on the control panel and then click . 2. When a dialog box appears, select Sound mixer tab. 3. Choose the desired sound effects from the drop-down list. 4. Then use , or the slider to control the “Stereo”, “Bass” and “Treble” level. 5.
Chapter 5 FM Radio 5.1 FM Radio Controls Click the FM Radio button to listen to your favorite radio station programs. Use the following button controls for selecting FM radio channels, adjusting volume, scanning FM channels, recording radio programs and more. To change back to live TV, click the Radio Source button. (This picture is only for reference) 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13.
2. Click New and the Program List dialog box will appear. Type in the desirable name and click OK. Note: The system will assign a default name (FM-Radio) if you don’t create a new program list before scanning. 3. Click Scan. All active channels will be automatically scanned and memorized. 4. To terminate the scanning, click Stop. 5. Click Apply to save the setting and click OK to exit the current dialog box. To abort the setting, click Cancel. 5.
5.5 Adjusting Volume On the Control Panel, click and drag your mouse over the Volume meter to increase or decrease the volume level. You can also press the + / – keys on the numeric keypad to adjust the volume. OR, 1. Right click on the TV monitor. When a pop-up menu appears, select Individual Channel Setting. Or click Program List button Individual Channel Setting button on the control panel and then click . 2. When a dialog box appears, select Video/Audio Settings tab. 3.
5.7 Adding a Radio Frequency If the desired channel cannot be found through scanning, follow the instructions below. and in the Setup 1. Click the Setup button dialog box, click FM Radio icon on the left pane. 2. Specify the correct frequency in the text box (as shown at right) and click Save. 5.8 Modifying a Radio Name You can manually modify any exiting FM radio channel. 1. Click the Setup button pane. and in the Setup dialog box, click FM Radio icon on the left 2.
3. Now you can start to scan FM radio channels and manage the scanned FM data for this new program list. For more information, refer to How to Auto Scan FM Radio Channels. 4. To add more program lists, repeat steps 2 to 3. To delete a program list: 1. Click the Setup button left pane. and in the Setup dialog box, click FM Radio icon on the 2. From the drop-down list, select the name of the program list that you want to remove. 3. Click Delete to remove the selected program list. 5.
3. In the Format dialog box, select the audio file format. 4. Enter the desired format name or description in the Format Name text box. 5. Click Next. In the Video dialog box, select the desired audio format. 6. Click Finish. 7. If you want to change the setting of your own file format, click Modify or you can click Delete to remove the unwanted file format that you created earlier. 8. Click Apply to save the setting and click OK to exit the current dialog box. To abort this operation, click Cancel.
2. When a dialog box appears, select Sound mixer tab. 3. Choose the desired sound effects from the drop-down list. 4. Then use , or the slider to control the “Stereo”, “Bass” and “Treble” level. 5. If you just want to adjust sound effects of one specific channel, select Individual Channel Setting and repeat step 4 and step 5. 6. To apply the converted settings to all channels, click Apply All button 7. Click Default button . if you want to revert the factory settings. 5.
Chapter 6 TimeShift The TimeShift function performs background recording of a TV/Radio program, and lets you return and watch any part of the recorded program. At the same time, the live TV/Radio program continues to be recorded and played back so you won’t miss any part of the show. You can also advance forward to skip commercials or rewind to replay scenes one more time. 6.
2. By default, TimeShift performs recording of the TV program by creating a temporary video file and deletes this file once you click the Stop button. If you want to save the video file, select the Keep TimeShift Files check box. 3. In the Record section, you can determine your filename format, recording time, file size and destination folder. 4. Click Apply to save the new settings and click OK to exit the current dialog box. Or, click Cancel to use the original settings.
6.3 Using the TimeShift Function To pause the live program: 1. Click the TimeShift button record the program. 2. When you want to rewind, use the Playback Seek slider bar to move back to the part you want to watch or listen again. Click and drag the slider tab to the left until you see the part of the show you wish to watch or listen, then release the mouse button. 3. You can also click the Backward button you reach the part where you left off. 4.
Chapter 7 DVR You can use your computer as a digital video recorder, and record your favorite TV programs or capture video from an external source to your hard drive. You can also divide the recording files in proper sizes to facilitate burning onto removable optical media, such as CD-R and DVD discs. 7.1 DVR Controls Use the following button controls for recording and video playback.
Before recording, check if the settings meet your needs. . In the Setup dialog box, click the Storage icon on the left 1. Click the Setup button pane. 2. By default, the system is set the recording “Date” and “Time” as the file name format. To create your own file name format, please click Custom. 3. The Duration option allows you to specify a recording duration otherwise the system will record the largest clip that your hard drive can accommodate. 4.
(3) To delete files from the Playback List, select them from the list in the bottom right pane and click Delete, or click Delete all to delete all files in the playback list. 7.5 Picture-in-Picture Display With the picture-in-picture window feature, you will be able to play back recorded video files, and at the same time, watch live TV. To enable PIP function, right click the TV monitor, select PIP and choose desired position of the PIP window.
Chapter 8 Image Capture While you watch TV or a recorded video on your PC monitor, you can use the AVerTV 6 application to capture images for your documents, presentations or web pages. 8.1 Before Capturing Before you start capturing images, first set the destination folder for saving captured images. Click the Setup button , and select the Snapshot icon on the left pane. Then click choose a folder where you want to save captured images. to 8.
2. From the File Format drop-down menu, select the format for saving the captured image. 3. Choose the Color format. The options here depend on the file format you choose. • • Choose 24-bit to capture image in 16M colors. Choose 8-bit to capture image in 256 colors. 4. Click Browse to scan for folders and select a destination location for saving the image. Then specify a file name for saving the captured image. 5. Choose the image size.
• 6. If you want to set your own image size, select Customize and enter the image Width and Height. If you want to maintain relative width and height, select the Keep Ratio option. Choose a measurement unit from the Unit drop-down list. You can specify any image size you want. The maximum capture size can be 1600×1200. Click OK to save the image. Click Cancel if you do not want to save the image. 8.3 Multiple Image Sequence Capture To capture a continuous sequence of images, do the following: .
Chapter 9 Teletext (PAL/SECAM only) Teletext makes TV viewing a unique experience. It allows you to view teletext broadcasts from your television programs to get the most updated information on TV Schedules, News, Stock Market Prices, Concert & Theatre information and so on. Teletext information may not be available if there is no such service provided in your region or country. 9.1 Customize the Display Mode 1. Click the Setup button and in the setup dialog box, click the Teletext icon in the left pane.
9.2 Overview Click the Teletext button on the control panel to open the Teletext application as shown below. For more information about Teletext, please see below in this chapter. 4 1 2 5 3 1 BUTTON Menu Bar FUNCTION This contains the names of the available drop-down list option menus. To access any of the menu items, simply click on it or hold down Alt and press the first character of each item.
9.3 Toolbar Buttons Lock Sub page Locks the current sub page. The upcoming transmitted sub pages will be stored in the Teletext Cache for later use. Previous Sub page/ Next Sub page Switches to the next or the previous sub page. Home (Ctrl+H) Connects to the Teletext home page which always goes to page 100, but page 100 may not be the primary Teletext source. Previous Page (-) / Next Page (+) Displays the preceding or the succeeding Teletext in hexadecimal page number.
The newly selected page number will appear on the upper left corner of the page. Sometimes, this may take a while to retrieve the newly selected Teletext page. There will be no changes on the page when there is no page data transmitted with the number you have selected. A Teletext page can be selected with one of the following methods: y Key in the hexadecimal or Teletext page number using the numeric buttons of your keyboard or AVerMedia TV remote control.
4. Enter a filename and click OK. Opening a Teletext Page 1. Choose Open from the File menu or press Ctrl+O. 2. From the Open dialog box, select the file containing the teletext page you want and click Open. Opening Another Teletext Window To open another teletext window, choose New Window from the File menu or press Ctrl+W. Closing the Active Teletext Window Choose Close Window from the File menu or press Ctrl+L to close the active Teletext page window.
Chapter 10 Scheduler The Scheduler allows you to create a list of preset schedules for watching and recording your favorite TV/Radio programs. You can set the day and time to record the TV/Radio program and specify the length of recording. To run this application, click the Schedule button Scheduler dialog box will appear. on the Control Panel.
5. Type the desired name in the Schedule Name text box. 6. From the Function drop-down list, select Activate AVerTV to watch a TV program or listen to a radio broadcast. Otherwise, select Record to save a TV/Radio program for future viewing/listening. You can also select Silent Record which means the system will perform background recording instead of activating the TV/Radio program. If you want to schedule a task to enable Timeshift function, select Timeshift.
8. In the Program Settings section, select the desired device, video source, group and channel you want. 9. Set the schedule to tune in live TV or to perform recording. You can set the schedule on Once, Daily or Weekly. ‧ Choose Once to perform schedule at a preset day and a preset time. ‧ Choose Weekly to perform schedule every week, at a preset day and time. ‧ Choose Everyday to perform schedule everyday at a preset time. 10. If you choose Activate AVerTV in step 4, click Insert to complete the settings.
Chapter 11 Hot Keys You can use the default hot keys or create your own hot keys. To re-define the shortcut keys: 1. Click the Setup button . In the Setup dialog box, click the Keyboard icon on the left pane. 2. Choose the signal status from the Category drop down list. 3. Choose a command that you want to specify a new hot keys. 4. Assign hotkey combination to the command that you use most often and then click Assign. Or you can click Remove to delete hotkeys. (This picture is only for reference) 5.
The following is the default definition: Hot Key Description Function UP/DOWN ARROW Channel or Frequency Up/Down Press to go to the next upper/lower TV/Radio channel. L Channel Loop Press to go to the previously accessed TV/Radio channel. NUMERIC KEYS Select Channel Use NUMERIC KEYS to directly enter the TV/Radio channel number. ESC Stop or, Change back to Normal View Stop (playback, recording, TimeShift, or 16-Channel Preview). Or change full screen back to normal view.
Chapter 12 Customer Service The AVerTV application provides a convenient tool, which allows users to contact AVerMedia’s customer service department easily via our website. Please make sure that you have already connected to the Internet. To contact the customer service: 1. Right-click on the TV monitor window. When a menu list pop-up, choose About (as shown at right). 2. When a information dialog box appear, select the office in your area from the drop-down list. 3. Click to connect to our website.
