NXP® i.MX 8M ARM Cortex-A53 core, 4GB LPDDR4, HDMI, Dual LAN, 16G eMMC,
1*M.2 E Key slot, 1*Micro SD Card, 3*USB 3.2 Gen 1
Features
• Pico-ITX Single Board Computer with NXP® i.MX 8M low power and scalable processor
• 16G on board eMMC and Micro-SD card for storage capacity
• Support Windows 10 IoT Core and Linux Yocto OS
• Wide Temperature Range: -20~60°C
Specifications
IMX8P-IM-A
Processor System
CPU
NXP® i.MX 8 M ARM Cortex-A53 core
MAX.SPEED 1.3 GHz
L2 Cache 1MB
Chipset Integrated
Memory
Technology LPDDR4
Max. 4GB on board memory
Display
HDMI 1, Supports HDMI 2.0 up to 3840 x 2160 @ 60 Hz
MIPI DSI 1, Supports MIPI DSI (2 lane) up to 1920 x 1080 @ 60 Hz
Expansion Slot
M.2 1 x M.2 2230 E Key for BT/WiFi module (cooperate with Google EdgeTPU Module)
Others 1 x Micro-SD Card connector
Ethernet
Speed
10/100/1000Mbps
Controller
1 x Realtek® RTL8211, supports WOL
1 x Intel I211-AT, supports WOL
Connector
2 x RJ-45
Storage eMMC 1 x 16GB onboard eMMC
Front I/O
HDMI
1
USB3.2 Gen1
2@Type A, 5V/2A
1@Type C OTG, 5V/1.5A
Ethernet
2
Power Button
1
Reset Button
1
Rear I/O Power Connector
DC Power input
Internal Connector
GPIO Header
1 x 40-pin headers includes:
- up to 6 x GPIO pins
- up to 2 x I2C bus
- up to 1 x UART
- up to 2 x PWM
- up to 1 x PCM/I2S
- 2 x 5V power pins
- 2 x 3.3V power pins
- 8 x ground pins
Micro-SD Card 1 Slot
TPM Header 1 (14-1 pin)
MIPI DSI 1, Supports MIPI DSI (4 lane) up to 1920 x 1080 @ 60 Hz
MIPI CSI 2, support two MIPI-CSI camera inputs (4-lane each)
I
2
C Header 1 (5-1 pin)
Watchdog Timer S/W Set up by software
Security Module
TPM TPM 2.0 power by Nuvoton NCPT 750 (Optional)
Crypto Module Cloud security power by Microchip ATECC608A/NXP SE050 (Optional)
Manageability WOL
Power
Power Type DC power input
Voltage 12-24V DC input
Operating System
Linux Linux Yocto
Microsoft Windows Windows 10 IoT Core (Limited support, beta version avavilable)
Environment
Operating Temperature
-20~60
°
C
Non-Operating Temperature
-40~85
°
C
Relative Humidity
10~95%
Dimension Form Factor 100mm x 72mm x 21mm
Certification Safety CE, FCC
