JENHR1D 7” LCD MONITOR WITH BUILT-IN DVD PLAYER FOR REAR SEAT ENTERTAINMENT PUSH OPERATION MANUAL/ INSTALLATION GUIDE ® 128-9095A 1
Important Notice Installation of headrest products require careful planning and preparation. Be extremely careful of seats that have airbags built into them. Keep wiring away from sides of seats. If you have any questions regarding wire routing or installation in a vehicle, please contact Audiovox Technical Support at 1-800225-6074. Do not bypass the fuse built into the accessory plug.
FEATURES • 7” Digital Thin Film Transistor (TFT) Active Matrix Liquid Crystal Display (LCD) Monitor • Built-in DVD Player • Last position memory for DVD player • Three Audio / Video Source inputs (DVD, AV and AUX)• USB 2.
MATERIAL TO USE IN THIS PACKAGE: 1) JENHR1D System Monitor with DVD Player (JENHR1D) (1pc) NOTE: The JENHR1D monitor has been designed to be interchangeable from one headrest to the other. The headrests will still have the Cigarette Lighter Adaptor cables and 3 RCA Jack (AV Input) on them and should be connected to their respective connectors. The headrest cover from the manufacturer is covered with shale colored vinyl.
HEADREST COVER REPLACEMENT: NOTE: Choose the best color match for your vehicle. 1. Lay the headrest on a flat surface, screen facing up. Using a Philips screwdriver, unscrew the two Philips screws and lift the bottom edge of the monitor upward. Figure A Unscrew Philips Screws 2. 3. 4. Carefully tilt the bottom edge of the DVD player upward and pull towards you to detach it from the top of the headrest. Carefully unplug the wire from the back of the DVD player and set aside in a safe place.
7. Replace the player into the headrest. a. Slide the top of the DVD player into the top of the headrest. b. When lowering the bottom of the DVD player make sure the cable is not trapped between the DVD player and the headrest inside the shell. c. P ress down on the DVD player to align the Philips head screws with the holes in the headrest. d. Secure the DVD player with two screws. Do not over tighten the screws. 8. Tighten screws.
VEHICLE PREPARATION 1. ead the manual and get familiar with the product requirements and R connections. 2. Install the headrests. a. Remove vehicle’s original headrests and store in a safe place. b. L ocate the box of tube adapters and find the tubes that match the diameter of your factory headrest post. There are six different sizes: 12mm, 12.5mm, 12.7mm, 13.8mm, 14mm, and 16mm The chart lists standard post sizes for different vehicle makes.
Wireless Headphones The JENHR1D is equipped with a dual channel IR (Infrared) transmitter for use with wireless IR headphones (not supplied with the JENHR1D) which are available at many electronics stores. If two JENHR1D’s are installed in a vehicle the first JENHR1D has to be set to transmit on channel A (1) and the second JENHR1D has to be set to transmit on channel B (2). See page 17 for details on setting the IR transmitter channel.
JENHR1D WIRING DIAGRAM Headrest Monitor PUSH Cigarette Lighter Adaptor RCA Jack (AV Input) 1. Connect the cigarette lighter adaptor to the car.
JENHR1D CONTROLS AND INDICATORS DIAGRAM (Front View) LCD PANEL POWER/SOURCE VOLUME /NEXT PUSH PLAY/PAUSE SYSTEM MENU VOLUME /PREVIOUS STOP SCREEN RELEASE IR SENSOR IR HEADPHONE TRANSMITTER LENS PULL DOWN HEADPHONE JACK AUX IN JACK AUX IN SD USB PHONE SD CARD READER USB PORT COVER (BOTTOM VIEW) DVD DISC PUSH (FRONT VIEW MONITOR OPEN) 10
Playing DVDs Press the screen release button and raise the screen to insert a DVD disc. Snap the DVD disc onto the hub (spin the disc with your finger to make sure the disc is seated properly). Lower and close the LCD screen, disc playback will not start until the screen is closed for safety reasons. When the DVD menu appears press the play button. Playing USB The System will detect the insertion of the USB media automatically if no disc is loaded.
Playing MP3 Discs MP3 is a format for storing digital audio. An audio CD-quality song can be compressed into MP3 format with very little loss of quality, while taking up much less space. CD-R discs that have been encoded in MP3 format can be played on the DVD player. The DVD player plays the songs in the order they were burned on to the disc Selecting Folders and Songs When an MP3 disc is loaded in the player, the navigation menu will appear on the screen automatically.
REMOTE CONTROL OPERATION NOTE: The remote control has a battery installed with a pull tab to prevent battery discharge. Remove the pull tab before attempting to use the remote. Battery Replacement 1. Remove the battery holder. 2. R emove the old battery and insert the new battery (CR2025) into the battery holder. Be sure to observe the correct polarity. 3. Align the battery holder with the remote control and push until the holder clicks.
* Function control is available on the unit and the remote control. 1. ) Button* OWER ( P Press this button to turn the unit ON and OFF. 2. S OURCE Button* Each time the button is pressed, the audio / video source will change in the following sequence: DVD > AV > AUX NOTE: The USB device and the SD card can be accessed using the DVD source button. Refer to Item 26. 3. M UTE Button Press this button to mute all the audio. Pressing the button again restores the sound to the previously set level. 4.
10. Z OOM Button Press this button to enlarge or decrease the picture size when playing a DVD disc. Press ZOOM button DVD Player performs Once Enlarges the picture 2X Twice Enlarges the picture 3X 3 Times Enlarges the picture 4X 4 Times Reduces the picture 1/2 5 Times Reduces the picture 1/3 6 Times Reduces the picture 1/4 7 Times Picture is returned to original size 11.
18. A UDIO Button Press to display and select the available AUDIO languages in DVD mode. Each time you press the button, the language changes. NOTE: The audio languages vary from disc to disc. 19. F F SCAN FORWARD ( ) Button* Press to search in the forward direction. Press repeatedly to change the search speed from 2, 4, 8, 16 and 32 times the normal speed. 20. S TOP ( ) Button* Press to stop playback. 21. N EXT ( ) Button* Press to skip to the next chapter or track. 22.
SYSTEM MENU SETTINGS AND ADJUSTMENTS The System Menu contains features and options that allow you to customize your system. 1. Press the “ ” button on unit or press the TV button and the SYSTEM MENU button on the remote control, the menu display below will appear on screen. 2. Use the “+” “-” buttons to change the setting . 3. To select the next menu press the “ ” button or the SYSTEM MENU button on the remote control.
The FM Modulator adjustments consist of turning the FM Modulator on or off and selecting the FM Modulator frequency. The wireless FM Modulator Frequencies that can be selected are: (CH1 87.7MHz, CH2 88.1MHz, CH3 88.5MHz, CH4 88.9MHz, CH5 106.7MHz, CH6 107.1MHz, CH7 107.5MHz, CH8 107.9MHz. FMM OFF The OSD Language feature allows the user to select the language for the on-screen display. The user can either select English, Dutch, French, Spanish, Russian or Chinese for the OSD language.
GENERAL PAGE Preference General Audio General Setup Page TV Display Wide Screen Saver On On Last Memory Exit Goto General Setup Page GENERAL SETUP PAGE TV Display The TV Display feature allows the user to change the screen format (aspect ratio to 4:3 PScan, 4:3 LB, or 16:9 Wide) • To select the screen aspect ratio mode use the cursor button (p or q) to highlight TV DISPLAY. Press the cursor button u to open the sub menu that contains the different options available.
AUDIO PAGE General Audio Preference Audio Setup Page Equalizer None Sound Mode Bass Boost Off Super Bass Off Treble Boost Off Exit Goto Audio Setup Page AUDIO SETUP PAGE Sound Mode The sound mode feature allows the user to apply preset sound effects to the unit’s audio output signal. The user may choose from: None ,Rock, Pop, Live, Dance, Techno, Classic and Soft. • To select the sound mode use the cursor button (p or q) to highlight SOUND MODE.
PREFERENCE PAGE General Audio Preference Preference Page TV Type NTSC Audio Eng Subtitle Eng Disc Menu Eng Parental Password Default Exit Goto Preference Page PREFERENCE PAGE NOTE: This menu page is available if there is no disc in the disc tray, the disc tray is open or the disc in the disc tray is stopped. There are seven items in the PREFERENCE PAGE. They are TV TYPE, AUDIO, SUBTITLE, DISC MENU, PARENTAL, PASSWORD, and DEFAULT.
Audio Menu This item allows a user to select a preferred audio language. This function only applies to discs encoded with different audio languages. Options: English, French, Spanish, Chinese, Japanese, Korean, Russian, and Thai. NOTE: If the selected language is not available for the currently playing disc, the disc’s default setting is applied. • To select the audio feature use the cursor button (p or q) to highlight AUDIO.
Parental This item allows the user to limit the content of movie playback from G to Adult. The lower the value, the more strict the control. Movies rated higher than the level set for the parental lock can not be viewed without entering the correct password. Options: 1) G, 2) PG, 3) PG – 13, 4) R, 5) NC17 6) Adult NOTE: The rating level can be changed only when the correct password is provided. This function only works with those discs with parental function.
EXIT SETUP PAGE General Audio Video Setup Page Exit Setup Page Preference Exit Exit Setup Menu The exit setup page allows the user to exit the setup menu and return to the DVD playback. 1. To exit the setup page use the u to highlight EXIT and press ENTER to confirm the selection. DVD Basics To get the optimum use out of the DVD Player, please read the following:. DVD Region Code The DVD player is preset to a region code at the factory depending on where the DVD player is sold.
TROUBLESHOOTING PROBLEM SOLUTION IR remote inoperative • Verify that the battery in the remote is fresh. • Verify that the remote sensor eye is not obstructed. Disc won’t play • Insert a disc with the label side facing out. • Check the type of disc you put into disc tray. This DVD only plays DVD, audio CD and MP3s. • Both the unit and the disc are coded by region. If the regional codes don’t match, the disc can’t be played. Play starts, but then stops immediately • The disc is dirty. Clean it.
® 12 MONTH LIMITED WARRANTY Applies To Jensen Mobile Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company’s option) without charge for parts and repair labor.
