CUSTOMER : Standard DATE : 2021. 03. 22 REV : Rev. 1.0 SPECIFICATIONS FOR APPROVAL REGX-XXXXC Model Model Name Customer P/N1 GATWAY REGX-XXXXC - RoHS Compliant APPROVAL REMARK APPENDIX DESIGNED CHECKED APPROVED 2020.06.19 K.S.AN 2020.06.19 H.H.HAN 2020.06.22 I.U.
SPECIFICATION MODEL GEN MINI REV. No. Rev. 1.0 REG. DATE 2021.03.16 PAGE 26 REV. DATE 2021.03.16 - - Revision History Revision Date 1.0 ’21.03.
1. Application This Specification is applied to ATEC IOT Gateway of Module Type used by retailers for managing ESL Product. Typically, GEN MINI is connected to Server System using its ethernet communication. • 2. Quality Quality should meet each condition which mentioned on this specification. However, the items which are not mentioned on this specification follow the inspection agreements and standards which are agree with both companies. 3. Appearance and Characteristics 3.1.
. Overall Service Scenario POS ESL EMS(1) Server Wired • WiFi / Ethernet • IEEE802.15.4 • 2,000 Tags per GW • One Platform & Integrated Gateway GATEWAY Wireless & Bi-Directional 2.
. General Features 5.1. Description Item Size Operating Environment Power Network Description 93.5(H)X 44(V) X 13(L) -. CPU : Cortex-A9 (1GHz) -. Memory : eMMC 16GB, DDR3 SDRAM 2GB -. 3 RF ZIGBEE Module -. Host USB2.0 Port supported for WiFi AP -. OS : Linux Kernel 4.1.15 -. Network & maintenance function ▷ Network setup / management ▷ Software upgrade -. On ceiling using bracket Rate : 5.0 V / 600 mA 802.15.4 2.4GHz IEEE802.15.
. Absolute Maximum Rating 6.1. Environmental Conditions The normal operating environmental conditions are those as below. In such conditions, ESL must be in conformity with the present specification. The conformity to such requirement must be certified by the manufacturer. Parameter Operating Environment (1) Storage Environment (2) Condition Min. Typ. Max.
. Electrical Specification 7.1. IEEE802.15.4 The REBE-TZ15K supports IEEE802.15.4. 7.2. General Specification • • • • • Standard : Only IEEE802.15.4 PHY Frequency : 2405 ~ 2480MHz Channel : 16CH. (5MHz Spacing) Modulation : DSSS/O-QPSK Max. Data Rate : 250Kbps 7.3. Electrical Specification • Channel power depend on each country regulations (EX. KC, etc) • The electrical specification which is shown below is ATEC IOT internal specification.
. Mechanical Information 8.1. Mechanical Dimension 93.5 x 44 x 13.0 (mm) 93.
. Disclaimers -. ATEC IOT is not responsible for any damages caused by any accidents or operational environments exceeding the absolute maximum ratings. -. Consultation with ATEC IOT is recommended for unassured environments or operations to avoid any possible malfunctions or damages of the products or risk of life or health. -. Any unauthorized, without prior written consents, from ATEC IOT disassembly is prohibited if purposed for reverse-engineering.
9. Description DC 5V -After a certain amount of time after turning on your device, Send images to ESL TAG at regular intervals. a. Rule Part 15.19(a)(3): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. b. Rule Part 15.
