Specification

6
© 2009 AS America Inc.
NOTES:
THIS TOILET IS DESIGNED TO ROUGH-IN AT A MINIMUM DIMENSION OF
305MM (2") FROM FINISHED WALL TO C/L OF OUTLET.
SUPPLY NOT INCLUDED WITH FIXTURE AND MUST BE
ORDERED SEPARATELY.
*
DIMENSION SHOWN FOR LOCATION OF SUPPLY IS SUGGESTED.
IMPORTANT: Dimensions of xtures are nominal and may vary within the
range of tolerance established by ANSI Standard A2.9.2
These measurements are subject to change or cancellation. No responsibility
is assumed for use of superseded or voided pages.
IMPORTANT: Water supply on the wall is required at 3-3/4" or 9" from centerline of the toilet (see rough-in).
First suggested position is hidden behind the toilet. The geometry of the toilet gives space for this installation.
The second suggested position is next to the toilet. Between these two positions, the space for the supply
between wall and toilet is limited to 3-1/4". In this case, check your supply and hose dimensions.
29-3/4"
(756 mm)
7-1/2"
(192 mm)
3/4"
(19 mm)
18-1/2"
(470 mm)
16-1/2"
(419 mm)
14-1/2"
(368 mm)
30-1/2"
(778 mm)
13-1/2"
(345 mm)
14-1/4"
(364 mm)
8-1/2"
(217 mm)
12"
(305 mm)
C/L OF SEAT POST
HOLES 5-1/2"
(140mm) CENTERS
FINISHED WALL
3-3/8"
(86mm)
3-1/4"
(83mm)
SUPPLY
AS
REQUIRED
(position 1 or
position 2)
6"
(152mm)
5-1/2"
(140mm)
3-3/4"
(95mm)
9"
(229mm)
14"
(350 mm)
FINISHED
FLOOR
BOULEVARD FloWise™ RIGHT HEIGHT™
ELONGATED ONE-PIECE TOILET
VITREOUS CHINA
BOULEVARD FloWise™ RIGHT HEIGHT™
ELONGATED ONE-PIECE TOILET
❑ 2891.128
• Vitreous china
• LXP (Luxury Performance) Toilet
• Meets denition for HET (High Efciency Toilet)
.28 gpf/4.8 Lpf
• Meets EPA WaterSense
SM
criteria
• Contributes to a LEED solution
• Elongated siphon action bowl with
smooth-sided, concealed trapway
• PowerWash™ rim scrubs bowl with each ush
• 6-/2" rim height for accessible applications
• Fully glazed 2" trapway
• Oversized 3" ush valve with chemically
resistant apper
• Chrome trip lever
• 2 color-matched bolt hole covers
• Includes color-matched Duroplast Slow
Close Toilet Seat and cover with concealed
seat ring and easy lift-off feature for simple
removal and reattachment for cleaning
• 00% factory ush tested
• Design coordinates with Studio and
Boulevard lavatories
• 0 year warranty on entire toilet
Nominal Dimensions:
756 x 368 x 778mm
(29-3/4" x 4-/2" x 30-/2")
Fixture only, supply by others
Compliance Certications -
Meets or Exceeds the Following Specications:
• ASME A2.9.2-2008 / CSA B45.-08
• US EPA WaterSense
SM
Specication for HET's
MEETS THE AMERICANS WITH DISABILITIES ACT GUIDELINES AND
ANSI A117.1 REQUIREMENTS FOR ACCESSIBLE AND USABLE
BUILDING FACILITIES-CHECK LOCAL CODES.
Certified by
IAPMO R&T
8/09
To Be Specied:
❑ Color:
❏ White ❏ Bone ❏ Linen
❑ Supply with Stop:
