6VH9KDC500 SLED-mPOS User Manual Rev 1.0 Dec.
SLED-mPOS User Manual INTRODUCTION Table of Contents 1. INTRODUCTION ................................................................................ 5 1.1 Specification ....................................................................................................................... 6 1.2 Package ............................................................................................................................... 7 1.3 Characteristics ....................................................
SLED-mPOS User Manual INTRODUCTION COPYRIGHT, LICENSE, and WARNING PAGE CopyrightÓ 2002-2021 by KOAMTAC, Inc. All rights reserved. No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from KOAMTAC, Inc. The material in this manual is subject to change without notice. KOAMTAC reserves the right to make changes to any product to improve reliability, function, or design.
SLED-mPOS User Manual INTRODUCTION Product Disposal This device should not be placed in municipal waste. Please check local regulations for disposal of electronic products. 4 Revision 1.0 Copyright®2012-2021, KOAMTAC, Inc.
SLED-mPOS User Manual INTRODUCTION 1. Introduction EMV/Chip&PIN/MSR/NFC Mobile POS Companion The PCI compliant EMV/MSR/NFC SmartSled® design provides a secure and convenient user payment transaction. Chip-and-PIN payment solutions are becoming the global industry standard and as a result, KOAMTAC has developed the most advanced mobile payment companion.
SLED-mPOS User Manual INTRODUCTION 1.1 Specification Main Processor 120MHz ARM Cortex-M4 Memory 1M program flash, 128KB RAM, 32-byte secure key storage, 8MB user data flash Display 128x64 monochrome Keypad Secure Touch Pinpad(15 buttons).
SLED-mPOS User Manual INTRODUCTION 1.2 Package The standard SLED-mPOS package contains: 1. One SLED-mPOS 2. USB Cable l 5pin Micro USB cable 7 Revision 1.0 Copyright®2012-2021, KOAMTAC, Inc.
SLED-mPOS User Manual INTRODUCTION 1.3 Characteristics Before starting to use the SLED-mPOS, the user should become familiar with its physical characteristics. Refer to the follow figure that indicate the placement of Secure Touch Pinpad, OLED display, LED, NFC Reader, Magnetic-Stripe Card Reader, IC Card Reader and ports on the KDC. 8 Revision 1.0 Copyright®2012-2021, KOAMTAC, Inc.
SLED-mPOS User Manual INTRODUCTION OLED Display NFC Reader IC Card Reader Secure Touch Pinpad Magnetic-Stripe Card Reader Figure 1 – SLED-mPOS Overview 9 Revision 1.0 Copyright®2012-2021, KOAMTAC, Inc.
SLED-mPOS User Manual INTRODUCTION 1.4 Secure Touch Pinpad While in the SLED-mPOS menu, press this button to scroll down the selection bar. While on the main screen, press (Menu/Down button) this button for 5 seconds then the SLED-mPOS will enter the SLED-mPOS menu mode. While in the SLED-mPOS menu, press this button to scroll up the selection bar. While the SLED-mPOS waits for Alpha-Numeric key entry, (FN/Up button) this button allows the user to switch between ABC and number input mode.
KDC User Manual GENERATION APPLICATION 2. Operating your SLED-mPOS 2.1 Basics Read NFC Tag (MIFARE) 1. The host application sends a command to enable the NFC Reader. 2. Touch NFC tag to the NFC antenna symbol on the front case, and make sure the tag and case are within 4cm of each other. 3. The SLED-mPOS will send the NFC tag UID to the host application and the user will hear a short beep if it has been read successfully. Read Magnetic-Stripe Card 1.
KDC User Manual WARRANTY 3. Warranty LIMITED WARRANTY AND DISCLAIMERS BY OPENING THE PACKAGE OF THIS PRODUCT YOU AGREE TO BECOME BOUND BY THE LIABILITY AND WARRANTY CONDITIONS AS DESCRIBED BELOW. UNDER ALL CIRCUMSTANCES, THIS MANUAL SHOULD BE READ ATTENTIVELY, BEFORE INSTALLING AND OR USING THE PRODUCT. Serial Number A serial number appears on the SLED-mPOS label. This official registration number is strictly related to the device purchased.
KDC User Manual WARRANTY Warranty Coverage and Procedure During the warranty period, KOAMTAC will repair or replace defective products returned to KOAMTAC warehouse. International customers should contact the local KOAMTAC office or support center. If warranty service is required, KOAMTAC will issue a Return Material Authorization Number. Products must be shipped in the original or comparable package, shipping and insurance charges prepaid.
KDC User Manual 5. Contact Information CORPORATE HEADQUARTERS 116 Village Blvd., Suite 305 Princeton, NJ 08540, USA Phone: 609-256-4700, FAX: 609-228-4373 Email: support@koamtac.com For more information, visit our website - www.KOAMTAC.com 14 Revision 1.0 Copyright®2012-2021, KOAMTAC, Inc.
