AGD933 User Manual Issue 2 1 of 4 17/03/09

for errors or omissions.

AGD933

Enforcement Radar Certification

Equipment

Incorporating

MC-116 Radar Target Simulator

User Manual

Summary of content (4 pages)

PAGE 1
TRAFFIC INFORMATION AND MEASUREMENT EQUIPMENT AGD933 Enforcement Radar Certification Equipment Incorporating MC-116 Radar Target Simulator User Manual AGD933 User Manual Issue 2 1 of 4 17/03/09 Copyright AGD Systems Ltd. 2009. All rights reserved. The information contained in this document is the property of AGD Systems Ltd., and is supplied without liability for errors or omissions.
PAGE 2
TRAFFIC INFORMATION AND MEASUREMENT EQUIPMENT Contents 1. INTRODUCTION ...................................................................................................................... 3 1.1 1.2 1.3 2. DOCUMENT SCOPE ............................................................................................................. 3 DOCUMENT CHANGE HISTORY ............................................................................................. 3 IMPORTANT INFORMATION..................................
PAGE 3
TRAFFIC INFORMATION AND MEASUREMENT EQUIPMENT 1. INTRODUCTION This manual details the use of the AGD933 Enforcement Radar Certification Equipment. Used with AGD radars, the AGD933 allows the user to determine the performance of relevant radars during their calibration period against known parameters by non-invasive methods (calibration seals do not need to be removed). The immediate application of the AGD933 equipment is for AGD340 and AGD330 radars.
PAGE 4
TRAFFIC INFORMATION AND MEASUREMENT EQUIPMENT 2. System General Overview The whole system is designated an AGD933 and comprises; a) b) c) d) e) f) g) h) A Frequency counter A Frequency generator A mechanical enclosure, lined with radar absorbing material A desk top pc and monitor USB to serial convertor. USB hi speed hub MC-116 24GHz Target Simulator Unit.
